Curtech CT-K35 User manual

35W Monocrystalline
Solar Panel Kit
User Manual

Installation
1. Remove solar panel kit from the box.
2. Fully extend battery lead and connect the battery clips to the +
positive (red) & - negative (black) battery terminals. Ensure that the
connection is secure.
3. Extend the leg to support the solar panel.
4. Locate in a clear sunlit area free from over hanging branches or
obstructions.
5. Place the solar panel kit facing the sun.
Note: To obtain maximum output it is suggested that the
panels’ angle be frequently adjusted to track the suns
movement through the day.
Operation
Charging Status indicator
Charge LED indicator is lit whenever sunlight is available for battery
charging.
Frequently Asked Questions
Q. Can I extend /lengthen the battery lead?
A. If the lead is extended this can result in a loss of voltage and
insufficient power transferred from the solar panels to charge the
battery.
Q. How do I clean the solar panel?
A. Dust & dirt should firstly be swept off the panel surface using a soft
brush and then use a wet cloth to wipe the panel surface to remove
remaining dirt & grime. It is recommended that any bird droppings be
removed as soon as possible as if left can cause damage to the
surface.

Trouble shooting if system does not function
Check all connections to ensure they are secure and free from moisture
& debris.
SC1205 PWM Solar Controller (see Manual enclosed)
Protection of solar charge controller
•Over-charge protection
•Over-discharge protection
•Reverse-current protection
•Over-load protection
Solar Panel Kit Specifications
Max
power
Max
power
voltage
Max
power
current
Open
circuit
voltage
Short
circuit
current
Dimensions
(mm)
Weight
35W
18.2V
1.92A
21.5V
2.13A
575x350x30
2.8kg
Solar Cell: Monocrystalline
Technical data on the solar panel kit can be found on the label on the
back of the solar panel.
Suitable for 12V Battery Charging.

1. Aluminium Frame
6. Cable
2. Aluminium Support Leg
7. Anderson Plugs
3. Solar Charge Controller
8. Battery Clips
4. Junction Box
9. Fuse
5. Label
WARNING
Solar panels produce power in sunlight.
Care should be taken to store the kit out of the sun.
Do not touch the positive and negative battery clips
together, short circuit and fire maybe caused.
