Cub Cadet 195 cc OHV User manual

MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Safe Operation Practices • Set-Up • Operation • Maintenance • Troubleshooting • Warranty
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
OperatOr’sManual
195 cc OHV Vertical Shaft Engine
Form No. 769-18830
(October 22, 2018)

This Operator’s Manual is an important part of your new engine. It will help you prepare and maintain the engine for the best
performance. Please read and understand the contents before operating the engine.
Thank You
Model NuMber
Serial NuMber
Customer Support
Please do NOT return the machine to the retailer or dealer without first contacting the Customer Support Department.
If you have difficulty assembling this product, have questions regarding the controls, operation, or maintenance of this machine, want
to order replacement parts/attachments/accessories, or want to view an online How-To video; you can seek help from the experts. Have
your full model number and serial number ready. Choose from the options below:
◊ Visit us on the web: www.mtdproducts.com
◊ Call a Customer Support Representative at: [phone] or [phone]
◊ Write to: MTD LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019
To The Owner 1
2
Table of Contents
Safe Operation Practices ........................................ 3
Safety Labels............................................................ 5
Set-Up ....................................................................... 6
Controls & Features................................................. 8
Operation................................................................. 9
Maintenance & Adjustments.................................10
Troubleshooting.....................................................15
Replacement Parts .................................................16
EZ Start Promise .....................................................18
Spanish....................................................................19
Record Product Information
Before operating your new engine, please locate the model plate on the engine (shaded area in Figure below) and record the
information in the provided area below. This information will be necessary, should you seek technical support via our web site or with
your local dealer.

Important Safe Operation Practices 2
3
WARNING! This symbol points out important safety instructions which, if not followed,
could endanger the personal safety and/or property of yourself and others. Read and follow
all instructions in this manual before attempting to operate the equipment. Failure to
comply with these instructions may result in personal injury. When you see this symbol.
HEED ITS WARNING!
DANGER! This engine was built to be operated according to the safe operation practices in
this manual. As with any type of power equipment, carelessness or error on the part of the
operator can result in serious injury. Failure to observe the following safety instructions
could result in serious injury or death.
CALIFORNIA PROPOSITION 65
WARNING! Engine Exhaust, some of its constituents, and certain vehicle components
contain or emit chemicals known to State of California to cause cancer and birth defects
or other reproductive harm.
Training
1. Read, understand and follow all instructions on the engine
and in the manual(s) before attempting to assemble and
operate. Keep this manual in a safe place for future and
regular reference and for ordering replacement parts.
2. Be familiar with all controls and their proper operation.
Know how to stop the engine and disengage them quickly.
3. Never allow children under 14 years of age to operate the
engine. Children 14 and over should read and understand
the instructions and safe operation practices in this manual
and be trained and supervised by an adult.
4. Never allow adults to operate the machine without proper
instruction.
5. Keep the area of operation clear of all persons, particularly
small children and pets. Stop machine if anyone enters the
area.
Preparation
1. Wear sturdy, rough-soled work shoes and close fitting
slacks and shirts. Loose fitting clothes or jewelry can be
caught in the moving parts. Never operate the machine in
bare feet or sandals.
2. Disengage clutch levers and shift (if equipped) into neutral
(“N”) before starting the engine.
3. Never leave the engine running while unattended.
4. Never attempt to make any adjustments while the engine
is running, except where specifically recommended in the
operator’s manual.
Safe Handling of Gasoline:
To avoid personal injury or property damage, use extreme care
in handling gasoline. Gasoline is extremely flammable and the
vapors are explosive. Serious personal injury can occur when
gasoline is spilled on yourself and/or your clothes which can
ignite. Wash your skin and change clothes immediately.
1. When adding fuel, turn engine OFF and let engine cool at
least 2 minutes before removing the gas cap.
2. Fill fuel tank outdoors or in well ventilated area.
3. Use only an approved gasoline container.
4. Never fill containers inside a vehicle or on a truck or trailer
bed with a plastic liner. Always place containers on the
ground away from your vehicle before filling.
5. If possible, remove gas-powered equipment from the truck
or trailer and refuel it on the ground. If this is not possible,
then refuel such equipment on a trailer with a portable
container, rather than from a gasoline dispenser nozzle.
6. Keep the nozzle in contact with the rim of the fuel tank or
container opening at all times until fueling is complete. Do
not use a nozzle lock-open device.

