Cub Cadet XT3 enduro series Service manual

March 06, 2017
XT3 Adjustable Lift Links.
XT3 GS (14W-3JM-010).
XT3 GSE (14Z-3GE-010).
XT3 GSX (14WD3LE-010).
XT3 ENDURO SERIES
PURPOSE:
We have encountered trouble adjusting the leveling of the mower deck side to side on the above model series tractors
during set-up. The Service Kit 759-05084 has been developed to include adjustable lift links on each side of the mower
deck, eliminating the need of the adjustment gear located on the left deck hanger bracket.
Models Affected:
Subject:
Date:
Model Year 2015 Early Production
Serial Number
Range Affected:
CC-942
SERVICE ADVISORY
ACTION REQUIRED:
Follow the Steps on page 2 of this Advisory.
NOTE: These materials are prepared for use by trained technicians who are experienced in the service and repair of
equipment of the kind described in this publication, and are not intended for use by untrained or inexperienced
individuals. Such individuals should seek the assistance of an authorized service technician or dealer.
NOTE: Always wear eye protection while servicing equipment. Wear hearing protection when appropriate. Always work
in a well ventilated area and follow all safety precautions when dealing with combustible materials.
NOTE: Left (LH) and Right (RH) sides are determined from the operator’s position and facing in the forward direction.
Service Advisory CC-942 1 of 2
FIGURE 1
1
2
34
5
6
78
ITEM
NO. PART NUMBER QTY DESCRIPTION
1 703-10167 2 LINK:LIFT
2 711-06284 2 FRL:0.496 X 0.528”
3 712-04063 1 NUT:FLGK:5/16-18:GRF:NYLON
4 712-05046 2 NUT:HEX:1/2-13:PATCH HD
Instruction sheet included with kit.
ITEM
NO. PART NUMBER QTY DESCRIPTION
5 712-3048 2 NUT:JAM:1/2-13:GR5
6 712-3083 2 NUT: HEXLK:1/2-13:GRB:NYLON
7 714-0470 2 PIN:COT:SPLIT:1/8 X 1.25”
8 603-05259 2 LINK:LIFT:ADJ
759-05084 Service Kit Contents
FIX-AS-FAIL

SERVICE MANAGER PARTS MANAGER SALES MANAGER SERVICE TECH. SERVICE TECH.
Circulate and Initial
Warranty: Normal warranty terms apply. Indicate Service Advisory CC-942 and 703-08245B as the original failed part on
the claim. Repair time allowance is 0.6 Hrs.
GROUP CODE: Implement, Housing, Lift Mech FAIL CODE: Adjustment
WORK PERFORMED: Lift Link Hangers (Each)
Mandatory>>>When completing the warranty claim, select the drop down text shown below for the following claim fields:
1. If a customer complains of uneven cutting or has difficulty in adjusting the mower deck from side to side order the
service kit 759-05084 and install per the service kit instructions.
2. If during Dealer set-up you encounter difficulty in adjusting the mower deck from side to side order the service kit
759-05084 and install per the service kit instructions.
3. Supply the customer with the Service Kit instructions for an IPL (Illustrated Parts List) and instructions for leveling the
mower deck from side to side for future use.
4. Submit a warranty claim for parts and labor.
THIS AREA LEFT INTENTIONALLY BLANK
Service Advisory CC-942 2 of 2
