Cypress OR-YUV44S User manual

OR-YUV44S
HD 4x4
Operation Manual
OR-YUV44S

Revision History
Version No Date Summary of Change
V1 20081021 Preliminary Release
Precaution
Failure to follow the precautions described below may cause damage to
OR-YUV44S and void the warranty.
 DO NOT open the case. Doing so will void the warranty. If you nd
problem with it, please return back to your retailer or seller who will
assist you or provide you with solution.
 DO NOT use third-party AC adapter or power cord. Doing so may
damage the unit.
 DO NOT bump, jar or drop contents of the products as it may
damage it and result in warranty void.
 DO NOT set any liquids or beverages on the case as they may
damage the unit.

Table of Contents
1
1
1
1
2
2
3
4
4
4
5
5
5
5
6
1. Introduction......................................................................................
2. Application……………………………………………………….......….
3. Features............................................................................................
4. Package Contents...........................................................................
5. Operation Controls and Functions.................................................
5.1 Rear Panel Installation.................................................................
5.2 Front Panel...................................................................................
5.3 Remote Control..........................................................................
5.4 RS-232 Protocol............................................................................
5.4.1 Pin Denition.............................................................................
5.4.2 Commands..............................................................................
6. Specications.........................................................................................
6.1. General Specication................................................................
6.2. Support Resolution.....................................................................
7. Connection and Installation.................................................................

1. Introduction
OR-YUV44S is a high performance Component of Digital/Analog Audio with
Video Matrix. It offers you maximum convenience in HDTV audio/video signal
distribution when you have multiple sources to display. Each of the four HDTV
audio/video sources can be directed to any one of the four outputs and
or all four displays can show one identical output sources at the same time.
It provides a variety of choices on where to play your image with remote
controller.
Please follow this manual to begin enjoying the benet of the unit. We
suggest keeping this manual in a safe place for future reference.
2. Application
 High performance Digital/Analog Audio and Video Matrix with remote
control.
 Link up-to 4 of your favor sources and enjoying playing them on different
HDTV with true HD.
 Each input can be direct to any/all output.
 Audio format of Digital or Analog both acceptable.
3. Feature
1. Provides 4 by 4 matrix input/output of Component (YPbPr/YCbCr) video
and L/R & Coaxial digital audio signal.
2. Buffered video and audio output.
3. Input source LED indicators on each output select.
4. Ideal for home theater integration, conference room and retail stores.
5. Supports high resolution input/output:
HDTV: 480i, 576i, 480p, 576p, 1080i, and 1080p
6. Supports analog stereo L/R audio input and output.
7. Support Coaxial audio input and output.
8. IR remote control.
9. RS-232 control.
4. Package Contents
1. OR-YUV44S Component Matrix
2. 12VDC Power Supply Adaptor
3. Remote Controller
4. Operation Manual
1

5. Operation Controls and Functions
5.1. Rear Panel installation
1 RS-232 Communication Port:
Connect to the COM port of your PC for the distant control over RS-232
Channel.
2 Component with Digital (Coaxial) & L/R Audio OUTPUT Ports A, B, C and D:
Connect each set of Component (3 RCA) and Audio (2 RCA/Coaxial) to
the input of your HDTV displays.
3 Component with Digital (Coaxial) & L/R Audio INPUT Ports 1, 2, 3 and 4:
Connect each set of Component (3 RCA) and Audio (2 RCA/Coaxial) to
the output of your source equipments such as DVD player or set-top-box.
4 Power:
Plug the 12VDC power supply into the unit and connect the adaptor to
AC wall outlet.
1
RS-232
RL
RL
Pr/Cr Pb/Cb Y
C
D
Pr/Cr Pb/Cb Y
RL
RL
Pr/Cr Pb/Cb Y
A
B
Pr/Cr Pb/Cb Y
RL
RL
Pr/Cr Pb/Cb Y
3
4
Pr/Cr Pb/Cb
INPUTOUTPUT
Y
RCoaxial
Coaxial
Coaxial
Coaxial
Coaxial
Coaxial
Coaxial
Coaxial
L
RL
Pr/Cr Pb/Cb
DC 12V
Y
1
2
Pr/Cr Pb/Cb Y
3 2 4
2

POWER
OUT A OUT BOUT COUT D
12 43
INPUT-SELECT
12 43
INPUT-SELECT
12 43
INPUT-SELECT
12 43
INPUT-SELECT
OR-YUV44S
HD 4x4
1 Remote control sensor.
2 Power Switch & LED Indicator:
The LED will illuminate when the power is turned on.
3 Input Select/Indicators for Output A:
Press the "OUT A" button repeatedly to switch to your desired source.
One of the four LEDs will illuminate to indicate which input source is being
selected, and routed to the display.
4 Input Select/Indicators for Output B:
Press the "OUT B" button repeatedly to switch to your desired source. One
of the four LEDs will illuminate to indicate which input source is being
selected, and routed to the display.
5 Input Select/Indicators for Output C:
Press the "OUT C" button repeatedly to switch to your desired source.
One of the four LEDs will illuminate to indicate which input source is being
selected, and routed to the display.
6 Input Select/Indicators for Output D:
Press the "OUT D" button repeatedly to switch to your desired source.
One of the four LEDs will illuminate to indicate which input source is being
selected, and routed to the display.
5.2. Front Panel
1 2 3 4 5 6
3

