Da-Lite 5000 User manual

POWER
PRESENTATION PRODUCTS
The
In
Instruction Book For
Model 5000 Portable
Standard Model (120 VAC 60 Cycles)
DA-LITE SCREEN COMPANY, INC.
3100 North Detroit Street
Post Office Box 137
Warsaw, Indiana 46581-0137
Phone: [phone]
800-622-3737
Fax: [phone]
http:// www.da-lite.com
e-mail: [email protected]

The “Safeguards” statement reproduced below is in accordance
with Underwriters Laboratories “Standard for Safety, UL 122,
Photographic Equipment.”
IMPORTANT SAFEGUARDS©
When using your photographic equipment, basic safety precautions
should always be followed, including the following:
1. Read and understand all instructions.
2. Close supervision is necessary when any appliance is used by
or near children. Do not leave appliance unattended while in
use.
3. Care must be taken as burns can occur from touching hot parts.
4. Do not operate appliance with a damaged cord or if the appli-
ance has been dropped or damaged—until it has been exam-
ined by a qualified serviceman.
5. Do not let cord hang over edge of table or counter or touch hot
surfaces.
6. If an extension cord is necessary, a cord with a suitable current
rating should be used. Cords rated for less amperage than the
appliance may overheat. Care should be taken to arrange the
cord so that it will not be tripped over or pulled.
7. Always unplug appliance from electrical outlet when not in use.
Never yank cord to pull plug from outlet. Grasp plug and pull to
disconnect.
8. Let appliance cool completely before putting away. Loop cord
loosely around appliance when storing.
9. To protect against electrical shock hazards, do not immerse this
appliance in water or other liquids.
10. To avoid electric shock hazard, do not disassemble this appli-
ance, but take it to a qualified serviceman when some service or
repair work is required. Incorrect reassembly can cause electric
shock hazard when the appliance is used subsequently.
SAVE THESE INSTRUCTIONS
© Copyrighted Underwriters Laboratories
“Standard for Safety, UL 122, Photographic Equipment”
IMPORTANT SAFEGUARDS©

NOTE: When folding the post for storage, the post latch
release lever must be pressed to release the post
prior to rotating the post.
17. While holding the top of the post, grasp the horizon-
tal arm and pull sideways in the direction indi-
cated by arrow #1, and rotate the arm to bring the
projection head assembly up into viewing posi-
tion (See figure 4). Release the arm and it will spring
back and lock into viewing position.
14. Grasping the projector firmly, set the projector up-
right onto its legs.
15. Release the lid latch on the side opposite the
carrying handle and open the lid (see figure 2).
13. Release both leg latches by pressing in the direction
indicated by the arrows (see figure 1). The leg
latches are located one on either side of the car-
rying handle. Press the leg latch firmly until it re-
leases the leg and the leg folds outward. Release
the latch. This will lock the leg in the extended posi-
tion. Repeat to extend and lock both legs.
NOTE: When folding legs for storage, the leg latch must
be released prior to folding leg.
16. Rotate the post hold down latch sideways to re-
lease the folded post assembly. Grasp the top of the
folded post (near the latch) and pull upward. This
will rotate the post, horizontal arm, and projection
head assembly to the upright position. The bottom
mirror will lower into position as the post is raised.
Continue rotating the post assembly upward until it
locks into the fully upright position (see figure 3).
ASSEMBLY INSTRUCTIONS:
Model 5000 Portable Projector
11. Remove the projector from the shipping carton care-
fully.
12. Grasp the carrying handle , and position the pro-
jector on its side with the handle upward. Remove
the protective dust cover (see figure 1).
INTRODUCTION
Congratulations! You have just purchased one of the
finest overhead projectors available today. The Model
5000 overhead projector is manufactured to Da-Lite’s
high quality standards. As illustrated in this instruction
manual, this projector will allow you all the flexibility and
reliability you will need for trouble-free presentations.
This instruction manual explains assembly and operation
of the Model 5000 Portable projector. While this projec-
tor has operating and maintenance instructions printed
on it, please read this manual thoroughly so you can
optimize usage of the many features your projector has
to offer.
1
A
B
Figure 1
Figure 2
C
H
E
D
Figure 3
F
G
B
A
C
B
D
F
G
H
E