4Section 2 — important Safe operation practiceS
7. Do not overfill fuel tank. Fill tank to full as indicated by
the fuel level indicator installed inside of the fuel tank or
marked on the tank. Do not over-fill to allow space for fuel
expansion. On some models, a fuel level indicator may NOT
be present, in this instance, fill the tank no more than 1/2
inch below the bottom of the filler neck to allow space for
fuel expansion.
8. Replace fuel cap and tighten until the cap ratchets.
9. If gasoline is spilled, wipe it off the engine and the
equipment. Move the machine to another area. Wait five
minutes before starting the engine.
10. To reduce fire hazards, keep the machine free of grass ,
leaves or other debris build up. Clean up oil or fuel spillage
and remove any fuel-soaked debris.
11. Keep gasoline away from sparks, open flames, pilot lights,
heat, and other ignition sources.
12. Never fuel equipment indoors because flammable vapors
will accumulate in the area.
13. Extinguish all cigarettes, cigars, pipes, and other sources of
ignition.
14. Check fuel line, tank, cap, and fittings frequently for cracks
or leaks. Replace if necessary.
Operation
1. When starting the engine, make sure spark plug, muffler,
and fuel cap are in place.
2. Do not crank engine with spark plug removed.
3. If fuel spills, wait until it evaporates before starting engine.
4. Allow muffler, engine cylinder, and fins to cool before
touching.
5. Keep children away from hot or running engines. They can
suffer burns from a hot muffler.
6. Remove accumulated combustibles from muffler and
cylinder area.
7. Operate equipment with all guards in place.
8. Keep hands and feet away from rotating parts.
9. Tie up long hair and remove jewelry.
10. Do not wear loose-fitting clothing, dangling drawstrings or
items that could become caught.
11. When starting the engine, pull cord slowly until resistance
is felt, then pull rapidly (if not electric start).
12. Remove all external equipment/engine loads before
starting engine.
13. Direct coupled equipment components such as, but not
limited to blades, impellers, pulleys, sprockets, etc., must
be securely attached.
Maintenance & Storage
1. Keep the engine in safe working order
2. Allow the engine to cool at least five minutes before
storing. Never tamper with safety devices. Check their
proper operation regularly.
3. Check bolts and screws for proper tightness at frequent
intervals to keep the engine in safe working condition.
Visually inspect the engine for any damage.
4. Before cleaning, repairing or inspecting; stop the
engine and make certain all moving parts have stopped.
Disconnect the spark plug wire and ground it against the
engine to prevent unintended starting.
5. Do not change the engine governor settings or over-speed
the engine. The governor controls the maximum safe
operating speed of the engine.
6. Maintain and replace safety and instruction labels as
necessary.
7. Always refer to the operator’s manual for important details
if the machine is to be stored for an extended period of
time.
8. If the fuel tank has to be drained, do this outdoors.
9. Observe proper disposal laws and regulations for gas, oil,
etc. to protect the environment.
Do not modify engine
To avoid serious injury or death, do not modify engine in any
way. Tampering with the governor setting can lead to a runaway
engine and cause it to operate at unsafe speeds. Never tamper
with factory setting of engine governor.
Notice Regarding Emissions
Engines which are certified to comply with California and federal
EPA emission regulations for SORE (Small Off Road Equipment)
are certified to operate on regular unleaded gasoline, and
may include the following emission control systems: Engine
Modification (EM), Oxidizing Catalyst (OC), Secondary Air
Injection (SAI) and Three Way Catalyst (TWC) if so equipped.
Spark Arrestor
WARNING! This machine is equipped with an
internal combustion engine and should not be used
on or near any unimproved forest-covered, brush
covered or grass-covered land unless the engine’s
exhaust system is equipped with a spark arrestor
meeting applicable local or state laws (if any).
If a spark arrestor is used, it should be maintained in effective
working order by the operator. In the State of California the
above is required by law (Section 4442 of the California Public
Resources Code). Other states may have similar laws. Federal laws
apply on federal lands.
A spark arrestor for the muffler is available through your
nearest engine authorized service dealer or contact the service
department, P.O. Box 361131 Cleveland, Ohio 44136-0019.

