Cub Cadet TANK Series User manual

COLLECTION SYSTEM
59A30042150
COLLECTION SYSTEM
21621216
MODEL #
Tank SZ Models:
Tank LZ Models:
ALTERNATE
MODEL #
ASSEMBLY OPERATION MAINTENANCE
MANUAL PART#: Q0466 REV: 4 - June 18 2018
OPERATOR’S MANUAL
*LZ MODELS: COLLECTION SYSTEM REQUIRES INSTALLATION
OF ADDED WEIGHT KIT P# 59A30037150 (A1149) FOR SAFE OPERATION!
PTO DRIVEN -
GRASS
COLLECTION SYSTEM
2014-2015
MODEL YEAR:
DESIGNED
TO FIT: TANK
SERIES - 54” & 60”
DECKS
SZ LZ
- 54” & 60”
DECKS
53AI2PTC050
53BI2PTD050
53YI2PTC050
53YI2PTD050
53BH2PTD330
53AI2PUC050
53BI2PUD050
53YI2PUC050
53YI2PUD050
53RE2PUD050
53AI2PUD330

2
PECO GRASS COLLECTION SYSTEM
TABLE OF CONTENTS
1-2 Description - - - - - - - - - - - - - - - - - - - - - - - - - 5
2-5 Drive Belt Installation and Adjustment - - - - - - - - 9
SECTION PAGE
Warranty - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4
Safety Alert Symbols- - - - - - - - - - - - - - - - - - - - - - 3
Safety - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2
I INTRODUCTION AND DESCRIPTION - - - - - - - - - - - - 5
1-1 Introduction - - - - - - - - - - - - - - - - - - - - - - - - - 5
II INSTALLATION FOR USE - - - - - - - - - - - - - - - - - - - - - 6
2-1 Preparation Of Mower - - - - - - - - - - - - - - - - - - 6
2-2 PTO Mount Plate Assembly Installation - - - - - - - 7
2-3 Lower Main Frame Installation - - - - - - - - - - - - - 7
2-4 PTO Assembly Installation - - - - - - - - - - - - - - - 8
2-9 Lower Main Frame Leg Installation - - - - - - - - - - 12
2-10 Main Frame Assembly Installation- - - - - - - - - - 12
2-14 Boot To Mower Deck Installation - - - - - - - - - - - 15
2-6 Cam Assembly Adjustment - - - - - - - - - - - - - - - 10
2-11 Lift Handle Installation - - - - - - - - - - - - - - - - - 13
2-8 Safety Interlock Harness Installation - - - - - - - - - 11
2-7 Blower Cone Installation - - - - - - - - - - - - - - - - - 10
2-13 Dump Mechanism Adjustment - - - - - - - - - - - - 14
2-12 Aluminum Grass Container Installation- - - - - - - 14
Wiring Diagram - - - - - - - - - - - - - - - - - - - - - - - - - 27
SECTION PAGE
Exploded Part Views and Assemblies - - - - - - - - - 20-26
Torque Specifications - - - - - - - - - - - - - - - - - - - - - 31
Safety Decals - - - - - - - - - - - - - - - - - - - - - - - - - - 30
4-2 Lubrication- - - - - - - - - - - - - - - - - - - - - - - - - - 29
4-1 Maintenance Checklist - - - - - - - - - - - - - - - - 28-29
2-20 Included Weight Kit Installation- - - - - - - - - - - - 19
2-19 Impeller Blade Removal/Replacement - - - - - - - 18
2-18 Lower Hose To Boot Installation - - - - - - - - - - - 16
2-21 Additional Weight Kit Installation - - - - - - - - - - - 19
3-2 Operation & Tips On Mowing - - - - - - - - - - - - - - 28
3-3 Disengagement Of The Blower - - - - - - - - - - - 28
2-16 Upper Hose Installation - - - - - - - - - - - - - - - - 16
3-4 Unloading The Collection System - - - - - - - - - - - 28
III OPERATING INSTRUCTIONS - - - - - - - - - - - - - - - - - - 28
V PARTS AND SERVICE - - - - - - - - - - - - - - - - - - - - - - 29
2-17 Lower Hose To Blower Cone Installation- - - - - - 16
2-15 Length Of Hose Adjustment - - - - - - - - - - - - - - 16
5-1 Parts And Service Information - - - - - - - - - - - - - 29
IV MAINTENANCE - - - - - - - - - - - - - - - - - - - - - - - - - - - 28
3-1 General Safety - - - - - - - - - - - - - - - - - - - - - - - 28
SAFETY
5. Keep your eyes and mind on your machine while mowing or operating your attachment. Don’t let others distract
1. Read the operator’s manual carefully and familiarize yourself with the proper use of your attachment. Do not allow
2. Know the controls and how to stop them quickly. READ THE OPERATOR’S MANUAL!
anyone who is not acquainted with the Safety Instructions to use your attachment.
3. Do not allow children to operate the machine. Do not allow adults to operate it without proper instruction.
4. Be especially watchful of children and pets entering into the area while operating.
you.
7. Always shut off blades and engine when emptying the container.
8. Stop machine, shut off deck attachment, set parking brake, shut off engine and remove ignition key before
removing clogs, removing or replacing hose, boot, blower cone, or performing any maintenance.
9. Mow across the face of slopes (not more than 10 degrees); never up and down the face.
10. It is recommended that the container be emptied when half full while operating on slopes. Start mowing on slopes
when the container is empty.
11. Inspect your lawn and remove any foreign objects before mowing. Never deliberately run the mower across any
foreign object.
12. Wear hearing protection.
6. Do not attempt to operate your machine when not in the driver’s seat.
13. Wear eye protection to prevent debris from getting into your eyes.
2017 (v1.0)

