CyClone SCB71136 User manual

USE AND CARE GUIDE
MODELS
OPERATION INSTRUCTIONS
Fan Operation
Fan Speeds: Three speed settings give the customer total control of their fan at the push of
a button.
Timer: This collection features a time-delay off feature to automatically shut the fan off after
1 to 9 minutes to conveniently clear the smoke and grease after cooking. To program the
time-delay feature, press the button with the clock icon while the machine is on and then use
the lowest speed setting button to toggle between 1 to 9 minutes.
Fan Housing
Removal:
Disassembly:
cleaned in the top rack of the dishwasher.
Reassembly:
the knob into the nut.
SCB71136
Fan
Control
Light
Control
Power/Timer
Nonstick-coated fan blades will separate grease from the air and the grease will then be
bag with the bracket and screws in the box. The grease cup can be used in conjunction with
Tip: Soak all parts in soapy water if there is heavy grease.
Grease Disposal
WARNING!
still hot.
Changing Light bulbs
To change the light bulb, remove light case from the light socket. The light case can be
accessed from the inside of the body of the machine.
1.
Disconnect the connecting wires of the light socket from the motherboard wires.2.
3.
remove the glass cover of the light case.
4. Detach light bulb and replace with a new bulb.
WARNING! Ensure that all power leading to your range hood has been disconnected
before changing bulbs. As well, ensure that lights have fully cooled before changing bulbs.

Cyclone Range Hoods Inc.
1361 Huntingwood Drive, Unit 16
Scarborough, ON M1S 3J1
Tel: [phone] or [phone] Fax [phone]
Email: [e-mail]
Website: www.CycloneRangeHoods.com
REPLACEABLE PARTS
FREQUENTLY ASKED QUESTIONS
When do I need a Cyclone Range Hood?
Peoples’ cooking habits vary, but getting rid of airborne contaminants
.enoyreveroftnatropmisiaeragnikoocruoyniregnilhcihwsruododna
Whether it is steam from cooking soups steaming vegetables, grease
ventilation in their kitchen
Can I install a Cyclone Range Hood myself?
Installing a Cyclone Range Hood is fairly straightforward, and we
provide detailed installation instructions. We do not recommend
range hood installation for novices to electrical or handy work.
What is the minimum mounting height between the range top to
hood bottom?
The minimum mounting height between the range top to hood bottom
should be no less than 30”. The maximum mount height should be no
more than 36”. The hood must be installed at the correct mounting
height. Hoods mounted too low can result in heat damage, and hoods
mounted too high will have impaired performance.
How often do I clean my Cyclone Range Hood?
Cyclone recommends that our range hoods are cleaned at least once
every month. However, cooking habits differ and cleaning should
pleasant aesthetic.
Cyclone canopy range hoods can accommodate to almost any ceiling
height. Extended chimney pieces can be purchased separately for
higher ceilings, and our chimneys can be custom cut to accommodate
shorter ceiling heights.
MAINTENANCE
Mesh Filters:
soaking in the sink.
Exterior: The exterior of the machine can be maintained by wiping the surface area. Use a
stainless steel cleaner and a very gentle cloth for stainless steel machines.
Cleaning
Fan Housing
NAME QTY DESCRIPTION IMAGE
WM 05 2 Type G4 12V
20W
WM 06 2 Light Socket Kit
(Includes light, socket,
connecting wire)
NAME QTY DESCRIPTION IMAGE
WM 01 1 Canopy Oil
Collector
BFC 14 2
