Cypress Chameleon CTM-15X User manual

COMPLETE
MANUAL
Model
Chameleon CTM-15X
modem
Revision:
Firmware 1.2.0
Revision 1.0
3066 Beta Avenue Burnaby, B.C. V5G 4K4
Phone: [phone]
Fax: [phone]
[email protected]

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
20BActivating Your Modem
Notice
Due to the nature of wireless communication the reception or transmission of data can never be
guaranteed. Data may be delayed, corrupted or never received. Data transfer problems are rare with
well-constructed and configured wireless networks used in conjunction with devices such as the CTM-15X
wireless data device. Cypress Solutions Inc. accepts no responsibility for damages of any kind including
but not limited to personal injury, death, or loss of property due to the delay or loss of data resulting from
the use of the CTM-15X wireless data device.
Safety & hazards
Wireless transmitters can cause interference with some critical operation equipment. For this reason it is
required that the RF portion of the CTM-15X Series wireless data device be turned off when in the vicinity
of blasting operations, medical equipment, life support equipment, or any other equipment that is
susceptible to radio interference. The CTM-15X series wireless data device must be turned off when on-
board or in the vicinity of any aircraft. The FAA prohibits the use of wireless transmitter equipment at any
time during aircraft flight.
Regulatory restrictions
CAUTION: Any modifications to the CTM-15X series wireless data device not expressly authorized by
Cypress Solutions Inc. may cause its regulatory approval status to become invalidated, thereby voiding
your authority to use the product.
The CTM-15X series wireless data device contains a wireless device approved under FCC CFR 47 part
2.1091 and Industry Canada RSS-102 rules for operation as a mobile or fixed device with its specified
antenna of gain ≤6dBi and from which a separation distance of at least 20cm (8”) must be maintained
from all persons at all times and during all modes of operation. The antenna used must not be co-located
or operated in conjunction with any other antenna or transmitter. These rules are in place to prevent any
possible hazard due to personal exposure to electromagnetic radiation.
The CTM-15X series devices are designed to operate with approved wireless cards installed. These cards
will have their own FCC and Industry Canada approval ID numbers. Contact Cypress Solutions for a
complete updated list of supported Wireless cards/modules.
Electromagnetic Interference (EMI) – United States FCC Information
This equipment has been tested and found to comply with limits for a class A digital device, pursuant to
part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a commercial installation. This equipment generates, uses, and can radiate radio
frequency energy, and if not installed and used in accordance with the instructions, may cause harmful

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
30BActivating Your Modem
interference to radio communication. However, there is no guarantee that harmful interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
•reorient or relocate the receiving antenna
•increase the separation between the equipment and receiver
•connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
•consult the dealer or an experienced radio/TV technician for help
Electromagnetic Interference (EMI) – Canada Information
This digital apparatus does not exceed the class A limits for radio noise emissions from digital apparatus
as set out in the interference causing equipment standard entitles “Digital Apparatus”, ICES-003 of the
Department of Communications.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils
numériques de Classe A prescrites dans la norme sur le matériel brouilleur: “Appareils Numériques”,
NMB-003 édictée par le Ministre des Communications.
Trademarks
All brand or product names, trademarks, logos, etc. used in this manual are owned by their respective
companies.

