Cub Cadet Yanmar Ex32002 Datasheet

Parts List
Manual
Ex Series Compact Tractor
Cub Cadet Yanmar LLC
P.O. Box 361052
Cleveland, OH 44136-1052
PRINTED IN U.S.A.
Version 1.0
Code No: NPC-4832P110

Ex Series Ex32002
INSTRUCTIONS FOR PARTS LIST MANUAL
ENGINE SECTION - PAGES 3 THROUGH 26
TRACTOR SECTION - PAGES 27 THROUGH 181
EXAMPLE - FIGURE & REFERENCE NUMBERS

Ex Series Ex320
0
FIG. NO. GROUP NAME
1 CYLINDER BLOCK
2 GEAR HOUSING
3 OIL PAN & REAR ENGINE PLATE
4 CYLINDER HEAD & VALVE COVER
5 INTAKE MANIFOLD
6 EXHAUST MANIFOLD & MUFFLER
7 CAMSHAFT & TIMING PARTS
8 CRANKSHAFT & PISTON
9 HYDRAULIC PUMP
10 LUBRICATING PARTS
11 COOLING WATER SYSTEM
12 FUEL INJECTION PUMP
13 GOVERNOR
14 FUEL SUPPLY PARTS
15 STARTER
16 ALTERNATOR
TRACTOR SECTION STARTS ON PAGE 27
3
ENGINE SECTION INDEX

Ex Series Ex32004
NOTES:

Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
1 CY-729005-01562 BLOCK ASSY, CYLINDER 1
4 CY-124060-01050 PLUG PT1/8 1
5 CY-129001-01250 PLUG 50 1
6 CY-124160-01910 PLUG PT1/4 2
7 CY-124160-01910 PLUG PT1/4 1
8 CY-171051-01921 PLUG 1
9 CY-129150-02020 BOLT, METAL CAP 8
12 CY-129795-02412 BUSH, CAMSHAFT 1
13 CY-27241-120000 PLUG 12 2
14 CY-27241-300000 PLUG 30 6
24 CY-129001-02931 MAIN BEARING SET 4
27 CY-129150-02931 METAL, THRUST 2
30 CY-129150-01200 STUD, CYL. HEAD 14
31 CY-129001-01340 GASKET, (NON-ASB.) 1
32 CY-129150-02871 MAIN METAL US=0.25 UNDER-SIZE 4
35 CY-129150-02941 METAL,THRUST.25 (2PIE) OVER-SIZE 1
5
FIG. 1. CYLINDER BLOCK
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
1CY-729008-01500 GEAR CASE ASSY W/SEAL 1
3CY-119934-01800 SEAL, OIL 1
4CY-129008-01520 FLANGE, GEAR CASE 1
5CY-119802-01561 STUD, M8X25 3
6CY-129150-01580 STUD 8 X 30 1
7CY-124160-01751 COVER, FILLER 1
8CY-124240-01871 COVER, HO-P 1
9CY-129795-01950 PIPE, KNOCK L=18 2
10 CY-119609-32040 O-RING P16 2
11 CY-121850-51960 O-RING, F.I.PUMP 1
12 CY-129001-91841 BOLT, M8X85 3
13 CY-22190-080002 SEAL WASHER 8S 4
14 CY-22190-080002 SEAL WASHER 8S 1
15 CY-24311-000320 O-RING 1A P-32.0 1
16 CY-26106-080162 BOLT M 8X 16 PLATED 4
17 CY-26106-080162 BOLT M 8X 16 PLATED 3
18 CY-26106-080302 BOLT M 8X 30 PLATED 1
19 CY-26106-080552 BOLT M 8X 55 PLATED 10
20 CY-26306-080002 NUT 3
21 CY-129150-91400 GEAR UNIT, TACHOMETER 1
23 CY-24341-000240 O-RING 1A S-24.0 1
24 CY-26106-060162 BOLT M 6X 16 PLATED 2
6
FIG. 2. GEAR HOUSING
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
1 CY-129100-01580 PARALLEL PIN 8X16 2
2 CY-129129-01600 PLATE, REAR MOUNTING 1
3 CY-26206-100202 BOLT M10X20 6
4 CY-26206-100202 BOLT M10X20 4
5 CY-129129-01550 PAN ASSY, ENGINE OIL 1
6 CY-129129-01540 COVER ASSY, OIL PAN 1
7 CY-105425-01690 PLUG M16 1
8 CY-129150-01721 COVER, OIL PAN 1
9 CY-22190-160002 SEAL WASHER 16S 1
11 CY-26106-080122 BOLT M 8X 12 PLATED 8
12 CY-129001-91841 BOLT, M8X85 8
