Daekyung Black Bear DS Series User manual

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
CHAIN BLOCK
USER MANUAL
DAEKYUNG CO., LTD.

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
1. Safety
1.1 Safety Information
1.2 Operating Instructions
2. General Terms & Specification
2.1 Layout & Parts Name
2.2 Specification
3. Transport and Storage
3.1 Transport
3.2 Storage
4. Preliminary Cautions Before Installation
4.1 Check for Completeness
4.2 Check for Specification
4.3 Areas of Application
4.4 Safety
5. Installation
5.1 Installation Method
5.2 Initial Test
6. Cautions
6.1 Preliminary Inspection
6.2 Prohibition of Overload
6.3 Safety Latch of Hook
6.4 Prohibition of Hoist Remodeling
6.5 Lifting
6.6 Cautions During Lifting/Hoist Operation
7. Maintenance
7.1 Initial Inspection
7.2 Periodic Inspection and Adjustment
7.3 Check List
7.4 Lubrication
7.5 Limitation of Hook and Load Chain Use
8. Warranty
CONTENTS
-------------------------------------------- 3
-------------------------------------------- 4
-------------------------------------------- 6
-------------------------------------------- 7
-------------------------------------------- 8
-------------------------------------------- 10
-------------------------------------------- 13
-------------------------------------------- 18

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
1.1 Safety Information
This manual provides important and crucial information for all personnel involved with
installation, operation, and maintenance of Black Bear hoists. Even if you are familiar with
this or similar equipment, you should read this manual carefully before operating the
hoists. Follow the instructions explained in this manual to avoid potential accidents or
injuries.
1.1.1 Sign Description
The following signs are used to indicate potential danger.
Notice
This sign indicates crucial notice, advice, and application remarks.
Caution
This sign indicates possibility of damage to the hoist/trolley in case of non-
compliance with the manual instructions.
Attention
This sign indicates all instructions relating to safety at work. Failure to comply
with these instructions will result in serious injury or death. Follow these
instructions at all times and be particularly alert and cautious.
Danger
This sign indicates possible danger to all personnel working in or around
hoist/trolley operating zone. Failure to comply to safety instructions may cause
serious injury or death.
1. Safety
1.2 Operating Instructions
Instructions are provided throughout this manual to inform the proper ways to operate
the hoist and prevent possible dangers. Safe operating instructions are not
necessarily limited to following list. Refer to specific sections in the manual for additional
safety information and operating instructions.
1. Only allow safety and operation trained personnel to work the hoist/trolley.
2. Only operate the hoist if you are physically fit to do so.
3. When a "DO NOT OPERATE" sign is placed (on any part of the hoist), do not operate
the hoist until the sign has been removed by a designated personnel.
-3 -

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
2.1 Layout & Parts Name
* Model Name & Capacity
MODEL CAPACITY TYPE REMARK
DS 1.0~2.0 Ton Chain Block Mini Type
DH 0.5~50.0 Ton Chain Block
①
③②
⑦
④
⑥
⑧
①Top Hook
②Gear Cover
③Hand Wheel Cover
④Load Chain
⑤Hand Chain
⑥Bottom Hook
⑦Chain Pin
⑧Safety Latch
[ Pic 2.1 ]
⑤
⑧
2. General Terms & Specification
-4 -
2.1.1 Chain Block
* Example : [DH-020] Chain Block 2.0 Ton

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
No. Parts Name No. Parts Name No. Parts Name
1. Gear Cover 12. Guide Roller 22-1. Safety Latch
2. Pinion Shaft 13. Wheel Side Plate Assembly 23. Top Pin
3. Pinion Gear 14. Disc Hub 24. Chain Pin & Nut
4. Pinion 15. Pawl 25. Pinion Bush for No.4
5. Load Gear 16. Pawl Spring 26. Load Bush for No.6
6. Load Sheave 17. Friction Plate 27. Split Pin for No.10
7. Load Chain 18. Ratchet 28. Snap Ring for Pawl Pin
8. Hand Chain 19. Hand Wheel 29. Washer for No. 19
9. Gear Side Plate 20. Hand Wheel Cover 30. Check Nut for No. 2
10. Load Chain Anchoring Pin 21. Top Hook with Holder 31. Cotter Pin for No. 31
11. Stripper 22. Bottom Hook with Holder
[ Pic 2.2 ]
-5 -
2.1.2 Chain Block Layout