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
40BActivating Your Modem
Notice.......................................................................................................................................................... 2
Safety & hazards ......................................................................................................................................... 2
Regulatory restrictions................................................................................................................................ 2
Electromagnetic Interference (EMI) – United States FCC Information....................................................... 2
Electromagnetic Interference (EMI) – Canada Information ....................................................................... 3
Trademarks ................................................................................................................................................. 3
1 Activating Your Modem .......................................................................................................................... 9
1.1 Gather Account Information.............................................................................................................. 9
1.1.1 CDMA/EV-DO devices ............................................................................................................... 9
1.1.2 GSM/GPRS/HSPA devices.......................................................................................................... 9
1.2 Embedded Web Page Activation ....................................................................................................... 9
1.2.1 Automatic Activation via Modem Embedded Web Browser .................................................... 9
1.2.2 Manual Activation via Modem Embedded Web Browser....................................................... 10
1.3 Command Line Activation................................................................................................................ 10
1.3.1 Automatic Activation (OTASP) ................................................................................................ 11
1.3.2 Manual Activation ................................................................................................................... 11
2 Installing Your Modem.......................................................................................................................... 12
2.1 Mounting ......................................................................................................................................... 12
2.2 Connecting the Power Cable............................................................................................................ 14
2.3 Connecting the Ethernet Cable........................................................................................................ 14
2.4 Mounting and Attaching the Cell Antenna ...................................................................................... 14
2.5 Mounting and Attaching the GPS Antenna...................................................................................... 15
2.6 Serial Data Cable Connection........................................................................................................... 15
2.7 Connecting to the I/O Port............................................................................................................... 15
2.7.1 Output Connection.................................................................................................................. 16
2.7.2 Input Connection..................................................................................................................... 16
3 Operating Your Modem ........................................................................................................................ 17
3.1 Automatic Power Control ................................................................................................................ 17
3.2 Power Consumption ........................................................................................................................ 18
3.3 Device Reset..................................................................................................................................... 18
3.4 LED Indicators .................................................................................................................................. 19
3.5 Making a Wireless Network Connection ......................................................................................... 20
3.6 GPS Operation.................................................................................................................................. 20
4 Connecting to a CTM-15X Modem Locally............................................................................................ 21

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
50BActivating Your Modem
4.1 Ethernet ........................................................................................................................................... 21
4.2 Telnet ............................................................................................................................................... 21
4.3 Browser ............................................................................................................................................ 22
4.4 Serial ................................................................................................................................................ 23
5 Connecting to a CTM-15X Modem Remotely ....................................................................................... 24
6List of Commands.................................................................................................................................. 25
6.1.1 A .............................................................................................................................................. 25
6.1.2 B............................................................................................................................................... 25
6.1.3 C............................................................................................................................................... 25
6.1.4 D .............................................................................................................................................. 25
6.1.5 E............................................................................................................................................... 26
6.1.6 F............................................................................................................................................... 26
6.1.7 G .............................................................................................................................................. 26
6.1.8 I................................................................................................................................................ 26
6.1.9 L ............................................................................................................................................... 27
6.1.10 M.......................................................................................................................................... 27
6.1.11 N........................................................................................................................................... 27
6.1.12 O .......................................................................................................................................... 27
6.1.13 P ........................................................................................................................................... 28
6.1.14 R........................................................................................................................................... 28
6.1.15 S ........................................................................................................................................... 29
6.1.16 T ........................................................................................................................................... 29
6.1.17 U........................................................................................................................................... 29
6.1.18 V........................................................................................................................................... 29
6.1.19 W.......................................................................................................................................... 30
7 Command Reference ............................................................................................................................ 31
7.1.1 “A” Commands........................................................................................................................ 31
7.1.2 “B” Commands ........................................................................................................................ 31
7.1.3 “C” Commands ........................................................................................................................ 32
7.1.4 “D” Commands........................................................................................................................ 33
7.1.5 “E” Commands ........................................................................................................................ 36
7.1.6 “F” Commands ........................................................................................................................ 38
7.1.7 “G” Commands........................................................................................................................ 40
7.1.8 “I” Commands ......................................................................................................................... 49

