CYBEX Eagle Row Instruction Manual

Cybex Eagle®Row
Owner’s and Service Manual
Strength Systems
Part Number 11030-999 J
www.cybexinternational.com

Cybex Eagle®Row
Owner’s and Service Manual
Strength Systems
Part Number 11030-999 J
Cybex®and the Cybex logo are registered trademarks of Cybex International, Inc.
Eagle®and its mark are registered trademarks of Cybex International, Inc.
DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to
revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such
revisions or changes.
© Copyright 2010, Cybex International, Inc. All rights reserved.
Printed in the United States of America.
10 Trotter Drive Medway, MA 02053 • 508-533-4300 • FAX [phone]
www.cybexinternational.com • [email protected] • 11030-999 J • March 2010

1 Safety
Safety. . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Warning/Caution Decals . . . . . . . . . . . 1-2
Regular Maintenance Activities . . . . . . 1-5
Using Proper Form . . . . . . . . . . . . . . . 1-5
2 Exercises
General Exercise Guidelines. . . . . . . . 2-1
3 Customer Service
Contacting Service. . . . . . . . . . . . . . . . 3-1
Ordering parts . . . . . . . . . . . . . . . . . . . 3-1
Return Material Authorization (RMA). . 3-1
Damaged Parts . . . . . . . . . . . . . . . . . . 3-2
4 Assembly
Assembly . . . . . . . . . . . . . . . . . . . . . . . 4-1
5 Maintenance
Daily Procedures . . . . . . . . . . . . . . . . . 5-1
Weekly Procedures . . . . . . . . . . . . . . . 5-4
Yearly Procedures . . . . . . . . . . . . . . . . 5-6
Environment. . . . . . . . . . . . . . . . . . . . . 5-7
Storage . . . . . . . . . . . . . . . . . . . . . . . . 5-7
6 Service
Parts Lists . . . . . . . . . . . . . . . . . . . . . . 6-4
Exploded-View Diagram . . . . . . . . . . . 6-5
Table of Contents
Page i

Cybex Eagle 11030 Row Owner’s Manual
Safety
Page 1-1
Safety
Read the Owner’s Manual carefully before assembling, servicing or using the equipment.
It is the responsibility of the facility owner and/or owner of the equipment to instruct users on proper operation of the
equipment and review all labels.
WARNING: Serious injury could occur if these safety precautions are not observed:
User Safety Precautions
Obtain a medical exam prior to beginning an exercise program.•
Read and understand warning labels and user manual prior to exercising. Obtain instruction• prior to use.
Keep body and clothing free from and clear of all moving parts.•
Inspect machine prior to use.• DO NOT use if it appears damaged or inoperable.
DO NOT• attempt to fix a broken or jammed machine. Notify floor staff.
Use the machine only for the intended use.• DO NOT modify the machine.
Be sure that the weight pin is completely inserted. Use only the pin provided by the manufacturer.• If unsure seek assistance.
Never pin the weights in an elevated position.• DO NOT use the machine if found in this condition.
See assistance from floor staff.
Children must not be allowed near these machines. Teenagers must be supervised.•
DO NOT• use if guards are missing or damaged.
DO NOT• use dumbbells or other incremental weights, except those provided by the manufacturer.
Inspect all cables and belts and connections prior to use.• DO NOT use if any components are worn, frayed or
damaged.
DO NOT• remove any labeling from equipment. Replace any damaged labels.
Stop exercising if you feel faint, dizzy or experience pain at any time while exercising and consult your• physician.
Facility Safety Precautions
Read the Owner’s Manual carefully before assembling, servicing or using the equipment.•
Securely anchor each machine to the floor using the anchor holes provided in each machine.•
NOTE: Cybex is not responsible for the actual anchoring of equipment. Consult with a professional
contractor.
NOTE: Use fasteners having a minimum of 500 lbs. tensile capacity (3/8” grade 2 bolts or better).
NOTE: If legs/frame does not contact surface, DO NOT pull down with anchors. Shim any
leg or frame not in contact with surface using flat washers.
1 - Safety

