Dacor DOB30M977 Series User manual

Installation Instructions
Modernist Built-In Electric Wall Oven
DOB30M977
Part No. 112174 Rev D

English2
Contents
Before you begin...
Important
Customer-service info 3
If You Need Help... 3
Important safety instructions 4
4
4
Related equipment safety
Transport
Installation requirements 6
6
7
8
11
Location requirements
Installation materials
Single ovens—Product Dimensions
Double ovens—Product Dimensions
Installation instructions 15
15
15
18
21
Preparing to install the oven
Removing and replacing the oven door(s)
Electrical connection
Installing the oven
Installation checklist
Self-diagnosis
22
3
3
23

English 3
Before you begin...
Important
Design/accessories vary with the model.
Installer
•For safety and to minimize problems,
read this manual thoroughly before
starting the installation.
•Leave this manual with the user.
•Write the oven’s model/serial
numbers in this manual for service/
maintenance reference.
User
•Keep this manual for personal and
professional reference.
Customer-service info
If You Need Help...
To resolve installation issues, contact your
Dacor® dealer or Dacor Customer Assurance.
Have the oven model/serial numbers ready
when you call. This information is on the
rating plate on the lower-left door trim. (For
double ovens, the plate is on the lower oven.)
Dacor Customer Assurance
[phone] x2813 (USA, Canada)
Mon – Fri, 5:00 a.m. to 5:00 p.m. Pacific Time
Website: www.dacor.com/customer-care/contact-us
All specifications are subject to change without notice. Dacor assumes no liability for suchchanges.
© 2017 Dacor. All rights reserved.
Rating
Plate

English4
Important safety instructions
Related equipment safety
Remove all tape and packaging before using the oven, and dispose of the packaging.
Never let children play with packaging material.
Do not modify the oven (e.g., do not remove panels, wire covers, or screws).
Transport
Oven (side)
To avoid damaging the oven vent, use
the transport method shown at left.
Lift/support the oven bottom from
either side, and move it to the
installation site.
Leave the oven attached to the pallet
until it is ready to be lifted into place.
Pallet
Pallet jack here
DANGER
ELECTRICAL SHOCK HAZARD
To avoid electrical shock, personal injury, or death, verify your appliance is grounded
according to local codes or, in their absence, with the National Electrical Code (NEC).
ANSI/NFPA 70-latest edition.
WARNING
MOVING HAZARD
To avoid severe personal injury, handle/move the oven with two or more people. Using
an appliance-moving device is recommended.

English 5
Important safety instructions
WARNING
•Follow the information in this manual precisely to avoid fire or electrical shock that
may cause property damage, personal injury, or death.
•Ensure the oven is properly installed and grounded by a qualified technician.
•New branch-circuit installations (1996 NEC), mobile homes, RVs, or installations
where local codes prohibit grounding through the neutral conductor, require 4-wire
branch-circuit connection.
•Improper connection of aluminum house wiring to copper leads can cause an
electrical/fire hazard. Use only connectors designed for joining copper to aluminum,
and follow the manufacturer’s recommended procedure.
•Mounting screws must be used to secure the oven so it cannot be shifted/dislodged.
CAUTION
•The cabinets and wall coverings around the oven must be able to withstand the heat
[up to 194 °F (90 °C)] generated by the oven.
•Do NOT remove the spacers from the oven's left/right sides. The spacers center the
oven in the cabinet cutout so heat does not build up in one area and damage the
cabinetry or cause a fire hazard.
IMPORTANT NOTE
The installer shall ensure proper installation. The warranty does NOT cover product
failure due to improper installation.
WARNING
Do NOT put weight on the oven door or let anyone climb, sit, stand, or hang on it. The
door could break free, causing personal injury and property damage.
WARNING
The electricity must be off while the electrical connections are made. If not, severe
personal injury or death may occur.
IMPORTANT NOTE
•Observe all governing ordinances.
•Properly ground the oven.
•Do not block oven vents (bottom-front of the oven) or leave combustible or
heat-sensitive items in front of them.

