Cuisinart ICE50BCU User manual

Ice Cream Professional
ICE50BCU

3
Congratulations on your purchase of the Cuisinart Ice Cream Professional.
For over 30 years Cuisinart’s aim has been to produce the very nest kitchen equipment
so that cooks at home as well as professional chefs have the tools to express their
creativity.
All Cuisinart products are engineered for exceptionally long life, and designed to be
easy to use as well as to give excellent performance day after day.That is why they have
come to be regarded as the dening machines in their eld by chefs across the world.
Whatever you cook, cook it better with Cuisinart.

4
Contents
Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Instructions for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
A Assembling the Ice Cream Professional . . . . . . . . . . . . . . . . . . . . . . . . . . 8
B Dismantling the Ice Cream Professional . . . . . . . . . . . . . . . . . . . . . . . . . . 9
C Making Frozen Desserts and Drinks . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
D Hints and Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cleaning & Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
UK Wiring Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
UK After Sales Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Recipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

5
Product Description
Stem
Motor Arm
Heavy Duty Compressor
(not shown)
Mixing Pad
Housing Base
Lid
Timer Dial
Mixing Bowl

6
Carefully read all the instructions thoroughly before using the appliance and keep in a safe place
for future reference
Safety Cautions
Always follow these safety cautions when using this appliance to avoid personal injury or damage to the appliance.
This appliance should be used only as described within this instruction book.
ßDo not immerse the base in water, any other liquid or in a dishwasher.
ßTo clean base, disconnect from the mains, clean using a damp cloth. Allow to dry thoroughly before re-use.
ßAlways disconnect the appliance immediately after use.
ßAlways unplug from the mains when not in use and before cleaning.
ßNever disconnect the plug by pulling on the mains lead.
ßAlways ensure that your hands are dry before removing the plug from the mains socket.
ßAvoid contact with moving parts. Keep hands, hair, clothing and spatulas and other utensils away during
operation to reduce the risk of injury and/or damage to the appliance.
ßNever use a scourer to clean appliance.Wipe with a warm moist cloth.
ßDo not allow the lead to overhang the edge of the table or work surface.
ßThis appliance should not be used by adults or children whose lack of experience, product knowledge or
disability might cause a hazard, unless they have been correctly instructed and are adequately supervised.
ßChildren should always be supervised to ensure that they do not play with this product.
ßDo not use this appliance if the lead is damaged. In the event of damage the lead must be replaced by a special
lead available from the manufacturer or its service agent. (See ‘’UK After Sales Service” section).

7
ßDo not use the appliance if it has fallen or shows signs of damage. Discontinue use immediately. (See ‘’UK After
Sales Service” section).
ßNo repair can be carried out by the user. Return the appliance to ‘’Cuisinart Service Centre’’ for inspection
and repair or replacement. (See ‘UK After Sales Service’’ section).
ßUse this appliance only as described within these instructions for use. Retain these for future reference.
ßFor indoor use only.
ßFor domestic use only.
ßThe appliance should remain upright at all times. If the appliance is turned on its side or upside down, you will
need to put it in an upright position and wait 24 hours before using.
ßThis appliance complies with the basic requirements of Directives 04/108/EEC (Electromagnetic Compatibility)
and 06/95/EEC (Safety of domestic electrical appliances) amended by Directive 93/68/EEC (CE Marking).
ßDo not use any attachments other than those recommended or sold by Cuisinart.
ßWARNING: A cut off plug inserted into a 13 amp outlet is a serious safety (shock) hazard. Ensure the cut
off plug is disposed of safely.
ßWARNING: Polythene bags over the product or packaging may be dangerous. To avoid danger of suffocation,
keep away from babies and children. These bags are not toys.
ßThe symbol on the product or on its packaging indicates that this product may not be
treated as household waste. Instead it should be handed over to an appropriate collection point for the
recycling of electrical and electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of this product. For more detailed
information about the recycling of this product, please contact your local council office or your
household waste disposal service.

