CUBE in-a-box V3.Series User manual

CUBE
in-a-box
V3.series
Tools needed: 1 screwdriver (or drill), Philips head
Time of assembly: 30-45 minutes with 2 people
For help call our Toll Free Customer Service at:
1-888-880 CUBE (2823)
Detailed Assembly Instructions

- 1 -
Cube in-a-Box - Assembly Instructions
V3.series
Unpack all the parts,
Double check quantities
with the packing list. If ther
e
is a problem with the count,
call our Customer Service
at 1-888-880-2823
(US Pacific Time)
or email at:
[email protected]

- 2 -
1
Slide panel 1T* (24”W) in
between end-post A (37”H),
and a 2-way post B (57”H).
Then slide half-panel 2
(36”W) in between post B
and linear-post C (57”H).
*TIP 1: letter T is for panels
with a pre-installed alu cap
(only on top panels).
2
Slide second half-panel 2
(36”W) in between post C
and second 2-way post B.
Slide panel 3 (36”W) in
between 2-way post B and
second linear-post C.
3
Slide first panel 4T (36”W)
in between linear-post C
and 2-way post D (37”H).
Slide other panel 1T (24”W)
in between 2-way post D
and second end-post A.
4
Slide the raceway-frames 5
(without the covers) on top
of the two half-panels 2.
Black plastic cavaliers have
to be at the bottom.
5
Slide rail-panels 6** (hooks
facing up) on top of panel 4
.
**TIP 2: rail-panels must be
installed with hooks facing
up so paper and pencil
trays can hold on them.
6
Slide last rail-panel 6
(hooks facing up) on top of
panel 3 between B and C.
Slide two panels 4T (36”W)
on top of the two rail-panel
s
6 above raceway-panels 5.

- 3 -
7
Slide whiteboard-panel 7T
on top of the last rail-panel
6 between posts B and C.
Make sure all the panels are
stacked all the way down in
the posts.
8
Assemble the two
wire-guides and slide them
into posts where you will
need them, preferably
under work top level.
9
Check and assemble all
brackets and cantilevers.
Use big chromed-screws
here.
10
Adjust the brackets and
cantilevers to the mark leve
l
(dot) on each post or at
28-1/4 inches high.
Both cantilevers go on
linear posts C.
11
Repeat the operation for all
brackets/cantilevers.
You just need to tighten the
big chromed-screw to make
it hold.
12
Display brackets on all
corners and on all end
posts.
13
Insert each filler designed
to hide the empty space at
the top of posts B and C, as
per pictures are showing.

- 4 -
14
Place the raceway cover on
top of the plastic cavaliers
on each side of the frame.
To close the raceway cover,
push down on each side of
the cover until it clips in.
15
Display and level the 3 wor
k
tops then screw them (you
may use an electric drill).
Use the black wood screws.
16
Check and assemble the
shelf-supports with the big
chromed-screws.
Slide both supports on the
right and left side of the
high panel of your choice.
17
Adjust the height of both
right/left shelf-supports.
Display the shelf on top of
the shelf-supports, push
down on the black plastic
brackets until it fits in.
18
Push the shelf all the way
toward the panel.
Use a leveler to adjust the
shelf-supports height.
Display the book-holders a
s
per the holes.
19
Place the metal-caps on top
of each post. Tighten them
with the self tapping
metal-screws.
20
Place magnet plastic-caps
on top of each post.
Place the grommet-cap on
the work-top hole.

- 5 -
21
Place the 2 paper trays and
the pencil box wherever
you want them, inside or
outside the cubicle.
You are done, enjoy your
workstation!!
Tell your friends about us!