English6
Installation requirements
Location requirements
IMPORTANT: Observe all governing ordinances.
•Specified cutout dimensions are minimums and must be used.
•The cabinet recess must completely enclose all but the face of the oven.
•A grounded electrical supply is required. (See Electrical Requirements.)
•Put the electrical-supply junction box at most 3” (7.6 cm) below the support platform.
•Drill a 1” (2.5 cm) min. diameter hole in the right-/left-rear corner of the support
platform for conduit access to the junction box.
NOTE
For under-counter installation, the junction box should be in the adjacent right/left
cabinet. For rear-wall installation, the junction box should be recessed in the upper-
right corner of the cutout.
•The support platform must be solid, level, and flush with bottom of cabinet cutout.
•Single oven: The floor must support 221 lb (100 Kg).
•Install the oven at least 12” (30 cm) from other appliances.
IMPORTANT: Verify with your builder or cabinet supplier that the materials used will not
discolor, delaminate, or sustain other damage. This oven complies with UL and CSA
International requirements, and the max. allowable wood-cabinet temp. of 194 °F (90 °C).

English 7
Phillips Screwdriver
Drill
Provided items
6 screws (M4 L16)
(4 needed for installation, 2 extra)
Needed Items
Junction Box Wire Nuts
3/4” Conduit Connector
Install Handle (only for double oven)
Installation Materials

English8
Single ovens—Product Dimensions
297⁄8”
(757 mm)
Front Side
231⁄8”
(587 mm)
287⁄8”
(731 mm)
271⁄4”
(691 mm)
13⁄8” (33 mm)
31⁄2”
(89 mm)
281/2”
(724 mm)
471⁄4” (1200 mm)
Conduit length
Top
Installation requirements

English 9
Standard cabinet dimensions
•Dimensions are minimums (except electrical supply location E)
•Allow at least 22” between the open oven door and opposing cabinetry, walls, etc.
•Leave at least 1” clearance under oven and 1-3/8 in. from cutout opening to
cabinet above or countertop.
•(Flush-mount only) Leave at least 2 1/2” unobstructed space below oven.
231⁄2”
mm)(597
Top
FrontSide
Min. 22”
(559 mm)
283/4”
(730.25 mm)
13/8” (34.9 mm)
Max. 91⁄2" (241 mm )
271/4”
(692 mm)

English10
Flush-cabinet dimensions
•Dimensions are minimums (except electrical supply location E)
•Allow at least 22” between the open oven door and opposing cabinetry, walls, etc.
•Leave at least 1” clearance under oven and 1-3/8 in. from cutout opening to
cabinet above or countertop.
•(Flush-mount only) Leave at least 2 1/2” unobstructed space below oven.
Top
FrontSide
247⁄8”
(630 mm)
13⁄8” (33 mm)
Min. 22”
(559 mm)
301⁄4” (767 mm)
283/4” (730.25 mm)
3/4” (19.05 mm) Tasseau
Max. 91⁄2”
(241 mm)
291/8”
(739.77 mm)
Tasseau
1 1/8”
(29 mm)
231⁄2”
(597 mm)
Installation requirements

English 11
Double ovens—Product dimensions
Front Side
297⁄8” (757 mm) 231⁄8” (587 mm)
511⁄2”
(1307 mm)
50”
(1267 mm)
13⁄8” (33 mm)
31⁄2”
(89 mm)
Top
281/2”
(724 mm)
67” (1700 mm)
Conduit length

12English
Standard cabinet dimensions
•Dimensions are minimums (except electrical supply location E)
•Allow at least 22” between the open oven door and opposing cabinetry, walls, etc.
•Leave at least 1” clearance under oven and 1-3/8 in. from cutout opening to
cabinet above or countertop.
•(Flush-mount only) Leave at least 2 1/2” unobstructed space below oven.
Top
231⁄2”
(597 mm)
FrontSide
Min. 47”
(1194 mm)
283/4”
(730.3 mm)
Max. 91⁄2”
(241 mm)
11/4” (31.75 mm)
501/4”
(1276 mm)
12”
(305 mm)

