CULITEK HD Series Operating and maintenance manual

Instructional Manual
HD-SERIES REACH-INS
R1SS, R2SS, R3SS, F1SS, F2SS, F3SS
This manual contains important information regarding your Culitek unit.
Read this manual thoroughly prior to equipment setup, operation, and
maintenance. Failure to comply with regular maintenance guidelines
outlined in this manual may void the warranty.

Page 1
TABLE OF CONTENTS
1. Terms and Conditions......................................... .......................................................................... 2
2. Preface................................................................ .......................................................................... 4
3. Use of Equipment.......................................... ................................................................................ 5
4. Technical Features............................................... ......................................................................... 5
5. Operation ....................................................................................................................................... 5
6. Control Unit ................................................................................................................................... 6
7. Handling ........................................................................................................................................ 6
8. Installation Procedure .................................................................................................................... 6
9. Connecting to Main Power Supply ................................................................................................ 6
10. Maintenance Instructions .............................................................................................................. 7
11. Troubleshooting ............................................................................................................................. 7
12. Technical Service .......................................................................................................................... 7
13. Configuration Sketch Map ............................................................................................................. 7
14. Operating Instructions ................................................................................................................... 8
15. Electrical Control Circuit Diagram ............................................................................................... 10
16. Technical Parameters ................................................................................................................. 13
17. Official Approval and Rules ......................................................................................................... 14
1

Page 2
2
1. TERMS AND CONDITIONS
Two Year Warranty
All claims for parts or labor must be made directly through Culitek, and must include the model, the serial
number, proof of purchase, date of installation, and all pertinent information supporting the alleged defect.
In case of compressor replacement under warranty, either the compressor or compressor tag must be
returned to Culitek, along with above listed information. Failure to comply with warranty policies will
result in voided claims.
Two Year Parts & Labor Warranty
Culitek warrants all new refrigerated components, such as the cabinet and all parts, to be free from
defects in materials or workmanship. Culitekʼs obligation under this warranty is limited to a period of two
(2) years from the date of shipment from Culitek. All parts covered under this warranty that are defective
within two (2) years from the date of shipment from Culitek are limited to repair or replacement (including
labor charges) of defective parts or assemblies. The labor warranty shall include standard straight time
labor charges only and reasonable travel time, as determined by Culitek.
Additional Three-Year Compressor Warranty
In addition to the two (2) year warranty, Culitek warrants its sealed compressor to be free from defects, in
both material and workmanship, under normal and proper use and maintenance service for a period of
three (3) additional years from the date of original installation, but not to exceed five (5) years.
Compressors that have been determined to be defective from Culitek within this extended period will be
either repaired or replaced with a compressor or compressor parts of similar design and capacity,
according to Culitek‘s discretion. The three (3) year extended compressor warranty applies only to sealed
parts of the compressor and does not apply to any other parts or components. This includes the cabinet,
paint finish, temperature control, refrigerant, metering device, motor starting equipment, fan assembly,
and other electrical components, etc.
Compressor Warranty
The (5) five-year compressor warranty will be void if the following procedure is not carefully adhered to:
1. System contains R290 refrigerant and lubricant. The lubricant has rapid moisture absorbing qualities.
2. Drier replacement is very important and must be changed when a system is opened for servicing.
3. Micron level vacuums must be achieved to insure low moisture levels in the system.
4. Compressor must be obtained through Culitek, unless otherwise specified in writing, through
Culitek’s warranty department.

