Cypress CP-268S User manual

Operation Manual
CP-268S
DVI/Coaxial to
HDMI Converter
CP-268S
5
TABLE OF CONTENTS
1. Introduction.............................................................................. 1
2. Features..................................................................................... 1
3. Package Contents................................................................... 1
4. Operation Controls and Functions......................................... 2
4.1 Front Panel......................................................................... 2
4.2 Rear Panel.......................................................................... 3
5. Pin Configuration..................................................................... 3
6. HDMI Output Pin Assignment ................................................ 3
6.1 General Specifications..................................................... 3
6.2 Supports Resolution............................................................ 3
7. Specifications.......................................................................... 4
1
1. Introduction
This converter box is converts DVI/Coaxial to HDMI output. It enables to
connect the DVI source and digital audio to a HDMI digital display. This
converter box also does signal amplification and equalization for
incoming TMDS data before re-transmitting them with optimal quality
regardless of the incoming signal quality.
2. Features
1. HDMI 1.2, HDCP 1.1 and DVI 1.0 compliant.
2. Supports DVI/Coaxial input and HDMI output.
3. Input format auto detection: Digital RGB or YPbPr.
4. Coaxial input supports LPCM 2CH, Dolby Digital 5.1CH and DTS 5.1CH
digital audio.
5. Full HDCP compliant.
6. Operation Frequency: 165MHz
7. Frequency Bandwidth: 1.65Gbps (single link).
8. Supports audio sampling frequencies: 32, 44.1 and 48kHz.
9. Supports high resolution input/output:
PC: VGA@60/72/75/85Hz, SVGA@60/72/75/85Hz,
XGA@60/70/75/85Hz, SXGA@60/75/85Hz, UXGA@60Hz.
SD/HD: 480i/p@60Hz, 576i/p@50Hz, 720p@50/60Hz, 1080i@50/60Hz
and 1080p@24/50/60Hz.
10. Easy to install and to operate.
3. Package Contents
1. DVI/Coaxial to HDMI Converter
2. 5V DC power supply adaptor
3. Operation Manual
4

TABLE OF CONTENTS
1. Introduction.............................................................................. 1
2. Features..................................................................................... 1
3. Package Contents................................................................... 1
4. Operation Controls and Functions......................................... 2
4.1 Front Panel......................................................................... 2
4.2 Rear Panel.......................................................................... 3
5. Pin Configuration..................................................................... 3
6. HDMI Output Pin Assignment ................................................ 3
6.1 General Specifications..................................................... 3
6.2 Supports Resolution............................................................ 3
7. Specifications.......................................................................... 4
1
1. Introduction
This converter box is converts DVI/Coaxial to HDMI output. It enables to
connect the DVI source and digital audio to a HDMI digital display. This
converter box also does signal amplification and equalization for
incoming TMDS data before re-transmitting them with optimal quality
regardless of the incoming signal quality.
2. Features
1. HDMI 1.2, HDCP 1.1 and DVI 1.0 compliant.
2. Supports DVI/Coaxial input and HDMI output.
3. Input format auto detection: Digital RGB or YPbPr.
4. Coaxial input supports LPCM 2CH, Dolby Digital 5.1CH and DTS 5.1CH
digital audio.
5. Full HDCP compliant.
6. Operation Frequency: 165MHz
7. Frequency Bandwidth: 1.65Gbps (single link).
8. Supports audio sampling frequencies: 32, 44.1 and 48kHz.
9. Supports high resolution input/output:
PC: VGA@60/72/75/85Hz, SVGA@60/72/75/85Hz,
XGA@60/70/75/85Hz, SXGA@60/75/85Hz, UXGA@60Hz.
SD/HD: 480i/p@60Hz, 576i/p@50Hz, 720p@50/60Hz, 1080i@50/60Hz
and 1080p@24/50/60Hz.
10. Easy to install and to operate.
3. Package Contents
1. DVI/Coaxial to HDMI Converter
2. 5V DC power supply adaptor
3. Operation Manual
4

