Installation and Maintenance Manual
CTC EcoAir 510M
Modulating Air/Water Heat Pump
230 V 1N~

Installation and Maintenance Manual
CTC EcoAir 510M
Modulating Air/Water Heat Pump
230 V 1N~

4CTC EcoAir 510M 230V 1N~
Enertech AB provides the information with reservation for any typing errors and subject to modification.
For your own reference
Fill in the information below. It may come in useful if anything should happen.
Product: Serial number:
Installer: Name:
Date: Tel. no.:
Electrical installer: Name:
Date: Tel. no.:
Table of Contents
1. Important to remember! _______________________________________ 6
1.1 Transportation____________________________________________________6
1.2 Positioning ________________________________________________________6
1.3 Recycling __________________________________________________________6
1.4 After commissioning___________________________________________6
Safety instructions _______________________________________________________ 7
Checklist _______________________________________________________________________ 8
2. Connection option CTCEcoAir510230V1N~ _ 9
3. Technical data _____________________________________________________ 10
3.1 Dimensions diagram ________________________________________11
3.2 Refrigerant system ___________________________________________12
3.3 Operating range_______________________________________________12
3.4 Component location_________________________________________13
4. Installation____________________________________________________________ 15
4.1 Delivery includes: _____________________________________________15
4.2 Location of the heat pump ________________________________16
4.3 Preparation and drainage _________________________________17
4.4 Condensation water _________________________________________18
5. Pipe installation___________________________________________________ 19
5.1 Pipe connection_______________________________________________19
5.3 Circulating pump – heat carrier__________________________ 20
5.2 Example of connection to
CTC EcoZenith i360 L______________________________________20
5.4 Pressure differential diagram for
CTCEcoAir510M 230 V 1N~ ___________________________21
6. Electrical installation___________________________________________ 22
6.1 General information, electrical connections _________22
6.1.1 Electrical installation 230 V 1N~ ____________________22
6.1.2 Communication connection ___________________________22
6.1.3 Compressor heater_______________________________________ 22
6.1.4 Alarm output________________________________________________ 22
6.1.5 Heat pump connections________________________________ 23
6.1.6 Termination for connection of
heat pumps in series ________________________________________23
6.2 Communication connection_______________________________25
6.2.1 Connection option for one heat pump_____________25
6.2.2 Connection option for multiple heat pumps _____25
6.3 Connecting the control system __________________________26
6.3.1 Define number of heat pumps________________________ 26
6.3.2 Numbering CTC EcoPart510M to HP2___________26
6.3.3 Good to know when setting an address__________28
6.3.4 Numbering CTC EcoPart510M to A2_____________29
6.4 Wiring diagram 230 V 1N~ (A3) _________________________32
6.5 Wiring diagram 230 V 1N~ (A4) _________________________34
6.6 Parts list__________________________________________________________35
6.7 Sensor Data ____________________________________________________36
7. First start______________________________________________________________ 38
8. Operation and Maintenance ______________________________ 39
9. Troubleshooting/Appropriate measures___________ 41

5
CTC EcoAir 510M 230V 1N~
The Complete System
CTCEcoAir510M
CTC EcoAir 510M is a modulating air source heat pump
that takes heat from the outside air and supplies it to the
existing heating system in the house. The heat pump
works with outdoor temperatures down to -22°C.
CTC EcoAir 510M is designed to operate with high
efficiency and low noise levels. The heat pump has
integrated discharge defrosting which keeps the
evaporator coil free from ice to maintain high efficiency.
EcoDesign information relating to the current
combination (current package) can be downloaded from
www.ctc.se/ecodesign. Energy labelling stickers can
also be printed from here.
Control
CTCEcoAir510M is controlled by these products:
• CTCEcoZenithi555/i550 PRO
• CTCEcoLogicM/L/PRO/Family
• CTCEcoZenithi255/i250
• CTCEcoZenithi360/i350
• CTC EcoVenti360F/i350F
Charge pumps
CTC’s PWM-controlled charge pumps are available
as accessories for CTCEcoZenithi555/i550 PRO and
CTCEcoLogicM/L/PRO/Family.

6CTC EcoAir 510M 230V 1N~
1. Important to remember!
Check the following points in particular at the time of delivery and installation:
1.1 Transportation
• Transport the heat pump to the installation location
before removing the packaging. Move the product
using one of the following means:
- Forklift
- Lifting band around the pallet. NB: Can only be
used with the packaging on.
• The heat pump must be transported and stored
upright.
1.2 Positioning
• The heat pump must be transported and stored
upright.
• Remove the packaging and check before
installation that the product has not been damaged
in transit. Report any transport damage to the
carrier.
• Place the product on a solid foundation, preferably
concrete.
If the heat pump needs to be placed on a soft
carpet, base plates must be placed under the
adjustable feet.
• Remember to leave an access and service area of
at least 1 metre in front of the heat pump.
• The heat pump must not be placed below floor
level.
• Avoid placing the heat pump in rooms where
the walls are of lightweight design, as people
in the adjoining room may be disturbed by the
compressor and vibrations.
1.3 Recycling
• The packaging must be deposited at a recycling
station or with the installation engineer for correct
waste management.
• Obsolete products must be disposed of correctly
and transported to a waste station or distributor/
retailer offering this service.
Disposal of the product as household waste is not
permitted.
• It is very important that the product’s refrigerant,
compressor oil and electric/electronic components
are disposed of correctly.
1.4 After commissioning
• The installation engineer advises the property
owner on the design and servicing of the system.
• The installation engineer fills in a checklist and
contact information – the customer and installation
engineer sign the list, which the customer keeps.
• Make sure to register your product for warranty
and insurance via the CTC website:
https://www.ctc-heating.com/customer-
service#warranty-registration
When contacting CTC, always mention the following:
• Serial number
• Model/Size
• the fault message shown in the display
• Your telephone number
!Information in this type of box
[!] is particularly important for
correctly installing and using
the product.
iInformation in this type of box
[i] is intended to help ensure
that the product functions
optimally.

