Cybex®Free Weight 45° Back Extension
Owner’s and Service Manual
Strength Systems
Part Number 16021-999-4 B
www.cybexinternational.com

Cybex®Free Weight 45° Back Extension
Owner’s and Service Manual
Strength Systems
Part Number 16021-999-4 B
Cybex®and the Cybex logo are registered trademarks of Cybex International, Inc.
DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to
revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such
revisions or changes.
© Copyright 2010, Cybex International, Inc. All rights reserved. Printed in the United States of America.
10 Trotter Drive Medway, MA 02053 • 508-533-4300 • FAX [phone]
www.cybexinternational.com • [email protected] • 16020-999-4 B • June 2010

1 Safety
Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Warning/Caution Decals . . . . . . . . . . . . . 2
Regular Maintenance Activities . . . . . . . . 3
2 Exercise
Intended Use . . . . . . . . . . . . . . . . . . . . . . 3
3 Customer Service
Contacting Service. . . . . . . . . . . . . . . . . . 4
Ordering parts . . . . . . . . . . . . . . . . . . . . . 4
Return Material Authorization (RMA). . . . 5
Damaged Parts . . . . . . . . . . . . . . . . . . . . 5
4 Assembly
Tools Required. . . . . . . . . . . . . . . . . . . . . 6
5 Maintenance
Daily Procedures . . . . . . . . . . . . . . . . . . . 7
Weekly Procedures . . . . . . . . . . . . . . . . . 7
6 Service
Parts Lists . . . . . . . . . . . . . . . . . . . . . . . 10
Exploded-View Diagram . . . . . . . . . . . . 10
Table of Contents
Page i

Page 1
Cybex Free Weight 16021 45° Back Extension Owner’s Manual
1 - Safety
Safety
Read the Owner’s Manual carefully before assembling, servicing or using Cybex equipment.
WARNING: Serious injury could occur if these safety precautions are not observed:
User Safety Precautions
Obtain a medical exam before beginning any exercise program.•
Stop exercising if feeling faint, dizzy or experiencing pain and consult your physician.•
Obtain instructions before using. Lisez les instructions avant I’untilisation.•
Read and understand the owner’s manual and all warnings posted on the machine before using• .
Keep all children (12 and under) away. Teenagers (13 and over) and disabled must be supervised.•
Garder tous les enfants (de 12 ans et moins) éloignés. Les adolescents (de 13 ans et plus) et les
handicapés doivent être surveillés.
Use a spotter.•
Keep body and clothing free from and clear of all moving parts.•
Use the machine only for the intended use.• DO NOT modify the machine.
Inspect machine prior to use.• DO NOT use if it appears damaged or inoperable.
DO NOT• attempt to fix a broken or jammed machine.
Report any malfunctions, damage or repairs to the facility• .
Replace any warning labels if damaged, worn or illegible.•
Facility Safety Precautions
Read the Owner’s Manual carefully before assembling, servicing or using this• equipment.
Make sure that each machine is set up and operated on a solid level surface.• Do not install
equipment on an uneven surface.
Make sure that all users are properly trained on how to use this equipment.•
Make sure there is enough room for safe access and operation of this equipment.•
Perform regular maintenance checks on this equipment. Also pay close attention to• all areas most susceptible to wear.
Immediately replace worn or damaged components. If unable to immediately replace worn or• damaged components then remove from service until the repair is made.
NOTE: It is the sole responsibility of the user/owner or facility operator to ensure that regular
maintenance is performed.

Page 2
Cybex Free Weight 16021 45° Back Extension Owner’s Manual
Warning/Caution Decals
Warning decals indicate a potentially hazardous situation, which, if not avoided, could result in death
or serious injury.
Caution decals indicate a potentially hazardous situation, which, if not avoided, could result in minor
or moderate injury.
The caution and warning decals are shown on this page.
45° Back Extension - 16021
A
A. Warning Decal...................5220-364-4
B. Caution Decal....................8500-025-4
DESCRIPTION PART NO.
A
B
B

