CUGGL 707/7768 User manual

Important
Age:18 months - 5 years
03456 400 800
CUGGL BEDRAIL NATURAL
CUGGL BEDRAIL BLUE
CUGGL BEDRAIL PINK
IMPORTANT! KEEP THE INSTRUCTION FOR FURTHER REFERENCE
Issue1-31/03/17
707/7768
706/2326
702/7079

Fabric
Metal Frame
Hinge System
Bottom Tube
Left Tube
Right Tube
1
Exploded diagram for single bedrail

Please check all the parts listed below:
A
D
C1
C2
B1 B2
2
It is recommended only to use the bedrail for children between 18 months and 5 years.
Only use the bedrail when the child is able to climb in and out of bed unaided.
The bedrail should not be used as a substitute for a cot, as it cannot provide
the same level of safety as a cot.
Once the bedrail is in locked position or when placed in the fitted position, it
should touch the side of the mattress.
The bedrail is fixed to the bed or to the mattress, the bedrail should not be
used unless the fixings are in place and securely attached to both the bed
and/or the mattress and the bedrail.
This bedrail is designed to fit most divan or slatted style single beds with a
separate mattress.
The length of the mattress must be between 150-200cm, with the width being
75cm-90cm, the thickness of the mattress must be between 8cm-23cm.
Once fitted in place, the bedrail should be checked to ensure that it is properly
fitted and secure.
The bedrail should be periodically checked for its general condition with
particular reference to the security of any locking mechanism and/or hinges that
are used on the product.
Additional and replacement parts should be obtained only from the manufacture.
B - Left tube ( B1 ) X 1& right tube ( B2 ) X 1
C - Bottom tube ( C1 & C2 ) X 1
D - Right hinge system X 1
A - Metal Frame + Fabric X 1
Complies to BS 7922:2001+A1:2009

Assembling Your Bedrail
Figure1
Figure2
3
Step 1: Unfold the bedrail, slide the plastic in place and lock it.
( See figure 1 )
Step 2: Fixed the bottom tube ( C1 & C2 ) together, and then get
through the fabric. （ See figure 2 ）
C1 C2

Figure3
Figure4
4
Step 3: Put the left tube ( B1 ) into the connected plastic, then get through
the fabric and assemble the B1 to left hinge system till the button locked in
place. （ See figure 3 ）
Put the right tube ( B2 ) into the connected plastic, then get through the fabric
and assemble the B2 to right hinge system till button locked in place.
（ See figure 4 ）
Step 4: Fix the right hinge system ( D ) to bedrail till button locked in place.
B1
D
B2

Figure5
L
L
R
R
R
L
5
Step 5: Slide the plastic behind button. （ See figure 5 ）

Installing Your Bedrail
Figure7
1
2
Figure6
Figure8
Figure9
6
Put on the mattress, make the
steel plate in place as stopper
against the mattress and bed.
( See figure 7 ）
Step 1: Adjust the straps length
according to the width.
Be careful: to let the straps
in flat and straight, not twist.
( See figure 6 ）
Pull back the strap
( lower one ) at the end of
the steel plate.
( See figure 8 ）
Pull up the strap end
( the upper one ) to tighten and
lock the steel plate to make
sure no movement space
against the mattress and bed.
( See figure 9 )

min 250mm ( 10in ) min 250mm ( 10in )
<600mm ( 23.6in )
Figure10
Figure11
7
Step 2: WARNING: To prevent the risk of strangulation it is essential to
ensure that when the bedrail is fitted into position, there is a gap of at least
250 mm( 10in ), between each end of the bed and the corresponding end of
the bedrail.
The bedrail should not be used on a sleeping surface that is more than
600 mm( 23.6in ) from the floor. （ See figure 10 ）
Step 3: Press the button at the same time and lay down the upper part of
the bedrail when it is not in use. ( See figure 11 )

Folding Your Bedrail for Storing
Figure12
Figure13
Figure14
Rotate
1
Push
2
Fold
Press Remove tube
1
2Press
1
Remove tube
2
Remove tube
8
Step 1: Remove the left/right tube
Press the upper button in place and then remove the left/right tube from hinge.
Press the under button in place and then remove them from bottom tube.
( See figure 12 ）
Step 2: Take off the bottom tube from fabric. （ See figure13 ）
Step 3: Slide the plastics as the arrow mark till the two tubes are separated,
and then fold the bedrail for storing. （ See figure 14 ）

Fabric composition: 100% Polyester.
Periodically check the bedrail for signs of damage, wear and/or for
missing components.
Do not use if any part is missing, worn or damaged.
Check the bedrail regularly to make sure all hardware and mountings
are tight and secure.
Never clean with abrasives, ammonia based, bleach based cleaners.
Make sure it is dry and clean storing.
Proper cleaning of bedrail can be done by sponging it with warm water
and mild detergent.
Care & Maintenance
Once you want to clean your fabric, please refer to the step1 and step
2 on page 8 and then take off the fabric from the metal frame as the
arrow. （ See figure15 ）
Figure15
Please keep all the relevant information for future reference.