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
2.2 Specification
-6 -
2.2.1 Chain Block
Model Capacity
(Ton)
No. of
Chain Falls
Load Chain
Size
(mm)
Lift
[STD]
(m)
Hand Chain
[STD]
(m)
Min. Distance
Hook to Hook
(mm)
Net Weight
(kgf)
DS-010 1.0 1 Ф6.3 x P19.0 2.5 2.0 330 10.5
DS-015 1.5 1 Ф7.1 x P20.2 2.5 2.0 360 13.0
DS-020 2.0 1 Ф7.9 x P23.0 3.0 2.5 350 20.0
DH-005 0.5 1 Ф6.3 x P19.0 2.5 2.0 330 10.5
DH-010 1.0 1 Ф7.1 x P20.2 2.5 2.0 340 12.0
DH-015 1.5 1 Ф7.9 x P23.0 2.5 2.0 400 18.0
DH-020 2.0 1 Ф9.5 x P28.6 3.0 2.5 440 25.5
DH-030 3.0 2 Ф7.9 x P23.0 3.0 2.5 530 28.5
DH-050 5.0 3 Ф7.9 x P23.0 3.0 3.0 670 44.0
DH-080 8.0 3 Ф11.1 x P33.3 3.5 3.5 850 91.0
DH-100 10.0 3 Ф11.1 x P33.3 3.5 3.5 850 91.0
DH-150 15.0 5 Ф11.1 x P33.3 3.5 3.5 1150 181.0
DH-200 20.0 6 Ф11.1 x P33.3 3.5 3.5 1250 235.0
DH-300 30.0 10 Ф11.1 x P33.3 3.5 3.5 1450 492.0
DH-400 40.0 14 Ф11.1 x P33.3 3.5 3.5 1650 750.0
DH-500 50.0 18 Ф11.1 x P33.3 3.5 3.5 1950 930.0
3. Transportation and Storage
Daekyung Co., Ltd. is not responsible for any damage resulting from improper
transport or storage.
3.1 Transportation
- Black Bear hoists are thoroughly checked and packed before delivery.
- Do not throw or drop the hoist.
- Proper and adequate transportation is required.
- Transportation of the hoist may only be done by qualified personnel.
-Any safety devices used during transportation must be completely removed before
operating the hoist.
3.2 Storage
- Store the hoist in a clean and dry environment.
- Protect the hoist against dirt, humidity, and damage by using proper covers.
- Protect the hooks, chains, and brakes against rust.

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
4. Preliminary Cautions Before Installation
4.1 Check for Completeness
Black Bear hoists/trolleys are manufactured under strict quality control and inspection.
Please check for following details of the hoist for completeness:
1) Hoist Body
2) Hook & Hook Holder
3) Load Chain / Hand Chain
4.2 Check for Specification
Please check for your specifications before use.
1) Capacity (Ton), Load Chain Length, Hand Chain Length
2) Contact manufacturer immediately if the specifications differ.
4.3 Areas of Application
1) This hoist is NOT explosion-proof. The hoist is NOT to be used in environments
that are open to potential explosions.
2) Please consult with manufacturer first if the hoist is going to be used in
environments with high (higher than 40°C) or low (lower than -20°C) temperatures,
or with high humidity (more than 90%), or environments that are open to chemicals
and other particular situations.
3) Observe temperature range. Metal parts of the hoist turn weak and could break in
low temperatures. Consult manufacturer if your are in doubt.
4) Do not use the hoist in high humidity environment.
Lifetime of the hoist will shorten if it is exposed to rain. If used outside, please
protect the hoist (entire equipment) with proper covers to avoid rain.
4.4 Safety
All personnel operating the hoist/trolley should use and wear proper safety measures
(gloves, safety shoes, safety helmet) to avoid possible danger.
-7 -

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
5. Installation
[ Pic 5.1 ]
-8 -
Hanging Plate
(or Lifting Sling)
Suspension Hook
Safety Latch
Trolley
Beam
Suspension Hook
Safety Latch
5.1 Installation Method
1) Chain block must be installed on Trolley or Lifting Slings that can safely support
the hoist's load capacity.
2) For safety, the Safety Latch must be completely closed when the hoist is suspended.
3) The Stopper should be installed on each end of the beam.
Stopper
Notice
Check the surroundings of the work area before installing and using the
hoist. Check the fixed structures of the work area.

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
-9 -
“UP”
“DOWN” [ Pic 5.2 ]
“A” “B”
5.2 Initial Test
Run following tests to check if everything is working properly.
5.2.1 Operating Test
Check if the hook goes down when hand chain is pulled down to “A” direction.
Check if the hook goes up when hand chain is pulled down to “B” direction.
* Example : [DH-020] Chain Block 2.0 Ton

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
6. Cautions
6.1 Preliminary Inspection
1) Do not use the hoist if the Safety Latch of hook has been broken/damaged.
2) Safety Latch must be completely closed before use.
3) There should not be any damages or deformation on the hook and chain.
4) All the fixed bolts and nuts should be attached and screwed in tightly.
5) The hook should revolve easily and smoothly.
6) There should not be any dirt or other unusual substances on the hoist.
6.2 Prohibition of Overload
1) Never lift a load that is heavier than the rated capacity of the hoist.
2) Always check for the capacity, written on the name plate of the hoist.
3) All Black Bear hoists are manufactured with consideration of its working area conditions and are tested
with a greater load than its rated safe working load.
4) However, overloading hoists is extremely dangerous as it is considered the same as removing safety
device. ALWAYS operate hoists within the safe working load.