3
WARNING! To avoid serious injury, perform maintenance on the vacuum collector; ONLY AFTER
STOPPING THE MOWER’S ENGINE AND WAITING FOR ALL MOVING PARTS TO COME TO A
COMPLETE STOP. Set the parking brake. Always remove the ignition key before beginning maintenance.
Safety Signs
WARNING! For your own personal safety, ALWAYS mow ACROSS the face of slopes and
NEVER UP and DOWN the face. NEVER attempt to mow excessively steep slopes, and use
caution when turning on any slope.
SAFETY
WARNING! NEVER operate the mower unless the discharge guard and either the deflector assembly or
the vacuum collector adapter are fastened securely in place.
Safety Alert Symbol
This Safety Alert Symbol means: “ATTENTION! BECOME
Should be followed by the operator to avoid accidents. When
could result in death or serious bodily injury.
WARNING! Do not work around the mower deck boot or the blower area until you are certain that the mower
blades and the blower impeller have stopped rotating.
ALERT! YOUR SAFETY IS INVOLVED!”
and heed its advice. Failure to comply with safety precautions
This symbol is used to call attention to safety precautions that
you see this symbol, carefully read the message that follows
The signal words DANGER, WARNING, and CAUTION are used on the equipment safety signs. These words
are intended to alert the viewer to the existence and the degree of hazard seriousness.
DANGER
!
CAUTION
This signal word indicates a potentially hazardous situation which, if not
avoided, will result in death or serious injury.
This signal word indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
It may also be used to alert against unsafe practices.
This signal word indicates a potentially hazardous situation which, if not
avoided, will result in minor or moderate injury.
It may also be used to alert against unsafe practices.
White letters on RED
Black letters on ORANGE
Black letters on YELLOW
WARNING
!
!
!
2017 (v1.0)

4
H. REMEDIED EXCLUSIVE
E. ACCIDENTS AND NORMAL MAINTENANCE
The only remedies the purchaser has in connection with the breach or performance of any warranty on New
PECO, Inc. consumer products are set forth above. In no event will PECO be liable for special incidental or
consequential damages.
G. PRODUCTS USED FOR RENTAL OR LEASE PURPOSES ARE WARRANTIED FOR 45 DAYS
FROM DATE OF ORIGINAL SALE ONLY
F. NO REPRESENTATIONS ADDITIONAL WARRANTIES, DISCLAIMER
The selling Service Center makes no warranty on his own on any item warranted by New PECO, Inc. unless he
delivers to purchaser a separate written warranty certificate specifically warranting the item. The dealer has no
authority to make any representation or promise on behalf of PECO or to modify the terms of this warranty in
any way.
The warranty covers only defective material and workmanship. It does not cover depreciation or damage
caused by normal wear, accident, improper use or abuse of products. The cost of normal maintenance and
normal replacement of service items such as belts, cutting blades, hoses, etc., which are not defective shall be
paid for by the purchaser.
All obligations of New PECO, Inc. under this warranty shall be terminated if products are altered or modified in
ways not approved by New PECO, Inc.
Neither New PECO, Inc. nor any company affiliated with it makes any warranties, representations or promises
as to the quality of performance of its products other than those set forth herein. Except as described above,
New PECO, Inc. makes no other warranties AND SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED
WARRANTIES OF FITNESS AND MERCHANTABILITY.
1. NO SERVICE CENTER WARRANTY
D. UNAPPROVED ALTERATION OR MODIFICATION
3. COMMERCIAL USE: Products put to personal use around a single household or residence is considered
'Residential'; Products put to any business use (agricultural, commercial, or industrial) or used at multiple
locations is considered 'Commercial.' Products designated as 'Commercial' are warrantied for 12 months
PECO LIMITED WARRANTY FOR NEW PRODUCTS
PECO extends the following warranties to the original purchaser of each new PECO consumer product subject
to the following limitations.
A. WHAT IS UNDER WARRANTY?
2. PARTS REPLACED DURING WARRANTY: Any new PECO part which is furnished in performance of
this warranty and is defective in material or workmanship as delivered to the purchaser will be repaired or
replaced, before the expiration of the original warranty period, whichever is later.
1. PRODUCT WARRANTY: Any part of any consumer product, which is defective in material or
workmanship as delivered to the purchaser will be repaired or replaced, as PECO elects, without charge for
parts or labor, if the defect appears within 12 months from the date of delivery of the product to the original
purchaser. ALL DEFECTIVE PARTS MUST BE RETURNED TO PECO FOR INSPECTION TO DETERMINE
VALIDITY OF WARRANTY CLAIMS. Freight and mailing will be borne by the customer.
from the date of delivery of the product to the original purchaser when used for in commercial applications.
Products designated as 'Residential' are warrantied for 90 days from the date of delivery of the product to the
original purchaser when in commercial applications.
B. SECURING WARRANTY ADJUSTMENTS
Call PECO for Return Authorization. Damaged or broken parts other than engines or batteries, must be
returned to New PECO, Inc. at 10 Walden Drive, Arden, NC 28704 before any warranty adjustment can be
authorized. At the time of requesting warranty adjustment, the purchaser must present evidence of the date of
delivery of the product. The purchaser shall pay any charge for the product to and from Arden, NC.
C. ITEMS NOT COVERED BY PECO WARRANTY
Engines and batteries attached to PECO products are covered under a separate warranty by the respective
manufacturer.
2017 (v1.0)

