Cumberland FLX-5363 User manual

Automated Slide Gate
Models:
FLX-5363
FLX-5364
Installation Manual
PNEG-2280
Version 1.0
Date: 03-25-20
PNEG-2280

All information, illustrations, photos, and specifications in this manual are based on the latest
information available at the time of publication. The right is reserved to make changes at any
time without notice.
2PNEG-2280 Automated Slide Gate

Contents
Chapter 1 Safety Precautions ....................................................................................................................5
Safety Guidelines........................................................................................................................5
Cautionary Symbol Definitions......................................................................................................6
Safety Cautions...........................................................................................................................7
Safety Decals .............................................................................................................................9
Safety Sign-off Sheet.................................................................................................................10
Chapter 2 Installing the Automated Slide Gate ........................................................................................ 11
Part Numbers............................................................................................................................ 11
Assembling the Single Slide Gate Actuator Assembly ..................................................................12
Assembling the Twin Slide Gate Actuator Assembly.....................................................................14
Installing the Receiver Assembly ................................................................................................16
Installing the Actuator Assembly.................................................................................................18
Installing and Wiring the Local Module ........................................................................................22
Connecting the Gate to the Actuator ...........................................................................................24
Chapter 3 Wiring Diagrams......................................................................................................................27
Chapter 4 Parts List.................................................................................................................................31
Automated Slide Gate Assembly (FLX-5363 and FLX-5364).........................................................31
Actuator Assembly - Single (FLX-5365).......................................................................................32
Actuator Assembly - Twin (FLX-5366).........................................................................................34
Limited Warranty - Protein Products .......................................................................................37
PNEG-2280 Automated Slide Gate 3

NOTES
4PNEG-2280 Automated Slide Gate

1Safety Precautions
Topics Covered in this Chapter
▪ Safety Guidelines
▪ Cautionary Symbol Definitions
▪ Safety Cautions
▪ Safety Decals
▪ Safety Sign-off Sheet
Safety Guidelines
Safety guidelines are general-to-specific safety rules that must be followed at all times. This manual is
written to help you understand safe operating procedures and problems that can be encountered by the
operator and other personnel when using this equipment. Read and save these instructions.
As owner or operator, you are responsible for understanding the requirements, hazards, and precautions
that exist and to inform others as required. Unqualified persons must stay out of the work area at all
times.
Alterations must not be made to the equipment. Alterations can produce dangerous situations resulting in
SERIOUS INJURY or DEATH.
This equipment must be installed in accordance with the current installation codes and applicable regula-
tions, which must be carefully followed in all cases. Authorities having jurisdiction must be consulted
before installations are made.
When necessary, you must consider the installation location relative to electrical, fuel and water utilities.
Personnel operating or working around equipment must read this manual. This manual must be delivered
with equipment to its owner. Failure to read this manual and its safety instructions is a misuse of the
equipment.
ST-0001–4
PNEG-2280 Automated Slide Gate 5

Chapter 1: Safety Precautions
Cautionary Symbol Definitions
Cautionary symbols appear in this manual and on product decals. The symbols alert the user of potential
safety hazards, prohibited activities and mandatory actions. To help you recognize this information, we
use the symbols that are defined below.
Table 1-1 Description of the different cautionary symbols
Symbol Description
This symbol indicates an imminently hazardous situation which, if
not avoided, will result in serious injury or death.
This symbol indicates a potentially hazardous situation which, if not
avoided, can result in serious injury or death.
This symbol indicates a potentially hazardous situation which, if not
avoided, can result in minor or moderate injury.
This symbol is used to address practices not related to personal
injury.
This symbol indicates a general hazard.
This symbol indicates a prohibited activity.
This symbol indicates a mandatory action.
ST-0005–2
6PNEG-2280 Automated Slide Gate