13 CY-129001-91910 BOLT, M8X120 4
14 CY-26106-080252 BOLT M 8X 25 PLATED 6
15 CY-26106-080502 BOLT M 8X 50 PLATED 4
16 CY-129100-01580 PARALLEL PIN 8X16 2
17 CY-729402-01650 CASE ASSY, OIL SEAL 1
19 CY-129120-01780 SEAL, OIL 1
20 CY-129486-01670 BOLT M8X30, COLLAR HD 9
7
FIG. 3. OIL PAN & REAR ENGINE PLATE
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
8
FIG. 4. CYLINDER HEAD & VALVE COVER
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
1 CY-129004-11241 SHAFT ASSY, ROCKER 1
2 CY-129004-11251 SHAFT, ROCKER ARM 1
4 CY-119802-11260 SUPPORT, ROCKER ARM 2
5 CY-119802-11270 SUPPORT, ROCKER ARM 2
6 CY-119802-11280 STUD, 8X18 3
7 CY-129150-11280 SPRING 3
8 CY-129004-11650 ARM ASSY, ROCKER 6
9 CY-129150-11230 SCREW, VALVE 6
11 CY-129150-11750 NUT M8XP1.0 6
12 CY-129150-11370 CAP, VALVE 6
13 CY-129008-11700 HEAD ASSY, CYLINDER 1
16 CY-120130-11860 GUIDE, VALVE 3
18 CY-129150-11810 GUIDE, VALVE 3
20 CY-27241-400000 PLUG 40 2
21 CY-129005-11100 VALVE, INTAKE 3
22 CY-129100-11112 VALVE, EXHAUST 3
23 CY-129795-11120 SPRING, VALVE 6
24 CY-129795-11180 RETAINER, SPRING 6
25 CY-121400-11340 SEAL, VALVE STEM 3
26 CY-124460-11340 SEAL, VALVE STEM 3
27 CY-27310-080001 COTTER 8 6
29 CY-119802-11870 PROTECTOR, NOZZLE 3
30 CY-119625-11880 SEAT, NOZZLE 3
31 CY-129004-11900 RETAINER, NOZZLE 3
32 CY-120270-54410 WASHER 3
33 CY-22351-060012 SPRING PIN 6X12 2
34 CY-26106-080252 BOLT M 8X 25 PLATED 2
35 CY-26106-080352 BOLT M 8X 35 PLATED 3
36 CY-26106-080502 BOLT M 8X 50 PLATED 6
37 CY-129055-11350 COVER ASSY, VALVE 1
38 CY-129004-03010 PLATE, BAFFLE 1
39 CY-129150-03070 BAFFLE, BREATHER 1
40 CY-119802-03110 PLATE, DIAPHRAGM 1
41 CY-119802-03121 COVER, DIAPHRAGM 1
42 CY-119802-03130 DIAPHRAGM 1
43 CY-119802-03141 SPRING, DIAPHRAGM 1
45 CY-129004-11310 GASKET, VALVE COVER 1
46 CY-22857-500100 SCREW 5X10,TAPPING 4
47 CY-22857-500100 SCREW 5X10,TAPPING 4
48 CY-124160-11360 KNOB 3
49 CY-24311-000120 O-RING 1A P 12.0 3
50 CY-129900-07900 LIFTER, ENGINE 1
51 CY-26106-080162 BOLT M 8X 16 PLATED 2
52 CY-119803-77830 HARNESS, GLOW PLUG 1
53 CY-129008-77800 PLUG, GLOW 3
54 CY-129008-77820 CONNECTOR, GLOW PLUG 1
FIG 4. CYLINDER HEAD & VALVE COVER
9
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
1 CY-129005-03080 PIPE, BREATHER 1
2 CY-129410-03990 CLAMP 22 2
3 CY-129005-12100 MANIFOLD, INTAKE 1
4 CY-129001-12110 GASKET,INT. MANIFOLD 1
5 CY-26106-080202 BOLT M 8X 20 PLATED 4
6 CY-26106-080802 BOLT M 8X 80 PLATED 1
7 CY-129486-12581 PIPE, INTAKE 1
8 CY-129150-77511 GASKET, (NON-ASB.) 1
9 CY-26106-080202 BOLT M 8X 20 PLATED 4
10
FIG. 5. INTAKE MANIFOLD
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
1 CY-129269-13100 MANIFOLD, EXHAUST 1
2 CY-129150-13110 GASKET, MANIFOLD 1
3 CY-119131-18320 BOLT M 8X 22 4
4 CY-123900-13630 BOLT 8X80 4
5 CY-129263-13220 BOLT M8X95 2