5
We are pleased to have you as a PECO customer. Your
collection system has been designed to give you a low
maintenance, simple, and effective way to collect the
grass clippings from your mower. This manual is
provided to give you the necessary instructions to
properly mount and operate the collection system on
your mower. Please read this manual thoroughly.
Understand what each control is for and how to use it.
Observe all safety decal precautions on the machine and
noted throughout the manual.
1-1 Introduction
NOTE: all references made to right, left, front, rear, top
or bottom are as viewed from the normal operator’s
position on the mower.
The grass collection system is designed for turf
maintenance where there is a need to collect the grass
clippings as the mower cuts the turf. It is also used for
picking up leaves and in pre-season and post-season
clean-up. The blower, mounted on the right side of the
unit, uses a belt and gearbox system from the engine
PTO shaft. Drive train protection comes through belt
slippage. The blower draws grass clippings from the
discharge area of the cutter deck back to the 12 cubic
foot aluminum box at the rear portion of the mower
frame. The operator can engage the blower with a push
of the over-center linkage on the right side of the unit.
Once the container is full, the operator can easily push
and raise the dump handle, opening the rear door on the
container and pivoting the box to the ground. Once
empty, the operator can easily lower and pull the dump
handle, pivoting the box back into position and closing
the door.
1-2 Description
Section I - INTRODUCTION AND DESCRIPTION
—Requires installation of included weight kit (A1213) for safe operation!
Contact your Cub Cadet dealer to order weight kit 59A30037150 (A1149).
—Requires installation of additional weight kit 59A30037150 (A1149) for
safe operation! SZ models only require the included weight kit (A1213).
All Tank LZ Models:
All Tank SZ Models:
Important! - Before Installing Collection System, Read Below:
—Requires installation of included weight kit
for weight kit installation instructions.
(A1213) along with the additional weight
kit 59A30037150 (A1149).
—Refer to Section 2-21 & 2-22 in this manual
Tank LZ Models w/ 48” Deck:
Installation Instructions:

6
2-1 Preparation Of Mower
NOTE: The mower deck PTO belt must be removed
from the electric clutch before continuing with the
installation. Refer to your Cub Cadet mower owner’s
manual for instructions on PTO belt removal.
From the underside of the engine, disconnect the wiring
harness attached to the electric clutch. Remove the bolt
and electric clutch from the mower. Remove the D-drive
spacer using an arbor press or equivalent. On removal,
adjacent bearing OUTER race must be supported or
bearing damage may occur. Refer to Figure 2-1a.
Once the Engine Pulley Bushing P#(S0210) is installed,
reattach the clutch assembly to the mower and then
review Figure 2-1c.
The engine pulley assembly must be installed using an
arbor press or equivalent. During installation, opposite
bearing inner race must be supported or bearing
damage may occur. Refer to Figure 2-1c.
To assemble and fasten the Engine Pulley, align Pulley
hole to the Engine Pulley Bushing and fasten using (1)
Clamp Washer P#(K0278), (1) 7/16”-20 x 3-3/4” HHCS
P#(K0350) and (1) 7/16” helical spring lock washer
P#(K0140). Torque the bolt to 55ft./lbs. Refer to
Figure 2-1d for reference.
NOTE: Replace the mower deck PTO belt removed at
the beginning of this section.
Remove the rear bumper and hardware from the mower
as shown in Figure 2-1e.
Section II - INSTALLATION FOR USE
PRESS
Remove
Rear Bumper
Figure 2-1a
Figure 2-1e
PRESS
Engine Pulley Bushing Installation
Figure 2-1c
Electric Clutch
Figure 2-1d
Engine Pulley Assembled Into Electric Clutch
Engine Pulley
Bushing
Hex Bolt
Lock Washer
Pulley
Bushing
Number
Located
Here
Figure 2-1c
Clamp Washer
Pulley

