Cub Cadet CC-4222V2 User manual

READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS BEFORE USING THIS EQUIPMENT
CC-4222V2
22 cu ft LA WN SWEEPER
U.S. Patent No. 7,610,646
6004280 - REV B 09/18

Read and understand all safety rules and operating instructions before using this
tractor attachment.
Follow all safety rules and operating instructions provided by your tractor's
manufacturer when using attachment.
Never allow children or untrained persons to operate tractor or attachment.
Reduce tractor speed to slowest setting when towing or operating on slopes.
Operate up and down slopes, never across the face of slopes.
Do not carry passengers on tractor or attachment.
Avoid sudden turns or maneuvers.
Use caution when backing up to prevent damaging attachment.
Do not tow attachment on public roadways.
Do not remove warning decals from product.
Check product for worn, loose, or damaged parts before each use. If any damage
is present, repair the product before using.
Check product for loose or missing fasteners before each use. Tighten or replace
fasteners as needed before using.
Do not fasten rope to any part of your body or clothing.
Do not hold rope while tractor and Lawn Sweeper are in motion.
Do not use Lawn Sweeper near fire or smoldering debris.
Always fasten rope to tractor to avoid contact with wheels and brushes.
Always empty hopper before storing to avoid spontaneous combustion of contents.
Do not exceed tractor speed of 6 miles per hour when towing or operating Lawn
Sweeper.
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
1
Safety Rules

If this product fails due to a defect in material or workmanship within THREE YEARS from the
date of purchase, we will at our option, only with receipt of purchase, repair or replace it free of
charge. This warranty excludes tires, wheels, brushes and bag, which are expendable and
become worn during normal use.
This warranty does not cover:
Repairs necessary because of operator abuse or negligence. •
Equipment used for commercial or rental purposes. •
Paint that is worn or faded due to normal use or exposure. •
To arrange for product repair visit ohiosteel.com/customer-support and fill out the warranty
repair form. You can also call 1-800-652-2321, ext. 212 to speak to our Customer Service Team
This warranty gives you specific legal rights, and you may also have other rights which may vary
from state to state. This warranty applies only while this product is in use in the United States.
IF YOU ARE MISSING PARTS DO NOT RETURN TO STORE
Email [email protected] or call 1-800-652-2321, ext. 212
Before you call,please email our customer service team at
[email protected] with the following :
A description of the issue you are having 1.
Photos of the issue that include an overall view and detailed view from 2.
multiple angles
If applicable, a short video showing the issue 3.
Replacement Parts:
You can place your parts order online at ohiosteel.com/partsstore
You can also reach our Customer Service Department at 1-800-652-2321, ext. 212 •
If you are ordering replacement part(s) for your product, please note that some parts are •
only available as a repair kit.
AttachReceipt Here:
2
Warranty

38 (x1)
41 (x2)
44 (x1)
43 (x1)
37 (x2)
10 (x4)
12 & 49 (x7)
48 (x2)
50 (x1)
40 (x2)
39 (x2)
(x1)
45 (x2)
46 (x2)
42 (x1)
6 (x2)
7 (x4)
8 (x4)
9 (x4)
11 (x1)
13 (x1)
14 (x1)
15 (x1)
47 (x2)
52 (x1)
TOOLS REQUIRED FOR ASSEMBLY:
9/16" Open End Box Wrench •
NOTE: Hardware shown to scale
3
Carton Contents

10 96
8
7
13
14
13
DETAIL Q
SCALE 1 : 2
34
Attach Hitch Mount Tubes (6) to Sweeper Assembly and tighten hardware.
Attach Hitch Cross Tube Assembly (13) by depressing snap buttons and
insterting into Hitch Mount Tubes (34).
Install Hitch Assembly (14) using tethered quick release pins in desired
position on Hitch Cross Tube Assembly (13).
DO NOT OVERTIGHTEN.
4
Assembly Instructions
1
3
2

Shown Installed:
Insert Bottom Frame Tubes (39) into Center Frame Tube (41) and snap into
position. (Note that snap buttons are oriented up)
15
R
DETAIL R
SCALE 1 : 5
39
39
41
DETAIL S
SCALE 1 : 2
Snap Button
UP
51
First remove factory hand tightened nuts from studs. Use nuts to attach
Height Adjustment Handle (15) Using a 9/16" Open End Box Wrench.
5
Assembly Instructions
4
5