6.3 Safety Latch of Hook
1) When loading the bottom hook, devices like wires and ropes and slings are often used. The Safety
Latch on the hook prevents these other devices to not come off from the hook creating a dangerous
lifting situation. Do NOT detach the Safety Latch from the hook.
6.4 Prohibition of Hoist Remodeling
1) Voluntary remodeling of the hoist by the user is strictly prohibited.
2) Use of this hoist as elevator (for both passenger and freight) is strictly prohibited.
-10 -

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
-12 -
6.5 Lifting
1) Never use Lifting Slings with lighter/lower capacity than the load being lifted. Always check for
any damages/deformations on Lifting Slings before use. Always consider lifting angels and lifting
mode when selecting slings.
2) To lift load safely, Lifting Sling with proper length and capacity should be used. Use Lifting Slings
that have sufficient load capacity for every operation.
3) Never suspend more than one load on a single hook.
4) Do not place any parts of the body (i.e. hands, fingers) inside the hook.
5) Do not force hook into place by thrashing or hammering.
6) The load (or rope/wire/sling) must be properly suspended in the saddle of the hook. If load or
sling is placed incorrectly, a dangerous situation may arise resulting in sling break causing load to
drop.
7) Never suspend the load or sling on the tip of the hook.
8) Always balance your lift. Ropes/Wires/Slings must not be tangled, slanted or twisted.
9) Never use the hoist as support or fixture.
10) Change the Lifting Sling if the Safety Latch does not close due to its (Lifting Sling) thickness.
11) When the angle of 2 Lifting Slings (or ropes) gets excessively wide (as they are suspended on a
hook), there are possibilities of the Lifting Slings falling off or breaking as the weight (applied
on Lifting Slings) gets bigger. For a safe operation, change the loading method or change the
Lifting Slings to longer one. When suspending load, the angle of sling (rope) should be less than
60°.
12) Never wind up the Load Chain around the load. It is dangerous because Load Chain has
weak horizontal pulling strength.

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
6.6 Cautions During Lifting/Hoist Operation
1) Pay full attention to the load and the surroundings at all times when operating the hoist. The
hoist must not be loaded when not in use.
2) Be sure everyone is clear of the load path. Do not lift load over people.
3) Never use the hoist to lift or lower people. Do not stand or sit on a suspended load.
4) Never place your hands/feet under the load. Always be aware of overhead loads.
5) Never lift a load with greater capacity than that of the hoist. Check capacity of the hoist before
use. Also never pull or load from the side.
6) Do not operate hoists with twisted, tangled, or damaged chains.
7) Be certain that Load Chain is tightly pulled. Check the balance of the load by hoisting a little bit.
8) The hoist must hang centrally under the beam or under its suspension point.
9) The load/sling must be properly suspended in the saddle of the hook. Never suspend the load/sling on
the tip or end of the hook.
10) Do not swing/shake a suspended load. Do not cut or weld a load that is suspended in the
hoist.
11) Lifetime of the hoist will be shortened if it is exposed to rain. If used outside, cover the entire hoist
(and chain basket) to avoid rain.
12) It is very dangerous to lift a load by using 2 hoists at the same time as the weight might shift to
one side. Be certain that load is properly balanced and kept horizontal.
13) Stop the hoist immediately if chains are making unusual or excessive noise, blocking over the
load, or binding occurs.
-12 -

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
7. Maintenance
-13 -
7.1 Initial Inspection
1) Change the lubricating grease in the gear box after first 500 hours of use. After 1st inspection, check
every 6 months and refill if necessary.
2) Do not install/operate hoist/trolley in humid environments/working areas.
3) Cover the entire hoist/trolley equipment when used/kept outside.
4) To inform other personnel in the working area, place a <DO NOT OPERATE> or <INSPECTION> sign
when hoist/trolley is under inspection.
7.2 Periodic Inspection and Adjustment
7.2.1 Daily Inspection
Check for following details before use (without any load suspended):
- Is there any unusual or excessive noise from the hoist?
- Is the Safety Latch of the bottom hook (of hoist) properly installed?
- Is the Load Chain lubricated with oil?