Chapter 1: Safety Precautions
Safety Cautions
Use Personal Protective Equipment
• Use appropriate personal protective equipment:
Eye
Protection
Respiratory
Protection
Foot
Protection
Hearing
Protection
Head
Protection
Fall
Protection
Hand
Protection
• Wear clothing appropriate to the job.
• Remove all jewelry.
• Tie long hair up and back.
ST-0004–1
Follow Safety Instructions
• Carefully read all safety messages in this manual and safety
signs on your machine. Keep signs in good condition.
Replace missing or damaged safety signs. Be sure new
equipment components and repair parts include the current
safety signs. Replacement safety signs are available from
the manufacturer.
• Learn how to operate the machine and how to use controls
properly. Do not let anyone operate without instruction.
• If you do not understand any part of this manual or need
assistance, contact your dealer.
ST-0002–1
PNEG-2280 Automated Slide Gate 7

Chapter 1: Safety Precautions
Maintain Equipment and Work Area
• Understand service procedures before doing work. Keep
area clean and dry.
• Never service equipment while it is operating. Keep hands,
feet, and clothing away from moving parts.
• Keep your equipment in proper working condition. Replace
worn or broken parts immediately.
ST-0003–1
Lifting Hazard
• Single person lift can cause injury.
• Use a mechanical lifting device to lift or move the equipment
during installation.
ST-0021–2
Install and Operate Electrical Equipment Properly
• Electrical controls must be installed by a qualified electrician
and must meet the standards set by applicable local codes
(National Electrical Code for the US, Canadian Electric
Code, or EN60204 along with applicable European Direc-
tives for Europe).
• Lock-out power source before making adjustments, cleaning,
or maintaining equipment.
• Make sure all equipment is properly grounded.
ST-0027–4
Sharp Edge Hazard
• This product has sharp edges, which can cause serious
injury.
• To avoid injury, handle sharp edges with caution and always
use proper protective clothing and equipment.
ST-0036–2
8PNEG-2280 Automated Slide Gate

Chapter 1: Safety Precautions
Rotating Auger Hazard
• Keep clear of rotating augers and
moving parts.
• Do not remove or modify guards or
covers.
• Lock-out power source before making
adjustments, cleaning, or maintaining
equipment.
• Failure to follow these precautions will
result in serious injury or death.
ST-0037–1
Stay Clear of Slide Gate
• Keep hands away from slide gate opening. Slide gates can
crush and dismember. Motor can start at any time.
• Lock-out power source before making adjustments, cleaning,
or maintaining equipment.
ST-0049–1
Safety Decals
The safety decals on your equipment are safety indicators which must be carefully read and understood
by all personnel involved in the installation, operation, service and maintenance of the equipment.
Location Decal No. Decal Description
On side of the
rain cover DC-1248 Decal, Warning Slide Gate
On side of the
rain cover DC-1948 Decal, Danger Hi-Voltage
To replace a damaged or missing decal, contact us to receive a free replacement.
GSI Decals
1004 E. Illinois St.
Assumption, IL 62510
Tel: [phone]
PNEG-2280 Automated Slide Gate 9

Chapter 1: Safety Precautions
Safety Sign-off Sheet
Below is a sign-off sheet that can be used to verify that all personnel have read and understood the safety
instructions. This sign-off sheet is provided for your convenience and personal record keeping.
Date Employee Name Supervisor Name
ST-0007
10 PNEG-2280 Automated Slide Gate