5Section 2 — important Safe operation practiceS
WARNING! Your Responsibility — Restrict the use of this power machine to persons who read, understand and
follow the warnings and instructions in this manual and on the machine.
SAVE THESE INSTRUCTIONS!
Safety Symbols
This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the
machine before attempting to assemble and operate.
Symbol Description
READ THE OPERATOR’S MANUAL(S)
Read, understand, and follow all instructions in the manual(s) before attempting to
assemble and operate.
WARNING—GASOLINE IS FLAMMABLE
Allow the engine to cool at least two minutes before refueling.
WARNING— CARBON MONOXIDE
Never run an engine indoors or in a poorly ventilated area. Engine exhaust contains carbon
monoxide, an odorless and deadly gas.
WARNING— ELECTRICAL SHOCK
Do not use the engine’s electric starter in the rain.
WARNING— HOT SURFACE
Engine parts, especially the muffler, become extremely hot during operation. Allow engine
and muffler to cool before touching.

Gas & Oil
NOTE: The engine is shipped without gasoline or oil in the
engine. Running the engine with insufficient oil can cause
serious engine damage and void the engine warranty.
WARNING! Always keep hands and feet clear of
equipment moving parts. Do not use a pressurized
starting fluid. Vapors are flammable.
Oil Recommendations
Before starting engine, fill with motor oil, capacity is 600 ml/20
oz. Refer to viscosity chart in Figure 3-1 for oil recommendations.
Do not over-fill. Use a 4-stroke, or an equivalent high detergent,
premium quality motor oil certified to meet or exceed
U.S. automobile manufacturer’s requirements for service
classification of a minimum level SJ (higher letter ratings are
acceptable such as SL and SM grades). Motor oil will display this
designation on the container.
SAE 30 is recommended for general, all temperature use. If
single viscosity oil is used, select the appropriate viscosity for the
average temperature in your area from the chart below.
-30º -20º
10w
20w
20
30
40
20w40, 20w50
15w40, 15w50
10w40
10w30
-10º 0º
0º 20º 40º 60º 80º 100º
10º 20º 30º 40º
-20º
(ºC)
(ºF)
1
2
Figure 3-1
1. Single Viscosity
2. Multi Viscosity
CAUTION: Do not use non-detergent oil or 2-stroke engine oil. It
could shorten the engine’s service life.
NOTE: A 5w30 synthetic oil may be used to improve start ability
for cold weather (temperatures below 40 F).
Checking Oil Level
NOTE: Be sure to check the oil while on a level surface with the
engine stopped.
1. Remove the oil filler cap/dipstick and wipe the dipstick
clean.
2. Insert the dipstick into the oil filler neck. Turn the dipstick a
1/4 turn into the locked position to fully seat.
3. Remove dipstick. If the level is low, slowly add oil to the
upper limit on the dipstick. See Figure 3-2 inset.
Figure 3-2
4. Reinsert the dipstick into the locked position before
starting the engine.
NOTE: Do not overfill. Overfilling with oil may cause
smoking, hard starting, spark plug fouling, or oil saturation
of air cleaner.
Set-Up 3
6