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
60BActivating Your Modem
7.1.9 “L” Commands......................................................................................................................... 58
7.1.10 “M” Commands ................................................................................................................... 61
7.1.11 “N” Commands .................................................................................................................... 68
7.1.12 “O” Commands.................................................................................................................... 69
7.1.13 “P” Commands..................................................................................................................... 74
7.1.14 “R” Commands .................................................................................................................... 90
7.1.15 “S” Commands................................................................................................................... 100
7.1.16 “T” Commands................................................................................................................... 110
7.1.17 “U” Commands .................................................................................................................. 111
7.1.18 “V” Commands .................................................................................................................. 113
7.1.19 “W” Commands ................................................................................................................. 115
8Report Messages................................................................................................................................. 120
8.1 Message Type 03, PMID................................................................................................................. 120
8.2 Message Type 16, $GPGLL ............................................................................................................. 121
8.3 Message Type 20, PIND ................................................................................................................. 121
8.4 Message Type 21 to 26, PINA ........................................................................................................ 122
8.5 Message Type 30, PCTM ................................................................................................................ 122
8.6 Message Type 40, ID= .................................................................................................................... 123
8.7 Message Type 80, $GPGGA............................................................................................................ 123
8.8 Message Type 82, GPRMC ............................................................................................................. 124
8.9 Message Type 84, $GPGSA ............................................................................................................ 124
8.10 Message Type 85, ULCP binary position message with GPS coordinates ................................ 125
8.11 Message Type 88, ULCP message with Acceleration/Deceleration and GPS information ....... 125
8.12 Message Type 89, ULCP binary format, Modem ID/Firmware, Revision/Odometer value...... 126
8.13 Message Type 90, ULCP binary format, Odometer value......................................................... 126
8.14 Message Type 98, ULCP binary format, Digital Inputs plus GPS data....................................... 127
8.15 Message Type 100, Trimble proprietary TAIP PV message ...................................................... 127
8.16 Message Type 101, Trimble Proprietary LN message............................................................... 128
8.17 Message Type 112, ULCP binary format, Digital input and Output states, Modem ID and GPS
data 128
8.18 Message Type 114, $PGPS........................................................................................................ 129
8.19 Message Type 115, $PKML ....................................................................................................... 130
8.20 Message Type 116, $PPWR....................................................................................................... 130
8.21 Message Type 117, $PRFI ......................................................................................................... 131

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
70BActivating Your Modem
8.22 Message Type 117, $PRFI ......................................................................................................... 131
8.23 Message Type 118, $GPGSV ..................................................................................................... 132
8.24 Message Type 119, $POBDA..................................................................................................... 132
8.25 Message Type 120, $POBDB..................................................................................................... 133
8.26 Message Type 121, $POBDC..................................................................................................... 133
8.27 Message Type 122, $POBDD..................................................................................................... 134
8.28 Message Type 136, $PACCEL .................................................................................................... 134
8.29 Message Type 137, $PODO....................................................................................................... 135
9 Email Message Format........................................................................................................................ 135
10 MODBUS Messages........................................................................................................................ 136
10.1 Read Digital Outputs................................................................................................................. 136
10.2 Set Digital Output ..................................................................................................................... 137
10.3 Read Digital Inputs.................................................................................................................... 137
10.4 Read Analog Inputs................................................................................................................... 138
10.5 Error response .......................................................................................................................... 139
10.6 MODBUS TCP Messages ........................................................................................................... 139
11 ULCP Remote Configuration Messages.......................................................................................... 140
11.1 ULCP Message Format .............................................................................................................. 140
11.2 ULCP Remote Configuration Messages .................................................................................... 141
11.2.1 Set Digital Outputs............................................................................................................. 141
11.2.2 NMEA GGA Query.............................................................................................................. 141
11.2.3 NMEA RMC Query ............................................................................................................. 141
11.2.4 ULCP Binary Position Query............................................................................................... 142
11.2.5 Time Based Reporting........................................................................................................ 142
11.2.6 Delta Position Based Reporting ......................................................................................... 143
11.3 Examples ................................................................................................................................... 144
11.3.1 1. Set all OUTPUT ports(1~4) on........................................................................................ 144
11.3.2 2. Set Delta Position Based Reporting ............................................................................... 145
12 Technical Specifications ................................................................................................................. 145
12.1 FCC/IC Approvals ...................................................................................................................... 145
12.2 Temperature ............................................................................................................................. 145
12.3 Humidity ................................................................................................................................... 145
12.4 Vibration ................................................................................................................................... 146
12.5 Shock......................................................................................................................................... 146