8
Instructions for Use
Before rst use, clean the lid, mixing bowl and mixing paddle in warm soapy water.
N.B. Do not clean any of the part with abrasive cleaners, hard implements or in the dishwasher.
A Assembling the Ice Cream Professional
ßTake the motor arm and place smooth side face down on a at surface so that the holes are visible on
top.
ßAlign the at end of the stem with the cut out in the motor arm, and push into position.
ßPlace the domed side of the lid face down over the top of the stem until resting on the motor arm with
the opening. Align the plastic ridge on the top of the lid with the bracket on the edge of the motor arm.
Push the lid back until locked into place. This will secure the lid to the motor arm.
ßAlign the mixing paddle with the top of the stem and push into place.
N.B. There should be a 1cm gap between the bottom of the paddle and the bottom of the stem.

9
ßPlace the mixing bowl into the housing base. Turn the motor arm over and attach to the top of the base
with the mixing paddle in the mixing bowl.
B Dismantling the Ice Cream Professional
ßCarefully lift out the motor arm and lid from the top of the unit by lifting upwards.Turn over and lay on a
at surface.
ßCarefully remove the mixing padding by lifting upwards. Slide the lid away from the motor arm so that the
round cut of the lid is directly around the bottom of the stem. Lift lid over and off of the stem.
ßPull the stem out away from the motor arm.
ßFinally, carefully lift the mixing bowl out of the housing base.
C Making Frozen Desserts or Drinks
WARNING: This appliance should remain upright at all times. If appliance is turned on its side or upside
down, you will need to put in an upright position and wait 24 hours before using.
ßFirstly, prepare the ingredients required for your recipe, following the recipes in this instruction book or
your own.
ßPlace the mixing bowl in the housing base.
ßPour the ingredients into the mixing bowl.
ßAssemble the mixing arm and t to the top of the appliance.
ßTurn the dial to required time, 35-45 minutes for a soft dessert, 45-60 minutes for a hard dessert. The
mixing process will begin. The unit will automatically stop mixing and turn itself off when the set time has
elapsed, an audible tone will sound to alert you.
N.B. if the frozen dessert reaches maximum thickness before the set time has elapsed, the unit will stop
mixing. If you do not shut off the timer manually it will continue counting down to ‘0’ and will then shut
itself off.

10
D Hints and Tips
ßProcessing time depends on the recipe, the amount of dessert being made and the temperature of the
ingredients being use. All recipes take between 35 and 60 minutes.
ßSoft ice cream takes between 35-45 minutes.
ßHard ice cream takes 45-60 minutes.
ßYour Ice Cream Professional makes ice cream using fresh natural ingredients, i.e. without the preservatives
etc as found in commercial ice creams.Therefore it will not have the same hard consistency, for a rmer
consistency, transfer the dessert to an airtight container and store in the freezer for at least 2 hours be-
fore serving.
ßAdd other ingredients e.g. chocolate chips and nuts approximately 5 minutes before the mixing is com-
plete. Once the dessert or drink has begun to thicken, add the ingredients through the lid whilst mixing
continues.
ßNuts and other ingredients should be no larger than a chocolate chip.
ßYou should begin with a maximum of 1 litre of mixture in the Ice Cream Professional.
ßSome recipes use precooked ingredients. For best results, the mixture should be chilled overnight before
using.
ßPrior to freezing, most mixed recipes may be stored in the refrigerator for up to 3 days.
ßYou may substitute lower fat creams and milk for double cream and whole milk used in many recipes.
However, the higher the fat content the richer and creamier the result. Using lower fat substitutes may
change the taste, consistency and texture of the dessert. When substituting ingredients, ensure you use
the same quantity of the substitute as the original ingredient required.
ßYou may also substitute articial sweeteners for sugar. If the recipe is to be precooked, add the sweetener
after the heating process is complete (the ingredients have been cooked). Stir the mixture thoroughly to
dissolve the sweetener.

11
ßWhen making sorbet, test the ripeness and sweetness of the fruit before you begin. The freezing process
reduces the sweetness of the fruit so that it will not taste as sweet as the recipe mixture. If the fruit
tastes tart, add sugar to the recipe. If the fruit is very ripe or sweet, reduce the amount of sugar in the
recipe.
ßDo not ll the mixing bowl higher than 3cm from the top.Take this into consideration if you wish to add
extra ingredients through the lid.
ßWell chilled ingredients require shorter mixing times.
ßMixing times suggestions can vary due to ingredients and type of recipe.
Cleaning & Maintenance
ßBefore rst use and after every use, clean each part thoroughly.
ßAlways unplug the appliance from the mains outlet before cleaning.
ßWash the mixing bowl, mixing paddle and lid in warm soapy water. Dry each part thoroughly. Do not
wash any of the parts in the dishwasher.
ßEnsure the appliance is stored in an upright position.
ßWipe the housing base with a clean damp cloth, do not use harsh abrasive cleaners or scourers.
ßNever submerge the motor base in the water or other liquid, or place in a dishwasher.