English 13
Installation requirements
Flush-cabinet dimensions
•Dimensions are minimums (except electrical supply location E)
•Allow at least 22” between the open oven door and opposing cabinetry, walls, etc.
•Leave at least 1” clearance under oven and 1-3/8 in. from cutout opening to
cabinet above or countertop.
•(Flush-mount only) Leave at least 2 1/2” unobstructed space below oven.
Side Front
Min. 47”
(1194 mm)
301⁄4” (767 mm)
283/4” (730.25 mm)
Max. 91⁄2”
(241 mm)
51 3/4”
(1314.5 mm)
12”
(305 mm)
3/4” (19.05 mm) Cleat
Cleat
Top
247⁄8”
mm)(630
13⁄8” (33 mm)
231⁄2”
(597 mm)
13⁄8” (33 mm)
3⁄4” (1.9 mm)
notch
3⁄4” (1.9 mm)
notch

14English
If codes permit and a separate ground wire is used, a qualified electrician should verify
that the ground path and wire gauge comply with local codes. Check with a qualified
electrician if you are unsure of the oven's grounding status. This oven must connect to
a grounded-metal, permanent wiring system.
Verify that the electrical connection and wire size are adequate and comply with the
Nat'l Electrical Code, ANSI/NFPA 70-latest edition or CSA Standards C22.1-94, Canadian
Electrical Code, Part 1 and C22.2 No. O-M91-latest edition, and all local regulations.
A copy of these standards can be obtained from:
National Fire Protection
Association 1 Batterymarch
Park Quincy, MA 02169-7471
OR
CSA International
8501 E Pleasant Valley Rd
Cleveland, OH 44131-5575
Electrical Connection
To properly install the oven, determine the type of electrical connection you will use,
and follow the directions in this manual.
•The oven must connect to the
proper voltage and frequency per
the rating plate. (See pg. 4 for the
plate's location.)
•
•
A circuit breaker is recommended.
Use the chart at right to decide
the minimum recommended
dedicated circuit protection:
KW Rating
(240 V)
KW Rating
(208 V)
Circuit Size
(Dedicated)
≤4.8 KW ≤4.1 KW 20 Amp
4.9 KW - 7.5 KW 4.3 KW - 6.2 KW 30 Amp
7.3 KW - 9.6 KW 6.3 KW - 8.3 KW 40 Amp
9.7 KW - 12.0 KW 8.4 KW - 10.4 KW 50 Amp
•Connect directly to the circuit-breaker box (or fused disconnect) via flexible, armored,
or non-metallic, sheathed, copper cable with ground wire.
•Connect the oven's flexible conduit directly to the junction box.
•Fuse both sides of the line.
•The conduit length must so the oven can be serviced without detaching the conduit.
•A UL-listed or CSA-approved conduit connector must be provided.
•If the house has aluminum wiring:
–Connect a section of solid copper wire to the ends of the flexible conduit leads.
–Connect the aluminum wiring to the added section of copper wire using special
connectors and/or tools designed and UL listed for joining copper to aluminum.
Follow the electrical-connector manufacturer’s recommended procedure. Copper/
aluminum connection must comply with local codes and accepted wiring practices.
Model 240 VAC 208 VAC
Power Circuit size Power Circuit size
DOB30M977S 5.6 kW 30 Amp 4.2 kW 30 Amp
DOB30M977D 11.2 kW 50 Amp 8.4 kW 50 Amp
Power requirements for
models DOB30M977S
and DOB30M977D:
*and associated models.

English 15
Installation instructions
Preparing to install the oven
WARNING
Excessive Weight Hazard
To avoid personal injury and property damage, use two or more people to move the oven.
1. Decide the oven's final location. Avoid drilling/cutting household wiring/plumbing.
2. To avoid floor damage, set the oven on a cardboard sheet. (Do not lift by the door
handle or any part of the front frame.)
3. Reduce the oven's weight to ease installation:
a. Remove packing material and tape from the oven.
b. Remove racks and other accessories from the oven chamber.
c. Remove the oven door(s) (see below).
4. Keep any packing material (e.g., corner posts) that may aid the installation.
5. Remove the hardware from the literature pack.
6. Slide the oven (with cardboard beneath) to its installation site.
Removing and replacing the oven door(s)
Removing the oven door(s) before lifting the oven into its cutout will make lifting easier
and will lessen the risk of damaging the door(s) or injuring personnel.
•Remove the door(s) with both hands.
•Before removing a door, arrange a blanket (or the corner posts from the packing
material) on a flat, stable surface on which you will lay the door(s).
Disconnecting the LED wire harness
Find the harness, and disconnect it before removing the door.
Wire Harness
Single Double

