F²MC - 8FX Family, MB95200 Series, How to make on-Board Debug
Debugging on the target board is a very important step in project design. This document will describe how to debug
on a target board. The debugging interface described in this document can be used both as the in-circuit debugging
tool and the in-circuit programming tool.
Contents
1Introduction..................................................................1
2Application Environment..............................................2
2.1 Debug Tool .........................................................2
2.2 SOFTUNE...........................................................2
3MCU Products.............................................................3
4Hardware Design.........................................................4
4.1 Single Flash MCU Debugging Circuit..................4
4.2 Dual Flash MCU Debugging Circuit....................5
5Debugging Operation..................................................7
5.1 Preparation before using F2MC-8L/8FX
SOFTUNE...........................................................7
5.2 Debugging with F2MC-8L/8FX SOFTUNE..........8
6Additional Information................................................12
Document History............................................................13
1 Introduction
Debugging on the target board is a very important step in project design. This document will describe how to debug
on a target board.
The debugging interface described in this document can be used both as the in-circuit debugging tool and the in-
circuit programming tool.

F²MC - 8FX Family, MB95200 Series, How to make on-Board Debug
www.cypress.com Document No. 002-05390 Rev.*A 2
2 Application Environment
This chapter introduces application environment for MB95200H/210H SOP20 PGM adaptor.
2.1 Debug Tool
The debugging tool is BGMA (BGM Adaptor) and its model No. is MB2146-08-E, as shown in the picture below. It is
available in the MB95200 MCU Starter Kit (PN: MB2146-410A-01-E).
Figure 1. BGM Adaptor
2.2 SOFTUNE
SOFTUNE is used as software development environment for programming and debugging.
The version currently being used is F2MC-8L/8FX SOFTUNE Workbench V30L31, as shown below in the picture. It is
available in the MB95200 MCU Starter Kit (PN: MB2146-410-01-E)
Figure 2. SOFTUNE Version

F²MC - 8FX Family, MB95200 Series, How to make on-Board Debug
www.cypress.com Document No. 002-05390 Rev.*A 3
3 MCU Products
This chapter introduces different models of MCU products.
As the in-circuit debugging interface in the single flash MCU is different from that in the dual flash MCU, MCUs are
classified into two categories in the list below.
Table 1. MCU Products
Series Flash type Chip list Series Flash type Chip list
MB95F200H
Single
Flash
MB95F202K
MB95F260H
Dual
Flash
MB95F262K
MB95F202H MB95F262H
MB95F203K MB95F263K
MB95F203H MB95F263H
MB95F204K MB95F264K
MB95F204H MB95F264H
MB95F210H
Single
Flash
MB95F212K
MB95F270H
Dual
Flash
MB95F272K
MB95F212H MB95F272H
MB95F213K MB95F273K
MB95F213H MB95F273H
MB95F214K MB95F274K
MB95F214H MB95F274H
MB95F220H
Single
Flash
MB95F222K
MB95F280H
Dual
Flash
MB95F282K
MB95F222H MB95F282H
MB95F223K MB95F283K
MB95F223H MB95F283H
MB95F284K
MB95F284H
MB95F330H
Dual
Flash
MB95F332K
MB95F332H
MB95F333K
MB95F333H
MB95F334K
MB95F334H

F²MC - 8FX Family, MB95200 Series, How to make on-Board Debug
www.cypress.com Document No. 002-05390 Rev.*A 4
4 Hardware Design
This chapter introduces the circuit of debugging interface.
As the MB95200 series has two types of flash, i.e. single flash and dual flash, there are two types of debugging
circuits corresponding to them. This chapter will introduce the two programming circuits. Make sure to choose the
correct circuit in application.
4.1 Single Flash MCU Debugging Circuit
Figure 3shows the circuit diagram of the in-system debugging interface. To design the in-system debugging
interface, four pins, UVCC_EV, GND, RSTIN and DBG, are needed. (Add pin RST_OUT if necessary).
Figure 3. Basic Connector Circuit for Single Flash MCU
Component Recommendation:
D1: VF < 0.3V when IF = 1mA. E.g. LL103A, 1SS294
Below is a list of functions of the interface connector.
1. J1 is a 10-pin connector, used as the circuit interface.
2. The write voltage (VCC = 4.5V to 5.5V) is supplied from the user system. The UVCC_EV and DBG pins
control the PGM mode entry.
3. Pin 2 of the connector connects to the GND.
4. The debugger provides 10 V directly to the RSTX pin during flash erase/write operation. If it is pulled high in
the user system, please consider to add a low-drop diode for separate H voltage.
5. The DBG pin provides 1-line UART communication with the debugger. Serial write mode can be set by
providing special timing of DBG and VCC pins.
If the MCU target needs a reset circuit, please design the reset circuit according to the diagram below.