12
Guarantee
ßThis Cuisinart appliance is guaranteed for domestic consumer use for 5 years.
ßThe guarantee covers defects under normal use from date of purchase and ceases to be valid in the event
of alteration or repair by unauthorized persons.
ßIf the appliance does not perform satisfactorily due to defects of material or manufacture, it will be repai-
red or replaced by the manufacturer (see UK after sales service for details).
ßThis guarantee is only valid in the United Kingdom (including Northern Ireland, Republic of Ireland, the
Channel Islands and the Isle of Man).
ßNo responsibility will be accepted for any damage caused in transit.
ßA charge may be made if goods are returned outside the relevant guarantee period or if the product is
returned unnecessarily.
ßThe manufacturer reserves the right to amend terms and specications without prior notice.
ßThis guarantee in no way affects your statutory rights.

13
UK Wiring Instructions
ßYour Cuisinart Ice Cream Professional includes a BS 3 amp moulded (fused) mains plug on the supply
cord.
ßShould it be necessary at any stage to remove this moulded plug and replace it with a re-wireable BS 3
amp mains plug, the re-wiring should be completed as follows: (NB The moulded plug should be disposed
of safely)
Class I (1)
The wires in the mains lead are coloured in accordance with the following code:
GREEN & YELLOW = EARTH
BLUE = NEUTRAL BROWN = LIVE
As the colours of the wire may not correspond with the coloured markings identifying the terminals in
your plug, proceed as follows:
ßThe wire which is coloured Green &Yellow must be connected to the terminal in the plug which is mar-
ked with the letter E or or coloured green or yellow.
ßThe wire which is coloured BLUE must be connected to the terminal which is marked with the letter N
or coloured black.
ßThe wire which is coloured BROWN must be connected to the terminal which is marked with the letter
L or coloured red.
With this appliance, if a 3 amp plug is used, a 3 amp fuse should be tted. If any other type of plug is used, a
10 amp fuse must be tted, either in the plug or at the distribution board.

14
UK After Sales Service
For further advice on using your Cuisinart Ice Cream Professional and other products in the Cuisinart
range, contact the Cuisinart Customer Care Line on 0870 240 6902 (09:00 to 17:00 hrs Monday to Friday)
or, alternatively, email your enquiry to [e-mail]
In Guarantee
Return the product to the Cuisinart Service Centre at the following address:
Cuisinart Service Centre
P.O. Box 506
WIGAN
WN1 9AA
Enclose your name and address, together with proof of purchase and details of the fault.
Cuisinart will either repair or replace the product, as appropriate.
Out of Guarantee
Contact the Cuisinart Customer Care Line on 0870 240 6902 (09:00 to 17:00 hrs Monday to Friday) or,
alternatively, email your enquiry to [e-mail] for details of the standard repair or replace-
ment charge. If you wish to proceed with the repair or replacement, return the product to the Cuisinart
Service Centre at the following address:
Cuisinart Service Centre
P.O. Box 506
WIGAN
WN1 9AA

15
Recipes
Basic
Vanilla Ice Cream . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Chocolate Ice Cream . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Coffee Ice Cream . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Mocha Latte Ice Cream . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Sweet Cinnamon Ice Cream. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Speciality
Crème Brulée Ice Cream . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Crème Brulée Crunch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
White Chocolate Ice Cream with Macadamia Nuts . . . . . . . . . . . . . . . . . . . . . . . 23
Chocolate Trufe Ice Cream . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
FrozenYoghurts
Vanilla Frozen Yoghurt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Chocolate FrozenYoghurt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Raspberry Frozen Yoghurt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Quick Peach Frozen Yoghurt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Sorbets
Fresh Lemon Sorbet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Cranberry Sorbet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Blueberry Sorbet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Orange & Mango Sorbet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