1
1. Introduction
This converter box is converts DVI/Coaxial to HDMI output. It enables to
connect the DVI source and digital audio to a HDMI digital display. This
converter box also does signal amplification and equalization for
incoming TMDS data before re-transmitting them with optimal quality
regardless of the incoming signal quality.
2. Features
1. HDMI 1.2, HDCP 1.1 and DVI 1.0 compliant.
2. Supports DVI/Coaxial input and HDMI output.
3. Input format auto detection: Digital RGB or YPbPr.
4. Coaxial input supports LPCM 2CH, Dolby Digital 5.1CH and DTS 5.1CH
digital audio.
5. Full HDCP compliant.
6. Operation Frequency: 165MHz
7. Frequency Bandwidth: 1.65Gbps (single link).
8. Supports audio sampling frequencies: 32, 44.1 and 48kHz.
9. Supports high resolution input/output:
PC: VGA@60/72/75/85Hz, SVGA@60/72/75/85Hz,
XGA@60/70/75/85Hz, SXGA@60/75/85Hz, UXGA@60Hz.
SD/HD: 480i/p@60Hz, 576i/p@50Hz, 720p@50/60Hz, 1080i@50/60Hz
and 1080p@24/50/60Hz.
10. Easy to install and to operate.
3. Package Contents
1. DVI/Coaxial to HDMI Converter
2. 5V DC power supply adaptor
3. Operation Manual

2
4. Operation Controls and Functions
4.1. Front Panel
4.2 Rear Panel
1. DVI input: Connect the DVI input port to the DVI output port of your
source equipment such as DVD player or set-top-box. It supports only
DVI-D signal via a DVI-I connector.
2. Coaxial input: Connect the Coaxial input port to the audio output of
your digital audio equipment.
1. HDMI output: Connect the HDMI output port to the HDMI input port of
your HDMI display.
2. Power: Plug the 5VDC power supply into the unit and connect the
adaptor to AC wall outlet.
1 2
12

5. Pin Configuration
A. DVI-D Input Pin Assignment
1 8 C1 C2
C5
C4
C3
9
17 24
Digital only connector pin assignments
Pin Signal Assignment Pin Signal Assignment
1
2
3
4
5
6
7
8
C1
C4
T.M.D.S Data2-
T.M.D.S. Data2+
T.M.D.S. Data2 Shield
N.C.
N.C.
DDC Clock
DDC Data
No Connect
N.C.
N.C.
9
10
11
12
13
14
15
16
C2
C5
T.M.D.S Data1-
T.M.D.S. Data1+
T.M.D.S. Data1 Shield
N.C.
N.C.
+5V Power
Ground (for +5V)
Hot Plug Detect
N.C.
N.C.
Pin Signal Assignment
17
18
19
20
21
22
23
24
C3
T.M.D.S Data0-
T.M.D.S. Data0+
T.M.D.S. Data0 Shield
N.C.
N.C.
T.M.D.S. Clock Shield
T.M.D.S. Clock+
T.M.D.S. Clock-
N.C.
DVI-Digital(DVI-D): Supports digital-only connections between the host computer
and display. This interface is designed for a 12 or 24-pin connection to enable
single or dual-link mode activation.
6. HDMI Output Pin Assignment
3
Pin#
1
3
5
7
9
11
13
15
17
19
Pin#
2
4
6
8
10
12
14
16
18
Function Assignment
TMDS Data2+
TMDS Data2-
TMDS Data1 Shield
TMDS Data0+
TMDS Data0-
TMDS Clock Shield
CEC
SCL
DDC/CEC Ground
Hot Plug Detect
Function Assignment
TMDS Data2 Shield
TMDS Data1+
TMDS Data1-
TMDS Data0 Shield
TMDS Clock+
TMDS Clock-
Reserved (N.C. on device)
SDA
+5V Power
1
2
19
18

4
7. Specifications
Input ports
Output port
Power Supply
Dimensions (mm)
Weight(g)
Chassis Material
Silkscreen Color
Operating Temperature
1 x DVI (only DVI-D supported) , 1 x Coaxial (S/PDIF)
1 x HDMI
5V/1A DC (US/EU standards, CE/FCC/UL certified)
105(W) x 76(D) x 30(H)
188
Aluminum
Silver
0°C ~ 40°C