Page 3
Cybex Free Weight 16021 45° Back Extension Owner’s Manual
Regular Maintenance Activities
Preventative maintenance activities must be performed to maintain normal operation of this equipment.
Keeping a log sheet of all maintenance actions will assist you in staying current with all preventative
maintenance activities.
WARNING: Equipment found to have worn or damaged components must be removed
from service until repair(s) is made. Failure to do so could result in injury.
Daily
1. Clean upholstery.
Weekly
1. Inspect all nuts and bolts for looseness. Tighten as required.
2. Check for worn handles, and worn warning labeling. Replace all worn parts immediately.
2 - Exercise
Intended Use
The intended use of this equipment is to aid or improve general physical fitness and exercise. For Comercial use.
Before you workout
Prior to starting a training program, get a complete physical exam to make sure your physician agrees that you are
ready. Always warm-up your muscles before a workout.A 5 - 10 minute cardio warm-up followed by slow stretching
(no bouncing) is recommended. Continue with a lighter set (50% of normal) of intended exercises. Start your program
conservatively. Choose weights you can easily lift in the first weeks. Always perform the full range of motion unless
you have an injury, then consult a professional trainer. Know the terms. A “repetition” (rep) is defined as one complete
movement through an exercise, returning to the start position. A “set” is a continuous series of reps usually between
6-15.
During your workout
The number of reps you perform in a set depends on your goal. To build muscle and strength, do fewer reps
(6 - 8) with heavier weight. To build endurance, do more reps (12-15) with lighter weight. Never “cheat” by shortening
the range of motion, bouncing the weight, or shifting your posture. This may allow you to lift more weight, but it is
dangerous and less effective. Catch your breath between sets, then continue. When “circuit training” move briskly
to the next exercise; when doing multiple sets on one exercise, rest 45 - 90 seconds before the next set. Work up to
three sets per exercise. When you can perform the desired reps and sets for any exercise, increase the weight by a
half or full plate.
Designing your workout
Circuit training is a good way to start. This involves doing one set per exercise, then moving to the next exercise,
pausing only briefly between them (to keep your heart and breath rate up) until completing a balanced “circuit” of 8 -
10 exercises for your entire body. Then repeat the circuit.After several weeks, you can move into multiple sets (3 in
a row) per exercise if you choose. For both of these, exercise the complete body every other day, up to three times a
week. NOTE: A full day’s rest, plus proper nutrition and hydration are required for optimum muscle-building or toning.
Alternatively, work out half your body one day (e.g., the upper body) and the other half the following day (e.g. the
lower body). At the end of your workout, cool down in a similar way to your warm-up.

Page 4
Cybex Free Weight 16021 45° Back Extension Owner’s Manual
Ordering Parts
Fax orders to 508-533-5183. To speak with a customer service representative, call 888-462-9239 (for customers living
within the USA) or 508-533-4300 (for customers outside the USA). You may also contact us through e-mail at techhelp@
cybexintl.com
Having the following information ready when calling will assist our Cybex representatives in serving you.
Unit Serial Number•
Product Name•
The unit serial number and product name can be found on the serial number decal. See Chapter 6 for exact location of
serial number decal.
Part Description•
Part Number•
Part descriptions and part numbers are located in Chapter 6 of this manual.
Shipping Address•
Contact Name•
In addition to your shipping address and contact name, your account number is helpful but not required.
3 - Customer Service
Contacting Service
Hours of phone service are Monday through Friday from 8:30 to 6:00 p.m Eastern Standard Time.
For Cybex customers living in the USA, contact Cybex Customer Service at 888-462-9239.
For Cybex customers living outside the USA, contact Cybex Customer Service at 508-533-4300 or fax [phone].
Find information on the web at www. cybexintl.com or e-mail at [email protected].

