D-Link DAP-1350 User manual

2D-Link DAP-1350 User Manual
Table of Contents
Product Overview ........................................................5
Package Contents....................................................5
System Requirements ............................................. 6
Introduction..............................................................7
Features...................................................................9
Hardware Overview ...............................................10
Connections.....................................................10
Side.................................................................. 11
Bottom .............................................................11
LEDs ................................................................12
Installation..................................................................13
Operation Modes ................................................... 13
Access Point Mode ..........................................14
Wireless Client Mode.......................................15
Router Mode .................................................... 16
Wireless Installation Considerations...................... 17
Configuration............................................................. 18
Access Point Mode ................................................18
Wireless Setup Wizard..................................... 19
Add Wireless Device With WPS ................... 24
Wireless Setup ............................................. 26
LAN Setup....................................................28
Static IP........................................................29
MAC Address Filter ...................................... 30
Advanced Wireless.......................................31
User Limit ..................................................... 32
Admin ...........................................................33
System .........................................................34
Language Pack ............................................35
Firmware ...................................................... 35
Time .............................................................36
Schedules ....................................................37
Device Info ................................................... 38
Logs .............................................................39
Statistics.......................................................40
Wireless .......................................................41
Help..............................................................42
Wireless Client Mode....................................... 43
Wireless Setup Wizard ................................. 44
Manual Wireless Setup ................................ 49
LAN Settings ................................................ 50
Logout ..........................................................51
Advanced Wireless.......................................52
Admin ...........................................................53
System .........................................................54
Language Pack ............................................55
Firmware ...................................................... 55
Time .............................................................56
Device Info ................................................... 57
Logs .............................................................58
Statistics.......................................................59
Help..............................................................60
Table of Contents

3D-Link DAP-1350 User Manual
Table of Contents
Router Mode .................................................... 61
Setup Wizard................................................ 62
Internet Setup...............................................65
Dynamic IP (DHCP) .....................................66
Static IP........................................................67
PPPoE.......................................................... 68
PPTP............................................................69
L2TP.............................................................70
Wireless Setup Wizard ................................. 71
Add Wireless Device with WPS Wizard........75
Wireless Settings ......................................... 76
Network Settings ..........................................77
DHCP Server Settings .................................78
DHCP Reservation....................................... 79
USB Settings................................................80
Virtual Server ............................................... 81
Application Rules ......................................... 83
MAC Address Filter ...................................... 84
Website Filters.............................................. 85
Firewall Settings ........................................... 86
Advanced Wireless Settings......................... 87
Wi-Fi Protected Setup .................................. 88
UPnP Settings..............................................90
Guest Zone .................................................. 91
DMZ .............................................................92
Administrator Settings .................................. 93
Time Settings ............................................... 94
SysLog .........................................................95
System Settings ........................................... 96
Firmware Update.......................................... 97
Schedules ....................................................98
Device Information .......................................99
Wireless .....................................................100
Logs ...........................................................101
Statistics.....................................................102
Internet Sessions ....................................... 103
Help............................................................105
Wireless Security.....................................................106
What is WEP?...................................................... 106
What is WPA? ......................................................107
Configure WEP .................................................... 108
Configure WPA/WPA2 Personal...........................109
Configure WPA/WPA2 Enterprise ........................ 110
Connect to a Wireless Network .............................. 111
Using Windows®XP............................................. 111
Configure WEP .................................................... 112
Configure WPA-PSK ............................................ 114
Connect to a Wireless Network .............................. 116
Using Windows Vista®.........................................116
Configure WEP .................................................... 118
Configure WPA-PSK ............................................ 119
Troubleshooting.......................................................120

4D-Link DAP-1350 User Manual
Table of Contents
Wireless Basics ....................................................... 124
What is Wireless? ................................................125
Tips...................................................................... 127
Wireless Modes ................................................... 128
Networking Basics .................................................. 129
Check your IP address ........................................129
Statically Assign an IP address ...........................130
Technical Specifications......................................... 131
Contacting Technical Support................................ 132
Warranty ...................................................................133
Registration..............................................................139

