D-Link PersonalAir DBT-120 User manual

2D-Link DBT-120 User Manual
Table of Contents
Product Overview .........................................................................................................3
Package Contents ....................................................................................................3
System Requirements ..............................................................................................3
Introduction ...............................................................................................................4
Uninstalling a Previous Version of the Bluetooth Software .......................................5
Installing the Bluetooth Software ..............................................................................6
Using the Add New Connection Wizard ..................................................................12
Introduction to the Bluetooth Software ....................................................................17
Bluetooth Tray ...................................................................................................17
Bluetooth Information Exchanger .....................................................................17
Using Bluetooth Information Exchanger .................................................................18
Bluetooth Software Basic Operations .....................................................................18
Start or Stop Bluetooth .....................................................................................18
Create a Conection From the Bluetooth Icon in the System Tray .....................20
Create a Connection Using the Bluetooth Setup Wizard ..................................20
View Connection Details Using Bluetooth Settings ...........................................20
Delete a Connection Using Bluetooth Settings .................................................22
Contacting Technical Support ...................................................................................23
Warranty ......................................................................................................................24
Registration .................................................................................................................29
Table of Contents

3D-Link DBT-120 User Manual
Section 1 - Product Overview
• D-Link DBT-120 USB Bluetooth Adapter
• USB Extension Cable
• Installation CD with Driver, Manual, & Bluetooth Software
• Installation Guide
If any of the above items are missing, please contact your reseller.
System Requirements
• Windows® XP SP2 or 2000 SP4 / Macintosh® OSX 10.4.3 or higher
• A CD-ROM drive
• One Available USB Port
Product Overview
Package Contents

4D-Link DBT-120 User Manual
Section 1 - Product Overview
Introduction
The term “Bluetooth” refers to a worldwide standard for the wireless exchange of data between two devices within
a Personal Area Network. In order to exchange data, two Bluetooth devices must establish a connection. Before a
connection is established, one device must request a connection with another, where the second device accepts (or
rejects) the connection. The originator of the request is known as the client. The device that accepts (or rejects) the
request is known as the server. Many Bluetooth devices can act as both client and server. A client Bluetooth device
runs a software program that requests a connection to another device as part of its normal operation. For example,
the program may request a connection to a remote computer, a printer, or a modem.
Becoming a Bluetooth client normally requires an action by the device operator, such as an attempt to browse a
remote computer, print a file, or dial out on a modem. Every Bluetooth device that provides a service must be prepared
to respond to a connection request. Bluetooth software is always running in the background on the server, ready to
respond to connection requests.
The D-Link Bluetooth USB Adapter is the perfect wireless solution for quick and easy access to Bluetooth enabled
devices. It is a class 2/3 low power device and is bundled with Bluetooth Software which allows you to connect to
several Bluetooth devices at once. The wireless transmission range of the D-Link DBT-120 Bluetooth USB Adapter is
about 30 feet. A PC configured as the Bluetooth server can support up to 7 Bluetooth client devices with IP addresses
being automatically assigned upon a successful connection. The Bluetooth Software also provides Internet sharing
and security access between the server and clients.
After finishing the steps outlined in this manual, you will have the ability to share information, obtain network access,
and take full advantage of a wireless connected environment.

5D-Link DBT-120 User Manual
Section 2 - Installation
Uninstalling a Previous Version of the Bluetooth Software
If you are installing the Bluetooth software for the first time, please skip this section.
Any previous versions of the Bluetooth software must be uninstalled before installing an upgraded version.
Please uninstall the software by completing these steps:
1) Close any open programs and insert the Driver CD into your CD-ROM Drive.
2) The Autorun screen will appear. Click on Install Bluetooth Software.
3) The Welcome screen will indicate the previous version of BTW that is currently installed. Click on the Next
button to continue.
4) Click on the Remove button from the Remove the Program screen.
5) When the files have been removed, you will be presented with a screen informing of its completion.
a.Click on the Finish button
b.Click on the Yes button when the pop-up dialog box appears on the screen to reboot your PC.
You have now removed the previous version of the Bluetooth software.

