Dacor DHD U790LS Series Installation instructions

Use and Care
Utilisation et entretien
Usos y Cuidados
LIB0180473
Hood Liner
Hotte d’armoire
Campana de gabinete
DHD**U790LS/DA

ENGLISH2
Contents
Important Information for Customer 3
Important Safety Information 4
Operations 7
Description of the hood 7
Care and Maintenance 8
Maintenance 8
Troubleshooting 10
Getting help 10
Warranty and Service 11

ENGLISH 3
Important Information for Customer
Installer
Leave these instructions with the owner.
Customer
Read this manual completely before using yourHood. Save the manual for reference.
Forservice and warranty information, see pg.11
If you have any questions (otherthan warranty questions) call Dacor customer service.

ENGLISH4
Important Safety Information
WARNING
This indicates that death or serious injuries may occuras a result of non-observance of this warning.
CAUTION
This indicates that minor ormoderate injuries may occuras a result of non-observance of this warning.
NOTE
This indicates that damage to the appliance or property may occuras a result of non-observance of this advisory.
WARNING
Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer.
WARNING
• When cutting or drilling into wall orceiling, do not damage electrical wiring and other hiding utilities.
• Ducted fans must always be vented to the outdoors.
INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE APPLIANCE AFTER INSTALLATION IS COMPLETE.
IMPORTANT: SAVE FOR THE LOCAL INSPECTOR’S USE.
WARNING
When properly cared for, your new appliance has been designed to be safe and reliable. Read all instructions carefully

kitchen appliances, basic safety precautions must be followed, including those in the following pages.
ProperInstallation and Maintenance
WARNING
Remove all the tape and packaging before using the appliance. Destroy the packaging after unpacking the appliance.
Neverallow children to playwith packaging material. This appliance is intended fornormal family household use only.
It is not approved for outdoor use. Referto the Statement of Limited Warranty in this manual. If you have any questions,
contact the manufacturer.


damage the appliance and could result in injury.
Do not operate this appliance if it is not working properly, or if it has been damaged. Contact an authorized servicer. Do

factory authorized service center.
CAUTION

WARNING
Hidden surfaces may have sharp edges. Use caution when reaching behind or under appliance.

ENGLISH 5
Important Safety Information
Fire Safety
WARNING
Use this appliance only for its intended use as described in this manual.


easily accesible nearthe appliance.

WARNING
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A RANGE TOP GREASE FIRE OBSERVE THE

• 

• 
• 
• Use an extinguisheronly if:
a) You have a class ABC extinguisher, and you already know how to operate it.
b) The fire is small and contained in the area where it started.
c) The fire department is being called.
d) You can fight the fire with your back to an exit.


turn it off.
READ AND SAVE THESE INSTRUCTIONS
WARNING
RISK OF FIRE


WARNING
RISK OF FIRE


WARNING
RISK OF FIRE


ENGLISH6
Important Safety Information
WARNING
RISK OF FIRE
Use only metal ductwork.
WARNING
RISK OF BURNS
The accesible parts get hot during operation. Nevertouch hot parts. Keep children away. When children become old
enough to use the appliance, it is the resposibility of the parents orlegal guardians to ensure that they are instructed

Do not allow anyone to climb, stand, lean, sit or hang on any part of an appliance. This can damage the appliance or
cause injury.
WARNING

before attempting to clean any part of the appliance.
Do not use steam cleaners to clean the appliance.
Proposition 65 Warnings
This product may contain a chemical known to the State of California, which can cause canceror reproductive harm.
Therefore, the packaging of your product may bearthe following label as required by California:
STATE OF CALIFORNIA PROPOSITION 65 WARNING:
WARNING
Cancerand reproductive harm - www.p65warnings.ca.gov
Protecting the environment
Unpack the appliance and dispose of the packaging inline with the environmental requirements.
NOTICE
Always turn appliance on when cooking to avoid condensation buildup. Condensation can lead to corrosion damage.
Risk of damage due to moisture entering into the electronic circuitry.
Neverclean operator controls with a wet cloth. Surface damage may be caused due to incorrect cleaning. Clean
stainless steel surfaces in the brushing direction only. Do not use any stainless steel cleaners for operators controls.
Neveruse strong orabrasive cleaning agents, since they can cause surface damage.