Page 5
Cybex Free Weight 16021 45° Back Extension Owner’s Manual
Return Material Authorization (RMA)
The Return Material Authorization (RMA) system outlines the procedures to follow when returning
material for placement, repair or credit. The system assures that returned materials are properly handled and
analyzed. Follow the following procedures carefully.
Contact your authorized Cybex dealer on all warranty-related matters. Your local Cybex dealer will request a RMA
from Cybex, if applicable. Under no circumstances will defective parts or equipment be accepted by Cybex without
proper RMA and an Automated Return Service (ARS) label.
1. Call the Customer Service Hot Line listed above for the return of any item that is defective.
2. Provide the technician with a detailed description of the problem you are having or the defect in the item you
wish to return.
3. Provide the model and serial number of your Cybex equipment.
4. At Cybex’s discretion, the technician may request that you return the problem part(s) to Cybex for evaluation
and repair or replacement. The technician will assign you a RMAnumber and will send you an ARS label. The
ARS label and the RMA numbers must be clearly displayed on the outside of the package that contains the
item(s) to be returned. Include the description of the problem, the serial number of the equipment and the name
and address of the owner in the package along with the part(s).
5. Forward the package through UPS to Cybex.
Attn: Customer Service Department
Cybex International, Inc.
1975 24th Ave SW
Owatonna, MN 55060
NOTE: Merchandise returned without an RMA number on the outside of the package or shipments sent COD
will not be accepted by the Cybex receiving department.
Damaged Parts
Materials damaged in shipment should not be returned for credit. Shipping damages are the responsibility of the carrier
(UPS, Federal Express, trucking companies, etc.)
Apparent Damage - Upon receipt of your shipment, check all items carefully. Any damage seen with a visual check must
be noted on the freight bill and signed by the carrier’s agent. Failure to do so will result in the carriers refusal to honor your
damage claim. The carrier will provide you with the required forms for filing such claims.
Concealed Damage - Damage not seen with a visual check upon receipt of a shipment but notices later must be reported
to the carrier as soon as possible. Upon discovery of the damage, a written or phone request to the carrier asking them to
perform an inspection of the materials must be made within ten days of the delivery date. Keep all shipping containers and
packing materials as they will be needed in the inspection process. The carrier will provide you with an inspection report
and the necessary forms for filing a concealed damage claim. Concealed damage claim is the carrier’s responsibility.

Page 6
Cybex Free Weight 16021 45° Back Extension Owner’s Manual
4 - Assembly
Tools Required
Rubber mallet• Flat head screwdriver•
Plastic shipping foot glides are used on Cybex Strength Systems machines to protect the bottom of machines
during transportation. These foot glides must be removed before a machine is first placed in service as the shipping
foot glides may cause the machine to be unstable.
WARNING: Failure to remove shipping foot glides before placing a machine in service may cause the machine
to be unstable, therefore, creating potential for personal injury or product damage.
NOTE: Failure to remove shipping foot glides before placing a machine in service may void warranty on the frames.
REMOVING FOOT GLIDES
NOTE: Be careful not to damage frame (such as chipping the paint) when removing foot glides.
NOTE: The foot of the machine will need to be raised slightly off the floor in order to remove foot
glide. Do not install weight stack (if applicable) until after removing foot glides.
1. Using a rubber mallet, carefully strike foot glide.
2. With a flat blade screwdriver, carefully pry off foot glide.
3. Carefully place rubber feet (supplied with machine) on each foot of the frame.
4. Carefully Install grips (if required) part number 16030-309, see exploded view for location.
45° Back Extension - Product No.16021
Total Weight and Size
Weight: 106 lbs. Size 30 W” x 58” L x 32” H
Weight: 48 kgcm. Size 76 cm W x 147 cm L x 81 cm H

Page 7
Cybex Free Weight 16021 45° Back Extension Owner’s Manual
5 - Maintenance
All preventive maintenance activities must be performed on a regular basis. Performing routine preventive
maintenance actions can aid in providing safe, trouble-free operation of all Cybex Strength Systems equipment.
NOTE: Cybex is not responsible for performing regular inspection and maintenance actions for your machines.
Instruct all personnel in equipment inspection and maintenance actions and also in accident
reporting/recording. Cybex phone representatives are available to answer any questions or concerns
that you may have.
1. Upholstery - Wipe down all upholstery.
2. Frames - Wipe down all frames using a mild solution of warm water and car wash soap. Be sure to dry thoroughly.
AVOID acid or chlorine based cleaners and also cleaners containing abrasives as these could scratch or
damage the equipment.
3. Chrome - Clean chrome tubes, first using chrome polish and then using a car wax seal. Neutral cleaners
with a pH between 5.5 and 8.5 are recommended. Be sure to dry thoroughly. AVOID acid or chlorine based
cleaners and also cleaners containing abrasives as these could scratch or damage the equipment.
1. Inspect all nuts and bolts for looseness. Tighten as required
2. Inspect all labeling for readability. This includes instructional placards, warning and
caution decals. Replace all worn labeling immediately.
Weekly Procedures
Daily Procedures

Page 8
Cybex Free Weight 16021 45° Back Extension Owner’s Manual
This page intentionally left blank

