CTI 2500 Series User manual

2500C-PS-24V-35 24VDC 35 Watt Power Supply
DESCRIPTION
The 2500C-PS-24V-35 is a triple wide module that
provides power for the CPU and all IO modules
plugged in the Compact Chassis.
FEATURES
Control Technology Inc.
5734 Middlebrook Pike, Knoxville, TN 37921-5914
Phone: [phone] Fax: [phone]
www.controltechnology.com
Power Supply Specifications
Field Wiring Connector 3 Pin Removable Connector
Input Voltage Operating Range 20 VDC to 30 VDC
Total Wattage Rating 35 watts maximum output
@ 0º to 60ºC
Steady State Input Current at
full Load
2.2 Amps max @ 20VDC
1.78 Amps max @ 24VDC
1.4 Amps max @ 30VDC
Peak Inrush Current 12.5 Amps max @ 24VDC
Fusing Littelfuse 0213005.MX
250V IEC SLO 5x20mm 5A
I2T=314
Hold Up Time 8mSec @ 35 Watt Full Load
Module Size Triple wide module
Isolation 1500VAC: 24 VDC-to-Backplane
500VDC: Chassis-to-Backplane
1500VAC: 24 VDC-to-Chassis
IEC 60950-1
Operating Temp Range 0ºC to 60ºC (32ºF to 140ºF)
Storage Temperature -40ºC to 85ºC (-40ºF to 185ºF)
Relative Humidity 5% to 95% (non-condensing)
Shipping Weight 2.0 lb. (0.91 Kg)
Agency Approvals Pending UL, ULC, FM(Class 1, Div 2), CE
2500 Series® Compact System
• Triple wide module
• 24VDC Power Supply
• Maximum 35 watts backplane power
• 8 mSec holdup time
• Front accessible fuse
Copyright© 2021 Control Technology Inc All Rights Reserved 17 January 2022
Note: Ideally the power should be turned off to the
power supply before doing any maintenance. It
must be noted that when the fuse is either blown or
removed the CPU will go into a normal shutdown.
Replacing the fuse with the power off guaranties
the system will come up in an orderly fashion. Re-
placing the fuse while power is still on could create
unpredictable restart issues.

2500 Series® Compact System
Control Technology Inc.
5734 Middlebrook Pike, Knoxville, TN 37921-5914
Phone: [phone] Fax: [phone]
www.controltechnology.com
2500C-PS-24V-35 24VDC 35 Watt Power Supply
Warning:
Disable all power to the base before in-
stalling or removing the power supply. Fail-
ure to do so could cause damage to the
equipment or injury to personnel.
2500C Compact Power
Supplies are always locat-
ed in the left most slot
Caution:
Do not attempt to operate the 2500C-PS-
24V-35 out of the Voltage Operating Rang-
es specified. Damage to the Power Supply
could occur if out of range power input is
applied.
Installing Power Wiring
Use the following steps for installing and removing the 2500C-PS-24V-35 Power Supply from the 2500C Chassis.
1. Position the power supply so that the bezel is facing you.
2. Grasp the top and bottom of the power supply.
3. Carefully slide the power supply into the left most slot in the base until it engages into the backplane connector.
4. Strip power wiring back, insert the wire into the wiring connector as shown above, then tighten screws.
5. Check to make sure the power input wires are securely inserted and the fastened in the wiring connector.
6. Insert and tighten down the 3 pin removable wiring connector.
7. Be sure to tighten the top and bottom bezel screws completely.
8. Once all the chassis modules including controllers and IO are inserted then you may apply power to the power supply
inputs.
To remove the power supply, remove power from the power input by removing the power wiring connector or turning off the
power source, loosen the bezel screws, and pull the power supply forward out of the chassis until it clears the chassis.
Copyright© 2022 Control Technology Inc All Rights Reserved 17 January 2022
Note: This label is found on the side
of the power supply. It provides the
user a way to record the date the
power supply was put in service.
Please visit our website for more
User Supplied Power Input Wiring Diagram
Note: Use Copper Cunductors Only.