Fuel Requirements
CAUTION: Operating the engine with E15 or E85
fuel, an oil/gasoline mixture, dirty gasoline, or
gasoline over 30 days old without fuel stabilizing
additive may result in damage to your engine’s
carburetor. Subsequent damage would not be
covered under the manufacturer’s warranty.
Use automotive gasoline (unleaded or low leaded to minimize
combustion chamber deposits) with a minimum of 87 octane.
Gasoline with up to 10% ethanol (E10) or 15% MTBE (Methyl
Tertiary Butyl Ether) can be used. Never use an oil/gasoline
mixture or dirty gasoline. Avoid getting dirt, dust, or water in the
fuel tank. DO NOT use E15 or E85 gasoline.
WARNING! Gasoline is extremely flammable and is
explosive under certain conditions.
• Refuel in a well-ventilated area with the engine stopped.
Do not smoke or allow flames or sparks in the area where
the engine is refueled or where gasoline is stored.
• Do not overfill the fuel tank. After refueling, make sure the
tank cap is closed properly and securely.
• Be careful not to spill fuel when refueling. Spilled fuel or
fuel vapor may ignite. If any fuel is spilled, make sure the
area is dry before starting the engine.
• Avoid repeated or prolonged contact with skin or
breathing of vapor.
Adding Fuel
WARNING! An adult should fuel this engine.
NEVER allow children to refuel the engine. Gasoline
(fuel) vapors are highly flammable and can explode.
Fuel vapors can spread and be ignited by a spark or
flame many feet away from engine. To prevent injury
or death from fuel fires, follow these instructions:
• DO NOT use leaded fuel.
• Fuel must be fresh and clean. NEVER use fuel left over
from last season or stored for long periods.
• NEVER mix oil with fuel.
• DO NOT use fuel containing Methanol (Wood
Alcohol)
NOTE: Before refueling, allow engine to cool two minutes.
1. Clean around fuel fill before removing cap to fuel.
2. Fill tank until fuel reaches ⁄ inch below the bottom of the
filler neck to allow space for fuel expansion. Be careful not
to overfill.
3. Replace the gasoline cap and tighten securely. Wipe up
spilled fuel before starting engine. If fuel is spilled DO NOT
start engine. Move machine away from area of spillage.
Avoid creating any source of ignition until fuel vapors are
gone.
7Section 3 — Set-Up

Controls and Features 4
8
Oil Fill Cap
Remove the oil fill cap to check the oil level and add oil.
Fuel Cap
Remove the fuel cap to add fuel.
Muffler
Spark Plug
Air Cleaner
Starter Handle
Oil Fill Cap Fuel Cap
Figure 4-1
Starter Handle
Pull the starter handle to start the engine.
Spark Plug
Refer to the Maintenance section for instructions on spark plug
maintenanance and replacement.
Air Cleaner
Refer to the Maintenance section for instructions on air cleaner
maintenance and replacement.

Operation 5
9
Pre-Operation Check
The engine is shipped without gasoline or oil in the engine. See
the Set-Up Section of this manual for instructions on adding oil
and gasoline.
Starting the Engine
WARNING: Always keep hands and feet clear of
equipment moving parts. Do not use a pressurized
starting fluid. Vapors are flammable.
1. Standing behind the mower, depress the blade control
handle and hold it against the upper handle. See Figure 5-1.
2. Pull the starter grip lightly until resistance is felt, then pull
rapidly to overcome compression, prevent kickback and
start engine. Repeat if necessary.
IMPORTANT: Do not allow the starter grip to snap back
against the engine. Return it gently to prevent damage to
the starter.
Stopping Engine
1. Release blade control or turn off the engine switch (if
equipped).
1
2
Figure 5-1

Engine Maintenance 6
10
WARNING: Shut off the engine before performing
any maintenance. To prevent accidental start-up,
disconnect the spark plug boot.
IMPORTANT: If engine must be tipped to transport equipment
or to inspect or remove grass, keep spark plug side of engine
up. Transporting or tipping engine spark plug down may cause
smoking, hard starting, spark plug fouling, or oil saturation of air
cleaner.
Periodic inspection and adjustment of the engine is essential if
high level performance is to be maintained. Regular maintenance
will also ensure a long service life. The required service intervals
and the kind of maintenance to be performed are described
in the table below. Follow the hourly or calendar intervals,
whichever occur first. More frequent service is required when
operating in adverse conditions.
WARNING: If the engine has been running, the
muffler will be very hot. Be careful not to touch the
muffler.
† Service more frequently when used in dusty areas.
†† Every season or 25 hours if operating under heavy load or high ambient temperature.
Maintenance Schedule
First 5 Hours Each Use or
Every 5 Hrs.
Every Season
or 25 Hours
Every Season
or 50 Hours
Every Season
or 100 Hours
Service
Dates
Check Engine Oil Level P
Change Engine Oil †† P P
Check Air Cleaner P
Service Air Cleaner † P
Service Carbon Canister Filter † P
Check Spark Plug P
Replace Spark Plug P
Clean Engine Shroud P
Clean around muffler P
Replace Fuel Filter P