Cybex Free Weight 16021 45° Back Extension Owner’s Manual
Page 9
Please refer to the next page for parts lists and exploded-view diagrams
6 - Service
Cybex will void warranty if
non-Cybex replacement parts
are used.
NOTE: All inspections
and repairs must be
performed by trained
service personnel only.
Free Weight 45° Back Extension
PRODUCT NO. 16021
NOTE: See exploded-view diagram for location of A (warning decal)
and E (serial number decal)
A. Warning Decal......................5220-364
B. Caution Decal......................8500-025
C. Pad W/Wear cover...............4800-416
D. Wear Cover..........................4800-419
E. Serial Number Decal
DESCRIPTION PART NO.
D
C
B

Cybex Free Weight 16021 45° Back Extension Owner’s Manual
Page 10
SERIALDECAL
SEE DECAL
LOCATION DETAIL
23
28
28
23
9
16
30
31
31
34
30
31
34
30
417
17
4
24 3
24
3
7
22
14
13
19
8
12
2
1
29
29
11
23
32
26 27
27
26
21
21
15
15
5
39
37
6
5
35 36
SEE LOCK KNOB
DETAIL
37
40
1 1 08229 PIN,DETENT
2 1 11040-440 KNOB
3 2 11090-374 END CAP
4 2 11090-376 RING, HANDLE GRIP
5 2 12090-322 FOOT PAD
6 2 16010-311 FOOT PAD
7 1 16021-200 FRAME
8 1 16021-201 HANDLE
9 1 16020-202 CUSHION PLATE
10 1 16020-322 PUSH PUCK
11 1 16020-323 SHAFT, PIVOT
12 2 16020-325 NON-SLIP
13 1 16060-311 PLASTIC GUIDE
14 1 16060-315 PLASTIC GUIDE
15 2 3900-447 DECAL, CYBEX BLACK
15 2 3900-448 DECAL, CYBEX SILVER
16 1 4505-331 BUMPER, 1.50 DIA
17 2 4605-524 GRAB GRIP 10.25
18 1 51198 WARRANTY BOOK
19 1 BS070201 COM SPRING .56 x .66 1.50 LG
20 CM000211 DECAL, PATENT PENDING
(REMOVED 7/6/09)
ITEM QTY PART NO. DESCRIPTION
*Language Key
1-German , 2-French, 3-Spanish, 4-English,
6-Japanese, 7- Swedish, 8- Russian
21 2 FB130211 BRG FLG 17MM X 19MM X 12MM
22 1 HC622808 SHCS .250-20 X .250
23 3 JC700412 BHSCS .375-16 X .50
24 2 HF449063 INSERT 3/4 X 1/4-20
25 1 HM532812 SHCS .138-6-32 x .50 GR 8
26 2 HM583208 10-32 X .25 LG
27 2 HP286810 SPRING PIN .188 X .37 LG
28 2 HS347600 WASHER, SAE .375
29 2 JC620422 BHSCS .250-20 x 1.50
30 4 JC700420 BHSCS .375-16 X 1.25
31 4 JS347400 LOCKWASHER, INT TOOTH .375
32 1 PP130003 INSERT, DOMED PLASTIC
33 1 PP460011 KNOB, OVAL .375-16 x 1.25 MALE
34 2 PR060003 BUMPER, RECESS
35 2 4800-416 PAD W/WEAR COVER
36 2 4800-419 WEAR COVER
37 1 5220-364-X* DECAL, WARNING
38 1 8500-025-X* DECAL, CAUTION
39 1 11040--790 DECAL, MADE IN USA
40 1 CM000244 DECAL, WEIGHT CAPACITY
ITEM QTY PART NO. DESCRIPTION
16021 Main Assembly Detail

Cybex Free Weight 16021 45° Back Extension Owner’s Manual
Page 11
SERIAL DECAL
DETAIL
8
40
CENTER ON
SERIAL DECAL
1.13±.12.25±.12
.50±.25
37
.50
2X.38±.06
2X.35±.12
FOOT PAD DETAIL
12 12
7
LOCKING KNOB
DETAIL
33
10
25
2X ±.12
.25 ±.12
15
2X CENTER
ON TUBE
CENTER ON TUBE
DECAL LOCATION
DETAIL
2.50 ±.25
CENTER ON TUBE
WARNING DECAL
DETAIL
38
16021 Decal Placement Detail

Cybex Free Weight 16021 45° Back Extension Owner’s Manual
Page 12
This page intentionally left blank

10 Trotter Drive Medway, MA 02053 • 508-533-4300 • FAX [phone]
www.cybexinternational.com • [email protected]
