Cygnett ExoDrive User manual

EXODRIVE WIRELESS
VENT
USER MANUAL
Caution
1.
2. Do not expose to extreme weather conditions.
3. Do not place close to a magnetic stripor stripcard
as it could cause magnetic failure.
4. Please keep charger a safe distance of at least 80cm
from any implantable medical devices to avoid medical
device interference.
5. This is not a toy and should be kept away from children.
6. In the case of the device overheating, please
disconnect immediately.
approved by the party responsible for compliance could
void the user’s authority to operate the equipment. Cygnett
takes no responsibility for damages caused by incorrect use
of its products. Made in China.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
try to connect the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician
for help.
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
Cygnett and the Cygnett logo are trademarks of Cygnett
Pty Ltd. Other brands and product names are trademarks or
registered trademarks of their respective holders.
Cygnett Pty Ltd,
858 Lorimer St, Port Melbourne,
Victoria 3207 Australia
Cygnett UK Limited,
London, WC2H 9JQ
Cygnett USA Inc,
3838 W Carson St,
Ste 220, Torrance, CA 90503
Cygnett EU,
2718RD Zoetermeer, The Netherlands
Warning: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
“FCC RF Radiation Exposure Statement Caution: To maintain
compliance with the FCC’s RF exposure guidelines, place the
product at least 20cm from nearby persons.”

Installation Instructions
Vent Mounting
Attach the product to your vent by pushing the spring-loaded
clip (A) and hook it onto the backof the vent blades in your
vehicle Once hooked on, release the spring-loadedclip to
grip onto the vent.
Adjusting the viewing angle
Adjust the angle by loosening the tightening ring (B) of the ball
joint on the back of the product. Once you are happy with the
viewing angle, tighten the ring (B) to hold in place.
Connecting the power source
end into the 12V USB Car Adapter and plug into your vehicle’s
12V power socket.
Charge your device wirelessly
To wirelessly charge your device, place your device on the
wireless charging output (D) and secure it with the retractable
arms. To remove your device, press the quick release button
(E) to open the retractable arms.
A Spring-loaded clip
B Adjustable ball joint for tightening ring
C Micro-USB Input
D Wireless charging output
E Quick release button
DA
C
B
E
Troubleshooting
Not charging or slow charging
Please ensure you are using the supplied power adapter within the wireless charger. Using
other chargers may result in slow charging or no charge at all. If you need to replace the
power adapter, please make sure it supports QC 3.0 and supports a 12V USB output.
For optimum charge speed, adjust your device so that it is aligned to the centre of the wireless
charging by removing it and checking the performance. Some cases interfere with wireless
charging if they contain metallic material or are overly thick.
Name ExoDrive Wireless Vent
Item Number CY3459WLCCH
Micro-USB Input 5.0V⎓2.0A (10.0W)
9.0V⎓2.0A (18.0W)
Wireless Output
5.0W
7.5W
10.0W
Total Output 10.0W
109.94kHz-165.38kHz
-17.79dBuA/m@10m
FCC ID 2AEDZCY345XWLCCH
Working Frequency Bands (For CE)
Max Output Power (For CE)