11Section 6 — Maintenance
Air Filter Service
Paper filters cannot be cleaned and must be replaced once a year
or every 100 operating hours; more often if used in extremely
dusty conditions.
WARNING: Never use gasoline or low flash point
solvents for cleaning the air filter element. A fire or
explosion could result.
IMPORTANT: Never run the engine without the air filter. Rapid
engine wear will result.
1. Turn cover to left (counterclockwise) and remove it and
paper element from flange. See Figure 6-2.
Paper
Element
Cover
Retainer
Flange
Tab
Figure 6-2
2. Discard paper element.
3. Clean cover and flange thoroughly.
4. Install new paper element into cover.
5. Position cover and element against flange with tab on the
cover inserted into the lower left corner of slot in flange.
6. Push cover firmly against flange and turn to right
(clockwise) as far as it will go until it locks.
Oil Service
• Check oil level regularly.
• Be sure correct oil level is maintained. Check every five
hours or daily before starting engine. See oil checking
procedure in the Operation section.
Oil Change
IMPORTANT: Be sure to check engine on a level surface with the
engine stopped. Drain the oil while the engine is still warm to
assure rapid and complete draining.
1. Remove all fuel from tank by running engine until it stops
from lack of fuel.
2. Remove drain plug and allow oil to drain into a suitable
container. See Figure 6-1.
Oil Fill Cap
Drain
Plug
Drain Plug (If
Accessible)
Figure 6-1
WARNING: Before tipping engine or equipment to
drain oil, drain fuel from tank by running engine
until fuel tank is empty.
3. Reinstall the drain plug and tighten it securely.
4. Refill with the recommended oil and check the oil level.
Refer to the Set-Up Section.
5. Reinstall the oil fill cap securely.
IMPORTANT: Used motor oil may cause skin cancer if repeatedly
left in contact with the skin for prolonged periods. Although this
is unlikely unless you handle used oil on a daily basis, it is still
advisable to thoroughly wash your hands with soap and water as
soon as possible after handling used oil.
NOTE: Please dispose of used motor oil in a manner that is
compatible with the environment. We suggest you take it in a
sealed container to your local service station for reclamation. Do
not throw it in the trash or pour it on the ground.

12 Section 6 — Maintenance
Carbon Canister Filter Service
The foam carbon canister filter must be cleaned or replaced once
a year or every 100 operating hours.
1. Remove outer engine shroud and nuts securing inner
shroud as shown in Figure 6-3.
Outer Engine
Shroud
Nut
Figure 6-3
2. Lift up inner engine shroud and carefully pull out carbon
canister filter assembly from under shroud as shown in
Figure 6-4.
Inner Shroud
Foam Filter
Cap
Figure 6-4
3. Remove cap from end of canister and pull out round
foam filter from inside the assembly. See Figure 6-4. Clean
element or replace when damaged.
4. To clean foam element, wash in mild liquid detergent and
water. Squeeze or press the foam element to rinse out dirt
and water. Do not twist, this could damage or tear the foam
element. Allow to dry thoroughly before using. Oil the
foam element with a light engine oil.
5. Carefully place foam filter back into canister assembly and
reattach the rubber cap removed earlier.
6. Snap the carbon canister filter assembly back into place
under the inner engine shroud. See Figure 6-5 inset.
IMPORTANT: Be sure the angled nipple points upwards
into the shroud to avoid interference with the autochoke
linkage.
Angled Nipple
Figure 6-5
7. Place the inner engine shroud back onto the engine and
fasten back down with nuts removed earlier.
8. Reattach the outer engine shroud.

13Section 6 — Maintenance
Spark Plug Service
WARNING: DO NOT check for spark with spark
plug removed. DO NOT crank engine with spark
plug removed.
To ensure proper engine operation, the spark plug must be
properly gapped and free of deposits.
1. Remove the spark plug boot and use a spark plug wrench
to remove the plug. See Figure 6-6.
Spark Plug Boot
Spark Plug
Figure 6-6
WARNING: If the engine has been running, the
muffler will be very hot. Be careful not to touch the
muffler.
2. Visually inspect the spark plug. Discard the spark plug
if there is apparent wear, or if the insulator is cracked or
chipped. Clean the spark plug with a wire brush if it is to be
reused.
3. Measure the plug gap with a feeler gauge. Correct as
necessary by bending side electrode. See Figure 6-7. The
gap should be set to 0.030 in.
Electrode
0.030 in.
Figure 6-7
4. Check that the spark plug washer is in good condition
and thread the spark plug in by hand to prevent cross-
threading.
5. After the spark plug is seated, tighten with a spark plug
wrench to compress the washer.
NOTE: When installing a new spark plug, tighten 1/2 turn
after the spark plug seats to compress the washer. When
reinstalling a used spark plug, tighten 1/8-1/4 turn after the
spark plug seats to compress the washer.
IMPORTANT: The spark plug must be securely tightened.
An improperly tightened spark plug can become very hot
and may damage the engine.