Page 3
What is NOT Covered by the Warranty
Culitek’s sole obligation under this warranty is limited to either repair or replacement of parts, subject to
the additional limitations below. This warranty neither assumes nor authorizes any person to assume
obligations other than those expressly covered by this warranty.
ROUTINE MAINTENANCE REQUIREMENTS MUST BE FOLLOWED, OR WARRANTY IS VOID.
No Consequential Damages
In no event will Culitek be responsible for economic loss, profit loss, or special, exemplary, punitive
indirect, or consequential damages, including without limitation losses or damages arising from food or
product spoilage, regardless of whether or not they result from equipment failure.
Warranty is Not Transferable
This warranty is not assignable and applies only to the original purchaser/user to whom delivered.
ANY SUCH ASSIGNMENT OR TRANSFER SHALL VOID THE WARRANTIES HEREIN AND
SHALL VOID ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY
OF MERCHANTABILITY OR LABOR COVERAGE FOR COMPONENT FAILURE OR OTHER
THE WARRANTY PACKET PROVIDED WITH THE UNIT.
Alteration, Neglect, Abuse, Misuse, Accident, Damage During Transit or Installation,
Fire, Food, or Acts of GOD
Culitek is not responsible for the repair or replacement of any parts that are determined to have been
subjected after the date of manufacture to alteration, neglect, abuse, misuse, accident, damage during
transit or installation, fire, flood, or act of God.
Improper Electrical Connections
Culitek is not responsible for repair or replacement of failed or damaged components, resulting from
electrical power failure, the use of extension cords, low voltage, or voltage drops to the unit.
The two (2) year parts & labor warranty and the additional three (3) year compressor warranty are as
described above. These warranties are exclusive and are in lieu of all other warranties and seller
disclaims any implied warranty of merchantability or that the goods will be fit for a particular purpose.
Seller also disclaims any implied warranties of non-infringement. There are no warranties which extend
beyond the description on the face hereof.
Stocking Period
Equipment distributed by stocking dealers are permitted a period of up to six (6) months for time
equipment is in-stock before sale to purchaser/user before warranty starts. For this extended warranty
stocking period to be honored, customer must provide model number of the unit, the serial number,
and dated proof of purchase.
Outside U.S.A. and Canada
This warranty does not apply to areas outside the continental USA. Culitek is not responsible for any
warranty claims made on products sold or used in such areas.
Residential
Culitek assumes no liability for parts or labor coverage for component failure, factory defect or any
other damages for units installed in non-commercial foodservice or residential applications.
* In some cases, a 25% restocking fee may be charged for returned items.
* Culitek may at any time modify equipment in order to provide and insure a superior product. Change is
sometimes necessary to keep up with today’s high standards in our industry. Culitek reserves the final
interpretation of all public materials.

Page 4
2. PREFACE
Please read instructions before using this unit.
IMPORTANT SAFETY INSTRUCTION
To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety
precautions should be adhered to, including the following:
p Before unit is used, it must be properly installed and operated in accordance with the
installation instruction.
p Before the unit is plugged in, ensure the rated voltage corresponds to the voltage of the
electrical system in your operation. The power plug should have its own independent socket.
Using adapters may cause overheating or burning.
p If the supply cord is damaged, it must be replaced by the manufacturer, or its service agent
or a similarly qualified person, in order to avoid a hazard.
p Connect to properly grounded outlets only. Avoid the use of extension cords. Do not run cord
under carpeting, runners or the like. Arrange cord away from traffic areas where it will not
create a tripping hazard.
p Always unplug unit when not in use and before cleaning, adjusting, or maintaining. To disconnect
the unit, turn switch off and remove plug from power source.
p Do not disconnect by pulling on the cord. Always disconnect by grasping and pulling on the plug top.
p Do not pull out the cord or touch the power plug with wet hands. Clean water or dust from the
power plug and insert it with the ends of the pins securely connected.
p Do not use outdoors.
p Do not splash water on unit; it may cause a malfunction or electric shock.
p Do not disassemble, repair or alter the unit; it may cause fire or abnormal operations, which
may lead to injury.
p Do not touch cold surfaces in the freezer compartment, particularly when hands are damp or wet.
Skin may adhere to these extremely cold surfaces.
p Never place glass products in the freezer because glass may explode when inner content freezes.
p The refrigerant and insulation blowing gas used in the unit require special disposal procedures.
When disposing, please consult with a service agent or a similarly qualified person.
p Do not store explosive substances, such as aerosol cans, with a flammable propellant in this unit.
p WARNING: Keep clear of obstruction all ventilation openings in the unit enclosure or in the
structure for build-in.
p WARNING: Do not use mechanical devices, or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
p WARNING: Do not damage the refrigerant circuit.
p WARNING: Do not use electrical appliances inside the food storage compartments of the unit,
unless they are of the type recommended by the manufacturer.