2Installing the Automated Slide
Gate
Topics Covered in this Chapter
▪ Part Numbers
▪ Assembling the Single Slide Gate Actuator Assembly
▪ Assembling the Twin Slide Gate Actuator Assembly
▪ Installing the Receiver Assembly
▪ Installing the Actuator Assembly
▪ Installing and Wiring the Local Module
▪ Connecting the Gate to the Actuator
Part Numbers
Table 2-1 Slide gate assembly part numbers
Callout # Part # Description Callout # Part # Description
1 S-10658 1/2" x 2-3/4" clevis pin 23 BLK-10496 Transfer plate
2 GC03387 1-15/16" cotter pin 24 FLX-4671B Unloader assembly
3 S-7053 1/4" x 2-3/4" HHCS bolt 25 FLX-5367 Receiver assembly - Single
4 S-4336 5/16" x 1" MS screws FLX-5368 Receiver assembly - Twin
5S-8956 5/16" x 3/4" flange bolt 26 Weather caulking
6 S-8534 1/4" x 1-1/2" eye bolt 27 Alignment punches
7 S-7045 5/16" x 2" HHCS bolt 28 FLX-5393A Slide gate - Single
8 S-9247 1/2" x 2-1/4" clevis pin 29 FLX-5394A Left slide gate - Twin
9 S-6798 1/4" x 3/4" HHCS bolt 30 FLX-5394B Right slide gate - Twin
10 S-10529 1/4" x 1" round knob 31 Purple signal cable
11 Lock nut 32 Black cable (from actuator)
12 S-4337 5/16" nylon hex nut 33 FLX-5390 Housing cover
13 S-7356 5/16" ESNA nut 34 S-7974 Limit switch
14 D03-1329 Connector 35 Floor jack
15 FLX-5365 Actuator housing - Single 36 Chain
16 Actuator - Single 37 Module box
17 FLX-5425 Top mount - Single 38 Leg mounting bracket
18 Cable tie mounts 39 Tank leg
19 FLX-5366 Actuator housing - Twin 40 Conduit
20 Actuator - Twin 41 Limit switch wire
21 FLX-5427 Top mount - Twin 42 Lid
22 FLX-2195 16" black boot
FLX-2195-C 16" clear boot
PNEG-2280 Automated Slide Gate 11

Chapter 2: Installing the Automated Slide Gate
Assembling the Single Slide Gate Actuator Assembly
1. Insert the connector (14) to the bottom of the actuator housing (15) and secure it with a lock nut (11)
as shown.
Figure 2-1 Inserting the conduit connector
2. Unpack the actuator (16) and place it inside the actuator housing (15).
3. Secure the back end of the actuator (16) to the bracket at the rear of the actuator housing (15) using
a 1/2" x 2-3/4" clevis pin (1). Lock the clevis pin (1) with a cotter pin (2).
Figure 2-2 Securing the back end of the actuator
12 PNEG-2280 Automated Slide Gate

Chapter 2: Installing the Automated Slide Gate
4. Place the front end of the actuator (16) over the bracket at the middle of the actuator housing (15)
and secure in place with a top mount (17) using two 1/4" x 2-3/4" HHCS bolts (3).
Figure 2-3 Securing the front end of the actuator
5. Connect one wire to the bottom terminal and another one to the middle terminal of the limit switch
(34).
NOTE: The wire from the bottom terminal will be connected to the VCC and the wire from the middle
terminal will be connected to the LS1 of the local module.
6. Route the cable from the actuator (16) and wires from the limit switch (34) through the connector
(14) and pull out from the actuator housing (15).
NOTE: Use the cable tie mounts (18) to safely orient the wires inside the actuator housing (15).
Figure 2-4 Routing the actuator cable and limit switch wires
PNEG-2280 Automated Slide Gate 13

Chapter 2: Installing the Automated Slide Gate
Assembling the Twin Slide Gate Actuator Assembly
1. Insert the connectors (14) to the bottom of the actuator housing (19) and secure it with a lock nut
(11) as shown.
Figure 2-5 Inserting the conduit connectors
2. Unpack the actuators (20) and place it inside the actuator housing (19).
3. Secure the back end of the actuators (20) to the bracket at the rear of the actuator housing (19)
using one 1/2" x 2-3/4" clevis pin (1) per actuator. Lock each clevis pin (1) with a cotter pin (2).
Figure 2-6 Securing the back end of the actuators
14 PNEG-2280 Automated Slide Gate

Chapter 2: Installing the Automated Slide Gate
4. Place the front end of the actuators (20) over the bracket at the middle of the actuator housing (19)
and secure in place with a top mount (21) using two 1/4" x 2-3/4" HHCS bolts (3).
Figure 2-7 Securing the front end of the actuators
5. Connect one wire to the bottom terminal and another one to the middle terminal of the limit switch
(34).
NOTE: The wire from the bottom terminal will be connected to the VCC and the wire from the middle
terminal will be connected to the LS1 of the local module.
6. Route the cable from the actuator (20) and wires from the limit switch (34) through the connector
(14) and pull out from the actuator housing (19).
NOTE: Use the cable tie mounts (18) to safely orient the wires inside the actuator housing (19).
Figure 2-8 Routing the actuator cables and limit switch wires
7. Repeat the above three steps for the other side of the actuator housing (19) and pull out the cable
and wires through the connector (14) on that side.
PNEG-2280 Automated Slide Gate 15

