DWL-120
Wireless Access Through USB
Easy Installation
High Data Encryption
(64/128-bit)
Cost-Effective
Wireless Adapter
New Flip-Up/Fold-Up
Compact Design
D-Link, the industry leader in wireless
networking, introduces the new and improved
DWL-1201,part of the D-LinkAirTM family of
award-winning wireless products. The DWL-
120 is a USB 1.1 wireless adapter capable of
data transfer rates up to 11Mbps, giving you the
ability to connect to a wireless network at
home, at the office or at any wireless hotspot.
Now, you can stay connected wherever you are
and wherever you go.
The DWL-120 is Wi-Fi certified, meaning
that it can connect and interoperate with other
802.11b Wi-Fi-compliant wireless routers,
access points and adapters. The DWL-120
includes a standard USB cable and connects to
any available USB port on a laptop or desktop
Windows-based PC. With its USB cable
(included) and the adapter’s flip-up antenna,
the DWL-120 can be positioned virtually
anywhere in a workspace to achieve the best
available wireless signal reception
- whether
that workspace is in your office, on your deck or
patio, by the pool, at the local coffee shop, or in
an airport terminal while waiting to board your
next flight.
The adapter's Microsoft WHQL-certified
drivers for Windows XP ensure that you'll be
up and running on a wireless network in just a
matter of seconds. The DWL-120 also features
128-bit WEP encryption providing a level of
security for the data that you wirelessly transmit.
Using its default settings, the DWL-120
automatically connects to other D-LinkAirTM
products as soon as it’s active.
1. version E1

SPECIFICATIONS
D-Link Systems, Inc. 53 Discovery Drive Irvine CA 92618 www.dlink.com
©Copyright D-Link Systems, Inc. 2002. All rights reserved. D-Link® is a registered trademark of D-Link Systems, Inc.
Other trademarks or registered trademarks are the property of their respective manufacturers or owners. Price and
specifications are subject to changes without notice. See inside package for warranty details.
* 24/7 Tech Support is available only in USA.
DWL-120
Standards
.IEEE 802.11b
.Wi-Fi certified
.USB 1.1
Host Interface
.Mini USB to A-type
Data Rates
With Automatic Fallback
.11Mbps
.5.5Mbps
.2Mbps
.1Mbps
Encryption
.64-, 128-bit WEP
Media Access Control
CSMA/CA with ACK
Frequency Range
2.4GHz to 2.462GHz
Range
Up to 328 feet Indoors*
Modulation
.Direct Sequence Spread Spectrum
Modulation Techniques
.CCK (11Mbps)
.CCK (5.5Mbps)
.DQPSK (2Mbps)
.DBSK (1Mbps)
Transmit Output Power
19dBm (79mW) +-2dB
Receiver Sensitivity
.-84dBm for 11Mbps@ 8% PER
(Packet Error Rate)
.-90dBm for 2Mbps@ 8% PER
(Packet Error Rate)
Operating Voltage
.5VDC +- 10%
Internal Antenna Type
Dual PIFA (Patched Inverse
“F”Antenna)
Temperature
Operating: -32˚F to 131˚F (0˚C to 55˚C)
Storing: -4˚F to 167˚F (20˚C to 75˚C)
Humidity
5% - 95% non-condensing
Certifications
.FCC part 15b
Dimensions
.L=3.3 inches (85mm)
.W=2.2 inches (55mm)
.H=0.5 inches (14mm)
Weight
1.2 lbs (544g)
Warranty
1 Year
*Environmental Conditions may
Adversely Affect Wireless Range
The D-Link AirTM DWL-120 is an IEEE 802.11b
Wireless USB adapter. The DWL-120 provides
wireless access for your USB-enabled desktop
or laptop PC. It’s flip-up/fold-up, compact
design allows you to take it wherever you go.