Cybex Eagle 11030 Row Owner’s Manual
Safety
Page 1-2
Make sure that each machine is set up and operated on a solid level surface.• Do not install equipment on an
uneven surface.
Make sure that all users are properly trained on how to use the equipment.•
Make sure there is enough room for safe access and operation of the equipment.•
Perform regular maintenance checks on the equipment. Also pay close attention to all areas most susceptible to wear,• including (but not limited to) cables, pulleys, belts and grips.
Immediately replace worn or damaged components. If unable to immediately replace worn or damaged components• then remove from service until the repair is made.
Use only Cybex supplied components to maintain/repair the equipment.•
Keep a repair log of all maintenance activities.•
Inspect all cables and belts and connections prior to use.• DO NOT use if any components are worn, frayed or
damaged.
NOTE: It is the sole responsibility of the user/owner or facility operator to ensure that regular maintenance is performed.
Safety Guidelines And Practices
Cybex recommends that all fitness equipment be used in a supervised area. It is recommended that the equipment be
located in an access controlled area. Control is the responsibility of the owner. The extent of control is at the discretion of
the owner.
It is the responsibility of the purchaser/user of Cybex products to read and understand the owner’s manual, and warning
labels; as well as instruct all individuals, whether end users or supervising personnel, on proper usage of the equipment.
PROPER USAGE:
Use machine only as described in the manual. Failing to follow proper instructions may result in injury.
Do Not Lean Against or Pull On the framework, weight stack, or any component, whether machine is at rest or in use.
Inappropriate or improper use may result in injury to users or third parties (bystanders).
Do not use machine if it is not located on a solid level surface or is improperly installed.
Provide an adequate safety perimeter between the machine, walls and other equipment to ensure that the facility has the
proper clearance for usage and training.
SECURING EQUIPMENT:
The machine has holes in the feet, which allow for ease in anchoring to the floor. Cybex strongly recommends that,
to eliminate rocking, tipping or falling over due to incorrect usage and misuse, equipment be secured to a solid, level
surface.
1. The solid, level surface should not deviate more than 1/8” over a 10’ distance or as defined and required by local
building and architectural codes.
2. Anchoring of equipment must be completed by a qualified licensed contractor.

Cybex Eagle 11030 Row Owner’s Manual
Safety
Page 1-3
3. Anchoring holes are provided on the feet of the frame. All anchoring locations must be used when anchoring the
equipment to the floor.
4. Due to the wide variation of flooring on which machines may be anchored or installed, verify anchoring method and
anchoring fasteners with a qualified and licensed contractor.
5. A minimum pull out force of 220 lbs/100 kgs is required for each anchor position..
6. Do not use machine until it is properly anchored.
MAINTENANCE:
Preventative maintenance allows proper equipment operation and reduces the risk of injury. Perform the maintenance
requirements as specified in the manual.
STANDARD COMPLIANCE:
Cybex products meet or exceed applicable ASTM and EN Standards.
Warning/Caution Decals
Warning decals indicate a potentially hazardous situation, which, if not avoided, could result in death or serious injury.
Caution decals indicate a potentially hazardous situation, which, if not avoided, could result in minor or moderate injury.
The warning and caution decals are shown on the following page. The diagrams following the decals show where each
decal is located.

Cybex Eagle 11030 Row Owner’s Manual
Safety
Page 1-4
4605-381-4 A
A
Personal injury may occur.
CAUTION
4000Y316-4
Keep away from moving
parts to avoid injury.
4520-362-4
Seat may fall if
improperly engaged.
Verify seat is secure
before exercising to
avoid injury.
CAUTION
B
C

Cybex Eagle 11030 Row Owner’s Manual
Safety
Page 1-5
Row - 11030
Warning DecalA. ..............4605-381-4
Caution DecalB. ...............4000Y316-4
Caution DecalC. ...............4520-362-4
DESCRIPTION PART NO.
A
B
B
B
B
C