37
41
M
46
49
37
41
40
40
DETAIL D
SCALE 1 : 4
Snap Button
DOWN
51
Snap Button
UP
Frame into Hopper
39
39
DETAIL M
SCALE 1 : 6
46 49
Unroll and flatten hopper bag (38) from shipping state. Then, slide
Hopper Stop Bar (42) into pocket of Hopper Bag as shown.
Insert Top Frame Tubes (40) into Center Frame Tube (41) and snap into position.
(Note that snap buttons (51) are oriented down)
Unroll Hopper Bag
38
44
First, place bottom frame assembly into bottom of Hopper Bag (38).
Second, Install Clevis Pins (46) through Hopper Bag (38), Hopper Stop Bar (42), and
Bottom Frame Tubes (39) then secure with Hairpins(49).
6
Assembly Instructions
6
8
7

X
44
48
37
49
42
47
37 37
49
47
40
38
40
Snap Button
Down
39
DETAIL X
SCALE 1 : 9
45
49
39
40
First, Place top frame assembly into Hopper Bag (38). Second, Install
Clevis Pins (45) through Top Frame Tubes (40) and Bottom Frame Tubes (39)
and secure with Hairpins (49).
Slide Hopper Pivot Rod (43) through Top Frame Tube (40) and Connecting Tube (37),
then through pocket of Hopper Bag (38), and then through
both Connecting Tube (37) and Top Frame Tube (40) on other side.
Secure both ends with Washer (47) and Hairpin (49).
Frame into Hopper
45
49
38
7
Assembly Instructions
9
10

38
42 41
Velcro Tab
38
DETAIL E
SCALE 1 : 2
41 42
G
DETAIL G
SCALE 1 : 4
Opening
R
DETAIL R
SCALE 1 : 1
T
DETAIL T
SCALE 1 : 1
Unscrew Thumb Screw from Tension Tube Assembly (44). Next, Hold Hopper Bag (38) open
and carefully insert Tension Tube Assembly (44) through opening in Hopper Bag and into hole
in bottom Center Frame Tube (41). Pull top Center Frame Tube over
tension tube and align holes.
Insert thumb screw that came with Tension Tube Assembly (44) through
top Center Frame Tube (41) and screw into top of Tension Tube.
Secure Hopper Bag around Top Frame Tubes with Velcro tabs.
SHOWN INSTALLED
SHOWN INSTALLED
8
Assembly Instructions
11
12

37
37
6
6
48
Do NOT fasten rope to any
part of your body or clothing.
5041
DETAIL V
SCALE 1 : 4
48
52
Insert Connecting Tubes (37) into Hitch Mount Tubes (6) and secure with
Quick-Release Pins (48). Install Hitch Pin (11) and secure with Hairpin(12).
Install handle (52) and tie Dump Rope (50) securely around exposed section
of Center Frame Tube(41).
9
Assembly Instructions
13
14

How to Sweep Lawn:
Remove large debris from lawn. 1.
Do not sweep if conditions are too wet or muddy. 2.
Attach Lawn Sweeper to tractor using supplied hitch pin. The reversable 3.
hitch allows the Lawn Sweeper to accomodate varying tractor hitch heights
by fliping over; choose the appropriate setting so that Lawn Sweeper hitch
tubes are roughly level with the ground and Bag is not touching the ground.
Attach dump rope to tractor so that it cannot contact the brushes or wheels. 4.
Start tractor engine and tow Lawn Sweeper to lawn in setting 7. 5.
Adjust brush height so that brushes extend roughly 1/2" below the tips of the 6.
grass. For best performance, always set the brushes to highest effective
setting to minimize resistance on brushes and wheels.
Engage tractor drive at its slowest speed and begin sweeping. Increase 7.
tractor speed as required to throw material to the back of the hopper bag.
DO NOT EXCEED 6 MPH.
Sweep in straight lines whenever possible and avoid sharp turns. 8.
Periodically check the sweeper while operating to ensure that wheels and 9.
brushes are rotating smoothly and that nothing is wrapped around the
brushes or brush shaft.
When filled, the hopper bag can be emptied by pulling the dump rope 10.
forward.
Before Using Lawn Sweeper:
Read all Safety Rules found on page 1. 1.
10
Operating Instructions

11
Operating Instructions
Periodic Maintenance:
Tighten fasteners as needed before each use. •
Empty hopper and thoroughly clean Lawn Sweeper after each use. •
Remove any materials that have wrapped around brushes or brush shaft •
after each use.
Lubricate wheel bearings and gears annually with a light coating of white •
lithium grease.
Offset Sweeping:
Remove both pins from drawbar. 1.
Slide drawbar on hitch cross tube to farthest holes on desired side. 2.
Re-pin both pins. 3.
Resume normal towing of sweeper. 4.
Durring opertion be mindful of wider towpath of sweeper 5.
How to Adjust Brush Height:
Place one hand on adjustment lever and use other hand to pull outward on 1.
plunger.
Move handle downwards to lower the brush height or upwards to raise the 2.
brush height.
Align the plunger with the nearest hole and release to select height setting. 3.