7
2-3 Lower Main Frame Installation
Secure the lower main frame P#(B0821) to the left rear frame of the
mower using (4) 3/8”-16 x 1” carriage bolts P#(K1182) and (4) 3/8”-
16 nylon flange locknuts P#(K2038). Leave the hardware loose.
Secure the lower main frame to the PTO mount plate assembly
using (2) 3/8”-16 x 1” carriage bolts P#(K1182) and (2) 3/8”-16 nylon
flange locknuts P#(K2038). Align lower main frame and PTO mount
assembly to be parallel and level to the mower’s chassis, then
tighten all hardware from Sections 2-2 and 2-3 at this time. Refer to
Figure 2-3.
Secure the PTO mount plate assembly P#(A1108) to the chassis of
the mower using (4) 3/8”-16 x 1” carriage bolts P#(K1182) and (4)
3/8-16 nylon flange locknuts P#(K2038). Leave the hardware loose
until the lower mount assembly is installed in the next section. Refer
to Figure 2-2.
2-2 PTO Mount Plate Assembly Installation
(4) 3/8”-16 x 1”
Carriage Bolts
(4) 3/8”-16
Locknuts
Figure 2-2
PTO Mount
Plate Assembly
Figure 2-3
PTO Mount
Plate Assembly
Lower Main
Frame
(4) 3/8”-16 x 1”
Carriage Bolts
(4) 3/8”-16
Locknuts
(2) 3/8”-16
Locknuts
(2) 3/8”-16 x 1”
Carriage Bolts
Mower’s
Chassis

8
Insert the PTO assembly P#(A1821) into the slots on the
PTO mount plate assembly. Secure the PTO assembly
with (1) mount pin P#(B0274) and (1) hair pin clip
P#(K0086).
Remove the belt guard P#(B0679) and hardware in
preparation for the belt installation. Refer to Figure 2-4a.
2-4 PTO Assembly Installation
Attach the PTO handle P#(A1142) to the PTO assembly
using (3) 1/4”-20 x 3/4” HHCS P#(K1222) and (3) 1/4”-
20 nylon flange locknuts P#(K2014). Attach the handle
grip P#(J0522) to the PTO handle. Refer to Figure 2-4b.
NOTE: The PTO Handle can be adjusted after
performing Step 2-6 to achieve proper belt adjustment.
To adjust the handle, remove (3) 1/4”-20 x 3/4” HHCS
P#(K1222) and (3) 1/4”-20 nylon flange locknuts
P#(K2014), rotate handle until positioned in the desired
location (while aligning holes) and reattach. The bolts
should be kept approximately 120 degrees apart to
ensure proper fastening.
PTO Handle
Handle Grip
Figure 2-4b
(3) 1/4”-20 x 3/4” HHCS
(3) 1/4”-20 Nylon
Flange Locknut
PTO
Mount Pin
Hair Pin
Clip
Belt Guard
PTO Assembly
Figure 2-4a

9
Loosen the (4) bolts P#(K1191), (2) on each side, that
secure the gear box assembly to the PTO assembly
P#(A1803) (Figure 2-5a and 2-5b).
Loosen the adjustment bolt P#(K0348) until the gear box
assembly is at its far left adjustment (the gear box is
moved toward the mower’s engine pulley). Refer to
Figure 2-5c.
2-5 Drive Belt Installation and
Adjustment
Connect the drive belt A59K P#(M0254) from the engine
pulley to the lower gear box pulley (Figure 2-5d).
To tension the drive belt, turn the adjustment bolt
clockwise (Figure 2-5e) until there is 1” of deflection, with
10-11 lbs. of pressure, at the center of the belt between
the engine pulley and the gear box pulley.
Once the correct tension of the belt is achieved, tighten
the (4) bolts that secure the gear box assembly. Refer to
Figures 2-5f and 2-5g. Replace the belt guard and
hardware that was removed in Section 2-4.
Loosen Bolts
Figure 2-5a
Figure 2-5b
Loosen Bolts
Figure 2-5c
Loosen The
Adjustment Bolt
Slide Gear Box
Towards The
Engine Pulley
Connect Belt
To Both Pulleys
Figure 2-5d
Figure 2-5e
Figure 2-5f
Figure 2-5g
Tighten Bolts
Tighten Bolts
Tighten The Adjustment
Bolt To Tension The Belt