Page 5
2. PREFACE (continued)
WARNING: RISK OF FIRE/FLAMMABLE MATERIALS
CAUTION: RISK OF FIRE AND FLAMMABLE REFRIGERANT R290
If you need the electronic version instruction manual, please ask the manufacturer or its service agent.
▲ Maximum load of shelf is 176 pounds
This instruction manual provides all the necessary information regarding:
▲ Use of the reach-in
▲ Technical specifications
▲ Installation and handling
▲ Operator procedures and instructions
▲ Maintenance operation
The manual is to be considered an integral part of the unit and should be stored in a safe place for further
consult to permit a good working life of the unit. Unit is intended for commercial use only.
p Component parts shall be replaced with like components and servicing shall be done by factory
authorized service personnel.
The manufacturer cannot be held liable in the following cases:
p Improper installation (not in accordance with the guidelines indicated herein)
p Misuse of the unit
p Power supply defects
p Improper or inadequate maintenance
p Unauthorized modification or tampering
p Use of non-original spare parts
p Partial or total failure to comply with the instructions
All electrical equipment can be hazardous to health. Current standards and legal requirements must be
complied with during the installation and use of any equipment.
3. Use of Equipment
The unit is for preserving fresh perishable food, with a built-in refrigerated unit. Do not utilize the
equipment to store medical supplies. The optimum operational temperatures are between
33°F to 40°F in refrigerators and -8°F to 0°F in freezers.
4. Technical Features
The unit is a ventilated system; the evaporator is in a separate insulated box on the top. All the materials
used in the manufacture of this unit are guaranteed to be suitable for use with food. Eco-friendly R290
hydrocarbon refrigerant. The refrigerating circuit is in compliance with the current normative
5. Operation
The gas in the refrigerating circuit is compressed, liquefied and evaporated in the ventilated evaporator,
which is situated on the top of the container.
This cycle involves the absorption of heat from the air in the refrigerator compartment and the reason is
cooled. The heat produced is dissipated to the outside environment by a condenser unit located on the
top of the unit.

Page 6
6. Control Unit
The unit is operated from a digital control unit and a main switch pilot light in the top panel of the unit. The
main switch pilot light is for turning on the power supply. The green pilot light turns on to indicate that the
unit is connected to the main electricity and to start work. The green pilot light comes off to indicate that
the unit is disconnected and will not work. The digital control unit is for the regulation of all parameters to
provide the correct working of the unit. Please consult all parameters in the manual of the digital control
unit.
This manual is part of the instruction manual and is very important in case of service.
7. Handling
The unit arrives in PET film and is packed in a cardboard box on a wood pallet. The unit must be
transported and handled with care to avoid posing a hazard to persons or property. Never place unit on
its side or turn it upside down, as this may damage or impair operation of the refrigerated unit. Culitek
cannot be held liable for any damage or defects arising directly or indirectly from improper handling of the
equipment or non-compliance with the safeguards noted above.
8. Installation Procedure
Place the unit in the coolest and best ventilated part of the room. Do not install near heat sources or in
direct sunlight. Remove the straps securing the cardboard packing, the cardboard covering and the PET
protection film before installation. Clean the unit with mild detergent and then dry it with a soft cloth.
9. Connecting to Main Power Supply
This operation must be carried out by professionally and only by qualified persons. The unit is supplied
with a power supply cable for the connection to the main power supply. A thermomagnetic circuit breaker
(not supplied) must be installed between the main power point and the power supply cable of the unit.
Before proceeding make sure:
▲ The main voltage corresponds to the voltage on the unit 115V/60Hz/1Ph; to ensure proper operation
it is essential for the power supply voltage to come within a range of +/- 10% of the unit’s rated voltage.
▲ The electrical system to which the unit is sized to cater for the rated electric output of the buffet unit
being installed.
▲ The electronic system to which the unit is connected is made in compliance with current standard
requirements.
▲ The electric connections and the installation of the thermomagnetic circuit breaker have been done
by a qualified person.
Connecting steps:
▲ Install a thermomagnetic circuit breaker suited to the rated output of the unit being installed.
▲ Connect the refrigerator unit to the thermomagnetic circuit breaker outlet.
▲ Check that refrigerator unit is in order as demonstrated by the pilot light incorporated in the main
switch coming on.