Chapter 2: Installing the Automated Slide Gate
Installing the Receiver Assembly
What You Should Know
Steps 1-3 is for installing the slide gate assembly to the existing tanks. If you are installing the slide gate
assembly to the new tanks, skip steps 1-3 and begin at step-4.
1. Remove the ten 5/16" x 1" MS screws (4) and 5/16" nylon hex nuts (12) to detach the existing
transfer plate (23) from the boot (22).
Figure 2-9 Removing the existing transfer plate from boot
2. Lower the unloader assembly (24) to the ground carefully by using blocks or floor jack (35).
Figure 2-10 Lowering the unloader with support
16 PNEG-2280 Automated Slide Gate

Chapter 2: Installing the Automated Slide Gate
3. Remove the four 5/16" x 3/4" flange bolts (5) and 5/16" ESNA nuts (13) to detach the existing
transfer plate (23) from the unloader assembly (24) and discord the transfer plate (23).
Figure 2-11 Removing the existing transfer plate from unloader
4. Unpack the receiver assembly (25) and install it to the boot (22) using ten 5/16" x 1" MS screws (4)
and 5/16" nylon hex nuts (12).
IMPORTANT: Do not overtighten the nuts (12). It may result in cracking of the boot (22).
Figure 2-12 Installing the receiver assembly
PNEG-2280 Automated Slide Gate 17

Chapter 2: Installing the Automated Slide Gate
5. Reinstall the unloader assembly (24) to the receiver assembly (25) using four 5/16" x 3/4" flange
bolts (5) and 5/16" ESNA nuts (13).
Figure 2-13 Installing the unloader assembly
Installing the Actuator Assembly
What You Should Know
The difference between the single actuator housing assembly (A) and twin actuator housing assembly (B)
is the number of gates installed inside the actuator housing. Follow the below steps to install the single or
twin slide gate actuator assembly.
1. Install two 1/4" x 1-1/2" eye bolts (6), one to each side of the actuator housing assembly (A or B).
Figure 2-14 Installing the eye bolts
18 PNEG-2280 Automated Slide Gate

Chapter 2: Installing the Automated Slide Gate
2. Attach one end of the chain (36) to the eye bolt (6) and use the other end to form a loop around the
collar brace (46) with a S-hook (45). Repeat for other side and hang the actuator assembly (A or B).
NOTE:
a. Check for levelness from front to back and side to side.
b. Once level, secure the chain (36) to the collar braces (46) with a screw (43) and washer
(44).
Figure 2-15 Hanging the actuator housing assembly
3. Apply weather caulking (26) around the gate slot on the inside of the actuator housing assembly
(A or B).
Figure 2-16 Applying caulking around the gate slot
PNEG-2280 Automated Slide Gate 19

Chapter 2: Installing the Automated Slide Gate
4. Align the actuator housing assembly (A or B) to the receiver assembly (25) by inserting alignment
punches (27) to two holes at alternate locations.
5. Install the 5/16" x 2" HHCS bolts (7) and 5/16" ESNA nuts (13) to the other two holes with bolt head
on the outside of the actuator housing assembly (A or B). Hand tighten the bolts (7).
Figure 2-17 Aligning the actuator housing assembly with receiver assembly
6. Remove the alignment punches (27) and install remaining two 5/16" x 2" HHCS bolts (7) and 5/16"
ESNA nuts (13). Hand tighten the bolts (7).
7. Make sure the actuator housing assembly (A or B) is hanging level from the chains (36) and the
gates should slide through the opening.
NOTE: After making necessary adjustments, tighten all the hardware.
Figure 2-18 Installing the actuator housing assembly
20 PNEG-2280 Automated Slide Gate