10
2-6 Cam Assembly Adjustment
The cam assembly P#(A0422), which controls the A30K
blower belt P#(M0250) tension, comes from the factory
pre-adjusted. If the belt is too tight or becomes too loose,
remove the hair pin clip P#(K0099) from the belt tension
rod P#(K0326) and pull the “L” end of the rod out of it’s
hole in the cam assembly. The tension rod may then be
screwed out to tighten the belt or screwed in to loosen
the belt. Replace the “L” end into the top hole in the cam
and replace the hair pin clip. Adjust the cam stop bolt
P#(K1159) to allow the cam to rotate slightly over center
when the blower is disengaged (Figure 2-6).
Thread (1) 5/16”-18 jam nut P#(K0120) onto each end of
(2) 5/16”-18 x 2-1/2” HHCS P#(K0125) as shown in
Figure 2-7a.
Now partially thread (1) bolt into each of the two
threaded bosses located on the blower housing. Place
blower cone so the two tabs line up with the bolts and
tighten completely as shown in Figure 2-7b.
2-7 Blower Cone Installation
Once the (2) bolts are tight, tighten the jam nuts against
the threaded boss as shown in Figure 2-7c.
Refer to Figure 2-7d for proper blower cone installation
reference.
Cam Assembly
Figure 2-6
Tension Rod
Cam Stop
Hair Pin Clip
Figure 2-7a
Thread (1) Jam Nut
Onto Each 5/16”-18 Bolt
Figure 2-7b
Threaded
Boss
Blower
Cone Tab
Figure 2-7c (1st) Tighten
Bolt
(2nd) Tighten
Jam Nut
Figure 2-7d
Blower
Cone

11
2-8 Safety Interlock Harness
Installation
To obtain access to the mower’s interlock switch, lift the
operator’s seat on the mower as shown in Figure 2-8a.
Refer to your Cub Cadet operator’s manual for
reference.
Start by routing the safety interlock harness from the
PTO assembly, underneath the right fuel tank and inside
the ROPS tube. Secure the harness where indicated in
Figure 2-8c, using the zip-ties P#(J0245). Ideally, the
harness should be clear of any moving parts or
mechanisms. The harness should not come in contact or
be in close proximity with any heat sources. Use as
many zip-ties as needed to ensure the harness is tightly
secured to the mower, and free from any pinch points or
potential areas that may cause damage to the harness.
Locate the collection system’s safety interlock harness
P#(P0208). It is connected to the PTO assembly
P#(A1821) shown in Figure 2-8b. This harness will need
to be connected to the mower safety interlock switch,
and then secured to the mower frame with the zip ties
P#(J0245) included in the mount kit hardware bag. Cut
the zip-ties retaining the safety interlock harness to the
PTO assembly, in preparation for routing the harness to
it’s proper location.
Disconnect the mower’s safety interlock switch (See
mower’s Owner’s Manual for location). Plug the male
end of the collection system’s wiring harness into the
port where the mower’s safety interlock switch was
removed. Then, plug the mower’s safety interlock switch
into the female end of the collection system’s wiring
harness. Refer to Figure 2-8c.
Use Figure 2-8c and 2-8d for clarification on the location
of the mower’s existing safety interlock switch and where
the collection system’s safety interlock harness should
be connected. A wiring schematic for the P#(P0208)
safety interlock harness is located on page 25 for
reference.
Figure 2-8b
Collection
System’s
Safety Interlock
Harness
Figure 2-8a
Lift Operator’s
Seat To Access
Safety Interlock
Switch
Safety Interlock
Switch Location
Under Seat
Figure 2-8c
Fuel
Tank
ROPS
Start Harness Route
Under Fuel Tank
& Inside ROPS
ROPS
Safety Interlock
Switch Location
P#(P0208)
Safety Interlock
Harness
Connect
Mower’s
Interlock
Switch Here
Zip
Tie
Zip
Tie
Safety Interlock
Mounting Bracket
P#(P0208)
Safety Interlock
Harness
Figure 2-8d
Existing Safety
Interlock
Mounting Bracket
And Plunger
Unplug Existing
Safety Interlock
Switch & Replace
With P#(P0208)