5.3. Remote Control
1. Power:
Press the button to turn on/off the unit.
2. Input Select for Component/Audio OUT A:
Press 1, 2, 3 or 4 to select the desired input source
for Component/Audio OUT A.
3. Input Select for Component/Audio OUT B:
Press 1, 2, 3 or 4 to select the desired input source
forComponent/Audio OUT B.
4. Input Select for Component/Audio OUT C:
Press 1, 2, 3 or 4 to select the desired input source
for Component/Audio OUT C.
5. Input Select for Component/Audio OUT D:
Press 1, 2, 3 or 4 to select the desired input source
for Component/Audio OUT D.
OUTPUT
A
OUTPUT
D
OUTPUT
C
OUTPUT
B
POWER
CR-33
1
2
3
4
5
5.4. RS-232 Protocol
5.4.1. Pin Denition
OR-YUV44S


Remote Control Console
PIN Denition PIN Denition
1 NC 1 NC
2 Tx 2 Rx
3 Rx 3 Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
*RS-232 transmission format:
Baud Rate: 9600 bps
Data bit: 8 Bits
Parity: None
Stop Bit: 1 bit
4

5.4.2. Commands
COMMAND ACTION
P0 Power Off (standby)
P1 Power On *
ST System Status *
VR Firmware Version
A1 Output A select Input1
A2 Output A select Input2
A3 Output A select Input3
A4 Output A select Input4
B1 Output B select Input1
B2 Output B select Input2
B3 Output B select Input3
B4 Output B select Input4
C1 Output C select Input1
C2 Output C select Input2
C3 Output C select Input3
C4 Output C select Input4
D1 Output D select Input1
D2 Output D select Input2
D3 Output D select Input3
D4 Output D select Input4
*: command "P1" and "ST" response: P? A? B? C? D?
6. Specications
6.1. General Specication
* Input Ports:
Component (YPbPr/YCbCr) + Coaxial & L/R Audio x 4 sets
* Output Ports:
Component (YPbPr/YCbCr) + Coaxial & L/R Audio x 4 sets
* 12V DC power supply
* Dimensions: 436 (W) x 120 (D) x 44(H)mm
* Weight: 1.6 Kgs
6.2. Support Resolution
INPUT 480i / 480p/576i / 576p/720p/1080i / 1080p@50Hz/60Hz
OUTPUT 480i / 480p/576i / 576p/720p/1080i / 1080p@50Hz/60Hz
5

5
Blu-raySTB
HD TV HD TV
HD TV HD TV
DVD PS3
4. Operation Controls and Functions
4.1. Front Panel
1. Remote control sensor.
2. Power Switch & LED Indicator:
The LED will illuminate when the power is turned on.
3. Input Select/Indicators for Output A:
Press the "OUT A" button repeatedly to switch to your desired source. One of
the four LEDs will illuminate to indicate which input source is being selected,
and routed to the display.
4. Input Select/Indicators for Output B:
Press the "OUT B" button repeatedly to switch to your desired source. One of
the four LEDs will illuminate to indicate which input source is being selected,
and routed to the display.
5. Input Select/Indicators for Output C:
Press the "OUT C" button repeatedly to switch to your desired source. One of
the four LEDs will illuminate to indicate which input source is being selected,
and routed to the display.
6. Input Select/Indicators for Output D:
Press the "OUT D" button repeatedly to switch to your desired source. One of
the four LEDs will illuminate to indicate which input source is being selected,
and routed to the display.
4.2. Rear Panel
1. RS-232 Communication Port:
Connect to the COM port of your PC for the distant control over RS-232
channel.
2. Component and L/R Audio OUTPUT Ports A, B, C and D:
Connect each set of Component (3 RCA) and Audio (2 RCA) to the input of
your HDTV displays.
3. Component and L/R Audio INPUT Ports 1, 2, 3 and 4:
Connect each set of Component (3 RCA) and Audio (2 RCA) to the output of
your source equipments such as DVD player or set-top-box.
4. Power:
Plug the 12VDC power supply into the unit and connect the adaptor to AC wall
outlet.
4.3. Remote Control
1. Power:
Press the button to turn on/off the unit.
2. Input Select for Component/Audio OUT A:
Press 1, 2, 3 or 4 to select the desired input source for
Component/Audio OUT A.
3. Input Select for Component/Audio OUT B:
Press 1, 2, 3 or 4 to select the desired input source for
Component/Audio OUT B.
4. Input Select for Component/Audio OUT C:
Press 1, 2, 3 or 4 to select the desired input source for
Component/Audio OUT C.
5. Input Select for Component/Audio OUT D:
Press 1, 2, 3 or 4 to select the desired input source for
Component/Audio OUT D.
4.4. RS-232 Protocol
4.4.1. Pin Definition
*RS-232 transmission format:
Baud Rate: 9600 bps
Data bit: 8 Bits
Parity: None
Stop Bit: 1 bit
2 3
1 2 3 4 5 6
POWER
OUT A OUT B OUT C OUT D
1 2 43
INPUT-SELECT
1 2 43
INPUT-SELECT
1 2 43
INPUT-SELECT
1 2 43
INPUT-SELECT
CCMX-44
HD 4x4
RS-232
R L
R L
Pr/Cr Pb/Cb Y
C
D
Pr/Cr Pb/Cb Y
R L
R L
Pr/Cr Pb/Cb Y
A
B
Pr/Cr Pb/Cb Y
R L
R L
Pr/Cr Pb/Cb Y
3
4
Pr/Cr Pb/Cb
INPUTOUTPUT
Y
R L
R L
Pr/Cr Pb/Cb
DC 12V
Y
1
2
Pr/Cr Pb/Cb Y
4321
OUTPUT
A
OUTPUT
D
OUTPUT
C
OUTPUT
B
POWER
CR-33
1
2
3
4
5
PIN
1
2
3
4
5
6
7
8
9
Definition
NC
Tx
Rx
NC
GND
NC
NC
NC
NC
PIN
1
2
3
4
5
6
7
8
9
Definition
NC
Rx
Tx
NC
GND
NC
NC
NC
NC
CCMX-44 Remote Control Console