6 CY-26306-080002 NUT 2
7 CY-129004-13200 GASKET, MUFFLER 1
8 CY-129055-13521 MUFFLER 1
9 CY-26306-080002 NUT 4
11
FIG. 6. EXHAUST MANIFOLD & MUFFLER
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
1 CY-129150-14200 TAPPET 6
2 CY-129150-14400 ROD, PUSH 6
3 CY-129129-14580 CAMSHAFT ASSY 1
4 CY-129150-02450 METAL, THRUST CAM 1
6 CY-129150-14101 GEAR, CAMSHAFT 1
7 CY-22512-070140 KEY 7X 14 1
8 CY-26106-080142 BOLT 8X 14 PLATED 2
9 CY-119803-25050 SHAFT, IDLE GEAR 1
10 CY-119802-25101 GEAR ASSY, IDLE 1
13 CY-119802-25071 BUSH, IDLE GEAR 1
14 CY-26106-080402 BOLT M 8X 40 PLATED 3
15 CY-129150-25301 BOLT, INJECTION PUMP GEAR 4
16 CY-119802-25901 GEAR, PUMP 1
17 CY-129150-01881 GASKET, (NON ASB.) 1
18 CY-129150-26000 GEAR ASSY, HYD PUMP CAM 1
19 CY-129150-26050 BRACKET, HYD PUMP GEAR 1
21 CY-24105-060064 BALL BEARING 2
22 CY-158552-51151 FLANGE 1
23 CY-22217-140000 SPRING WASHER 14 1
24 CY-26776-140002 LOCK NUT M14 PLATED 1
12
FIG. 7. CAMSHAFT & TIMING PARTS
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
1 CY-129008-21000 CRANKSHAFT ASSY 1
2 CY-129100-01580 PARALLEL PIN 8X16 1
4 CY-119803-21200 GEAR, CRANKSHAFT 1
5 CY-22512-070140 KEY 7X 14 1
7 CY-22512-070140 KEY 7X 14 1
8 CY-129055-21650 V-PULLEY, CRANKSHAFT 1
9 CY-129795-21661 WASHER 1
10 CY-121850-21680 BOLT, V-PULLEY 1
11 CY-124160-21501 BOLT, FLYWHEEL 6
12 CY-129269-21590 FLYWHEEL ASSY 1
14 CY-119865-21600 GEAR, RING 1
15 CY-121820-21690 BEARING 1
16 CY-129005-22080 PISTON ASSY 3
18 CY-129005-22500 RING SET, PISTON 3
22 CY-129202-22300 PIN, PISTON 3
23 CY-22252-000260 CLIP, PISTON PIN 6
24 CY-729402-23100 ROD ASSY, CONNECTING 3
27 CY-129100-23910 BUSH, PISTON PIN 3
28 CY-121550-23200 BOLT, CONNECTING ROD 6
29 CY-129150-23601 BEARING SET, CON-ROD 3
31 CY-129150-23611 BEARING SET, CON-ROD US=0.25 3
33 CY-129005-22900 PISTON W/RING OS=.25 3
35 CY-129005-22950 RING SET OS=0.25 3
13
FIG. 8. CRANKSHAFT & PISTON
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
1 CY-124240-01883 GASKET, (NON-ASB.) 2
2 CY-178070-16000 PUMP, HYDRAULIC 1
4 CY-178070-10401 SQUARE RING 1
13 CY-194521-41570 PIN 11X7 2
15 CY-22252-000320 CIRCLIP 32 1
16 CY-24421-153207 SEAL TC15 32 07, OIL 1
17 CY-26016-080352 BOLT M 8X 35 4
18 CY-178070-44000 PUMP, HYDRAULIC 1
20 CY-178070-10401 SQUARE RING 1
26 CY-194521-41570 PIN 11X7 2
31 CY-22252-000320 CIRCLIP 32 1
32 CY-24421-153207 SEAL TC15 32 07, OIL 1
33 CY-26016-080352 BOLT M 8X 35 4
34 CY-26106-080802 BOLT M 8X 80 PLATED 2
35 CY-26106-080952 BOLT M 8X 95 PLATED 2
36 CY-26216-080222 STUD M 8X 22 PLATED 2
37 CY-26216-080402 STUD M 8X 40 PLATED 1
38 CY-26306-080002 NUT 4
14
FIG. 9. HYDRAULIC PUMP
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
1 CY-129001-32001 PUMP ASSY, ENGINE OIL 1
14 CY-129150-32020 GASKET, ENGINE OIL PUMP 1
15 CY-26450-060252 BOLT M 6X 25 4