DETAIL W
SCALE 1 : 5
12
Operating Instructions
Storing Lawn Sweeper:
Empty hopper bag and thoroughly clean Lawn Sweeper before storing. 1.
Store Lawn Sweeper away from excessive heat to prevent damage. 2.
Brushes must not contact ground during storage to prevent damage. 3.
Remove quick-release pins to separate hopper bag from Lawn Sweeper. 4.
Carefully remove tension tube and collapse hopper bag for compact storage. 5.
Remove one quick-release pin from hitch, fold hitch onto cross hitch tube, 6.
and replace quick release pin.
4 5
6

ohiosteel.com/partsstore OHIO STEEL INDUSTRIES 1-800-652-2321
1
45
6
7
8
9
10
13
14
11
12
15 16 17
18
19
20
21
22
23
24
25
26
27
28
29
30 31
32
33
34
35
2
ITEM PART N0 DESCRIPTION QTY. ITEM PART N0 DESCRIPTION QTY.
1
6004353-Y1
SWEEPER HOUSING 1 19 6000540 WHEEL BUSHING 4
2 WHEEL WELDMENT 1 20 307011 WHEEL(BUSHING INCLUDED) 2
4 6000733-ZC 1/4" -20 X 1" CARRIAGE BOLT 8 21 6000539 DUST COVER 2
5 3000716-ZC WASHER, 1/4" SAE 4 22 6004023 PLUNGER KNOB 1
6 307034-B2 HITCH MOUNT TUBE 2 23 6004022 PLUNGER SPRING 1
7
KIT
6004344
3/8"-16 X 2" HEX BOLT 4 24 6004020-ZC PLUNGER PIN 1
8 CURVED WASHER, 3/8" USS 4 25
KIT
6000828
PINION ASSEMBLY, RIGHT 1
9 WASHER, 3/8" USS 4 26 PINION ASSEMBLY, LEFT 1
10 NYLOCK NUT, 3/8-16 UNC 4 27 BEARING ASSEMBLY 2
11 3" HITCH PIN 1 28 307124-B2 SPIRAL BRUSH TUBE 1
12 HAIRPIN 1 29 307122-ZC STEEL BRACKET 4
13 6003953-B2 HITCH CROSS TUBE ASSEMBLY 1 30 307121-ZC STEEL CLAMP 8
14 6003965-B2 HITCH ASSEMBLY 1 31 300065-ZC 1/4" -20 LOCK NUT 22
15 6003957-B2 HEIGHT ADJ. HANDLE 1 32 3000539-ZC 1/4" -20 X 1-1/4" BOLT 14
16 307241 WHEEL CAP 2 33 307321 42" SPIRAL BRUSH 2
17 300081-ZC COTTER PIN, 1/8" X 1-1/2" 2 34 6000222-ZC SNAP BUTTON 2
18 3000721-ZC WASHER, 3/4" SAE 2 35 3000618-ZB NYLOCK NUT, 3/8-16 UNC 2
13
Repair Parts

38
41
40
51
47
49
45
4243
37
48
41
38 5144
46
49
50
52
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
37 307032-B2 CONNECTING TUBE 2 45
KIT
6004344
CLEVIS PIN, 3/8" X 1/2" 2
38 6004249 HOPPER BAG 1 46 CLEVIS PIN, 1/4" X 1-1/4" 2
39
KIT
6004133-B2
BOTTOM FRAME TUBE 2 47 3/8" USS FLAT WASHER 2
40 TOP FRAME TUBE 2 48 QUICK-RELEASE PIN 2
41 CENTER FRAME TUBE 2 49 HAIRPIN 6
42 TENSION TUBE ASSEMBLY 1 50 307361 DUMP ROPE 1
43 307051-B2 HOPPER PIVOT ROD 1 51 6000208-ZC SNAP BUTTON 4
44 307061-B2 HOPPER STOP BAR 1 52 6003894 DUMP HANDLE 1
14
Repair Parts
ohiosteel.com/partstore
OHIO STEEL INDUSTRIES1-800-652-2321

[phone]
MODEL # CC-4222V2
[phone]
Designed And Tested In Columbus, Ohio
Manufactured In The U.S.A. From Domestic
And Imported Components

6004280 - REV B 09/19
CC- 4 222V2
BALAYEUSE FEUILLES/GAZON, 623 L (22 pi3)
Brevet américain no7,610,646
LIRE ET OBSERVER TOUTES LES CONSIGNES DE SÉCURITÉ
ET LES DIRECTIVES AVANT D’UTILISER CET ÉQUIPEMENT