5D-Link DAP-1350 User Manual
Section 1 - Product Overview
Product Overview
Note: Using a power supply with a different voltage rating than the one included with the DAP-1350 will cause damage and void the warranty for this product.
D-Link DAP-1350
Wireless N
Pocket Router/Access Point
Power Adapter
Ethernet Cable
CD-ROM
USB Power Cable
Travel Case
Package Contents

6D-Link DAP-1350 User Manual
Section 1 - Product Overview
Network Requirements
• An Ethernet-based Cable or DSL modem (router mode only)
• IEEE 802.11n-draft or 802.11g wireless clients (router or AP mode)
• IEEE 802.11n-draft or 802.11g wireless AP or router (client mode)
• 10/100/1000 Ethernet
Web-based Configuration
Utility Requirements
Computer with the following:
• Windows®, Macintosh®, or Linux-based operating system
• An installed Ethernet adapter
Browser Requirements:
• Internet Explorer 6.0 or higher
• Firefox 3.0 or higher
• Safari 3.0 or higher
• Chrome 2.0 or higher
Windows®Users: Make sure you have the latest version of Java installed.
Visit www.java.com to download the latest version.
CD Installation Wizard
Requirements
Computer with the following:
• Windows®XP with Service Pack 2 or Vista®
• An installed Ethernet adapter
• CD-ROM drive
System Requirements

7D-Link DAP-1350 User Manual
Section 1 - Product Overview
Introduction
D-Link, an industry leader in networking, introduces the new D-Link DAP-1350 Wireless N Router/Access Point. With
the ability to transfer files with a maximum wireless signal rate of up to 300Mbps*, the DAP-1350 gives you high-speed
wireless network access for your home or when you travel.
The DAP-1350 is Wi-Fi IEEE 802.11n compliant, meaning that it can connect and interoperate with other 802.11n
compatible wireless client devices. The DAP-1350 is also backwards compatible with 802.11b/g. It can be flexibly
configured to operate in 3 different modes: Access Point, Wireless Client, and Router. With its Setup Wizard, the
DAP-1350 ensures that you will be up and running on a wireless network in just a matter of minutes.
The DAP-1350 features Wi-Fi Protected Access (WPA-PSK/WPA2-PSK) to provide an enhanced level of security for
wireless data communications.The DAP-1350 also includes additional security features to keep your wireless connection
safe from unauthorized access.
The DAP-1350 supports WPS on all three operation modes, with each capable of being conveniently set up by using
the PIN method or Push Button.
• Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network
overhead, lower actual data throughput rate.

8D-Link DAP-1350 User Manual
Section 1 - Product Overview
TOTAL PERFORMANCE
Combines award winning access point features and Draft 802.11n wireless technology to provide the best wireless performance.
TOTAL SECURITY
The most complete set of security features including WPA/WPA2 encryption to protect your network against outside intruders.
TOTAL COVERAGE
Provides greater wireless signal rates even at farther distances for best-in-class Whole Home Coverage.
ULTIMATE PERFORMANCE
The D-Link Wireless N Pocket Router/Access Point (DAP-1350) is a draft 802.11n compliant device that delivers real world
performance of up to 650% faster than an 802.11g wireless connection (also faster than a 100Mbps wired Ethernet connection).Create
a secure wireless network to share photos, files, music, video, printers, and network storage throughout your home. Connect the
DAP-1350 to router and share your high-speed Internet access with everyone on the network.
EXTENDED WHOLE HOME COVERAGE
This high performance Wireless AP provides superior Whole Home Coverage while reducing dead spots. The DAP-1350 is
designed for use in bigger homes and for users who demand higher performance networking.
TOTAL NETWORK SECURITY
The DAP-1350 supports all of the latest wireless security features to prevent unauthorized access, be it from over the wireless
network or from the Internet. Support for WPA and WPA2 standards ensure that you’ll be able to use the best possible encryption
method, regardless of your client devices.
* Maximum wireless signal rate derived from IEEE Standard 802.11g, 802.11a and Draft 802.11n specifications. Actual data throughput will vary. Network conditions and
environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental
conditions will adversely affect wireless signal range.