16 CY-121520-34810 TUBE, DIPSTICK 1
17 CY-119265-34830 DIPSTICK, ENGINE OIL 1
18 CY-129150-35042 GASKET, (NON-ASB.) 1
19 CY-129129-35090 PICK-UP ASSY, ENGINE OIL 1
20 CY-129129-35010 INLET 1
21 CY-129129-35080 PIPE, ENGINE OIL PICK-UP 1
22 CY-26106-080122 BOLT M 8X 12 PLATED 1
23 CY-26106-080352 BOLT M 8X 35 PLATED 2
24 CY-119802-35100 BRACKET ASSY, FILTER 1
25 CY-119802-35110 BRACKET, FILTER 1
26 CY-129100-35140 STUD 1
27 CY-129150-35111 GASKET, (NON-ASB.) 1
28 CY-129150-35160 FILTER 80X80L 1
29 CY-26106-080202 BOLT M 8X 20 PLATED 3
30 CY-114250-39450 SWITCH,(0.5KG) ENGINE OIL 1
31 CY-124160-39140 BOLT, BANJO 1
32 CY-119802-39450 PIPE ASSY, INJECTION PUMP 1
33 CY-129005-59830 BOLT WITH SEAL 1
34 CY-22190-080002 SEAL WASHER 8S 1
35 CY-23857-030000 BOLT, BANJO 1
36 CY-22190-080002 SEAL WASHER 8S 1
37 CY-22190-100002 SEAL WASHER 10S 2
38 CY-26366-060002 NUT M 6 1
15
FIG. 10. LUBRICATING PARTS
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
16
FIG. 11. COOLING WATER SYSTEM
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
1 CY-129403-42380 V-PULLEY(D=110) 1
2 CY-129211-42290 V-BELT 1
3 CY-129120-44741 FAN, COOLING (D=360) 1
4 CY-129030-44760 SPACER 1
5 CY-26106-060502 BOLT M 6X 50 PLATED 4
6 CY-129155-49801 THERMOSTAT (71) 1
7 CY-129150-49811 GASKET, (NON-ASB.) 1
8 CY-129795-49551 GASKET, (NON-ASB.) 1
9 CY-129350-49560 COVER, THERMOSTAT 1
10 CY-26306-080002 NUT 2
11 CY-129263-49610 PIPE, COOLING WATER 1
12 CY-129263-49710 PIPE, COOLING WATER 1
13 CY-124722-59050 CLAMP 9 2
14 CY-129263-49620 PIPE, COOLING WATER 1
15 CY-129263-49720 PIPE, COOLING WATER 1
16 CY-124722-59050 CLAMP 9 2
17 CY-119620-49290 DRAIN ASSY 1/4 1
21 CY-121450-42450 PLUG M16 1
22 CY-129054-42450 PLUG, M12X1.5 1
23 CY-124465-44950 GASKET 16 1
24 CY-124250-49351 THERMOMETER 1
25 CY-129150-49360 GASKET 10 1
26 CY-22190-120002 SEAL WASHER 12 1
27 CY-129486-42050 GASKET 1
28 CY-23414-080000 GASKET 8, ROUND 1
29 CY-26106-080122 BOLT M 8X 12 PLATED 1
30 CY-26106-080552 BOLT M 8X 55 PLATED 2
31 CY-26106-080602 BOLT M 8X 60 PLATED 1
32 CY-26106-080702 BOLT M 8X 70 PLATED 1
33 CY-129269-42000 PUMP ASSY, WATER 1
34 CY-129457-42050 PACKING 1
35 CY-129457-42121 PLATE 1
39 CY-129150-42301 FLANGE, PUMP 1
40 CY-24358-240310 O-RING 5 24031 1
42 CY-129054-42320 O-RING 1
43 CY-26577-060152 SCREW M 6X 15 3
44 CY-26106-060202 BOLT M 6X 20 PLATED 2
45 CY-26116-060162 BOLT 6X16 5
46 CY-119802-49113 JOINT 2
47 CY-23875-030000 PLUG PT3/8,STEEL 2
49 CY-129555-44750 STUD 2
FIG. 11. COOLING WATER SYSTEM
17
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
18
FIG. 12. FUEL INJECTION PUMP
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
REF
NO. PART NUMBER DESCRIPTION QTY
1 CY-729269-51300 INJECTION PUMP ASSY 1 94 CY-158601-51790 PLUG 1
7 CY-119802-51090 KEY, WOODRUFF 4X16 1 95 CY-22190-120002 SEAL WASHER 12 1
