START BY LAYING OUT THE PARTS.
ALWAYS READ YOUR OWNER’S
MANUAL.
MOUNT ASSEMBLY ON TRACTOR
a. Place hooked ends of the mounting assembly over
the shoulder bolts, use the clevis bolt and hairpin clip
to secure bracket to tractor
INSTALL HANGER ASSEMBLY
a. Use hanger position C, secure using the carriage bolt
and wing knob
b. Place hanger assembly onto the upright support
bracket, secure using two carriage bolts and two
1/2” lock nuts and washers
ASSEMBLE MOUNTING BRACKETS
a. Attach the two side brackets to the rear attachment, use
two carriage bolts and the wing knobs to secure them
b. Flip over the assembly and mount the hitch support
bracket, use the holes furthest away from the rear
hooks and use two carriage bolts and the wing
knobs to secure them
XT™ SERIES BAGGER
ASSEMBLY GUIDE
HOW TO ASSEMBLE THE DOUBLE BAGGER ON AN XT™LAWN TRACTOR
1
2
3
4
(CONTINUED ON NEXT PAGE)

ASSEMBLE REMAINING BAGGER
a. Snap the upper chute support into place
b. Slide the left side into the upper chute support
using the tabs
c. Align the cover tabs with the chute support, slide
hinge pin in place
d. Add the bags
INSTALLING THE CHUTE
a. Install the boot rod mount using the 7/16” nuts
(2 wrenches are used)
b. Slide the boot rod into the deck, secure the boot with
a wing knob
c. Slide the chute into the opening, turn counterclock-
wise until secure
XT™ SERIES BAGGER
ASSEMBLY GUIDE
5 6