9D-Link DAP-1350 User Manual
Section 1 - Product Overview
• FasterWireless Networking - The DAP-1350 provides up to 300Mbps* wireless connection with other 802.11n
wireless clients.This capability allows users to participate in real-time activities online, such as video streaming,
online gaming, and real-time audio.The performance of this 802.11n wireless access point gives you the freedom
of wireless networking at speeds 650% faster than 802.11g.
• Compatible with 802.11b and 802.11g Devices - The DAP-1350 is still fully compatible with the 802.11b/g
standards, so it can connect with existing 802.11b/g PCI, USB, and Cardbus adapters.
• WPS PBC- (Wi-Fi Protected Setup Push Button Configuration) Push Button Configuration is a button that can
be pressed to add the device to an existing network or to create a new network. A virtual button can be used on
the utility while a physical button is placed on the side of the device.
This easy setup method allows you to form a secured wireless link between the DAP-1350 and another WPS
enabled device. A PC is no longer needed to log into the Web-based interface.
• WPS PIN - (Wi-Fi Protected Setup Personal Identification Number ) A PIN is a unique number that can be used
to add the access point to an existing network or to create a new network. The default PIN may be printed on
the bottom of the access point. For extra security, a new PIN can be generated.You can restore the default PIN
at any time. Only the Administrator (“admin” account) can change or reset the PIN.
• User-friendly SetupWizard - Through its easy-to-use web-based user interface, you can configure your access
point to your specific settings within minutes.
Features

10D-Link DAP-1350 User Manual
Section 1 - Product Overview
Hardware Overview
Connections
Mode Selector
Select from one of the three modes:
AP (top) - Access Point (AP) Mode
CL (middle) - Wireless Client Mode
RT (bottom) - Router Mode
Power Receptor
Receptor for the supplied power
adapter.
LAN/WAN Port
When using as a LAN port, connect Ethernet
devices such as computers or game consoles.
When using as a WAN port, connect your
Broadband modem or Internet connection.

11D-Link DAP-1350 User Manual
Section 1 - Product Overview
Hardware Overview
Side
USB Port
The USB port is used to connect
USB devices such as a printer
to share on your network.
Bottom
WPS Button/LED
Press to start the WPS process. You
will have 120 seconds to start the WPS
process on another wireless device.
When enabling WPS, the light will blink
during broadcast. Once connected, the
LED will stay solid for 5 seconds and
then turn off.
Reset Button
Press and hold to reset the
device back to the factory
default settings
Stand

12D-Link DAP-1350 User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
Power LED
A solid light indicates a proper
connection to the power supply.
Wireless LED
A solid light indicates that the wireless
segment is ready. This LED blinks
during wireless data transmission.
LAN/WAN LED
A solid light indicates a connection to
an Ethernet-enabled device. This LED
blinks during data transmission.

13D-Link DAP-1350 User Manual
Section 2 - Installation
Installation
Please configure the DAP-1350 by following the Install Guide poster. The next few pages will explain the different
operational modes you can use.
Operation Modes
Depending on how you want to use your DAP-1350 will determine which mode you use.This section will help you figure
out which setting works with your setup.
• Access Point mode - page 14
• Wireless Client mode - page 43
• Router mode - page 61

14D-Link DAP-1350 User Manual
Section 2 - Installation
Access Point Mode
In the Access Point mode, the DAP-1350 acts as a central connection point for any computer (client) that has a 802.11n
or backward-compatible 802.11b/g wireless network interface and is within range of the AP. Clients must use the same
SSID (wireless network name) and channel as the AP in order to connect. If wireless security is enabled on the AP,
the client will need to enter a password to connect to the AP. In Access Point mode, multiple clients can connect to
the AP at the same time.