7
CTC EcoAir 510M 230V 1N~
Turn off the power with an omnipolar switch before doing any work on the
product.
The product must be connected to protective earth.
The product is classified as IP X4.
When handling the product with a hoist ring or similar device, make sure that
the lifting equipment, eyebolts and other parts are not damaged. Never stand
under the hoisted product.
Never jeopardise safety by removing bolted covers, hoods or similar.
Never jeopardise safety by deactivating safety equipment.
Any work on the product’s cooling system should be carried out by authorised
personnel only.
The product’s electrical systems should only be installed and serviced by a
qualified electrician.
-If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
This device can be used by children from the age of eight years and above and
by people with reduced physical, sensory or mental ability or lack of experience
or knowledge if they have been taught, either with supervision or with the
instructions provided, how to use the device safely and understand the risks
involved. Children should not play with the device. Cleaning and maintenance
should not be carried out by children without supervision.
If these instructions are not followed when installing, operating and maintaining
the system, Enertech’s commitment under the applicable warranty terms is not
binding.
Safety instructions

8CTC EcoAir 510M 230V 1N~
Checklist
The checklist must always be completed by the installation engineer
• If service is needed, you may be required to provide this document.
• Installation must always be done according to the installation and maintenance instructions
• Installation must always be carried out in a professional manner
Following installation, the unit must be inspected and functional checks performed as
indicated below:
Pipe installation
Heat pump filled, positioned and adjusted in the correct manner according to the
instructions.
The heat pump is positioned so that it can be serviced
Capacity of the charge/radiator pump (depending on type of system) for the flow required.
Open radiator valves (depending on type of system) and other relevant valves.
Tightness test
Bleed the system
Check proper operation of the requisite safety valves
Action taken to deal with condensation water
Electrical installation
Power switch
Correct tight wiring
Requisite sensors fitted
Heat pump activated and started
Accessories
Customer information (adapted to the relevant installation)
Start-up with customer/installer
Menus/controls for selected system
Installation and maintenance manual supplied to the customer
Check and filling, heating circuit
Information on fine adjustments
Alarm information
Functional test of safety valves fitted
Register your Installation Certificate at ctc-heating.com.
Information on procedures for fault registration
________________________________________________ ____________________________________________
Date/Customer Date/Installer

9
CTC EcoAir 510M 230V 1N~
CTCEcoZenithi255
CTCEcoZenithi360
CTCEcoZenithi250
CTCEcoZenithi350
CTC EcoZenith i555 Pro
CTC EcoZenith i550 Pro CTC EcoVent i360F
CTC EcoVent i350F
CTCEcoAir510
230V1N~
CTC EcoLogic Pro/Family CTC EcoLogic S, M, L
Below are illustrations of the different connection options available for the
CTCEcoAir510230V1N~. In some cases, a CTC Converter or CTC Basic
Display may be needed. See the chapter on "Connecting the control system".
CTCEcoAir510230V1N~ can be connected to the products below.
2. Connection option
CTCEcoAir510230V1N~
!
CTCEcoZenithi250 must
have software version
20160119 or later.
CTC EcoZenith i550 must
have software version
20160301 or later.
CTC EcoLogic PRO/Family
must have application
version 20160301 or later.

10 CTC EcoAir 510M 230V 1N~
CTC EcoAir 510M 59.7 dB(A) 37-40 dB(A) 30-33 dB(A)
CTC EcoAir 510M
230V 1N~ 50Hz
kW 0.54 / 2.42
kW 2.52 / 6.60
COP 1) 4.67 / 2.73
A 20.8
A 2.8 A
liter 1.9
kg 2.2
ton 4.594
bar 45
bar 2.5
mm 545 x 1245 x 1080
Twin rotary / PVE FV50S
m3/h 3800
rpm
W 73
kg 148/119
dB(A) 59.7/55.6
IP-cl. IPX4
Heat pump Keymark Cert. No. 012-061
Electrical data
Input power 1)
Output power 1)
Rated current 2)
Max start current
Water volume
Refrigerant quantity (R410A, fluorinated
greenhouse gases GWP 2088)
CO2 equivalent
High pressure switch
Max. operating pressure water (PS)
Dimensions (D x W x H)
Compressor / Oil type
Air flow 100%
Fan speed Modulating
Fan, max power
Weight with/without packaging
Sound power 3)
1) At 35°C water temperature. +7 @ 20 rps / -7 °C @ 90 rps. According to EN 14511.
2) At 120 rps (from factory max 90 rps). Incl. Grundfos UPM GEO 25-85 charge pump.
3) Sound power level in accordance with EN12102/ISO3741 at test conditions A7 W47/55 and A7
W30/35.
No annual leakage control of the refrigerant is required.
Sound power Sound pressure 5 m * Sound pressure 10 m *
!Note: In case of deviations, the product's data plate
applies. When servicing always check the product's
data plate for correct refrigerant quantity.
* The noise specified should be regarded as an indication since the level
is affected by the compressor’s and the fan’s speed, as well as the
surroundings. The upper value corresponds to 100% reflective ground and
walls (smooth concrete). Values according to EN12102 at A7/W35.
3. Technical data
Noise data