Page 7
10. Maintenance Instructions
The smooth operation and life of the equipment are mainly determined by correct and regular
maintenance. Regular cleaning is strongly recommended each month. Please follow the instructions
below:
! Disconnect the unit power supply cable from the main power source
prior to carrying out any type of cleaning operation.
▲ Cleaning the Exterior
Clean with mild detergent and then dry it with a soft cloth. Do not use abrasive detergents!
▲ Cleaning the Interior
Clean the inside a minimum of once each month with a detergent suitable for use with foodstuff.
▲ Cleaning the Condenser
For efficient operation, it is advisable to clean the condenser regularly, a minimum of once
every 4 months with a dry brush or vacuum cleaner.
11. Troubleshooting
Unit stops working (light off):
▲ Power supply failure
Remedies:
Ü Check that the plug is inserted properly in the socket
Ü Check the on/off switch
Ü Check that the main voltage powers the plug
Unit temperature goes up:
▲ Unit too near to a heat source
▲ Condenser dirty or closed
Remedies:
Ü Move the counter or the heat source further away
Ü Clean the condenser
12. Technical Service
For technical service, please contact the dealer technical support department and provide them with the
model number, serial number and the purchase date.
13. Configuration Sketch Map
1. Power switch
2. Micro-computer controller
3. Compressor
4. Evaporator
5. Evaporator fan motor
6. Condenser fan motor
7. Condenser
8. Drain case
9. Shelf
10. Lamp
11. Caster
Top Mount Bottom Mount

Page 8
14. Operating Instructions
1. New upright air-cooling unit should be opened and ventilated before it is used.
After that, users should use warm water to clean its inside.
2. After connecting the power supply, press the "POWER" switch on the
controller keyboard (Green Indicator Light ON), the fridge will turn on.
The microcomputer controller, installed in the controller keyboard,
can automatically adjust the temperature ranges. This intelligent
digital controller works by recognizing when the temperature
increases and reaches set point, plus differential when the compressor
is started and turns off when the temperature reaches the set point value again.\
3. Microcomputer Controller Operation Instruction:
4. Microcomputer panel sketch map, meanings of running indicator light and LED showing.
5. Display target set point. In programming mode,
it selects a parameter or confirms an operation.
Start a manual defrost.
In programming mode, it browses the parameter codes,
or increases the displayed value.
In programming mode, it browses the parameter codes,
or decreases the displayed value.
Lock or unlock keyboard.
To enter in programming mode.
To return to room temperature display.
6. How to see the point:
Push and immediately release key, the point will be displayed;
Push and immediately release key, or wait 5 seconds to return to normal visualization.
7. How to change the point:
To change point value, push the key for more than 2 seconds;
the value of the point will be displayed and the
°
F or
°
C LED will start blinking.
To change value, push the or arrows.
To memorize the new point value, push the key again, or wait 10 seconds.
8. How to start a manual defrost:
Push key for more than 2 seconds, and a manual defrost will start.
9. How to change a parameter value:
Enter programming mode by pressing and keys;
°
F or
°
C LED starts blinking.
Select the required parameter. Press to display its value.
Use or to change its value.
Press to store the new value and move to the following parameter.
To exit press or wait 15 seconds without pressing a key.
NOTE: The value is stored even when exiting the procedure by waiting for the time-out to expire.
AUX
+
+
+
AUX
AUX
AUX

Page 9
10. To lock the keyboard:
Press for 3 or more seconds.
The "OFF" message will be displayed, and the keyboard will be locked.
11. To unlock the keyboard:
Press for 3 or more seconds until the "ON" message is displayed.
12. Alarm signaling:
P1
Room probe failure
Compressor output according to "'Cy" e "Cn"
P2
Evaporator probe failure
Defrost end is timed
HA
Maximum temperature alarm
Outputs unchanged
LA
Minimum temperature alarm
Outputs unchanged
EA
External alarm
Outputs unchanged
CA
Serious external alarm
All outputs OFF
DA
Door Open
Compressor and fans restarts
+
+
Culitek products have been modified precisely before
leaving factory. To avoid damaging compressor unit or
other malfunctions, users must not modify the
microcomputer parameters privately.

Page 10
ELECTRICAL CONTROL CIRCUIT DIAGRAMS
Refrigerator

Page 11
ELECTRICAL CONTROL CIRCUIT DIAGRAMS
Freezer

Page 12
ELECTRICAL CONTROL CIRCUIT DIAGRAMS
Three-Door Freezer

Page 13
TECHNICAL PARAMETERS
Bottom Mount Reach-Ins
NOTE: Technical data subject to changes

Page 14
OFFICIAL APPROVAL & RULES
Conforms to UL STD.471
Certified to CSA STD.C22.2 NO. 120
Conforms to NSF/AMSI STD. 7