Cybex Eagle 11030 Row Owner’s Manual
Safety
Page 1-6
Regular Maintenance Activities
Preventative maintenance activities must be performed to maintain normal operation of your equipment.
Keeping a log sheet of all maintenance actions will assist you in staying current with all preventative
maintenance activities. The preventative maintenance actions are described in detail in Chapter 5.
Briefly, they include:
Daily
Clean upholstery.1.
Weekly
Inspect all nuts and bolts for looseness. Tighten as required.1.
Inspect all cables and belts for damage or wear (see Chapter 5).2. If a cable or belt is worn or
damaged, immediately discontinue use until cable or belt has been replaced.
Check for worn handles, worn snap links, and worn warning labeling. Replace all worn parts3. immediately.
Inspect for loose or worn grips. Replace all loose or worn grips immediately.4.
Inspect weight stacks for proper alignment and operation. Correct all improper alignmentand5. operation issues immediately.
Lubricate guide rods using automotive engine oil only.6.
Yearly
Replace all cables and belts at least annually.1.
Using Proper Form
Before working out, read and understand the exercises located on the placard and in Chapter 2.

Exercise
Page 2-1
Cybex Eagle 11030 Row Owner’s Manual
2 - Exercise
Intended Use
The intended use of this equipment is to aid or
improve general physical fitness and exercise.
For Commercial use.
Instructions
Read and understand all instructions and warnings
prior to using this machine. See Chapter 1, Safety in
the Eagle Owner’s Manual or consult with floor staff.
NOTE: Do not turn knob when weight stack is elevated
NOTE: All adjustment points on the machine have yellow handles or knobs.
NOTE: See next page for “Set Up” and “Movement”.
MUSCLES USED
Lattisimus Dorsi, Teres Major, Biceps,
Middle Trapezius, Rear Deltoid,
Rhomboideltoid
START FINISH
NOTE: Motion Developed: Shoulder Extension, Elbow Flexion

Exercise
Page 2-2
Cybex Eagle 11030 Row Owner’s Manual
Set Up
1. Adjust chest pad to allow comfortable reach of handles.
2. Grasp handles with hands in front of and level with the shoulders.
Movement
1. Pull the handles towards you until your elbows are at your sides.

Cybex Eagle 11030 Row Owner’s Manual
Customer
Service
Page 3-1
3 - Customer Service
Contacting Service
Hours of phone service are Monday through Friday from 8:30 to 6:00 p.m. Eastern Standard Time.
For Cybex customers living in the USA, contact Cybex Customer Service at 888-462-9239.
For Cybex customers living outside the USA, contact Cybex Customer Service at 508-533-4300
or fax [phone].
Find information on the web at www.cybexintl.com or by e-mail at [email protected].
Ordering Parts
Fax order to 508-533-5183. To speak with a customer service representative, call 888-462-9239 (for customers
living within the USA) or 508-533-4300 (for customers outside the USA). You may also contact us through e-mail
at [email protected]
Having the following information ready when calling will assist our Cybex representatives in serving you.
Unit Serial Number
• Product Name•
The unit serial number and product name can be found on the serial number decal. See Chapter 6 for exact
location of serial number decal.
Part Description• Part Number•
Part descriptions and part numbers are located in Chapter 6 of this manual.
Shipping Address
• Contact Name•
Return Material Authorization (RMA)
In addition to your shipping address and contact name, your account number is helpful but not required.
The Return Material Authorization (RMA) system outlines the procedures to follow when returning
material for placement, repair or credit. The system assures that returned materials are properly handled and
analyzed. Follow the following procedures carefully.
Contact your authorized Cybex dealer on all warranty-related matters. Your local Cybex dealer will request a RMA
from Cybex, if applicable. Under no circumstances will defective parts or equipment be accepted by Cybex without
proper RMA and an Automated Return Service (ARS) label.

