CY8CPROTO-062S3-4343W PSOC®62S3 Wi-Fi BT PROTOTYPING KIT QUICK START GUIDE
© 2019-2020 Cypress Semiconductor Corporation. All rights
reserved. All trademarks or registered trademarks referenced
herein are the properties of their respective owners.
002-28125 Rev.*E
• PC with USB port •UART terminal software such as Tera Term or Minicom
Before starting, ensure you have the following.
For more information, please visit: www.cypress.com/CY8CPROTO-062S3-4343W
KitProg3 USB
connector (J8)
Power selection jumper (J3)
Reset button (SW1)
1) Visit the kit website to download and install the required software.
2) Ensure the jumper J3 is at position 2-3 to select 3.3V.
3) Connect the KitProg3 USB connector (J8) to your PC.
4) Wait for the drivers installation to complete.
5) Open the UART terminal software and connect to the KitProg3.
USB-UART COM port with the settings – Baud rate: 115200,
Data: 8 bit, Parity: None, Stop bit: 1 bit, Flow control: None.
6) Press the RESET switch (SW1) on the device.
7) Follow the instructions displayed on the UART terminal to use the
pre-programmed code example.
Refer to the Kit Guide available at the kit website for details.
Contains Model: Type1DX
FCC ID: VPYLB1DX
IC: 772C-LB1DX
001-P00840

PSOC Rocks!

CY8CPROTO-062S3-4343W
PSOC®62S3 Wi-Fi BT PROTOTYPING KIT