F²MC - 8FX Family, MB95200 Series, How to make on-Board Debug
www.cypress.com Document No. 002-05390 Rev.*A 5
Figure 4. Debugging Connector and Reset Circuit for Single Flash MCU
Pin 4 of the connector is used to connect to the reset circuit. Please design a switch K1 between the reset circuit and
the reset pin (RSTX). Make sure to cut off K1 to stop the high voltage flowing through the reset circuit during the
debugging operation. Turn on K1 to supply the reset circuit to the target MCU when the debugging operation is over.
4.2 Dual Flash MCU Debugging Circuit
Figure 5 shows the circuit diagram of the in-system debugging interface. To design the in-system debugging
interface, three pins, UVCC_EV, GND and DBG, are needed. (Add pin RST_OUT if necessary.)
Figure 5. Dual Flash MCU Debugging Circuit
Component Recommendation:
D1: VF < 0.3V when IF = 1mA. E.g. LL103A, 1SS294
Below is a list of functions of the interface connector.
1. J1 is a 10-pin connector, used as the interface of this circuit.
2. The write voltage (VCC = 4.5V to 5.5V) is supplied from the user system. The UVCC_EV and DBG pins control
the PGM mode entry.
3. Pin 2 of the connector connects to the GND.
4. The DBG pin provides 1-line UART communication with the debugger. Serial write mode can be set by providing
special timing of DBG and VCC pins.
If the MCU target need a reset circuit, and please design a reset circuit as follow circuit.

F²MC - 8FX Family, MB95200 Series, How to make on-Board Debug
www.cypress.com Document No. 002-05390 Rev.*A 6
Figure 6. In-system Debugger Interface
Pin 4 of the connector is used to connect to the reset circuit. Design a switch K1 between the reset circuit and the
reset pin (RSTX). When debugging operation is over, K1 can be switched on to supply the reset circuit to the target
MCU.

F²MC - 8FX Family, MB95200 Series, How to make on-Board Debug
www.cypress.com Document No. 002-05390 Rev.*A 7
5 Debugging Operation
This chapter introduces debugging operation by F2MC-8L/8FX SOFTUNE.
5.1 Preparation before using F2MC-8L/8FX SOFTUNE
1. Connect the BGMA to a PC.
2. Connect the EV-board to the BGMA (Note that user can only power on the MCU after connecting the target
board to the BGM adaptor).
3. Power on the EV-board.
Figure 7. Step 1-3
4. Open a project (E.g. IO_LED) using SOFTUNE.
Figure 8. Open the Demo Project
(1)
(3)
(2)

F²MC - 8FX Family, MB95200 Series, How to make on-Board Debug
www.cypress.com Document No. 002-05390 Rev.*A 8
5.2 Debugging with F2MC-8L/8FX SOFTUNE
After the 3-step preparation introduced in Chapter 5.1, user can start debugging as shown below.
1. Start debugging. (by clicking Start Debug in Debug)
Figure 9. Start Debugging
2. Start Debugging (Code Update)
Select Debug -> Run to start debugging or use the shortcut key as indicated in Figure 11.
Figure 10. Run Operation

F²MC - 8FX Family, MB95200 Series, How to make on-Board Debug
www.cypress.com Document No. 002-05390 Rev.*A 9
Figure 11. Shortcut Keys
3. Register Operation
Select View -> Register to open the Register window. Then right click, select Setup from shortcut menu to
add/delete registers in the register window. Select Edit -> Register from the pull-down list, input the value in
Register value, and Click OK to store the new value to the register.
Figure 12. Register Operation
4. Memory Operation
Then select View -> Memory to display the Memory window, Address content can be modified by highlight the
address and then type the new value.
Figure 13. Memory Operation

F²MC - 8FX Family, MB95200 Series, How to make on-Board Debug
www.cypress.com Document No. 002-05390 Rev.*A 10
5. Watch Operation
Highlight the symbol to be watched. Right click and select Watch in the shortcut menu.
Figure 14. Select the Watch Window
Put the mouse pointer inside the window. Right click and select Monitoring from shortcut menu to monitor
symbols continuously.
Figure 15. Continuously Monitoring