14 Section 6 — Maintenance
Fuel Filter Service
The fuel filter cannot be cleaned and must be replaced once a
year or every 100 operating hours; more often if run with old
gasoline.
1. Remove all fuel from tank by running engine until it stops
from lack of fuel.
2. Remove hose clamp from fuel line and remove fuel line
from tank outlet. See Figure 6-8.
Fuel Filter
Figure 6-8
3. Pull out old fuel filter from tank outlet. Replace when dirty
or damaged.
4. Grasp new fuel filter from shouldered end and insert it
completely to the shoulder into the tank outlet.
5. Replace fuel line and hose clamp.
Clean Engine
If the engine has been running, allow it to cool for at least half
an hour before cleaning. Periodically remove dirt build-up from
engine. Clean finger guard and around muffler. Clean with a
brush or compressed air.
IMPORTANT: Do not spray engine with water to clean because
water could contaminate fuel. Using a garden hose or pressure
washing equipment can also force water into the air cleaner or
muffler opening. Water in the air cleaner will soak the paper
element, and water that passes through the element or muffler
can enter the cylinder, causing damage.
WARNING: Accumulation of debris around muffler
could cause a fire. Inspect and clean before every
use.
Storage
CAUTION: Failure to use a fuel stabilizing additive
or completely run the engine until it’s out of fuel
before off-season storage may result in damage to
your engine’s carburetor. Subsequent damage
would not be covered under the manufacturer’s
warranty.
Engines stored between 30 and 90 days need to be treated with
a gasoline stabilizer and engines stored over 90 days need to be
drained of fuel to prevent deterioration and gum from forming
in fuel system or on essential carburetor parts. If the gasoline in
your engine deteriorates during storage, you may need to have
the carburetor, and other fuel system components, serviced or
replaced.
1. Remove all fuel from tank by running engine until it stops
from lack of fuel.
WARNING: Never leave engine unattended while
running.
2. Change oil. See Oil Change section.
3. Remove spark plug and pour about 1/2 an ounce of engine
oil into cylinder. Replace spark plug and crank slowly to
distribute oil.
4. Clean debris from around engine, under finger guard, and
under, around and behind muffler. Touch up any damaged
paint, and coat other areas that may rust with a light film
of oil.
5. Store in a clean, dry and well ventilated area away from any
appliance that operates with a flame or pilot light, such
as a furnace, water heater, or clothes dryer. Also avoid any
area with a spark producing electric motor, or where power
tools are operated.
6. If possible, also avoid storage areas with high humidity,
because that promotes rust and corrosion.
7. Keep the engine level in storage. Tilting can cause fuel or
oil leakage.
Removing From Storage
1. Check your engine as described in the Pre-Operation Check
section of this manual.
2. If the fuel was drained during storage preparation, fill the
tank with fresh gasoline. If you keep a container of gasoline
for refueling, make certain it contains only fresh fuel.
Gasoline oxidizes and deteriorates over time, causing hard
starting.
3. If the cylinder was coated with oil during storage
preparation, the engine will smoke briefly at startup. This
is normal.

