CYP CH-101 User manual

CH-101
HDMI to HDMI
Repeater (V1.3)
Operation Manual
CH-101

TABLE OF CONTENTS
1. Introduction.................................................................................1
2. Main Features............................................................................. 1
3. Package Contents..................................................................... 1
4. Hardware Description................................................................ 1
4.1 Front Panel.............................................................................1
4.2 Rear Panel............................................................................. 1
5. Connection and Installation......................................................2
6. Specifications............................................................................. 2

1
1. Introduction
This is the most advanced solution for HDMI to HDMI signal repeater. This is
compatible to HDMI v1.3 specifications, a cutting-age technology which
defines the support to transfer Deep Color (12 bits/color) video and new
lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master
Audio) digital audio, with a high bandwidth up to 225MHz. The HDMI v1.3
Distribution Amplifier also does signal amplification and equalization, so as
to provide high performance I/O of audio and video through HDMI cables
for a distance up to 15 meters each side at 1080p@60Hz.
2. Main Features
●Compliant with HDMI 1.3, HDCP 1.1 and DVI1.1 standards.
●Supports digital video formats in Deep Color Mode at up to 36 bits
(12bits/color) and new lossless compressed (Dolby TrueHD, Dolby Digital
Plus and DTS-HD Master Audio) digital audio.
●Supports equalize and recover incoming TMDS data before re-transmitting
them with optimal quality regardless of the incoming signal quality.
●Supports high definition input up to 1080p@60Hz, output resolution follows
input. The distances up to 15 meters each side and can cascaded more
then 4 layers.
●Full HDCP Compliant.
●Support CEC function.
●Easy to install and simple to operate.
3. Package Contents
●HDMI to HDMI Repeater.
●5V DC power supply adaptor.
●Operation Manual.
4. Operation Controls and Functions
4.1. Front Panel 4.2. Rear Panel
1 . HDMI input: Connect the HDMI input port to the HDMI output port of
your source equipment such as DVD player or set-top-box.
2 . Power: Plug the 5VDC power supply into the unit and connect the
adaptor to AC wall outlet.
DC 5V
HDMI INPUT
POWER
1 2
HDMI OUTPUT
3

2
3 . HDMI output: Connect the HDMI output port to the HDMI input port of
your display or next to the HDMI transmitter box.
5. Connection and Installation
6. Specifications
Input port 1 x HDMI
Output port 1 x HDMI
Power Supply 5V/2.6A DC (US/EU standards,
CE/FCC/UL certified)
Dimensions (mm) 50(W) x 52(D) x 23(H)
Weight(g) 62
Chassis Material Aluminum
Silk Skin Color Silver
Operating Temperature Operating from 0°C ~ 40°C
HDMI
HDMI
DC 5V
HDMI INPUT
POWER
HDMI OUTPUT
HDMI LCD TV
DVD PLAYER
HDMI
Cable
HDMI
Cable
HDMI
HDMI

2008.1.8 MPM-CH101

Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD.