16English
1. Carefully pull out the wire to reveal
the connector.
2. Uncouple the connector.
1.
2.
Open the oven door fully flat.
Find the door hinge locks in both
corners of the door, and flip them
down to the unlocked position (see
left) so the door can be removed.
3. Partially close the door to engage the
door hinge locks. (The door stops at
this point.)
4. Grasp each side of the door, and
pull it away from the oven. (You
may need to wiggle the door side-
to-side as you pull.)
5. Rest the door(s), handle-down, on
the prepared surface.
Unlocked
Locked
Removing the oven door(s)

English 17
Installation instructions
CAUTION
If needed, get help lifting the door into the hinge slots. Do not lift the door by the handle.
Slot
1. Grasping each side at the midpoint, lift
the door, and face the oven.
2. With the door at a 45° angle, align the
hinges with the slots in the lower front
of the oven.
3. Slowly insert the hinges into the slots.
(You will know the hinges are engaged
when you feel the door drop slightly.)
4. Open the oven door fully flat.
(If the door does not open a full 90°,
repeat Steps 1 – 3.)
5. Flip the hinge locks up to the locked
position. (See pg. 22.)
6. Close the oven door.
(If the gap between the door and
control panel is wider on one side, the
hinge on that side is improperly set.)
7. Connect the wire harness.
Replacing the oven door(s)

18 English
Electrical connection
WARNING
Electrical Shock Hazard
•Disconnect power before servicing.
•Use 8-gauge solid copper wire.
•Ground the oven.
•Failure to follow these instructions can result in fire, electrical shock, or death.
This oven is manufactured with a neutral (white) power-supply wire and a cabinet-
connected ground (green or bare) wire twisted together.
UL-listed or
CSA-
approved
conduit
connector
1. Disconnect power.
2. Feed the oven's conduit through the
opening in the cabinet.
3. Remove the junction-box cover.
4. Install a UL-listed or CSA-approved
conduit connector on the junction box.
5. Route the oven conduit through the
connector into the junction box.
6. Tighten the conduit connector screws.
7. See the Electrical Connection Options
Chart to complete installation for your
type of electrical connection.
Electrical Connection Options Chart
If your home has: Go to section:
4-wire
1/2"
1.3 cm
4-Wire Cable from Home Power Supply
3-wire 3-Wire Cable from Home Power Supply
1/2"
1.3 cm

English 19
4-Wire Cable from Home Power Supply
IMPORTANT: Use the 4-wire cable from home power supply in:
•the US where local codes do not allow grounding through neutral
•New Branch circuit installations (1996 NEC)
•mobile homes and recreational vehicles
•new construction
•Canada.
A
E
B
G
H
I
C
D
F
A. Cable from home power supply
B. Black wires (normally L1)
C. Red wires (normally L2)
D. 4-wire flexible conduit from oven
E. Junction box
F. White wires (normally N-neutral)
G. UL-listed wire connectors
H. Green wires (normally G-ground)
I. UL listed or CSA approved conduit connector
NOTE: Connect all wires with UL-listed wire
connectors (G).
1. Con nect the 2 black wires (B).
2. Connect the 2 red wires (C).
3. Untwist the white wire from the green
(or bare) ground wire from the oven.
4. Connect the 2 white wires (F).
5. Connect the green (bare) ground wire
(H) from the oven cable to the green
(bare) ground wire (in the junction box).
6. Install the junction-box cover.
Installation instructions

20English
3-Wire Cable from Home Power Supply - U.S. Only
IMPORTANT: Use the 3-wire cable from home power supply where local codes permit a
3-wire connection.
A
E
B
G
H
I
C
D
F
A. Cable from home power supply
B. Junction box
C. Black wires (normally L1)
D. White wires (normally N-neutral)
E. Green wires (normally G-ground)
F. 4-wire flexible conduit from oven
G. Red wires (normally L2)
H. UL-listed wire connectors
I. UL-listed or CSA approved conduit connector
1.
2.
3.
Connect the 2 black wires (C).
Connect the 2 white wires (D) and
the oven's green (bare) ground wire.
Connect the 2 red wires (G).
4. Install the junction box cover.
NOTE: Connect all wires with UL-listed
wire connectors (H).