Troubleshooting 7
15
Problem Cause Remedy
Engine fails to start 1. Blade control disengaged (Lawn mower
only).
2. Spark plug boot disconnected.
3. Fuel tank empty or stale fuel.
4. Fuel shut-off valve closed (if equipped).
5. Engine not primed (if equipped with primer).
6. Faulty spark plug.
7. Reduced fuel flow/blocked fuel filter.
8. Engine flooded.
9. Engine not choked (if equipped with choke).
1. Engage blade control.
2. Connect wire to spark boot.
3. Fill tank with clean, fresh gasoline.
4. Turn on fuel shut-off valve.
5. Prime engine as instructed in the Operation
section.
6. Clean, adjust gap, or replace.
7. Replace fuel filter as instructed in the Maintenance
section.
8. Wait a few minutes to restart, but do not
prime.
9. Choke engine. See Operation section.
Engine fails to start
with electric starter
(Electric Start Units
Only)
1. Electric starter push key not fully inserted.
2. Battery not charged.
3. Circuit breaker tripped.
1. Insert electric starter push key into starter housing
until it snaps into place.
2. Charge battery. See Service section of equipment
Operator’s Manual.
3. Debris may be blocking blade operation. Stop
engine, remove electric starter push key, and
disconnect spark plug boot. Verify grass or other
debris are not obstructing the blade. Carefully clean
out debris if necessary. Reattach spark plug boot and
reinsert electric starter push key. Wait one minute
after tripping for circuit breaker to automatically self-
reset then reattempt start.
Engine runs erratic 1. Spark plug boot loose.
2. Reduced fuel flow/blocked fuel filter.
3. Vent in gas cap plugged (if equipped).
4. Water or dirt in fuel system.
5. Dirty air cleaner.
6. Unit running with CHOKE (if equipped)
applied.
1. Connect and tighten spark plug boot.
2. Replace fuel filter as instructed in the Maintenance
section.
3. Clear vent.
4. Drain fuel tank. Refill with fresh fuel.
5. Refer to Maintenance section.
6. Push CHOKE knob in.
Engine overheats 1. Engine oil level low.
2. Air flow restricted.
1. Fill crankcase with proper oil.
2. Clean area around and on top of engine.
Occasional skips
(hesitates) at
high speed
1. Spark plug gap too close. 1. Adjust gap to .030”.
Idles poorly 1. Spark plug fouled, faulty, or gap too wide.
2. Dirty air cleaner.
1. Reset gap to .030” or replace spark plug.
2. Refer to Maintenance section.
Engine stalls with
full tank
1. Carbon canister vent line(s) pinched/kinked
(if equipped with carbon canister).
1. Refer to Carbon Canister Filter Service section on
page 13 to remove engine shroud and relieve
pinched/kinked vent line(s). Re-install engine shroud
making sure vent line(s) are not pinched or kinked.

Replacement Parts 8
16
Phone [phone] or [phone] to order replacement parts or a complete Parts Manual (have your full model number and
serial number ready). Parts Manual downloads are also available free of charge at www.mtdproducts.com.
Component Part Number and Description
951-10292 Spark Plug
951-14512 Air Cleaner (Includes pre-filter)
951-14407 Fuel Cap Assembly
951-12296 Fuel Filter