2500 Series® Compact System
Control Technology Inc.
5734 Middlebrook Pike, Knoxville, TN 37921-5914
Phone: [phone] Fax: [phone]
www.controltechnology.com
2500C-PS-24V-35 24VDC 35 Watt Power Supply
Copyright© 2022 Control Technology Inc All Rights Reserved 17 January 2022
CAUTION – Non-Hazardous Areas/Hazardous Areas
Turn off power to the system before replacing fuses either in power supplies or IO modules. Refer to Product
Bulletin or Installation and Operation Guide for specific information on the correct fuse for replacement. If
there are any questions please contact CTI support. Fuses should only be replaced by qualified technicians.
WARNING – EXPLOSION HAZARD. DO NOT
REMOVE OR REPLACE WHILE CIRCUIT IS LIVE
UNLESS THE AREA IS FREE OF IGNITIBLE
CONCENTRATIONS.
AVERTISSEMENT – RISQUE D’EXPLOSION. NE
PAS RETIRER NI REMPLACER PENDANT QUE LE
CIRCUIT EST SOUS TENSION À MOINS QUE
L’EMPLACEMENT NE SOIT EXEMPT DE
CONCENTRATIONS INFLAMMABLES.
WARNING – EXPLOSION HAZARD. DO NOT
REMOVE OR REPLACE FUSE WHEN ENER-
GIZED.
AVERTISSEMENT – RISQUE D’EXPLOSION. NE
PAS RETIRER NI REMPLACER UN FUSIBLE SI
L’APPAREILLAGE EST SOUS TENSION.

2500 Series® Compact System
Control Technology Inc.
5734 Middlebrook Pike, Knoxville, TN 37921-5914
Phone: [phone] Fax: [phone]
www.controltechnology.com
2500C-PS-24V-35 24VDC 35 Watt Power Supply
Copyright© 2022 Control Technology Inc All Rights Reserved 17 January 2022
2500C Compact Modules Backplane Power Requirements
Model # Description Backplane Power Budget
2500C-C100 CPU, 128K 7 watts
2500C-C200 CPU, 256K 7 watts
2500C-C300 CPU, 512K 7 watts
2500C-C400 CPU, 3072K 7 watts
2500C-2572-BFast Ethernet TCP/IP Adapter (100 Mbit) for Compact 2.5 watts
2500C-RBC-PRF Profibus Remote Base Controller 1.5 watts
2500C-RBC-RS485 RS485 Remote Base Controller 1.5 watts
2500C-16-DI-24V 16 Non-isolated 24 VAC/VDC Digital Inputs 1.2 watts (with all Inputs ON)
2500C-16-DI-120V 16 Non-isolated 120 VAC/VDC Digital Inputs 1.2 watts (with all Inputs ON)
2500C-16-IDI-120V 16 Isolated 120 VAC/VDC Digital Inputs 1.2 watts (with all Inputs ON)
2500C-16-IDI-24V 16 Isolated 24 VAC/VDC Digital Inputs 1.2 watts (with all Inputs ON)
2500C-8-IDO-120V 8 Isolated 120/240VAC Digital Outputs 1.09 watts (with all Outputs ON)
2500C-8-IDO-24V 8 Isolated 24VDC Digital Outputs 1.09 watts (with all Outputs ON)
2500C-16-DO-120V 16 120VAC Non-isolated Digital Outputs (Note Range
is 79-132VAC) 1.25 watts (with all Outputs ON)
2500C-16-DO-24V 16 24VDC Non-isolated Digital Outputs 1.25 watts (with all Outputs ON)
2500C-8-RL-FC 8 Form C Relay Outputs 1.22 watts
2500C-8-AI 8 Analog Inputs .706 watts
2500C-8-AO 8 Analog Outputs .312 watts
2500C-8-TC 8 Thermocouple Inputs 1.25 watts
2500C-8-RTD 8 RTD Inputs 1.125 watts
2500C-4-HSC 4 Channel High Speed Counter (Note: Release Date
Target 2016) TBD
How to calculate the power requirements for the system.
Using the Table above find your module and the Backplane Power Budget Value. Add all the modules
Power Budget Requirement that will be installed in the base to arrive at the expected power requirement
for your system.