5. To install a new lamp, hold lamp by base and insert
the two pins on the lamp into the matching slots in
the socket .
NOTE: Make sure the lamp is pushed into the socket com-
pletely, otherwise the filament of the lamp will not be lo-
cated for proper operation.
LAMP CHANGER INSTRUCTIONS
MODEL 5000
Uninterrupted service during presentation is permitted
with the lamp changer which allows you to switch from
a burned out lamp to a new one, merely by sliding a
lever on the outside of the case. A highly visible LED
gives instant indication of the spare lamp condition (use
of lamp changer requires prior installation of second
lamp, ANSI code FXL).
To use lamp changer, turn power switch “off”. Slide
lamp changer lever to the opposite extreme position.
Turn power switch “on”.
2
N
O
For your convenience, this projector has an upper mirror
assembly which can be rotated 360˚. This allows image
projection in any direction.
To rotate the upper mirror assembly, firmly grasp the
lower portion of the projection head assembly and hold
stationary, while rotating the upper portion of the
projection head assembly.
The rotating upper head has detents at 90˚ intervals
which will latch the upper mirror into position at exact
90˚ locations.
L
LAMP REPLACEMENT (figure 5)
1. Turn off the projector and disconnect the power cord
from the electrical outlet.
2. Allow the projector to cool down until the lamp is cool
to touch.
3. If changing the right bulb, move the lamp changer to
its extreme left position. If changing the left bulb,
move the lamp changer to its extreme right position.
4. Rotate bulb ejection lever as shown in figure 5 to
eject the bulb.
M
Figure 5
ASSEMBLY INSTRUCTIONS:
Model 5000 Portable Projector (cont.)
1. Slide the lamp changer lever to extreme left or
right position.
2. Select high or low power setting with the high/low
switch.
3. Turn on/off switch to the “ on“ position.
4. The spare lamp indicator will light only if the spare
lamp is installed and in good condition.
5. Place projection copy or LCD platen on projection
stage.
6. Raise or lower image location on screen by tilting the
upper mirror on head assembly.
7. Focus image on screen by turning the focusing knob,
which raises or lowers the projection head.
8. To use the lamp changer, turn power switch “off”.
Slide lamp changer lever to opposite extreme posi-
tion. Turn power switch “on”.
K
18. Rotate the focus control knob counter-clockwise
to raise the arm and head assembly. Raise this as-
sembly just high enough to clear the lid as it is
closed.
19. Close and latch the projector lid.
10. Rotate the upper mirror on the projection head
assembly into viewing position.
J
I
Figure 4
J
G
L
K
I
H
OPERATING INSTRUCTIONS: Model 5000 (figure 4)
O
N
M

REF. QTY/ DA-LITE
NO. DESCRIPTION UNIT NUMBER
1 Head assembly 1 77920
2 Head mirror, 1/8"T 1 77819
3 TR-13B Triplet lens 1 77871
4 Shoulder screw .242x.218 8-32 2 77938
5 Bow washer, .437ODx.255ID 6 77095
6 Horizontal arm, black 1 77922
7 Shoulder screw 3/8"x2" 5/16-18 1 77835
8 Compression spring, 1/2"ODx1" L 1 77836
9 Flush retainer 1 77888
10 Post locking bracket 1 77859
11 Post assembly 1 77919
12 Black knob, 1/4" bushing 1 77860
13 Bolt, carriage 1/4"-20x1.80L 1 77829
14 Post locking lever 1 77933
15 Cover & fresnel assembly 1 77918
16 Mini latch, black 1 77935
17 Flush retainer 8 77888
MODEL 5000 PORTABLE PROJECTOR REPLACEMENT PARTS:
3
REF. QTY/ DA-LITE
NO. DESCRIPTION UNIT NUMBER
18 Fresnel lens, 50lpi 310mm sq 1 77820
19 Glass, 10-1/2"x10-1/2" border 1 77895
20 Plastic top 1 77803
21 Glass retainer clip 2 77866
22 Plastic strap, 1/2"x5-5/8" 1 77926
23 Tap screw 6x3/8" 6 77814
24 Piano hinge, black 1 77849
25 Mirror & box assembly 1 77913
26 Mirror, 1/8"Tx7"x10.20"x10.98" 1 77873
27 Leg latch, arrow 2 77929
28 Dark grey leg 2 77801
29 Handle, black 1 77810
30 Handle base, nickel 1 77850
31 Handle cap, w/logo 1 77944
32 Cord wrap clip, black 2 78245
33 Plastic button, red 1 46030
34 Strain relief bushing, SR 5N-4 1 77870
35 Impeller, 3-1/2" cw celcon 1 77845
21
54
6
9
10
11
12
13
42
44 45
41
14
40
34
38
32
36
35
24
15
16
17
18
22 23 25 26 378

4
MODEL 5000 PORTABLE PROJECTOR REPLACEMENT PARTS:
REF. QTY/ DA-LITE
NO. DESCRIPTION UNIT NUMBER
36 Blower & motor assy, 120v 1 77914
37 Diode, rectifier 1 51606
38 Receptacle, nema 5-1 3/16" term. 1 77892
39 Cord set, 120v SVT 10' 1 77848
40 Push switch, spdt 1 51542
41 Switch, 10.0 amp tungsten rated 1 77934
REF. QTY/ DA-LITE
NO. DESCRIPTION UNIT NUMBER
42 Circuit breaker, 7 amp 1 50451
43 Resistor & connector assembly, 120V 1 77917
44 Led diode, red 1 51585
45 Lamp holder assembly, 120V 1 77915
46 Lamp, 410 watt 82V GE FXL 2 77842
47 Thermal switch, open 240F 1 51551
3
29
28
27
19 21 21
31
30
20
34
33
32
28
27
14
36
37
38 39
40
40
41
42
43
44
45
46
47 40
40
PORTABLE PROJECTOR WIRING DIAGRAM