32 CY-158600-51270 STOPPER 1 96 CY-22190-180002 SEAL WASHER 18 1
33 CY-158563-51281 O-RING 1 97 CY-23887-120002 PLUG M12, HEX. 1
34 CY-158563-51281 O-RING 1 99 CY-158553-51770 BOLT 4
35 CY-129008-51300 VALVE ASSY, DELIVERY 3 100 CY-158552-52310 O-RING 1
43 CY-158563-51330 SPRING 3 101 CY-158552-52400 O-RING 4E S42 1
44 CY-129008-51340 HOLDER, DELIVERY 3 102 CY-22190-120002 SEAL WASHER 12 2
51 CY-158601-51550 PLUG 1 103 CY-22190-180002 SEAL WASHER 18 2
52 CY-119802-51560 BARREL PLUG 1 104 CY-22217-140000 SPRING WASHER 14 1
53 CY-158552-51570 GASKET 3 105 CY-22312-050140 PARALLEL PIN 5X14 2
54 CY-158552-51570 GASKET 1 106 CY-22351-050010 SPRING PIN 5X10 2
55 CY-158557-51570 PLUG 1 108 CY-24311-000070 O-RING 1A P-7.0 1
56 CY-158601-51570 PLUG, WATER PUMP 1 109 CY-24356-010180 O-RING 1
57 CY-158552-51580 LIFTER 1 110 CY-24356-010200 PACKING, 1020 1
58 CY-119802-51590 TIMER SET 1 111 CY-26106-060102 BOLT 6X 10 PLATED 1
59 CY-119802-51600 TIMER CMP 1 115 CY-26450-080452 BOLT M 8X 45 4
62 CY-158553-51670 O-RING, 1011 1 116 CY-26776-140002 LOCK NUT M14 PLATED 1
63 CY-119802-51680 BACKUP RING 1 119 CY-158553-51551 JOINT, COOLING WATER 1
64 CY-119802-51690 O RING 1 120 CY-158601-51650 JOINT 1
65 CY-24356-010200 PACKING, 1020 1 121 CY-158552-51670 JOINT 1
66 CY-24372-000150 RING, BACKUP T2 P 15 1 123 CY-158552-52100 PUMP ASSY, FEED 1
67 CY-158552-51600 PACKING, HEAD 1 124 CY-158552-52500 O-RING, FEED P INNER 1
68 CY-158553-51630 SPRING, TIMER 1 125 CY-129916-59020 JOINT 12, PIPE 1
70 CY-158553-51640 ELEMENT, THERMO 1 127 CY-22190-120002 SEAL WASHER 12 2
71 CY-158553-51660 O-RING,P14 1 128 CY-23857-060000 JOINT BOLT 6,PIPE 1
72 CY-158553-51680 PACKING, TIMER 1 129 CY-119802-51250 BRACKET, PUMP 1
92 CY-158601-51770 PISTON 1 130 CY-26106-080162 BOLT M 8X 16 PLATED 1
93 CY-158552-51781 DAMPER ASSY 1 131 CY-26106-080202 BOLT M 8X 20 PLATED 1
19
FIG. 12. FUEL INJECTION PUMP
Copyright 2007 Cub Cadet Yanmar LLC

Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
1 CY-194150-01370 ADJUSTER 1
4 CY-158553-61050 PACKING, CASE 1
5 CY-158553-61070 PACKING 1
7 CY-129155-51280 O-RING S6 1
23 CY-129255-61410 NUT 1
24 CY-119807-61420 SPRING 1
25 CY-158552-61441 LEVER, REGULATOR 1
26 CY-129155-61460 BOLT, IDLE LIMIT 1
60 CY-119660-61901 RETAINER, SHAFT 1
64 CY-22190-120000 SEAL WASHER 12(BOLT) 1
66 CY-23887-120002 PLUG M12,HEX. 1
68 CY-26106-060102 BOLT 6X 10 PLATED 1
69 CY-26756-060002 LOCK NUT 6 1
78 CY-158552-61900 O-RING 1
83 CY-26106-060142 BOLT M 6X 14 PLATED 2
84 CY-26106-060142 BOLT M 6X 14 PLATED 4
85 CY-26106-060202 BOLT M 6X 20 PLATED 10
87 CY-129642-61060 COVER, CASE 1
130 CY-119653-77950 SOLENOID, STOP 1
131 CY-22137-080000 WASHER 8, POLISHED 1
132 CY-22417-160180 COTTER PIN 1.6X18 1
20
FIG. 13. GOVERNOR
Copyright 2007 Cub Cadet Yanmar LLC