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
80BActivating Your Modem
12.6 Sealing....................................................................................................................................... 146
12.7 Material..................................................................................................................................... 146
12.8 Power Supply ............................................................................................................................ 146
12.9 Host Connectivity...................................................................................................................... 146
12.10 I/O ............................................................................................................................................. 147
12.11 RF .............................................................................................................................................. 147
12.11.1 CDMA/EV-DO..................................................................................................................... 147
12.11.2 GSM/GPRS/HSPA............................................................................................................... 147
12.12 GPS............................................................................................................................................ 147
12.13 Physical ..................................................................................................................................... 148
13 Technical Support .......................................................................................................................... 148

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
90BActivating Your Modem
1 Activating Your Modem
1.1 Gather Account Information
1.1.1 CDMA/EV-DO devices
For Sierra Wireless AC595/AC597/AC598/AC580 CDMA/EV-DO devices, the following information is
typically required:
•Phone number (10-digit MDN)
•Lock code (6-digit CSL)
•User name (number@… format)
•Password
•Dial number (usually #777)
For all other manufacturer data devices and cards, network activation of the device must be done in a
laptop prior to installing in the modem.
1.1.2 GSM/GPRS/HSPA devices
For GSM/GPRS/HSPA devices, the following information is required:
•An activated SIM card needs to be installed in the Modem or data card
•cmd factory gsm must be entered
Note: TRU-install™ must be disabled on devices that support the TRU-install™ feature prior to
installation into the modem, or activation will not be successful
1.2 Embedded Web Page Activation
Note: Activation via the modem Embedded web browser is supported only on Sierra Wireless AC595,
AC597 Express Card, AC597/8 USB and AC580 data devices with the TRU-install™ feature disabled. For all
other devices, activate the device using a laptop
1.2.1 Automatic Activation via Modem Embedded Web Browser
On the OTASP (Over-The-Air Service Provisioning) page, click Initiate to start the OTASP processing,
depending on the programming data on the modem card, one or more of the following messages will be
displayed on the OTASP page’s status window:
•SPL Unlocked
•Authentication key has been updated
•Shared secrets data has been exchanged

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
100BActivating Your Modem
•New NAM parameters have been downloaded
•New MDM has been downloaded
•IMSI has been downloaded
•PRL has been downloaded
During updating, if any of the above data is unsuccessful, the "OTASP Timeout" message and the "OTASP
Disconnected" message will be displayed. To retry the OTASP process, click Initiate to re-start. When the
OTASP process is complete and the provisioning parameters have been committed the "OTASP
Disconnected" message will be displayed.
Click Initiate and cycle the power on the modem.
1.2.2 Manual Activation via Modem Embedded Web Browser
On the Activate page, enter the Lock code (CSL), the Phone number (MDN), and the Mobile Identification
Number (MIN).
CSL, MDN and MIN are all required to successfully activate the data device.
The MIN entry is provided to add support for the Wireless Number Portability (WNP).
If you were provided with a MIN from your service provider then enter the 10-digit number in the MIN
field and enter the Lock code (CSL).
If you were not provided with a MIN then copy the 10-digit number for the MDN in the MIN field and
enter the Lock code (CSL).
Click Submit and cycle the power on the modem.
1.3 Command Line Activation
Note 1: Command line activation can be via a local telnet session or console session via the modem serial
interface
Note 2: Activation via the command line interface is supported only on Sierra Wireless AC595, AC597
Express Card, AC597/8 USB and AC580 data devices with the TRU-install™ feature disabled. For all other
devices, activate the device using a laptop
There are two methods, OTASP is a single command entry and the simplest, if OTASP does not work
follow the Manual Activation instructions.