Notes 9
17

GDOC-100163 Rev. B
The EZ Start Promise
Provisions of Your Limited Warranty
In addition to the other terms and conditions of the Limited
Warranty applicable to your new mower, MTD LLC (“MTD”) hereby
warrants that your mower’s engine will start on the first or second
attempt by an able-bodied adult (subject to the limitations
described below) for the duration of the manufacturer’s limited
warranty applicable to your product. If the engine on your mower
fails to conform to this limited warranty, MTD will cover the cost
of parts and labor associated with any adjustments and/or repairs
necessary to return your engine to its warranted condition. In
order to make a claim under these provisions of your warranty, you
must bring the product and proof of purchase to an authorized
MTD service provider. In many cases, the retailer who sold you
your mower is not equipped to provide warranty service, so please
locate the authorized service dealer nearest you by either calling
the phone number provided in your Operators Manual or looking
up an authorized service dealer on-line at www.mtdproducts.com.
Items and Conditions Not Covered
The EZ Start Promise does not cover and/or apply to the following:
• Cost of regular maintenance service or parts, such as filters,
fuel, lubricants, oil changes, spark plugs, air filter, blade
sharpening, worn blades, cable/linkage adjustments, or brake
and clutch adjustments
• Transportation costs to and from an authorized MTD service
provider
• Any engine used for commercial, rental, institutional,
governmental, or non-residential applications
• Any product or part that has been altered or misused or
required replacement or repair due to misuse, accidents, or
lack of proper maintenance
• Repairs necessary due to improper battery care, electrical
supply irregularities, or failure to properly prepare the mower
prior to any period of non-use over three months
• Pickup and/or delivery charges
• Operational misuse, neglect, accidents, unauthorized repairs
or attempted repairs of the engine or its components by
anyone other than an authorized MTD service provider.
• Repairs or adjustments to correct starting difficulties due to
any of the following: failure to follow proper maintenance
procedures — rotary mower blade striking an object —
contaminants in the fuel system — improper fuel or fuel/oil
mixture (consult your Operator’s Manual if in doubt) — failure
to drain the fuel system prior to any period of non-use over
three months.
• Any starting problem which results from the use of
inappropriate fuels, lubricants, or additives.
• Special conditions or circumstances that normally require
more than two pulls to start, specifically: 1) First start-up
following your initial purchase, 2) first time starts after
extended period(s) of non-use over one month or seasonal
storage, 3) cool temperature starts such as those found in
early spring and late autumn, and 4) difficult starting that
results from the operator’s failure to follow the proper
starting procedures identified in the Operator’s Manual. If
you are having difficulty starting your unit, please check the
Operator’s Manual to ensure that you are using the correct
starting procedures. This can save an unnecessary visit to a
Service Dealer.
Owner Responsibilities
You must maintain your mower (including its engine) by following
the maintenance procedures and starting instructions described
in the Operator’s Manual. Such routine maintenance, whether
performed by a dealer or by you, is at your expense. In addition,
please retain your proof of purchase and service receipts as these
may be required to validate a claim.
General Conditions
An authorized MTD service provider using approved replacement
parts must perform all repairs covered by the EZ Start Promise.
Repair by an MTD authorized service dealer is your sole remedy
under this warranty. MTD is not liable for indirect, incidental, or
consequential damages in connection with the use of the products
covered by these warranties, including any cost or expense of
providing substitute equipment or service during reasonable
periods of malfunction or non-use pending completion of repairs
under this warranty.
Some states do not allow exclusions of incidental or consequential
damages, or limitations on how long an implied warranty lasts, so
certain exclusions and limitations may not apply to you.

MTD LLC. APARTADO POSTAL 361131 CLEVELAND, OHIO 44136-0019
Medidas importantes de seguridad • Configuración • Funcionamiento • Mantenimiento
• Solución de problemas • Garantía
ADVERTENCIA
LEA Y RESPETE TODAS LAS NORMAS DE SEGURIDAD E INSTRUCCIONES INCLUIDAS EN ESTE
MANUAL ANTES DE PONER EN FUNCIONAMIENTO ESTA MÁQUINA.
SI NO RESPETA ESTAS INSTRUCCIONES PUEDE PROVOCAR LESIONES PERSONALES.
Manual del OperadOr
Motor de 195 cc con eje vertical y válvulas en cabeza

Este Manual del Operador es una parte importante de su nuevo motor. Le ayudará a preparar y mantener la unidad para obtener los
mejores resultados. Antes de operar el motor lea cuidadosamente y comprenda todo el manual.
Gracias
NúMero de Modelo
NúMero de Serie
Asistencia al Cliente
Por favor, NO devuelva la unidad al minorista o distribuidor sin ponerse en contacto primero con el Departamento de
Asistencia al Cliente.
En caso de tener problemas para montar este producto o de tener dudas con respecto a los controles, funcionamiento o
mantenimiento del mismo, puede solicitar la ayuda de expertos. Elija entre las opciones que se presentan a continuación:
◊ Visite nuestro sitio web en www.mtdproducts.com
◊ Llame a un representante de Asistencia al Cliente al [phone] ó [phone]
◊ Escríbanos a MTD LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019
Al propietario 1
2
Índice
Medidas importantes de seguridad ...................... 3
Configuración.......................................................... 6
Controles y Características..................................... 8
Funcionamiento...................................................... 9
Mantenimiento y Ajustes.......................................10
Solución de problemas ..........................................15
Piezas de Reemplazo .................16 (Manual inglés)
EZ Start Promise‡ ...................................................18
Registro de información de producto
Antes de operar su motor nuevo, por favor localice su placa de modelo en el motor (Área sombreada en la figura a continuación) y
registre la información en el área situada a continuación. Si tiene que solicitar soporte técnico a través de nuestro sitio web o de un
distribuidor de servicio local, necesitará esta información.
