Cyrus TTP User manual

TURNTABLE USER GUIDE
BUILDING A BETTER MUSIC EXPERIENCE

Cyrus Turntable User Instrucons
IMPORTANT! READ BEFORE OPERATING THIS EQUIPMENT! ...1
Power supply .............................................................................2
Servicing ....................................................................................2
Product service centres .............................................................2
FCC Noce .................................................................................3
WELCOME TO THE WORLD OF CYRUS........................................4
Preparaons for Installaon......................................................4
INSTALLATION...............................................................................5
Key to the rear panel drawing ...................................................5
Important – read before making any connecons ....................5
Fing the plaer.......................................................................5
Fing the belt ...........................................................................5
Fing a cartridge ......................................................................5
Arm balancing ...........................................................................6
Applying tracking pressure........................................................6
Applying an-skang (bias) adjustment....................................6
Connecng analogue audio.......................................................6
External power supply - PSX-R...................................................6
Connecng to the AC mains supply...........................................6
OPERATION ...................................................................................7
Key to the front panel drawing..................................................7
Power ........................................................................................7
Mains power..............................................................................7
Standby......................................................................................7
Speed selecon .........................................................................7
Playing a record.........................................................................7
SPECIFICATIONS............................................................................8
Speed.........................................................................................8
Power Supply.............................................................................8
Power Consumpon..................................................................8
Enclosure...................................................................................8
WEEE..............................................................................................8
CONTENTS

1
Cyrus Turntable User Instrucons
WARNING: To reduce the risk of electrical shock do not
remove any unit covers or panels. There are no user
serviceable parts in this product.
WARNING: To reduce the risk of electric shock, do not
expose this equipment to rain or moisture.
HEED WARNINGS: All warnings on the product and in the
operang instrucons should be adhered to.
READ ALL THE INSTRUCTIONS: All the safety and operang
instrucons should be read before the product is operated.
RETAIN INSTRUCTIONS: The safety and operang
instrucons should be retained for future reference.
FOLLOW INSTRUCTIONS: All operang and use instrucons
should be followed.
CLEANING: Unplug this product from the mains before
cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
WATER AND MOISTURE: Do not use this product near
water - for example, near a bath tub, wash bowl, kitchen
sink, or laundry tub, in a wet basement; or near a
swimming pool and the like. The product must not be
exposed to dripping or splashing and no objects lled with
liquids, such as vases, shall be placed on the product.
HEAT: The product should be situated away from heat
sources such as radiators, stoves, or any other products
(including ampliers) that produce heat.
VENTILATION: Slots and openings in the cabinet are
provided for venlaon, to ensure reliable operaon of
the product and to protect it from overheang and these
openings must not be blocked or covered. The openings
should never be blocked by placing the product on a bed,
sofa, rug or similar surface. This product should not be
placed in a built-in installaon such as a bookcase or rack
unless proper venlaon is provided or the manufacturer’s
instrucons have been adhered to.
OBJECT OR LIQUID ENTRY: Never push objects of any kind
into this product through openings as they may touch
dangerous voltage points or short-out parts that could
result in a re or electric shock.
ACCESSORIES: Do not place this product on an unstable
cart, stand, tripod, bracket, or table. The product may
fall, causing serious injury to a child or adult, and serious
damage to the product. Use only with a cart, stand, tripod,
bracket or table recommended by the manufacturer, or
sold with the product. Any mounng of the product should
follow the manufacturer’s instrucons, and should use a
mounng accessory recommended by the manufacturer.
POWER SOURCES: This product should be operated
only from the type of power source indicated on the
marking label. If you are not sure of the type of power
supply to your home, consult your product dealer or local
power company. For products intended to operate from
baery power, or other sources, refer to the operang
instrucons.
OVERLOADING: Never overload wall outlets, extension
cords, or integral convenience receptacles. This can result
in an increased risk of re or electric shock.
POWER CORD PROTECTION: Power supply cords should
be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying
parcular aenon to cords at plugs, convenience
receptacles, and the point where they exit from the
product.
NAKED FLAMES: No naked ame sources, such as candles,
must be placed on this product.
LIGHTNING: For added protecon for this product during
a lightning storm, or when it is le unaended or unused
for long periods of me, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line
surges.
BATTERIES: Warning: Baeries shall not be exposed to
excessive heat such as sunshine, re or the like.
CAUTION! POLARISED CONNECTOR (CANADA and USA):
To prevent electrical shock, match wide blade of plug to
wide slot, fully insert. Do not alter or remove this plug if
it does not t your mains power socket. Have a suitable
socket installed by a competent electrician.
ACCESS TO THE MAINS PLUG: The means to disconnect
this product from the mains supply is the mains plug.
Ensure that the mains plug is accessible at all mes.
IMPORTANT! Read before operang this equipment!
CAUTION: The exclamaon mark is to draw your
aenon to important instrucons and safety
procedures in this manual.
ATTENTION: The lightning ash warns you of the
risk of electrical shock presented by components
inside this product. Unauthorised personnel
must not open this unit.
MOVING THE PRODUCT: A product and cart
combinaon should be moved with care.
Sudden stops, excessive force, and uneven
surfaces may cause the product and cart to
overturn.
ATTACHMENTS: Do not use aachments not recommended
by the product manufacturer as they may cause hazards.