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
110BActivating Your Modem
1.3.1 Automatic Activation (OTASP)
At # prompt, type the command:
cmd otasp and press Enter.
This command is used to perform automatic wireless network activation and updates any required
network related files that are embedded in the wireless modem. The modem responds with one or more
of the following messages:
•SPL Unlocked
•Authentication key has been exchanged
•Shared secrets data has been updated
•New NAM parameters have been downloaded
•New MDM has been downloaded
•IMSI has been downloaded
•PRL has been downloaded
During updating, if any of the data is unsuccessful, the "OTASP Timeout" message and "OTASP
Disconnected" message will be displayed. A progress message reading "OTASP Processing" will be
displayed every 10 seconds. When the OTASP process has successfully completed and the provisioning
parameters have been committed, a message "OTASP Disconnected" message will be displayed.
1.3.2 Manual Activation
At # prompt, type the following commands:
cmd spc pppppp where pppppp is the 6 digit lock code
cmd dir nnnnnnnnnn where nnnnnnnnnn is the 10 digit MDN phone number
cmd pwrmode 2 power cycle the modem
The MIN entry is provided to add support for Wireless Number Portability (WNP) and also needs to be set
on the modem by entering the following commands:
If no MIN is provided use the MDN number provided.
cmd spc pppppp where pppppp is the 6 digit lock code
cmd dir + nnnnnnnnnn where nnnnnnnnnn is the 10 digit MIN number
cmd pwrmode 2 power cycle the modem

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
121BInstalling Your Modem
2 Installing Your Modem
2.1 Mounting
The CTM-15x is provided with a flexible mounting bracket that has eight 5mm mounting holes suitable for
#10 screws. These may be used to screw or bolt the device to a suitable surface – take care not to over-
tighten these screws and damage the bracket. Once this has been installed in the required location the
modem clips into the 4 tabs of the bracket. The bracket can be used as drill guide template. There are a
total of 8 mounting holes, (2, 4 hole patterns, 2 x 5.5 and 1.75 x 3.75)

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
131BInstalling Your Modem
The modem can be installed in any orientation, but it is suggested that the modem not be mounted with
the interconnect face directed upwards as this can allow liquids to enter the modem.
The modem should be mounted in an area where it is free from excessive dust and liquids.

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
141BInstalling Your Modem
2.2 Connecting the Power Cable
The power cable has three wires:
Red +V supply (+9 to +36VDC)
Black 0V return
White Standby (+V for operation, Off for standby)
A 5 Amp “slow-blow” fuse is recommended in the +V supply line.
The operate/standby switch may, for example, be the accessory position on a vehicle ignition switch. In
order to minimize the acquisition time of the GPS module in the CTM-15x at power on, it is recommended
to keep the +V supply connected – this will provide the “keep-alive” power required by the GPS module
to maintain its internal almanac.
2.3 Connecting the Ethernet Cable
Plug one end of a standard Ethernet patch cable into the CTM-15x Ethernet port, and the other end into
the LAN device, PC or Ethernet peripheral. The Ethernet port is compatible with 10Base-T or 100Base-T
connection types.
2.4 Mounting and Attaching the Cell Antenna
The antenna used with the CTM-15x must be a type suitable for operation on the network for which the
modem is activated. For CDMA/EV-DO/GPRS/HSPA networks this is typically a dual band 800 Mhz and
1900 Mhz antenna.
For optimum performance the antenna should be mounted in a vertical orientation as high up as possible
and with clear line of sight in all directions. For regulatory purposes it must be mounted in such a position
as to maintain a separation distance from any person of at least 20cm (8”).