ENGLISH 7
Operations
Description of the hood
A. Fan and light controls
B. Strip LED C. Filter
D. Filter handle
A
C
D
B
Control
The hood is designed to remove smoke, cooking vapors
and odors from the cooktop area. For best results, start
the hood before cooking and allow it to operate several
minutes afterthe cooking is complete to clearall smoke
and odors from the kitchen.
The hood controls are located on the center side of the
hood.
A B
A. Light knob
B. Fan knob
Operating the lights
1. 
hood lights On.
2. 
hood lights Off.
Operating the fan
1. 
2. Turn the fan knob to the desired speed position.
3. 
hood on maximum.
4. 
hood fan Off.
Auto On fan
The hood is equipped with a sensorto automatically
turn on the fan when excessive heat is detected in the
area. This sensorwill turn the fan to boost speed when
necessary. When the heat decreases, the fan will be back
to previous setting.
CFM reduction



fan model and max. 810 CFM fordouble fan models.

ENGLISH8
Care and Maintenance
Maintenance
WARNING

from the powersupply before servicing or cleaning.
Do not use steam cleaners to clean the appliance. Hidden surfaces may have sharp edges. Use caution when reaching
behind or under the appliance.
WARNING
RISK OF BURNS
The appliance will become hot when in use, let it cool before cleaning.
WARNING
RISK OF ELECTRIC SHOCK

breaker in the fuse box.
Cleaning agents

Do not use:
• Cleaning agents that are harsh or abrasive
• Cleaning agents with high alcohol content
• Hard abrasive pads orsponges
• High pressure orsteam cleaners
Thoroughly rinse all new sponges before use.
Exterior surfaces

wipe dry to avoid water marks.
Cleaning method
• Liquid detergent soap and wateror all-purpose cleanser.
• Wipe with a damp soft cloth ornon-abrasive sponge, then rinse with clean water and wipe dry.
• Do not use cleaning agents containing bleach.

ENGLISH 9
Filters and drip trays
1. 
toward the front of the hood and pull down on the rear

 1
2
2. Untighten and remove drip tray screws and uninstall drip trays.
A. Drip trays
B. Drip tray screws
3. 
4. Place drip tray in its original positon, replace and tighten drip tray screws.
5. 
6. 

1
2
Replacing strip LED
The strip LED is replaceable by a service technician only. See the support contact information in the Warranty section.
Care and Maintenance

ENGLISH10
This table lists various minorproblems concerning hood issues, possible causes, and solutions. If you have an issue
listed in this table, try resolving the issue by applying the corresponding solution. If you cannot resolve the issue,
contact Dacor (see Warranty and Service forcontact info).
Problem Cause Solution
Nothing works (fan lights not
working)
• Main poweris OFF; Powerto
hood OFF
• Power outage
• Hood not connected to the
power source
• Check hood’s main power; turn on power
at source; check for tripped breakeror
blown fuse.
• Call your electric company
• Connect it to power source
Light(s) not working (fan working) • Strip LED burned out • Call for service
Fan not drawing heat and smoke
properly
• Fan speed to low
• Filters clogged
• Damperjammed shut;
ducting clogged
• See Operating instructions section
• Call for service
• 
Fan not working (lights working) • Fan electrical malfunction • Call for service
Fan turns on byitself
• Auto on feature is working • The fan will automatically turn off when
the heat has cooled down
• Auto on does not work as
intended • Disconnect power source and call for service


Getting help
Before requesting service:
1. Review Troubleshooting
2. Familiarize yourself with the hood warranty, terms and conditions
3. If none of the previous suggestions resolves your issue, call Dacor customer service.
Troubleshooting