2
Cyrus Turntable User Instrucons
Power supply
Connect the moulded IEC connector of the supplied AC
cord into the power inlet on the power supply. Connect
the power connector to the turntable.
The mains supply requirement of your amplier is marked
on a label on the rear panel. Before connecng, check that
this voltage is the same as your mains supply.
115-230V Products: Voltage Range 110V-240V
There are no user replaceable fuses in this unit.
Servicing
Do not aempt to service this product yourself as opening
or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualied service
personnel.
CONDITIONS REQUIRING SERVICE: Unplug this product
from the wall outlet and refer servicing to qualied service
personnel when:
• When the power supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into the
product.
• If the product has been exposed to rain or water.
• If the product has been dropped or damaged in any
way.
• If the product does not operate normally by following
the operang instrucons. (Adjust only those controls
that are covered by the operang instrucons.
Improper adjustment of other controls may result
in damage requiring extensive work by a qualied
technician to restore the product to its normal
operaon).
• When the product exhibits a disnct change in
performance.
REPLACEMENT PARTS: When replacement parts are
required, be sure the service technician has used
replacements specied by the manufacturer or have the
same characteriscs as the original part. Unauthorised
substuons may result in re, electric shock, or other
hazards.
SAFETY CHECK: Upon compleon of any service or repairs
to this product, ask the service technician to perform
safety checks to determine that the product is in proper
operang condion.
Product service centres
For product service or technical advice, contact only
authorised Cyrus service centres. Contact details for
Cyrus distributors may be found on the Cyrus website at
www.cyrusaudio.com.

3
Cyrus Turntable User Instrucons
FCC Noce
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed
to provide reasonable protecon against harmful interference in a residenal
installaon. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucons, may cause
harmful interference to radio communicaons. However, there is no guarantee that
interference will not occur in a parcular installaon. If this equipment does cause
harmful interference to radio or television recepon, which can be determined by
turning the equipment o and on, the user is encouraged to try and correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modicaons not expressly approved by the manufacturer could void
the user’s authority to operate the equipment.

4
Cyrus Turntable User Instrucons
Welcome to the world of Cyrus
Congratulaons on your choice of Cyrus hi- products. Our
state-of-the-art design technology and outstanding quality
of manufacture has won countless awards around the
world. We are condent that you will derive great pleasure
from owning a product from one of the most recognised
and respected manufacturers of hi- equipment.
Now is a good me to register your new Cyrus product.
To register, click here or visit -
www.cyrusaudio.com/support/warranes.
Please read these instrucons carefully before commencing
installaon. They provide full guidance to help you install
your turntable safely and correctly.
Preparaons for Installaon
Before installing your Cyrus turntable check that the
following items are included in the packing.
• Power supply
• Power Cables for UK, US, Europe
• Plaer Mat
• Plinth
• Plaer
• Belt
• Replacement Bearing Oil
• Quick-Start guide
• Cartridge alignment template
Aer removing these items, please retain the packaging.
Install the turntable in a well venlated locaon away from
sources of high temperature, dust or humidity. Never stand
the turntable under another unit or on any surface likely to
obstruct its cooling or venlaon.
Place the plinth in the desired locaon. This must be a at
surface that is capable of supporng the full weight of the
turntable once assembled.

5
Cyrus Turntable User Instrucons
Installaon
1. PSU inlet
2. 33RPM speed adjustment
3. 45RPM speed adjustment
4. Ground terminal
5. PSX-R connecon
Key to the rear panel drawing
d
ae bc
To avoid possible damage to your audio system, it
is essenal to disconnect all system components
from the mains supply before connecng or
disconnecng audio interconnects.
Important – read before making any connecons Fing the plaer
• Remove the cover strip from the bearing hole on the
plinth. Carefully insert the spindle of the plaer into the
bearing hole and slowly lower the plaer into place.
Gently spin the plaer to ensure it spins easily. Fit the
supplied plaer mat onto the plaer. Let the plaer
sele for around 15 minutes before turning on the
turntable.
• Note: The bearing is pre-lubricated at the factory so no
user lubricaon should be required.
Fing the belt
• Fit the belt rstly around the plaer and then into the
motor pulley groove. Gently rotate the plaer by hand
for a few turns and the belt will self-align.
Fing a cartridge
• If your Cyrus dealer has not ed a cartridge, t the
cartridge and align it in accordance with the cardge
manufacturer’s instrucons. The supplied cartridge
alignment template should be used to aid this process.
• The tonearm wires are colour-coded as follows:
Red - right hot
Green - right ground
White - le hot
Blue - le ground