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
151BInstalling Your Modem
The modem antenna connector is a standard SMA female type that requires the antenna cable to use a
male SMA connector. The CTM-15x can be provided with alternate antenna connector types – contact
Cypress Solutions for details.
2.5 Mounting and Attaching the GPS Antenna
The GPS antenna used with the CTM-15x (with GPS) must be an active type with gain of at least 26dB and
compatible with a 3.3 volt dc supply provided directly by the modem over the coax cable. The antenna
installation should typically be on an upper horizontal surface of a vehicle with a clear 360 degree view of
the sky.
The GPS antenna connector is a standard MCX type or SMA female depending on whether the CTM-15X
modem is PC-CARD based or Express card/module/USB based. The CTM-15x can be provided with
alternate antenna connector types – contact Cypress Solutions for details.
2.6 Serial Data Cable Connection
The serial data port is a standard DB9 female connector configured as Data Communication Equipment
(DCE) and is wired as per the table below.
DB9 Pin Signal Name Direction
1 DCD Data Carrier Detect CTM-15x to PC
2
RxD
Received Data (by DTE)
CTM-15x to PC
3 TxD Transmitted Data (by DTE) PC to CTM-15x
4
DTR
Data Terminal Ready
PC to CTM-15x
5 GND Signal Ground
6 DSR Data Set Ready CTM-15x to PC
7 RTS Request To Send PC to CTM-15x
8 CTS Clear To Send CTM-15x to PC
9 RI Ring Indicator CTM-15x to PC
Serial data ports on most computer equipment are configured as Data Terminal Equipment (DTE) with a
DB9 male connector. A standard serial data cable will allow for direct connection of the CTM-15x to most
computer and terminal equipment. In some cases it may be necessary to insert a “null modem” or
“gender changer” in the serial data line in order to correctly connect between the devices.
2.7 Connecting to the I/O Port
The I/O port provides for the control of 4 external devices and for monitoring 6 external sensors.
Connections are made via the 12 position connector.

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
161BInstalling Your Modem
OUT1 OUT3 OUT GND IN1 IN3 IN5
1 3 5 7 9 11
2 4 6810 12
OUT2 OUT4 GND IN2 IN4 IN6
2.7.1 Output Connection
The 4 outputs are configured as “open drain” which means that they can be directly connected to
energize external relays, lamps or other DC devices.
Maximum supply voltage is 36 volts, with a maximum load current of 500mA.
Recommended wire gauge for use with the connector is 16AWG. Note that the OUT GND connection is
referenced to the modem’s supply ground.
2.7.2 Input Connection
The 6 inputs may be configured in the modem for monitoring a digital DC voltage state or an analog DC
voltage.
For digital state monitoring the minimum input voltage is 0 volts while the maximum is 36 volts.
The threshold detection voltage is 2.5 volts with 1 volt of hysteresis. Note that the IN GND connection is
referenced to the modem’s supply ground.

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
172BOperating Your Modem
For analog voltage monitoring the measurement range is 0 to +10 volts with 10mV resolution. The input
can withstand up to 36 volts. Note that the IN GND connection is referenced to the modem’s supply
ground.
3 Operating Your Modem
3.1 Automatic Power Control
The supply voltage must be a minimum of 9VDC for the CTM-15x to operate. With the power applied it
will power-up in its operating mode.
Note: In some vehicle operation, when starting the engine the vehicle supply voltage will dip below 9VDC
momentarily. This will cause the modem to reset as the power dips below 9VDC. If continual operation is
required, contact Cypress Solutions for an accessory power regulator that plugs in-line with the modem
power supply. This power regulator will prevent unnecessary resets.

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
182BOperating Your Modem
The CTM-15x Chameleon device has two power modes:
Mode Description Mode change event
Operation In this mode the device is fully
powered up and ready to receive
or make network connections
The device will go back into shutdown mode when the
ignition/standby signal is deactivated or upon expiry of
the power ON timer as configured.
Shutdown
Only the modem’s power
management circuits are
operating.
The device will go back into operation mode when the
ignition/standby signal is activated, an input event
occurs, or upon expiry of the power OFF timer as
configured.
The CTM-15x can be configured to remain on for a defined period after the standby/ignition signal has
been turned off. This enables the modem to continue sending position reports or be used for data
operations even after the vehicle ignition has been switched off – e.g. for short duration driver breaks.
When in its power shutdown mode the modem may be configured to resume full operation by either the
standby/ignition signal becoming active, an input event occurring, or the power OFF timer expiring.
3.2 Power Consumption
The power consumption of the CTM-15x modem will depend on its supply voltage, its current operating
function and its RF environment.
The following table is provided to assist application integrators in defining the power requirements for
their specific application.
Power Consumption
Weak RF
signal(12V)
Strong RF
signal(12V)
Weak RF
signal(24V)
Strong RF
signal(24V)
Shutdown Mode 1.5mA typical 1.5mA typical 2.0mA typical 2.0mA typical
Downloading (Receive
data)
450mA max 350mA max 220mA max 195mA max
Uploading (Transmit
data)
500mA max 390mA max 260mA max 210mA max
3.3 Device Reset
The CTM-15X modem may be manually reset via the front panel using a <1mm diameter (0.04”) wire tool
(a standard paper clip). This can be used to cause the modem to reset its operation, or to enter its
standby power mode.
reset: Press and hold for 0.25 to 1 second

