Cura1 iBeam 2721 User manual

Optional 2723 EzyStand
Tightening Nut
Cable Clips
Height
Adjustment
Lock
Magnet
2404 AC Adapter
(Optional)
Rear View
2721 iBeam
Screws
(supplied)
Double
sided tape
(supplied)
Mounting hardware
Mounting tape and screws
are supplied if you wish to
permanently mount the
iBeam to a fixture.
iBeam Bracket
UM-028d
2721 .
Optional Accessories (Sold Seperately)
2723 EzyStand, 3501 ActiveCare Pager, 3508 LED Pager,
2700 Six Channel Cordless Falls Monitor, 3500 ActiveCare
Console, 2544 Cordless Multiport Expander, 2549 Cordless
Multiport Expander Bracket Mount, 2404 Plug Pack
*The range of wireless devices and detection distance may vary and
be dependent on your specific environmental conditions.
cura¹ products are designed to augment well designed care programs
& practices, cura¹ does not claim that any of its products are suitable
as a substitute, or as a total solution for individuals that require care
and constant supervision & are at risk.
The 2721 iBeam has a narrow detection beam which detects
movement up to 6m* away, and a wireless range of approx.
30m*. Use in bedrooms, doorways, near stairs etc.
The narrow beam is especially useful if you have other people
in the same room who do not require movement detection or
where only a very specific area requires monitoring.
Front View
Antenna.
Extend fully
when in use.
Side View
Adjustable tilt can
be used when the
iBeam is located on
the ground or up
high.
1. Rotate the
iBeam in it’s
bracket 90 degrees
so that it is facing
the ceiling.
2. Apply gentle
pressure to one
arm of the
bracket so that
the iBeam can
easily pop out.
If you use screws to fix the iBeam bracket to a permanent
position, you will need to separate the iBeam and bracket
before you screw the bracket to a fixture.
To easily separate the iBeam from it’s bracket:
Detaching the iBeam from it’s mounting bracket
            
    
     
    
iBeam curtain window
Status LED flashes
red every 5 seconds
when motion detected.
Mode Selection
Switch - LOCAL, OFF
or SEND
PAUSE / RESET
Press this to pause
detection for 15 seconds or
to reset the device after a
detection.

1
QUICK START GUIDE
2721
Step
Insert 3 x AA alkaline batteries and / or
connect the 2404 Plug Pack.
Ensure iBeam is switched OFF.
Release the battery compartment cover by pressing the
compartment latch to the left and allowing it to lever open.
Insert 3 x AA batteries.
Connect a 2404 Plug Pack (optional) to the power socket on
the back.
3
4
Step
Optional Mounting
If the iBeam is to be used with a Pager (or any other
compatible cura1wireless receiving device) then it needs to be
paired with that device.
With the iBeam within range of the receiving device, put the
receiving device into Programming Mode (for instructions please
refer to the documentation that came with the receiving device).
To pair the iBeam with the receiving device, extend the antenna
fully and slide the main switch from OFF to SEND.
The iBeam should now be paired with the receiving device.
Now turn OFF the iBeam while completing any further
programming for other devices (if needed).
Step
Pair the iBeam with receiving device/s (if used).
The 2721 iBeam has an extremely narrow detection beam
allowing it to be positioned so that the detection area is very
precise.
Use in bedrooms, doorways, near stairs etc. Some positioning
suggestions are depicted below.
Turn on the iBeam and be sure to thoroughly test before use.
The LED illuminates red when movement is detected.
IMPORTANT - When testing, please wait 15 seconds
between activations. After it detects movement, the iBeam is
disabled for approximately 15 seconds before it can detect
movement again. During this time the STATUS light will flash
green rapidly.
5
Step
Position iBeam for desired detection area.
Back View
While the 2721 iBeam can be used free-standing on a bedside
table, or on the floor next to a bed, chair or door, it can also be
fixed in position with the included mounting adhesive pads and
/ or the included screws. PTO for information about securing the
iBeam to a fixture.
An optional EzyStand is also available which provides a sturdy,
height-adjustable base that can be repositioned as needed.
3500
ActiveCare
Console
3501 ActiveCare
Pager
(also 3508)
2700 Six
Channel Cord-
less Falls Monitor
2544 Cordless
Multiport Expander
(also 2549)
The iBeam can be paired with the following
cura1devices:
Push in to release battery
compartment cover.
Detection range
setting
Power socket for 2404
AC Adaptor (optional)
2
Step
Configure for standalone operation.
If the iBeam is to be used without any wireless alarm device
then move the Mode Selection Switch to the LOCAL position. In
LOCAL Mode, iBeam will emit an audible alarm when it detects
movement. Skip Step 3 and proceed to Step 4.
If the iBeam is to be used with a Pager or any other wireless
device then skip this step and proceed to Step 3.
Operation
LOCAL Mode - when movement is detected, iBeam will beep
and the status light will flash red every 5 seconds until the
RESET button is pushed.
SEND mode - when movement is detected, iBeam will
transmit a signal to paired devices and the status light will be
solid red for 15 seconds. iBeam will automatically reset itself.
The extremely narrow detection zone opens up many
innovative usage possibilities, compared with a typical PIR
sensor with a broad detection zone.