5
TROUBLE SHOOTING
SYMPTOM
1. Lamp will not light.
2. No power to accessory outlet.
3. Spare lamp LED does not light.
CAUSE
(a) Mirror box not down completely.
(b) Lamp changer not in extreme left
or right position.
(c) Lid not closed completely.
(d) Lamp burned out
(a) Circuit breaker tripped.
(a) No spare lamp or spare lamp is
not good.
SOLUTION
(a) Remove obstruction and/or tilt
mirror box completely.
(b) Move lamp changer to extreme
left or right.
(c) Close and latch lid securely.
(d) Switch to spare lamp or replace
lamp.
(a) Reset circuit breaker.
(a) Install or replace spare lamp.
DA-LITE
DESCRIPTION NUMBER
Dust Cover 77912
Spare Lamp (410W, 82V, ANSI Code FXL) 77842
Carrying Case 79084
ACCESSORIES

LIMITED ONE YEAR WARRANTY ON DA-LITE OVERHEAD AND OPAQUE PROJECTORS
SERVICE INFORMATION
Da-Lite projectors (except lamps) are warranted against
defects in material and workmanship for a period of one
(1) year from the date of purchase by the original pur-
chaser provided they are properly operated according to
Da-Lite’s instructions and are not damaged due to im-
proper handling or treatment after shipment from the
factory.
This warranty does not apply to equipment showing evi-
dence of misuse, abuse, or accidental damage, or which
has been tampered with or repaired by persons other
than authorized Da-Lite personnel.
Da-Lite’s sole obligation under this warranty shall be to
repair or to replace (at Da-Lite’s option) the defective
part of the merchandise. Returns for service should be
made to your Da-Lite dealer. If it is necessary for the
dealer to return the machine or part to Da-Lite, trans-
portation expenses to and from Da-Lite are payable by
the purchaser and Da-Lite is not responsible for damage
in shipment. To protect yourself against damage or loss
in transit, insure the product and prepay all transporta-
tion expenses. Allow at least six weeks for correction of
the defect.
THIS WARRANTY IS IN LIEU OF ALL OTHER WAR-
RANTIES, EXPRESS OR IMPLIED, INCLUDING
WARRANTIES AS TO FITNESS FOR USE AND MER-
CHANTABILITY. Any implied warranties of fitness for
use, or merchantability, that may be mandated by
statute or rule of law are limited to the one (1) year war-
ranty period. This warranty gives you specific legal
rights, and you may also have other rights which vary
from state-to-state. NO LIABILITY IS ASSUMED FOR
EXPENSES OR DAMAGES RESULTING FROM IN-
TERRUPTION IN OPERATION OF EQUIPMENT, OR
FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL
DAMAGES OF ANY NATURE.
In the event that there is a defect in materials or work-
manship of our audio-visual product, you may contact
our Customer Service Department at P.O. Box 137,
Warsaw, Indiana 46581-0137 (219/267-8101).
IMPORTANT: THIS WARRANTY SHALL NOT BE VALID
AND DA-LITE SHALL NOT BE BOUND BY
THIS WARRANTY IF THE PRODUCT IS
NOT OPERATED IN ACCORDANCE WITH
DA-LITE’S WRITTEN INSTRUCTIONS.
Keep your sales receipt to prove the date
of purchase and your original ownership.
(Applicable in U.S.A.)
IMPORTANT! KEEP THIS INFORMATION HANDY FOR FUTURE REFERENCE
(Applicable in U.S.A.)
A Return Authorization is required for ALL service work,
whether the unit is in or out of warranty. Da-Lite will
need the model and serial number in order to issue the
Return Authorization.
If the unit is an obsolete model, you will be advised be-
fore you ship the unit, whether or not Da-Lite can make
the repair.
Address your request for a Return Authorization to:
Customer Service Department, Da-Lite Screen
Company, Inc., P.O. Box 137, Warsaw, Indiana 46581-
0137 or phone [phone] (Fax [phone]).
Should you need service for your Da-Lite equipment
after the warranty has expired, contact your local dealer.
If it is necessary for the dealer to return the machine or
part to Da-Lite, transportation expenses to and from Da-
Lite are payable by the purchaser and Da-Lite is not re-
sponsible for damage in shipment. Pack the product in a
sturdy box with plenty of protective packing material. To
protect yourself against damage or loss in transit, insure
the product and prepay all transportation expenses.
Da-Lite will refuse collect shipments. Allow at least six
weeks for correction of the defect.
ENCLOSE complete information showing your name
and address, what is wrong with the equipment, and the
return shipping address. Tape the information to the
equipment to be sure it does not get separated during
the repair.
ADDRESS the package to the address shown on your
Return Authorization.
CHARGES. If Da-Lite determines it will cost over 33%
of current suggested retail price, you will be contacted
for written approval of the estimated charges before the
repair is made.
PAYMENT. When unit is repaired, it will be returned
C.O.D. for cost of repair and shipping charges unless
other arrangements have been made in advance.
6
Printed in U.S.A. 77857 Rev. 4/01