7. Connection and Installation
6

5
Blu-raySTB
HD TV HD TV
HD TV HD TV
DVD PS3
4. Operation Controls and Functions
4.1. Front Panel
1. Remote control sensor.
2. Power Switch & LED Indicator:
The LED will illuminate when the power is turned on.
3. Input Select/Indicators for Output A:
Press the "OUT A" button repeatedly to switch to your desired source. One of
the four LEDs will illuminate to indicate which input source is being selected,
and routed to the display.
4. Input Select/Indicators for Output B:
Press the "OUT B" button repeatedly to switch to your desired source. One of
the four LEDs will illuminate to indicate which input source is being selected,
and routed to the display.
5. Input Select/Indicators for Output C:
Press the "OUT C" button repeatedly to switch to your desired source. One of
the four LEDs will illuminate to indicate which input source is being selected,
and routed to the display.
6. Input Select/Indicators for Output D:
Press the "OUT D" button repeatedly to switch to your desired source. One of
the four LEDs will illuminate to indicate which input source is being selected,
and routed to the display.
4.2. Rear Panel
1. RS-232 Communication Port:
Connect to the COM port of your PC for the distant control over RS-232
channel.
2. Component and L/R Audio OUTPUT Ports A, B, C and D:
Connect each set of Component (3 RCA) and Audio (2 RCA) to the input of
your HDTV displays.
3. Component and L/R Audio INPUT Ports 1, 2, 3 and 4:
Connect each set of Component (3 RCA) and Audio (2 RCA) to the output of
your source equipments such as DVD player or set-top-box.
4. Power:
Plug the 12VDC power supply into the unit and connect the adaptor to AC wall
outlet.
4.3. Remote Control
1. Power:
Press the button to turn on/off the unit.
2. Input Select for Component/Audio OUT A:
Press 1, 2, 3 or 4 to select the desired input source for
Component/Audio OUT A.
3. Input Select for Component/Audio OUT B:
Press 1, 2, 3 or 4 to select the desired input source for
Component/Audio OUT B.
4. Input Select for Component/Audio OUT C:
Press 1, 2, 3 or 4 to select the desired input source for
Component/Audio OUT C.
5. Input Select for Component/Audio OUT D:
Press 1, 2, 3 or 4 to select the desired input source for
Component/Audio OUT D.
4.4. RS-232 Protocol
4.4.1. Pin Definition
*RS-232 transmission format:
Baud Rate: 9600 bps
Data bit: 8 Bits
Parity: None
Stop Bit: 1 bit
2 3
1 2 3 4 5 6
POWER
OUT A OUT B OUT C OUT D
1 2 43
INPUT-SELECT
1 2 43
INPUT-SELECT
1 2 43
INPUT-SELECT
1 2 43
INPUT-SELECT
CCMX-44
HD 4x4
RS-232
R L
R L
Pr/Cr Pb/Cb Y
C
D
Pr/Cr Pb/Cb Y
R L
R L
Pr/Cr Pb/Cb Y
A
B
Pr/Cr Pb/Cb Y
R L
R L
Pr/Cr Pb/Cb Y
3
4
Pr/Cr Pb/Cb
INPUTOUTPUT
Y
R L
R L
Pr/Cr Pb/Cb
DC 12V
Y
1
2
Pr/Cr Pb/Cb Y
4321
OUTPUT
A
OUTPUT
D
OUTPUT
C
OUTPUT
B
POWER
CR-33
1
2
3
4
5
PIN
1
2
3
4
5
6
7
8
9
Definition
NC
Tx
Rx
NC
GND
NC
NC
NC
NC
PIN
1
2
3
4
5
6
7
8
9
Definition
NC
Rx
Tx
NC
GND
NC
NC
NC
NC
CCMX-44 Remote Control Console


7

8