6D-Link DBT-120 User Manual
Section 2 - Installation
Installing the Bluetooth Software
Insert the D-Link PersonalAir DBT-120 Driver CD into your
CD-ROM drive.
Click Install the Bluetooth Utility
If this Autorun screen does not automatically appear, click on
Start > Run, enter “D:\Autorun.exe” and click OK. “D” represents
the letter of your CD-ROM drive.
Warning: Install the driver and software located on the D-Link CD that came with your purchase BEFORE installing the
DBT-120 USB Bluetooth Adapter into your computer.

7D-Link DBT-120 User Manual
Section 2 - Installation
Click Next
Click Accept
Click Next

8D-Link DBT-120 User Manual
Section 2 - Installation
Click Install

9D-Link DBT-120 User Manual
Section 2 - Installation
Click Yes

10D-Link DBT-120 User Manual
Section 2 - Installation
Click Ok
When this screen appears, connect the DBT-120 to an available
USB port on your USB host adapter or USB hub.

11D-Link DBT-120 User Manual
Section 2 - Installation
Click Finish

12D-Link DBT-120 User Manual
Section 2 - Installation
Click Yes
Using the Add New Connection Wizard
After you have completed the driver and software installation and reboot your computer, a Bluetooth icon will appear
on your desktop and in the bottom right hand corner of your desktop screen (systray). The Bluetooth icon gives you
access to Add New Connection Wizard, for configuring your Bluetooth settings.
Double-click the Bluetooth icon for access to Add New
Connection Wizard.

13D-Link DBT-120 User Manual
Section 2 - Installation
The Add New Connection Wizard launches the first time that you
double click on the Bluetooth Icon.
Click Next

14D-Link DBT-120 User Manual
Section 2 - Installation
Select your Bluetooth device and click Next.
Click Next

15D-Link DBT-120 User Manual
Section 2 - Installation
Click Next
Click Next

16D-Link DBT-120 User Manual
Section 2 - Installation
Click Finish

17D-Link DBT-120 User Manual
Section 3 - Configuration
Introduction to the Bluetooth Software
Bluetooth Tray
The Bluetooth icon resides in the Windows system tray, which is normally located in the lower-right corner of the screen.
The Bluetooth icon provides fast access to most Bluetooth operations.
From the Bluetooth tray you can:
• Access the Add New Connection Wizard. This wizard will help you:
• Configure how this computer accesses a service on another Bluetooth device
• Locate remote Bluetooth devices
• Configure the way that this computer provides services to remote Bluetooth devices
• Set the name and type of this Bluetooth device, e.g., “John’s PC” and “Desktop”
• Start/Stop Bluetooth on this computer.
Bluetooth Information Exchanger
Bluetooth Information Exchanger is placed on the desktop.
• On the desktop, double-click the Bluetooth Information Exchange icon
• Open Windows Explorer and select My Bluetooth Places in the Folders

18D-Link DBT-120 User Manual
Section 3 - Configuration
Location to place files for sharing between
Bluetooth devices.
Location to place images for sharing between
bluetooth devices.
Push files or services to Bluetooth devices that
support OPP (Object Push Profile).
To start Bluetooth: In the Windows system tray, Double-click the Bluetooth icon to Start the Bluetooth Manager.
Right-click your Bluetooth device and click on Connect. The Bluetooth icon is blue in color with a white insert when
Bluetooth is running but not connected. When connected successfully, the insert will appear green.
To stop Bluetooth: In Bluetooth Manager right-click your Bluetooth device and click on Disconnect. The Bluetooth
icon is blue in color with a red insert when Bluetooth is stopped.
Bluetooth Software Basic Operations
Using Bluetooth Information Exchanger
Start or Stop Bluetooth

19D-Link DBT-120 User Manual
Section 3 - Configuration
Double-Click
Click Connect
Click Disconnect

20D-Link DBT-120 User Manual
Section 3 - Configuration
In the Windows system tray, right-click the Bluetooth icon, select Add New Connection. Choose the following
options for your Bluetooth device.
• Use Express mode for a quick search of the Bluetooth device you wish to use.
or
• Use Custom mode wish allows you to set the details for your connection.
• From Bluetooth settings click the Detail button to display your connection details.
Click Detail
Create a Conection From the Bluetooth Icon in the System Tray
• From Bluetooth Manager, click on the New Connection icon.
• From the Windows system tray: right-click the Bluetooth icon and select Add New Connection.
Follow the wizard’s on-screen instructions.
Create a Connection Using the Bluetooth Setup Wizard
View Connection Details Using Bluetooth Settings