Cybex Eagle 11030 Row Owner’s Manual
Customer
Service
Page 3-2
1. Call the Customer Service Hot Line listed above for the return of any item that is defective.
2. Provide the technician with a detailed description of the problem you are having or the defect in the
item you wish to return.
3. Provide the model and serial number of your Cybex equipment.
4. At Cybex’s discretion, the technician may request that you return the problem part(s) to Cybex for
evaluation and repair or replacement. The technician will assign you a RMAnumber and will send
you an ARS label. TheARS label and the RMA numbers must be clearly displayed on the outside
of the package that contains the item(s) to be returned. Include the description of the problem, the
serial number of the equipment and the name and address of the owner in the package along with
the part(s).
5. Forward the package through UPS to Cybex.
Attn: Customer Service Department
Cybex International, Inc.
1975 24th Ave SW
Owatonna, MN 55060
NOTE: Merchandise returned without an RMA number on the outside of the package or shipments sent
COD will not be accepted by the Cybex receiving department.
Materials damaged in shipment should not be returned for credit. Shipping damages are the responsibility
of the carrier (UPS, Federal Express, trucking companies, etc.)
Apparent Damage - Upon receipt of your shipment, check all items carefully. Any damage seen with a
visual check must be noted on the freight bill and signed by the carrier’s agent. Failure to do so will result
in the carriers refusal to honor your damage claim. The carrier will provide you with the required forms for
filing such claims.
Concealed Damage - Damage not seen with a visual check upon receipt of a shipment but
notices later must be reported to the carrier as soon as possible. Upon discovery of the
damage, a written or phone request to the carrier asking them to perform an inspection of the materials
must be made within ten days of the delivery date. Keep all shipping containers and packing materials as
they will be needed in the inspection process. The carrier will provide you with an inspection report and
the necessary forms for filing a concealed damage claim.
Concealed damage claim is the carrier’s responsibility.
Damaged Parts

Cybex Eagle 11030 Row Owner’s Manual
Assembly
Page 4-1
4 - Assembly
TOOLS REQUIRED
7/32” Allen wrench• 3/4” Allen wrench• 9/16” Wrench• External snap ring pliers• Phillips screwdriver• Medium weight automotive engine oil• Torque Wrench•
NOTE: Two people will be required for this procedure.
NOTE: It is the responsibility of the facility owner/owner of the equipment to ensure that
there is appropriate clearance around each machine to allow for safe use and passage.
1. Read and understand all instructions thoroughly before starting any of the procedures
listed on this instruction sheet.
2. Verify you have received the appropriate configuration.
Verify that you received the correct color machine that you ordered.A.
Verify you received weight plates and weight plate decals.B.
Verify you received the Cybex Eagle Row Owner’s Manual.C.
Verify you received the warranty sheet.D.
3. Move to desired location.
Note the diminsions of the machine:A. Idle - 54 L x 58 W x 72 H inches
137.16 L x 147.32 W. x 182.88 H cm
In use - 54 L x 58 W x 72 H inches
137.16 L x 147.32 W. x 182.88 H cm
Machine Weight with weight stack - 736 lbs. (333.84 kg)
Determine if you can move your machine through the required doorway(s).B.
If the machine fits through the the doorway(s), move machine to desired location and skip to step 5.C.
If weight stacks need to be installed proceed to step 6.D.
If the machine does not fit through the door-way(s) then see step 4.E.
4. Doorway Instructions.
NOTE: If your machine fits through the doorway then skip step 4.
If your machine does not fit through the doorway, then perform step 4.
Carefully remove each (standard) cone-shaped shipping support using a 3/4” socket or wrench.A.
Make a note of the current belt routings and connections. This will assist you in reinstalling them properly.B.

Cybex Eagle 11030 Row Owner’s Manual
Assembly
Page 4-2
Cut shipping tie securing top weight.C.
Rotate cam and disconnect weight stack belt from camD. (by loosening the two set screws on the belt clamp with a
7/32” Allen wrench). See Figure 1.
Locate the pulley bracket that is located near the cam.E. See Figure 2.
Remove bolt, washer and hex nut securing the pulley toF. the pulley bracket.
Remove pulley from pulley bracket.G.
Using a Phillips screwdriver, remove the two screws securing theH. cam cover plate (guard) and remove the plate. See Figure 3.
At the opposite end of the pivot shaft (from step 4H),I. locate the small plate shown in Figure 4.
Using a 7/32” Allen wrench, remove the two BHSCSJ. securing the small plate and remove the plate.
Remove one of the two BHSCS securing the pivot shaft.K. See Figure 5.
Carefully remove pivot shaft. See Figure 5.L. NOTE: Be
extremely careful when removing shaft so you don’t ruin
the threads on the shaft.
Rotate cam so that the flat part is facing down.M.
Carefully slide pulley shaft out of machine.N.
Figure 2
Hex Nut/Washer
Bolt
Figure 3
Cam Cover Plate
Screw
Figure 5
BHSCS
Pivot Shaft
Washer Pulley Shaft
Pulley/Cable
Figure 4
Small Plate
BHSCS (2)
Pulley
Bracket
Figure 1
Set
Screws
Cam