6
Cyrus Turntable User Instrucons
Arm balancing
• Fit the balance weight (1).
• With the cartridge correctly mounted and with the
stylus guard removed, ensure that the tracking force
dial (2) and bias adjustment (5) are set to zero. Adjust
the balance weight unl the arm is “oang” with the
stylus approximately 1mm clear of the record.
• Note: It is normal for the arm to swing back towards
the arm clip posion even if the bias is set to zero.
Therefore it is advisable to gently hold the arm bearing
carrier (just below the tracking dial) this prevenng
horizontal movement during the balancing procedure.
Applying tracking pressure
• Once the arm is balanced, rotate the tracking force
adjustment dial to the required tracking force.
Numbers ‘0’ to ‘3’ are marked on the dial. if in
doubt, it is usually advisable to use a tracking force
that corresponds to the upper limits of the cartridge
manufacturer’s range.
Applying an-skang (bias) adjustment
• Set the bias adjustment slider located to the same
gure as the cartridge tracking force pressure quoted by
your cartridge manufacturer.
• Note: This is not crical and a gure of between 1.5 &
2.0 will normally be suitable.
Connecng analogue audio
• Connect the le and right cables to the Phono input of
your amplier of phono pre-amp, using the MM/MC
input as appropriate to your cartridge.
External power supply - PSX-R
The PSX-R is a unique DC power supply that will upgrade
the sonic performance of compable products in the Cyrus
range.
CAUTION:
• Disconnect both the PSX-R and Turntable from the
mains.
• Plug the mul-pin interconnect from the PSX-R into the
PSX-R socket on the back panel.
• Connect a mains supply to both units.
NOTE: Connecon of a PSX-R is detected automacally, so
no internal adjustments are required.
Connecng to the AC mains supply
Connect the socket on the AC Power block to the power
inlet on the Turntable. Now connect the AC power cable to
a suitable AC power point.
NOTE: The means to disconnect this product from the
mains supply is the mains plug. Ensure that the mains plug
is accessible at all mes.
3
2
1
4
5
6

7
Cyrus Turntable User Instrucons
Operaon
• Standby and indicator
• 33RPM selector
• 45RPM selector
Key to the front panel drawing
a
bc
Power
Mains power
In regular use mains power can be le connected
permanently.
When unaended for a long period (holidays etc) mains
power should be disconnected.
Standby
When mains power is connected, the standby key
() is used for power control.
Speed selecon
Press either the 33 or 45 key to select the appropriate
speed. The plaer will reach the desired speed within a
few seconds.
Playing a record
Place the record on the plaer mat. Select the correct
speed and wait for the plaer to get up to speed. Release
the tone arm by moving arm clip (4) to the right. li
the tonearm with the cueing device (3) by moving it
backwards. Using the nger li (6), gently move the
tonearm above the lead in groove on the record and gently
lower by moving the cueing device forward.
Once the side of the record has nished, li the tonearm
with the cueing device and rotate the tonearm back to the
right.

8
Cyrus Turntable User Instrucons
Troubleshoong guide
If your turntable is not operang properly, disconnect the
power and check carefully all connecons.
If you are in any doubt, consult your retailer.
No sound
Cartridge wired incorrectly. Check cartridge wiring.
Stylus guard le in place. Remove stylus guard.
Low output
MC cardge ed but MM
incorrectly selected on
phono pre-amp / incorrect
gain selected.
Check phono pre-amp
cardge type and gain
sengs are correct for the
ed cartridge.
Anything else?
Issue 3. Soluon 3.
Specicaons
Speed
33, 45 RPM
Power Supply
Voltage ................................................................... 90-256V
Power Consumpon
Standby...................................................................... <0.5W
Maximum ..................................................................... 20W
Safety compliance ................................................. UKCA, CE
EMC (230V)............................................................ UKCA, CE
EMC (115V)..................................................................... FCC
Enclosure
Size (HxWxD) . 98 x 430 x 376 mm (3.86” x 16.93” x 14.82”)
Weight ........................................................... 26.0kg (57lbs)
Material................................... Aluminium chassis & plaer
Cyrus reserves the right to change all specicaons without noce. E &OE
Warranty
The warranty period is three years. No retailer or
distributor may vary the terms of this warranty, which is
personal to the original purchaser and is not transferable.
Please retain the sales receipt as proof of purchase.
Warranty claims must wherever possible be made through
the retailer from whom the equipment was purchased.
This warranty excludes:
• Damage caused through neglect, accident, misuse,
wear and tear, or through incorrect installaon,
adjustment or repair by unauthorised personnel. Any
unauthorised servicing will result in loss of warranty.
• Liability for damage or loss occurring in transit to or
from the purchaser.
• Consequenal damage, loss or injury, arising from or in
conjuncon with this equipment.
Equipment for aenon under warranty should be
consigned return carriage paid. If returned equipment is
found to comply with the published specicaon, CYRUS
reserves the right to raise a charge.
The above condions do not aect your statutory rights as
a consumer.
WEEE
This logo means that this product is not to be disposed of
with your household waste. This product should be handed
over to a designated collecon point to be recycled. Your
cooperaon in the correct disposal of this product will
contribute to the eecve usage of natural resources. For
more informaon on collecon points, contact your local
government for more informaon about recycling.

Cyrus Audio Ltd., Ermine Business Park, Hunngdon, PE29 6XY, U.K.
Issue 1.0
www.cyrusaudio.com