12
Secure (1) lower main frame leg P#(B0822) to the lower
main frame bracket using (2) 3/8”-16 x 1” carriage bolts
P#(K1182) and (2) 3/8”-16 nylon flange locknuts
P#(K2038). Secure (1) lower main frame leg P#(B0822)
to the PTO mount plate assembly using (2) 3/8”-16 x 1”
carriage bolts P#(K1182) and (2) 3/8”-16 nylon flange
locknuts P#(K2038). Refer to Figure 2-9.
2-9 Lower Main Frame Leg Installation
Lift the main frame assembly P#(A1192) into position and
secure to the lower main frame legs using (4) 3/8”-16 x 1”
carriage bolts P#(K1182) and (4) 3/8”-16 nylon flange
locknuts P#(K2038). Refer to Figure 2-9.
2-10 Main Frame Assembly Installation
Figure 2-9 Main Frame
Assembly
Lower Main
Frame Leg
(2) 3/8”-16 x 1”
Carriage Bolts
(2) 3/8”-16 x 1”
Carriage Bolts
(2) 3/8”-16 x 1”
Carriage Bolts
(2) 3/8”-16 x 1”
Carriage Bolts
Lower Main
Frame Leg
(4) 3/8”-16 x 1”
Carriage Bolts
(2) 3/8”-16
Locknuts
(2) 3/8”-16
Locknuts
(4) 3/8”-16
Locknuts
(2) 3/8”-16
Locknuts
(2) 3/8”-16
Locknuts

13
2-11 Lift Handle Installation
Slide the lift handle through the slot on the handle mount
bracket. Insert the lift handle into the box frame as
shown in Figure 2-11b, and secure using (1) 3/8”-16
flange nut P#(K1215) on the inside of the container as
shown in Figure 2-11c. Now test the movement of the
handle. It should have full-range of movement in the slot.
If the handle does not have full-range of movement,
adjust the 3/8”-16 flange nut from step 2-11a. Once
achieved, tighten the fasteners.
NOTE: Before continuing the lift handle installation,
have someone assist you in turning the grass container
upside down. Insert (1) 3/8”-16 x 2” HHCS P#(K1208)
into the lift handle P#(A0273), and secure with (1) 3/8”-
16 flange nut P#(K1215). Thread the flange nut onto the
bolt upside down, as shown in Figure 2-11a. Do not
tighten the nut fully at this time.
Fasten the ball joint P#(K1442) to the end of the latch
rod P#(A0620). Tighten the ball joint to approximately
half way down the threads on the latch rod. Attach the
ball joint to the latch hook as shown in Figure 2-11d,
using (1) 5/16”-24 hex nut P#(K1444) and (1) 5/16” lock
washer P#(K0043).
Attach the other end of the latch rod to the lift handle, as
shown in Figure 2-11e. Attach one end of the spring
P#(J0176) to the lift handle and the other end of the
spring to the handle mount bracket as shown in Figure
2-11f. Adjust the ball joint up or down on the latch rod
threads until the latch hook closes completely. After
adjusting the latch hook, secure the latch rod to the lift
handle using (1) cotter pin P#(K0094).
Insert (1) 3/8”-16 x 2”
HHCS Into The Lift Handle
Secure With
(1) 3/8”-16 Flange Nut
Figure 2-11a
Slide Lift Handle Through
Handle Mount Bracket And
Fasten To Box Frame
Use (1) 3/8”-16 Flange Nut
On The Inside Of The
Grass Container
Figure 2-11b
Figure 2-11c
Ball Joint
Latch Rod
Latch Hook (1) 5/16”-24 Hex Nut
(1) 5/16” Lock Washer
Figure 2-11d
Attach Latch Rod
To Lift handle
Secure With
(1) Cotter Pin
Attach Spring To
Lift Handle And To
Handle Mount Bracket
Figure 2-11e
Figure 2-11f

14
NOTE: It is recommended that (3) people assist in
mounting the container. With three people available, two
can lower the container onto the frame while the third
person inserts the pivot pins P#(K0172) through the
holes. Insert the pins from the outside to the inside.
Secure with (1) 5/8” washer P#(K0058) and (1) 5/32” x
2-5/8” hair pin clip P#(K0088) per pivot pin (Figure 2-
12b). Reattach the bottom ends of the door opening
linkages to the main frame by using (1) Rue-Ring cotter
pin P#(K1437) per side. To test the functionality of the
dump mechanism, pull the lift handle away from the unit,
and lift upward. The door of the container should open
and the box should pivot clockwise towards the ground.
2-12 Aluminum Grass Container
Installation
The linkage may be adjusted in two places, at the
adjusting screw P#(K1435) and the latch assembly
items. See page 21 for visual clarification. To change the
door closure tightness, thread the adjusting screw
(Figure 2-13) in or out. To adjust the latch, change the
length of the latch rod by threading the latch adjusting
ball joint in or out. The latch hook pivot should be in the
middle of the slot in the latch hook pivot plate. Slide the
pivot back or forth and then re-tighten.
2-13 Dump Mechanism Adjustment
Rue-Ring
Cotter Pin
Adjustment
Screw
Figure 2-13
Figure 2-12b
Washer
Hair Pin
Clip
Pivot
Pin
Attach
Here
Figure 2-12a Box Assembly

