CYCLETOTE Dog Trailer Cozy User manual

Fabric Boom
The fabric boom with the, plasc installed, is shipped in place. At the front and back ends of the trailer, open the Velcro in the
fabric. Wrap the fabric over the top struts, then re-aach the Velcro. The sides aach later, aer the Fabric Top is installed.
Leaving the boom only parally aached makes it easier to put on the roll bars.
Hardboard Floor
The hardboard oor is installed rough side up. Use the loop in the board to aach a short leash to
your dog. If you need more than one leash to control your dog, loop another leash either to the back
ring or to the base of the roll bars.
Roll bars and Fabric Canopy Top, Front Mesh, Back Fabric and Front Vinyl
(On Large Dog Trailers only, unscrew the boom half of a roll bar’s collar clamp and loosely aach it to
the sides of the frame in the center (the fabric will go over this 3rd bar.)
Insert 2 roll bars (one for each end) into the sleeves of the canopy top fabric.
Remove the boom half of the collar clamps from the 2 end roll bars, spread out the roll bars and place
them on the top of the trailer where indicated. Loosely re-aach the boom half of the collar clamps.
Stretch the Canopy top fabric taut and ghten the collar clamps securely. Take your me to get them in
the correct posion.
Parts
 Trailer frame
 Tow bar (tongue)
 Roll bars, 3 for Large
2 for Small & Cozy
 2 wheels, res, tubes
 2 wheel reectors
 Rear reector
 Safety ag
 Safety strap
 2 red set screws
Ball joint
Hitch
nut
Tow bar
 Hardboard oor
 Seat post hitch
 Hitch nut
 Hex key 3/16
Fabric
 Boom fabric with
plasc insert
 Canopy Top
 Front Mesh cover
 Front Vinyl cover
 Back Cover
 FABRIC COLORS
MAY VARY
1

Finish aaching the boom fabric. Secure the boom fabric to the frame on each side, opening the Velcro and rolling it over the
top of the side rails of the frame. The boom fabric has Velcro loops that need to be aached around the boom of frame’s
sides.
The canopy top now aaches with the Velcro to the sides of boom fabric.
Back Cover, Front Mesh and Front Vinyl Rain Guard
 Back cover: Start at the top center-back of the canopy top and aach the center of the back cover to the canopy top. From
the center, work your way down on both sides unl the fabric lines up evenly and reaches the Velcro on the fabric boom.
 Front Mesh: Start at the center-front of the canopy top and aach the front mesh to the canopy top. From the center, work
your way down on both sides unl the fabric lines up evenly and reaches the Velcro on the front of the fabric boom.
 Vinyl Rain Guard; The vinyl rain guard ts over the front mesh and will only aach to the mesh, not to the canopy top.
Wheels
NOTE: If you have a braking system, skip this secon, go to the separately enclosed Braking System Instrucons, and then return
to Wheel Reectors.
If the Wheel’s Quick Release Skewers are separate from the wheels ,unscrew the nut and remove one spring. Then slide the
skewer through the axle of the hub (center of the wheel). Replace the spring with the smaller end towards the inside, and loosely
aach the nut.
Set the wheel into the dropouts of the
frame with the quick release lever to the
outside of the trailer.
Tighten the nut unl the
quick release lever can be
closed ghtly (press lever
in, not around in a circle).
The wheels should be very secure in the drop outs.
Wheel Reectors
If not pre-installed, Install the wheel reectors into the wheels with
enough space from the tube valve to add air easily to the res.
Tow bar
Insert the two red set screws (wing nuts) into the threaded holes in the main frame
just far enough to hold them in place. Slide the tow bar downwards, between the
main frame and the two notched front struts.
There are two grooves in the tow bar. Select the grooves that allow your trailer to sit
closest to level. Adjust the tow bar while you ghten the red set screws by hand so
that the screw ps t into the indentaons in the front of the tow bar.
When ghtened securely, the tow bar is pressed rmly against the struts to prevent
it from loosening.
Jogger Stroller
If you are installing the Jogger wheel, instead of the tow bar, follow Jogger Stroller
instrucons which are a included separately, then return to Rear Reector.
RING
Red Set Screw
Grooved strut
under fabric
Grooved strut
Skewer
2
Drop Out
Press Lever

Aluminum
 Tow bar (tongue)
 Roll bars, 3 for Large
2 for Small or 2 Cozy Roll
bars
 Seat post hitch –various sizes
 Hitch nut
 Rack hitch
Fabric
 Boom Fabric—Large or Small/Cozy
 Plasc insert for boom
 Canopy top– Small, Cozy or Large
 Front Mesh cover-Small, Cozy or Large
 Front vinyl cover—Small, Cozy or Large
 Back Cover– Large, Small or Cozy
Miscellaneous
 Hardboard oor
 Hex key 3/16
 Safety ag
 Safety strap
 red set screws
Seat Post Hitch
Aach the hitch to the seat post with the bevel facing upward at a height which allows the trailer to be as parallel to the ground as
possible. Open, then re-ghten the hitch’s collar evenly on both sides of the seat post by screwing each bolt in part way, and ro-
tang between bolts as you ghten. Tighten the hitch to the seat post so that it cannot move.
The ball joint is at the p of the tow bar. Feed the ball joint, top to boom, through the hitch. The ball joint should rotate freely in
the hitch.
Aaching Trailer to Seat Post Hitch
Spin the hitch nut onto the ball joint’s threads, with the teeth pressing against the
hitch. Hand ghten rmly.
Safety Strap
Wrap the safety strap around the seat post and aach, keeping it loose enough to
avoid binding while cornering.
Rear Reector
Install the rear reector on the mount at the rear center of the trailer. The oponal Blinky light can be mounted here instead.
Safety Flag
Join the two pieces of the agpole to make a 6’ long pole. Insert the safety ag into the tube at the le rear of the trailer. The
movement of the ag draws drivers aenon and makes the trailer more visible.
Owner’s Manual
Please read and understand your Owner’s Manual.
Dog Tip : On the rst few rides, leash your dog in at two points so there is no chance of jumping out.
Hitch
Safety Strap
Ball Joint
Tow Bar
Hitch Nut
3