5
1
1. Introduction
This converter box is converts DVI/Coaxial to HDMI output. It enables to
connect the DVI source and digital audio to a HDMI digital display. This
converter box also does signal amplification and equalization for
incoming TMDS data before re-transmitting them with optimal quality
regardless of the incoming signal quality.
2. Features
1. HDMI 1.2, HDCP 1.1 and DVI 1.0 compliant.
2. Supports DVI/Coaxial input and HDMI output.
3. Input format auto detection: Digital RGB or YPbPr.
4. Coaxial input supports LPCM 2CH, Dolby Digital 5.1CH and DTS 5.1CH
digital audio.
5. Full HDCP compliant.
6. Operation Frequency: 165MHz
7. Frequency Bandwidth: 1.65Gbps (single link).
8. Supports audio sampling frequencies: 32, 44.1 and 48kHz.
9. Supports high resolution input/output:
PC: VGA@60/72/75/85Hz, SVGA@60/72/75/85Hz,
XGA@60/70/75/85Hz, SXGA@60/75/85Hz, UXGA@60Hz.
SD/HD: 480i/p@60Hz, 576i/p@50Hz, 720p@50/60Hz, 1080i@50/60Hz
and 1080p@24/50/60Hz.
10. Easy to install and to operate.
3. Package Contents
1. DVI/Coaxial to HDMI Converter
2. 5V DC power supply adaptor
3. Operation Manual
4
2
4. Operation Controls and Functions
4.1. Front Panel
4.2 Rear Panel
1. DVI input: Connect the DVI input port to the DVI output port of your
source equipment such as DVD player or set-top-box. It supports only
DVI-D signal via a DVI-I connector.
2. Coaxial input: Connect the Coaxial input port to the audio output of
your digital audio equipment.
1. HDMI output: Connect the HDMI output port to the HDMI input port of
your HDMI display.
2. Power: Plug the 5VDC power supply into the unit and connect the
adaptor to AC wall outlet.
1 2
12
5. Pin Configuration
A. DVI-D Input Pin Assignment
1 8 C1 C2
C5
C4
C3
9
17 24
Digital only connector pin assignments
Pin Signal Assignment Pin Signal Assignment
1
2
3
4
5
6
7
8
C1
C4
T.M.D.S Data2-
T.M.D.S. Data2+
T.M.D.S. Data2 Shield
N.C.
N.C.
DDC Clock
DDC Data
No Connect
N.C.
N.C.
9
10
11
12
13
14
15
16
C2
C5
T.M.D.S Data1-
T.M.D.S. Data1+
T.M.D.S. Data1 Shield
N.C.
N.C.
+5V Power
Ground (for +5V)
Hot Plug Detect
N.C.
N.C.
Pin Signal Assignment
17
18
19
20
21
22
23
24
C3
T.M.D.S Data0-
T.M.D.S. Data0+
T.M.D.S. Data0 Shield
N.C.
N.C.
T.M.D.S. Clock Shield
T.M.D.S. Clock+
T.M.D.S. Clock-
N.C.
DVI-Digital(DVI-D): Supports digital-only connections between the host computer
and display. This interface is designed for a 12 or 24-pin connection to enable
single or dual-link mode activation.
6. HDMI Output Pin Assignment
3
Pin#
1
3
5
7
9
11
13
15
17
19
Pin#
2
4
6
8
10
12
14
16
18
Function Assignment
TMDS Data2+
TMDS Data2-
TMDS Data1 Shield
TMDS Data0+
TMDS Data0-
TMDS Clock Shield
CEC
SCL
DDC/CEC Ground
Hot Plug Detect
Function Assignment
TMDS Data2 Shield
TMDS Data1+
TMDS Data1-
TMDS Data0 Shield
TMDS Clock+
TMDS Clock-
Reserved (N.C. on device)
SDA
+5V Power
1
2
19
18
7. Specifications
Input ports
Output port
Power Supply
Dimensions (mm)
Weight(g)
Chassis Material
Silkscreen Color
Operating Temperature
1 x DVI (only DVI-D supported) , 1 x Coaxial (S/PDIF)
1 x HDMI
5V/1A DC (US/EU standards, CE/FCC/UL certified)
105(W) x 76(D) x 30(H)
188
Aluminum
Silver
0°C ~ 40°C