15
Lift the grass deflector on the mower deck. Secure the
deck plate assembly P#(A1960) to the discharge chute
of the mower deck using (2) 5/16”-18 x 1” carriage bolts
P#(K1144) and (2) 5/16”-18 nylon flange locknuts
P#(K2516). Refer to Figure 2-14a.
2-14 Boot To Mower Deck Installation
NOTE: The boot kit assembly is designed to fit the 48”,
54” and 60” deck. To ensure a snug fit between the boot
and the mower deck, follow the instructions in this step
thoroughly, and remove and tighten all hardware in the
sequence specified.
Secure the boot plate assembly P#(A1961) to the
aluminum boot P#(E0026) using (2) 3/8”-16 x 1” carriage
bolts P#(K1182) and (2) 3/8”-16 nylon flange locknuts
P#(K2038). Insert the carriage bolts from the inside of
the boot so the threads are on the outside of the boot
(Figure 2-14a). This will prevent grass clippings from
collecting on the bolt threads.
Align the mount holes in the boot plate assembly with
the mounting holes in the deck plate assembly and insert
(1) boot rod P#(B0288) into the mounting holes. Secure
the boot rod with (1) hair pin clip P#(K0099). Refer to
Figure 2-14b.
(2) 5/16”-18 x 1”
Carriage Bolts
(2) 5/16”-18 Locknuts
Deck Plate
Assembly
Discharge
Chute
Figure 2-14a
Figure 2-14b
Grass
Deflector
Boot Plate
Assembly
Aluminum
Boot
(2) 3/8”-16 x 1”
Carriage Bolts
(2) 3/8”-16 Locknuts
Insert Boot Rod
From This End
Hair Pin
Clip

16
Figure 2-18
Inlet
Hose
Clamps
Hose
Clamps
Blower
Cone
Blower
Outlet
Boot
Lower
Hose
Upper
Hose
The hoses in steps 2-16 and 2-17 must be cut to fit your
machine. Follow steps 2-16 and 2-17. Do not cut the
hoses until you have tried to fit them on your machine.
allow for the opening and closing of the collection
system, PTO blower housing engagement, as well as
allowing ample clamping surface between each
component.
2-16 Upper Hose Installation
Fasten the inlet to the plastic top by sliding the inlet from
2-15 Length Of Hose Adjustment
Remember that the hoses need to be long enough to
the inside of the top to the outside and lock into place.
Slide a pre-assembled hose clamp P#(J0060) onto both
ends of the 6” upper hose (Figure 2-18). Then slide one
end of the 6” hose onto the inlet. Make sure there is
assembly inlet. Tighten the hose clamps.
6” hose onto the outlet of the blower assembly. See
(Figure 2-18) for details. Make sure both ends of the
about a two-inch overlap between the hose end and the
container inlet. Proceed to slide the opposite end of the
hose are clearly attached to the inlet and the blower
Slide a pre-assembled hose clamp P#(J0080) over both
ends of the lower hose. Then proceed to slide the lower
hose onto the blower cone. Tighten the hose clamp. The
2-18 Lower Hose To Boot Installation
Take the unattached end of the lower hose and slide it
2-17 Lower Hose To Blower Cone
Installation
assembly should look like Figure 2-18.
(away from yourself) approximately 1” to aid in retaining
boot to mower deck.
over the circular end of the boot. Use the lower hose
clamp to secure the hose to the boot (Figure 2-18). Tip:
Before securing clamp rotate hose counter-clockwise

17
3
2
4
5
1
3
5
6
7
8
9
10
12
13
11
14
9Taper-Lock Bushing
Enlarged View
Tips on removing impeller blade;
1 - Try carefully hitting the base of the impeller blade
(#1), between each vein (#12), with a rubber mallet to
loosen the taper-lock bushing hold.
To Replace: First, place the impeller blade (#1) over the
drive shaft (#13). Next, slide the taper-lock bushing (#9)
on to the drive shaft and into the impeller blade, aligning
the non-threaded holes (#14) of the taper-lock bushing
to the threaded holes of the impeller blade. Then, fasten
by using two 1/4”-20 x 1” HHCS (#10), one spacer
bushing (#8) one taper lock bushing washer (#7), and
one 3/8”-16 x 1-1/2” HHCS (#6). Torque all bolts to the
specifications located in the chart towards the back of
this manual. Last, rotate the impeller blade to ensure
that the blade is clear of contact on all sides of the
blower housing.
2 - Spray break-free lubricant into the surrounding areas
of the taper-lock bushing (#9) and repeat Tip 1.
To Remove: First, remove one 3/8”-16 x 1-1/2” HHCS
P#(K1211) (#6), one taper-lock bushing washer
P#(K0278) (#7) and one spacer bushing P#(S3242) (#8)
from the taper-lock bushing (#9). See Figure 2-20. Next,
remove two 1/4”-20 x 1” HHCS (#10) and place them
into the threaded holes (#11) of the taper-lock bushing
P#(S4302). Last, gradually thread each bolt evenly into
the taper-lock bushing, forcing the blade to break-away
from the taper-lock bushing.
2-19 Impeller Blade
Removal/Replacement
To gain impeller blade (#1) access, first remove the
blower cone (#2) from the blower housing, located on
the PTO assembly P#(A1821), by removing two blower
cone bolts and nuts (#3). Next, remove the blower
housing front (#4) by removing seven bolts and nuts (#5)
around the outer housing edge. Refer to Figure 2-19.
Figure 2-19