16
Vanilla Ice Cream
225ml whole milk
175g granulated sugar
450ml double cream
1-2 tsp vanilla extract
ßPour the milk and sugar into a medium bowl and whisk until the sugar has dissolved. Stir in the cream
and vanilla, cover and refrigerate if time allows.
ßOnce chilled, pour into the mixing bowl. Attach the motor arm to the housing with the mixing paddle
and lid in correct position. Set the timer to 35-45 minutes for soft ice cream and 45-60 for hard ice
cream, the mixing process will begin.
ßWhen nished an audible tone will sound, ice cream is ready to serve.
Variations:
ßMint chip: omit vanilla and replace with - 1 tsp peppermint extract. Chop 100g milk chocolate into very
small pieces and add through the lid during the last 5 minutes of mixing.
ßCookies and Cream: add 150g coarsely chopped cookies e.g. chocolate chip through the lid during the
last 5 minutes of mixing.
ßPistachio: add tsp almond extract to the base mixture. Coarsely chop 100g shelled pistachios and add
through the lid during the last 5 minutes of mixing.

17
Chocolate Ice Cream
225ml whole milk
100g granulated sugar
200g milk chocolate, broken into 1cm pieces
450ml double cream
1 tsp vanilla extract
ßHeat the milk over a medium heat until just bubbling around the edges.
ßPlace the sugar and chocolate into a food processor and pulse with the chopping blade until nely chop-
ped.
ßAdd the hot milk and process well until smooth. Transfer to a medium bowl and allow to cool completely.
Cover and refrigerate for 2 hours.
ßOnce chilled, stir the chocolate mixture and pour into the mixing bowl.
ßAttach the motor arm to the housing with the mixing paddle and lid in correct position. Set the timer to
35-45 minutes for soft ice cream and 45-60 for hard ice cream, the mixing process will begin.
ßWhen nished an audible tone will sound, ice cream is ready to serve.
Variations:
ßChocolate Almond: add tsp pure almond extract with the vanilla. Add 100g chopped toasted almonds
through the lid during the last 5 minutes of mixing.
ßChocolate Cookie: add 100g-150g chopped cookies through the lid during the last 5 minutes of mixing.

18
Coffee Ice Cream
225ml whole milk, chilled
175g granulated sugar
1-3 tbsp instant coffee/ espresso, to taste
450ml double cream, well chilled
1 tsp vanilla extract
ßPlace the milk, sugar and coffee into a medium bowl and whisk until the sugar and coffee have dissolved.
Stir in the cream and vanilla and cover and refrigerate until chilled.
ßOnce chilled, pour the mixture into the mixing bowl.
ßAttach the motor arm to the housing with the mixing paddle and lid in correct position. Set the timer to
35-45 minutes for soft ice cream and 45-60 for hard ice cream, the mixing process will begin.
ßWhen nished an audible tone will sound, ice cream is ready to serve.

19
Mocha Latte Ice Cream
225ml whole milk, well chilled
150g soft brown sugar
2 tbsp instant coffee/ espresso
2 tbsp cocoa powder
450ml double cream, well chilled
1 tsp vanilla extract
ßPlace the milk, sugar, coffee and cocoa into a medium bowl and whisk until the sugar and coffee have dis-
solved. Stir in the double cream and vanilla.
ßPour the ingredients into the mixing bowl.
ßAttach the motor arm to the housing with the mixing paddle and lid in correct position. Set the timer to
35-45 minutes for soft ice cream and 45-60 for hard ice cream, the mixing process will begin.
ßWhen nished an audible tone will sound, ice cream is ready to serve.

20
Sweet Cinnamon Ice Cream
225ml whole milk, well chilled
150g soft brown sugar
2 tsp ground cinnamon
450ml double cream, well chilled
1- tsp vanilla extract
ßPlace the milk, brown sugar and cinnamon into a medium bowl and whisk together until the sugar has
dissolved. Stir in the cream and vanilla, cover and chill.
ßPour the mixture into the mixing bowl.
ßAttach the motor arm to the housing with the mixing paddle and lid in correct position. Set the timer to
35-45 minutes for soft ice cream and 45-60 for hard ice cream, the mixing process will begin.
ßWhen nished an audible tone will sound, ice cream is ready to serve.