15D-Link DAP-1350 User Manual
Section 2 - Installation
Wireless Client Mode
In the Wireless Client mode, the DAP-1350 acts as a wireless network adapter for your Ethernet-enabled device (such
as a game console or a laptop). Connect your Ethernet-enabled device to the AP using an Ethernet cable. The AP
Client mode can support one wired client.
Example: Connect a gaming console using an Ethernet cable to the DAP-1350. The unit is set to Wireless Client mode
which will wirelessly connect to a wireless router on your network.

16D-Link DAP-1350 User Manual
Section 2 - Installation
Router Mode
In the Router mode, the DAP-1350 connects to a broadband modem. In this mode, the DAP-1350 also acts as a router
for wireless clients on your network and provides NAT (Network Address Translation) and a DHCP server to generate
IP addresses. NAT and the DHCP server allow many computers to share the same Internet connection.

17D-Link DAP-1350 User Manual
Section 2 - Installation
Wireless Installation Considerations
The D-Link wireless access point lets you access your network using a wireless connection from virtually anywhere
within the operating range of your wireless network. Keep in mind, however, that the number, thickness and location
of walls, ceilings, or other objects that the wireless signals must pass through, may limit the range. Typical ranges vary
depending on the types of materials and background RF (radio frequency) noise in your home or business. The key to
maximizing wireless range is to follow these basic guidelines:
1. Keep the number of walls and ceilings between the D-Link access point and other network devices to
a minimum. Each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position
your devices so that the number of walls or ceilings is minimized.
2. Be aware of the direct line between network devices. A wall that is 1.5 feet thick (.5 meters), at a
45-degree angle appears to be almost 3 feet (1 meter) thick. At a 2-degree angle it looks over 42 feet
(14 meters) thick! Position devices so that the signal will travel straight through a wall or ceiling (instead
of at an angle) for better reception.
3. Building Materials make a difference. A solid metal door or aluminum studs may have a negative effect
on range. Try to position access points, wireless access points, and computers so that the signal passes
through drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation,
water (fish tanks), mirrors, file cabinets, brick, and concrete will degrade your wireless signal.
4. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that
generate RF noise.
5. If you are using 2.4GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and
home security systems), your wireless connection may degrade dramatically or drop completely. Make
sure your 2.4GHz phone base is as far away from your wireless devices as possible. The base transmits
a signal even if the phone is not in use.

18D-Link DAP-1350 User Manual
Section 3 - Configuration
Configuration
This section will show you how to configure your new D-Link wireless access point using the web-based configuration
utility.
Access Point Mode
If you wish to change the default settings or optimize
the performance of the DAP-1350, you may use the
web-based configuration utility.
To access the configuration utility, open a web browser
such as Internet Explorer and enter dlinkap or
192.168.0.50 in the address field.
Type admin and then enter your password. Leave the
password blank by default..
If you get a Page Cannot be Displayed error, please
refer to the Troubleshooting section for assistance.
Change the mode selector to AP on the device. Connect an Ethernet cable from the Ethernet port on the DAP-1350
to a computer for configuration.

19D-Link DAP-1350 User Manual
Section 3 - Configuration
Click Launch Wireless Setup Wizard to configure
your access point and skip to the next page.
To set up your wireless network, click Add Wireless
Device With WPS and skip to page 24.
If you want to enter your settings without running the
wizard, click Wireless Setup on the left side and
skip to page 26.
Wireless Setup Wizard

20D-Link DAP-1350 User Manual
Section 3 - Configuration
Enter the Device Name of the AP and click Next to
continue. This is the NetBIOS name for the AP. It is
recommended to change the Device Name if there
is more than one D-Link device within the same
wireless network.
This Wizard is designed to assist you in configuring your DAP-1350 as an access point.
If you want to change the admin account password,
enter a new password and click Next. It is strongly
recommended to change your password.