18
2-20 Included Weight Kit Installation
Installation Instructions For All Tank SZ Models:
— Slide (1) weight bar (D) per side into position from above. Each weight bar (D) should be positioned with longer
— Slide weight clamp (C) into position as shown in Figure 2-20b. Fasten weight clamp (C) loosely with
— Tighten mower’s steering rack bolts (B) to secure weight bars (D) with weight clamp (C).
— Remove the front caster guard (A).
— Remove (2) bolts (B) from mower’s steering rack.
mowers’s steering rack bolts (B).
— Refer to Figure 2-20a & 2-20b.
length vertical.
— Replace mower’s front caster guard (A).
— Remove (2) carriage bolts (R) from backside of mower’s front caster area. Keep existing nuts (B) and replace
— Tighten bolts (C) to secure weight bars (F) with weight clamp (E).
— Slide weight clamp (E) into position over loosened bolts as shown in Figure 2-21b.
carriage bolts with (2) 3/8”-16 x 1-1/4” hex bolts (C) P#(K1192) and (2) flat washers (D) P#(K0047). Loosely tighten
— Slide (1) weight bar (F) per side into position from above. Each weight bar (D) should be positioned with longer
length vertical.
bolts with existing nuts (B). See Figure 2-21c for carriage bolt removal locations circled (R) .
Installation Instructions For Tank LZ Models w/ 48” Decks:
— Refer to Figure 2-20c & 2-20d.
— Remove mower’s front caster guard (A).
— Replace the mower’s front caster guard (A).
Please Note: The images below may not fully
represent your mower as some parts have been
removed/hidden for visual clarity during installation.
Figure 2-20a
Figure 2-20a
A
C
D
Figure 2-20c Figure 2-20d
A
EB
B
R
R
F
B
B
D
F
C
DC
D

19
Installation Instructions For All Tank LZ Models:
2-21 Additional Weight Kit Installation
Installing the additional weight kit 59A30037150 (A1149)
is mandatory for safe operation of the collection system.
SZ models only require the included weight kit (A1213).
Completely thread (2) 3/8”-16 flange nuts P#(K1215)
onto (1) 3/8”-16 U-bolt P#(K0407). Repeat process again
to create two sets. Secure each U-Bolt, w/ attached
flange nuts, to the weight bracket P#(B0703) using (2)
3/8”-16 nylon flange locknuts P#(K2038) as shown in
Figure 2-21a.
Remove the mower’s pulley access cover shown in
Figure 2-21b.
Insert the weight bracket assembly into the recess as
shown in Figure 2-21c. Align the weight bracket’s
mounting holes to the mower’s frame and secure using
(2) 1/4”-20 x 3/4” HHCS P#(K1222) and (2) 1/4”-20
nylon flange locknuts P#(K2014). Insert the bolts from
the bottom of the weight bracket so that the nuts fasten
to the top of the bracket as shown in to Figure 2-21c.
(2) U-Bolts
w/ Flange Nuts
Weight
Bracket
(2) 3/8”-16 Nylon
Flange Locknuts
per U-Bolt
Remove Pulley
Access Cover
Figure 2-21b
Figure 2-21a
One at a time, add (1) large weight bar P#(B0704) to the
weight bracket, then (2) small weight bars P#(B0741).
Refer to Figure 2-21d.
Add the remaining (2) large weight bars P#(B0704) to
the weight bracket. Secure the weights to the weight
bracket with (1) weight strap P#(B0719) and (2) 1/4”-20
self-tapping screws P#(K0353). Refer to Figure 2-21e.
Replace mower’s pulley access cover when completed.
Figure 2-21c
(2) 1/4”-20 x 1”
HHCS
(2) 1/4”-20 Nylon
Flange Lock Nuts
Figure 2-21d
(2) Small
Weight Bars
(1) Large
Weight Bar
Weight
Strap
1/4”-20
Self-Tapping
Screw
Figure 2-21e
(2) Large
Weight Bars

20
A1933
ALUMINUM GRASS
CONTAINER
EXPLODED VIEW