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
192BOperating Your Modem
shutdown: Press and hold for 2 to 5 seconds (the PWR LED will go off at the 2-second mark). Press again
for more than 0.25 second to return to operating mode.
3.4 LED Indicators
There are five LED indicators on the CTM-15x top. These are used to show the status and operation of the
device.
For Sierra Wireless/Kyocera Wireless CDMA/EV-DO data devices or modules:
LED Description Solid Blinking Off
PWR Power status of the
device
full operating mode
and able to connect
device is in shutdown
mode
the device has no
power
CELL status of the device on
the wireless network
receiving a signal
greater than or equal
to -95dBm
receiving a signal less
than -95dBm
device is not
detecting a valid RF
signal
TX/RX data is being
transmitted or
received
N/A Data is being
transmitted or
received
no data is being
transmitted or
received
GPS status of the GPS
module
GPS module has
obtained a valid
position fix
GPS module does not
have a valid position fix
3G indicates the type of
wireless data
connection
EV-DO Rev A (typical
downlink 450 to
800kbps)
EV-DO Rev 0 (typical
downlink 400 to 700
kbps)
1xRTT (typical
downlink 40 to 100
kbps)
For Sierra Wireless HSPA, Novatel Wireless, Option or other Manufacturer devices:
LED Description Solid Blinking Off
PWR Power status of the
device
full operating mode
and able to connect
device is in shutdown
mode
the device has no
power
CELL
status of the device on
the wireless network
device is connected
to the wireless
network
N/A
device is not
connected to the
wireless network

© 2009 Cypress Solutions Complete Manual: CTM-15X Firmware 1.2.0
(Revision 1.0)
202BOperating Your Modem
TX/RX data is being
transmitted or
received
N/A Data is being
transmitted or
received
no data is being
transmitted or
received
GPS status of the GPS
module
GPS module has
obtained a valid
position fix
GPS module does not
have a valid position
fix
3G indicates the type of
wireless data
connection
N/A N/A N/A)
3.5 Making a Wireless Network Connection
The CTM-15X will attempt to connect to the wireless network whenever power is applied, when
configured with cmd mode 2 (default)
If no wireless network connection is available the IP address will be given as 0.0.0.0. This can be queried
using cmd ipadr For Sierra Wireless RF devices, wireless signal strength information can be queried using
cmd rssi. These values for both 1x and EV-DO are given in dBm with range typically -60dBm (very good) to
-105dBm (weak).
With the wireless network connection active you may now open Windows® applications that will make
use of this connection – this includes email, web browsers, and VPN connections.
3.6 GPS Operation
The GPS module in the CTM-15X Modem will continuously track the unit’s position whenever power is
applied and the GPS antenna has a clear view of the sky. The time taken for the module to achieve a valid
positional fix is determined by the previous state of the unit:
For a “cold” start (after all power is applied to the modem) the acquisition time typically will be less than
50 seconds.
For a “warm” start (standby power is maintained to the CTM-15x) the acquisition time will typically be
less than 38 seconds.
For reacquisition (after the GPS module has temporarily lost signal) the time to acquire a valid position fix
is typically less than 2 seconds.
The GPS information can be sent by the device as a message in any of the configured reports.
The GPS receiver uses the WGS-84 datum.