20080324 MPM-CP268S
Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD.
1
1. Introduction
This converter box is converts DVI/Coaxial to HDMI output. It enables to
connect the DVI source and digital audio to a HDMI digital display. This
converter box also does signal amplification and equalization for
incoming TMDS data before re-transmitting them with optimal quality
regardless of the incoming signal quality.
2. Features
1. HDMI 1.2, HDCP 1.1 and DVI 1.0 compliant.
2. Supports DVI/Coaxial input and HDMI output.
3. Input format auto detection: Digital RGB or YPbPr.
4. Coaxial input supports LPCM 2CH, Dolby Digital 5.1CH and DTS 5.1CH
digital audio.
5. Full HDCP compliant.
6. Operation Frequency: 165MHz
7. Frequency Bandwidth: 1.65Gbps (single link).
8. Supports audio sampling frequencies: 32, 44.1 and 48kHz.
9. Supports high resolution input/output:
PC: VGA@60/72/75/85Hz, SVGA@60/72/75/85Hz,
XGA@60/70/75/85Hz, SXGA@60/75/85Hz, UXGA@60Hz.
SD/HD: 480i/p@60Hz, 576i/p@50Hz, 720p@50/60Hz, 1080i@50/60Hz
and 1080p@24/50/60Hz.
10. Easy to install and to operate.
3. Package Contents
1. DVI/Coaxial to HDMI Converter
2. 5V DC power supply adaptor
3. Operation Manual
4
2
4. Operation Controls and Functions
4.1. Front Panel
4.2 Rear Panel
1. DVI input: Connect the DVI input port to the DVI output port of your
source equipment such as DVD player or set-top-box. It supports only
DVI-D signal via a DVI-I connector.
2. Coaxial input: Connect the Coaxial input port to the audio output of
your digital audio equipment.
1. HDMI output: Connect the HDMI output port to the HDMI input port of
your HDMI display.
2. Power: Plug the 5VDC power supply into the unit and connect the
adaptor to AC wall outlet.
1 2
12
5. Pin Configuration
A. DVI-D Input Pin Assignment
1 8 C1 C2
C5
C4
C3
9
17 24
Digital only connector pin assignments
Pin Signal Assignment Pin Signal Assignment
1
2
3
4
5
6
7
8
C1
C4
T.M.D.S Data2-
T.M.D.S. Data2+
T.M.D.S. Data2 Shield
N.C.
N.C.
DDC Clock
DDC Data
No Connect
N.C.
N.C.
9
10
11
12
13
14
15
16
C2
C5
T.M.D.S Data1-
T.M.D.S. Data1+
T.M.D.S. Data1 Shield
N.C.
N.C.
+5V Power
Ground (for +5V)
Hot Plug Detect
N.C.
N.C.
Pin Signal Assignment
17
18
19
20
21
22
23
24
C3
T.M.D.S Data0-
T.M.D.S. Data0+
T.M.D.S. Data0 Shield
N.C.
N.C.
T.M.D.S. Clock Shield
T.M.D.S. Clock+
T.M.D.S. Clock-
N.C.
DVI-Digital(DVI-D): Supports digital-only connections between the host computer
and display. This interface is designed for a 12 or 24-pin connection to enable
single or dual-link mode activation.
6. HDMI Output Pin Assignment
3
Pin#
1
3
5
7
9
11
13
15
17
19
Pin#
2
4
6
8
10
12
14
16
18
Function Assignment
TMDS Data2+
TMDS Data2-
TMDS Data1 Shield
TMDS Data0+
TMDS Data0-
TMDS Clock Shield
CEC
SCL
DDC/CEC Ground
Hot Plug Detect
Function Assignment
TMDS Data2 Shield
TMDS Data1+
TMDS Data1-
TMDS Data0 Shield
TMDS Clock+
TMDS Clock-
Reserved (N.C. on device)
SDA
+5V Power
1
2
19
18
7. Specifications
Input ports
Output port
Power Supply
Dimensions (mm)
Weight(g)
Chassis Material
Silkscreen Color
Operating Temperature
1 x DVI (only DVI-D supported) , 1 x Coaxial (S/PDIF)
1 x HDMI
5V/1A DC (US/EU standards, CE/FCC/UL certified)
105(W) x 76(D) x 30(H)
188
Aluminum
Silver
0°C ~ 40°C