1
Consignes de sécurité
Ce pictogramme est le symbole d’alerte de sécurité. Il sert à
prévenir l’utilisateur des risques de blessures corporelles.
Respecter tous les messages de sécurité qui suivent ce
symbole pour éviter des blessures ou la mort.
Lire et bien connaître toutes les consignes de sécurité et les directives avant d’utiliser
cette remorque pour tracteur.
Observer toutes les consignes de sécurité et les directives fournies par le fabricant du
tracteur lorsqu’on utilise cet accessoire.
Ne jamais permettre à des enfants ou à des personnes inexpérimentées de conduire le
tracteur ou d’utiliser cet accessoire.
Avant d’aborder une pente, régler le tracteur à la vitesse minimum.
Ne jamais rouler en zigzag sur une pente; monter et descendre en ligne droite.
Ne pas transporter de passagers sur le tracteur ou sur l’accessoire.
Éviter les brusques coups de volant.
Reculer avec prudence pour éviter d’endommager l’accessoire. Ne pas remorquer
l’accessoire sur la voie publique.
Ne pas enlever les autocollants d’avertissement du produit.
Avant chaque utilisation, s’assurer qu’aucune pièce n’est usée, desserrée ou
endommagée. En cas de dommages, faire réparer le produit avant de l’utiliser de
nouveau.
Avant chaque utilisation, s’assurer également qu’aucune fixation n’est desserrée ou
manquante; resserrer ou remplacer au besoin.
Ne pas attacher une partie du corps ou un vêtement avec la corde.
Ne pas tenir la corde lorsque le tracteur et la balayeuse sont en mouvement.
Ne pas utiliser la balayeuse près d’un feu ou de débris fumants.
Toujours attacher la corde au tracteur pour éviter qu’elle se prenne dans les roues ou dans
les brosses.
Toujours vider la benne avant le remisage pour éviter une combustion spontanée du
contenu.
Rouler à moins de 10 km/h pendant le remorquage ou l’utilisation de la balayeuse.

2
Garantie
NE PAS RETOURNER AU MAGASIN SI DES PIÈCES MANQUENT
Envoyez un courriel à [e-mail] ou composez le 1 800 652-2321, poste 212
Attacher le reçu ici :
Avant votre appel, veuillez fournir par courriel, au [email protected] les
renseignements suivants à notre équipe du service à la clientèle :
1. Un exposé de l’anomalie constatée
2. Des photos du défaut (vue d’ensemble et vue détaillée prise sous plusieurs angles)
3. S’il y a lieu, une brève vidéo montrant l’anomalie
Pièces de rechange :
Passez vos commandes sur Internet à ohiosteel.com/partsstore
• Ou encore, communiquez avec notre service à la clientèle au 1 800 652-2321, poste 212.
• Commande de pièce(s) de rechange : À noter que certaines pièces sont proposées
uniquement avec une trousse de réparation.
Si ce produit présente des défauts causés par des vices de matériau ou de fabrication dans
les TROIS ANS à partir de la date d’achat, nous le réparerons ou le remplacerons, à notre
discrétion, sans frais, uniquement sur présentation du reçu d’achat. Cette garantie exclut les
pneus, les roues, les brosses et le sac, qui sont des consommables soumis à l’usure lors
d’une utilisation normale.
Cette garantie ne couvre pas :
• Les réparations dues à une utilisation abusive ou à la négligence de l’utilisateur.
• L’utilisation de l’équipement à des fins commerciales ou de location.
• L’usure ou la décoloration de la peinture en raison d’une utilisation ou d’une exposition
normales.
Pour arranger une réparation du produit, visitez ohiosteel.com/customer-support et remplissez
le formulaire de réparation sous garantie. Vous pouvez également joindre notre équipe du service
à la clientèle au 1 800 652-2321, poste 212.
Cette garantie vous confère des droits juridiques précis, auxquels peuvent s’ajouter d’autres droits,
selon la province ou le territoire. Cette garantie s’applique uniquement lorsque le produit est utilisé
aux États-Unis.

38 (x1)
41 (x2)
44 (x1)
43 (x1)
37 (x2)
10 (x4)
12 & 49 (x7)
48 (x2)
50 (x1)
40 (x2)
39 (x2)
(x1)
45 (x2)
46 (x2)
42 (x1)
6 (x2)
7 (x4)
8 (x4)
9 (x4)
11 (x1)
13 (x1)
14 (x1)
15 (x1)
47 (x2)
52 (x1)
3
Carton Contents
OUTILS REQUIS POUR L’ASSEMBLAGE :
• Clé à fourche et polygonale 9/16 po
Remarque : Illustrations de la boulonnerie à l’échelle
