CUBE in-a-box V4 Series Operating and maintenance manual

CUBE
in-a-box
V4.series
Tools needed: 1 screwdriver (or drill), Philips head
Time of assembly: 20-30 minutes with 2 people
For help call our Toll Free Customer Service at:
1-888-880 CUBE (2823)
Detailed Assembly Instructions

- 1 -
Cube in-a-Box – V4.series – Assembly Instructions
1
Unpack all the parts,
double check quantities
with the packing list.
If there is a problem with
the count, call our
Customer Service at
1-888-880-2823
(Pacific Time)
or email at
[email protected]
2
TIP 1: Identify panels that
come with a pre-installed
alu cap. They go on the top.
TIP 2: On each panel make
sure that the plastic covers
(sliders) are in place.
3
Slide (4) rail-panels 1
(24”W) in between the first
end-post A (41”H) and a
2-way post B (41”H).
TIP 3: all rail-panels must
be installed with the hooks
facing up so paper/pencil
trays can hold onto them.
4
Slide (4) rail-panels 2
(36”W) in between the
2-way post B and the
linear-post C (41”H).
5
Slide (4) rail-panels 2
(36”W) in between linear
post C and 2-way post B.
Same with (4) rail-panels 1
(24”W) in between 2-way
post B and last end-post A.

- 2 -
6
Slide panels 3 (24”W) and
panels 4 (36”W) on top of
the four rail panels already
there. Then finish up with
the last rail-panels mounted
with alu cap (see TIP 1).
7
Assemble the 2 wire-guides
and slide/adjust them into
posts where you will need
them, preferably under
work top level.
8
Check and assemble all
brackets and the cantilever.
Use big chromed-screws
here.
9
Adjust the brackets and
cantilever to the mark level
(dot) or at a 28-1/4 inches
high on each post.
Cantilever goes on post C,
brackets go on other posts.
10
Display brackets on corner
s
and on all end posts.
You just need to tighten the
big chromed-screw to make
it hold.
11
To attach the counter top
you would need first to
place the 2 round-brackets
on top of the panels, as wel
l
as 2 brackets back to back
as shown on picture.

- 3 -
12
Present the counter top,
then adjust the support
brackets height.
13
Use the leveler to adjust th
e
work-tops and brackets.
You are now ready to screw
the 2 work tops and the
counter top.
Use the black wood-screws
here for tops and counter.
You may use an electric dril
l
to screw from underneath.
14
Place the metal-caps on top
of each post. Tighten them
with the self tapping
metal-screws.
15
Place magnet plastic-caps
on top of each post.
Place the grommet-caps on
the work-top holes.
16
Place the 2 paper trays and
the pencil box wherever
you want them, inside or
outside the cubicle.
You are done, enjoy your
reception cubicle!!
Tell your friends about us!