Cybex Eagle 11030 Row Owner’s Manual
Assembly
Page 4-3
With an assistant, carefully remove the six BHSCSO. securing the two halves of the frame. See Figure 6.
Carefully lay the taller half of the frame down on theP. floor until you are ready to move it.
Carefully move each half through the door-way to theQ. desired location. Again, lay the taller half of the frame
down on the floor until you are ready to reattach the two
halves.
With an assistant, carefully attach each half togetherR. using the six BHSCS removed in step 4O. See Figure 6.
With the flat part facing down, carefully slide the pulleyS. shaft back into the machine (removed from steps 4M
and 4N).
Carefully slide the pivot shaft through the pulley shaftT. (removed from steps 4K and 4L).
Secure the pivot shaft using the BHSCS removed inU. step 4K.
Reconnect the pulley to the pulley bracket (removed inV. steps 4F and 4G).
Verify the two belts are routed properly (one belt connecting from the cam toW. the pulley bracket and the other belt connecting from the pulley to the arms).
Connect the weight stack belt to the belt clamp of cam (removed in step 4D).X. See Figure 1.
Continue on with Step 5C.Y.
5. Remove shipping feet and remove the back shrouds.
Carefully remove each (standard) cone-shapedA. shipping support using a 3/4” socket or wrench.
Cut shipping tie securing top weight.B.
Carefully place rubber feet (supplied with machine)C. on each foot of the frame.
Lift top weight and turn the Increment WeightAdjusting Knob to select all 15 lbs. (three increment weightsD. each side).
Remove the three Phillips head screws securing the top (back) shroud and carefully remove the shroud.E. See Figure 7.
Loosen bottom two screws shown in Figure 8.F. NOTE: Do not remove the bottom two screws.
Remove the top two screws securing the back shroud. See Figure 9.G.
Carefully slide rear shroud assembly upward and remove.H.
Figure 7
Phillips Head
Screw (3)
Figure 6
BHSCS (qty 6)
Nylon Locknut (6)
Figure 8
Screw (loosen -
do not remove)
Figure 9
Screw

Cybex Eagle 11030 Row Owner’s Manual
Assembly
Page 4-4
6. Install the weight stack.
Note how the increment weights are installed.A.
With an assistant holding the increment weights,B. move the adjusting knob to 0 lbs. and remove all six
increment weights (three each side).
Using an external snap ring pliers, remove the upperC. snap ring from one of the guide rods and carefully lower
the guide rod. See Figure 10.
Remove lower snap ring and wave washer from the guide rod. Repeat steps 6C and 6D to removeD. both snap rings from other guide rod.
If possible, lean guide rods outward, away from machine in order to provide the most room forE. installing weight plates.
Carefully slide top weight/second plate up and out of machine and carefully set it aside.F.
Wipe guide rods clean over entire length. Lubricate with light coating of medium weight automotive engine oil.G.
Carefully install each weight plate one at a time.H. NOTE: When installing weight plates, position plates
so wide edges of bushing face upward and narrow edges of bushing face downward. See Figures 11A
and 11B.
Carefully slide the top weight/second plate onto the guide rods.I.
Place lower snap ring and wave washer onto guide rod (about 3” from the top end of guide rod).J.
Raise guide rod up through mounting hole and install the upper snap ring.K.
Lower guide rod and secure lower snap ring. Repeat steps 6J - 6L for the other guide rod.L.
Figure 10
Upper snap ring
Lower snap ring
Frame
Guide rod
Wave washer
NARROW
bushing edge
WRONG
WIDE bushing
edge faces
upward
CORRECT
NOTE: The narrow bushing
edge must face downward.
Figure 11A Figure 11B