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
7.2.2 Monthly Inspection
1) Load Chain Test
When the chain (which the load will be suspended on) is rusted
or stretched out, replace the chain immediately! Rusted/stretched
chain causes potential danger/problems in operating the hoist.
Notice
Measure the diameter and inside length of the chain. If the measured lengths go over the
allowable limit, replace the chain. [ Refer to 7.5.1 ]
2) Hook Inspection
The hook will not be deformed or broken if it is used within the safe working load and complied
to this manual instructions. However, when used over long period of time, overloading the hook
may occur. Therefore, be certain to inspect the hook regularly. Replace the hook if the hook
gate is open or seems deformed in any other way.
Notice
Measure the hook opening length. Replace the hook if the length go over the allowable limit.
[ Refer to 7.5.2 ]
[ Pic 7.1 ]
-14 -
Capacity Material
Diameter
Inside
Length
Outside
Length No. of Chain
Fall Remark
(Ton) mm(D) mm(P) mm(B)
0.5 6.3 19 20.9 1 DS-010
1 7.1 20.2 23.2 1 DS-015
1.5 7.9 23 25.9 1 DS-020
2 9.5 28.6 31.3 1
3 7.9 23 25.9 2
5 7.9 23 25.9 3
8.0 11.1 33.3 36.4 3
10.0 11.1 33.3 36.4 3
15.0 11.1 33.3 36.4 5
20.0 11.1 33.3 36.4 6
30.0 11.1 33.3 36.4 10
40.0 11.1 33.3 36.4 14
50.0 11.1 33.3 36.4 18

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
-15 -
7.2.3 Annual Inspection
1) Disassemble the gear box and check for abrasion/damage of gear parts. Replace them if necessary.
2) Check for abrasion/damage of ratchet, stopper (pawl), or brake lining. Replace them if necessary.
3) When the inspection is completed, assemble the hoist and fill the lubricating grease.
4) Check for any unusual noise, etc. by hoisting/descending the hoist about 40-50cm for 2-3 times
without any load suspended. Then try the same inspection again with a load suspended, and check for
any sliding and other problems. Use the hoist if everything is working properly.
7.3 Check List
Part Check List Check Standard
Body
Exterior Appearance There should not be any rust, dent, or damage.
Noise There should not be any unusual or excessive noise.
Side Plate There should not be any dent, abrasion or deformation.
Reduction Gear There should not be any dent, abrasion or deformation.
Load Sheave There should not be any dent, abrasion or deformation.
Load Chain
Rust/Dent There should not be any rust, dent, or deformation.
Oil Lubrication Oil must be thoroughly and evenly distributed.
Top & Bottom Hook
Deformation Hooks should not be deformed (sagging or cracked open).
Holder There should not be any dent, abrasion or deformation.
Bottom Hook Pin There should not be any abrasion or bending.
Safety Latch Safety Latch must be in place and it should move freely.
Other Hand Chain Hand chain must operate smoothly.

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
7.4 Lubrication
Change the lubricating grease in the gear box after first 500 hours of use. After the 1st change, inspect every 6
month and refill the oil if necessary.
7.5 Limitation of Hook and Load Chain Use
7.5.1 Load Chain
[ Pic 7.2 ]
-16 -
Capacity Dimension (mm)
Remarks
(Ton) Standard
Dimension (P) Allowable Limit Standard Dimension (D) Allowable Limit (D)
0.5 19.0 19.6 6.3 6.0 DS-010
1.0 20.2 20.8 7.1 6.8 DS-015
1.5 23.0 23.7 7.9 7.5 DS-020
2.0 28.6 29.5 9.5 9.1
3.0 23.3 24.0 7.9 7.5
5.0 23.3 24.0 7.9 7.5
8.0 33.3 34.3 11.1 10.6
10.0 33.3 34.3 11.1 10.6
15.0 33.3 34.3 11.1 10.6
20.0 33.3 34.3 11.1 10.6
30.0 33.3 34.3 11.1 10.6
40.0 33.3 34.3 11.1 10.6
50.0 33.3 34.3 11.1 10.6
Capacity
Required Q’ty
Brand
Remark
(Ton)
(Gram)
TOTAL
SHELL
MOBIL
BP
CASTROL
FAMM
0.5
30
CERAN WR2
ALVANIA
EP(LF)2
MOBILUX
EP2
ENERGREASE
MM-EP2
SHPEEROL
EPL2
MULTIFAK
EP2
Grease Type
1.0
30
1.5
40
2.0
60
3.0
40
5.0
40
8.0
80
10.0
80
15.0
80
20.0
160
30.0
160
40.0
160
50.0
160

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
7.5.2 Hook
[ Pic 7.3 ]
-17 -
Caution
Replace the load chain and hook if the dimensions go over the allowable limit
(refer to Table 7.5.1 and 7.5.2)
Capacity Dimension (mm)
Remark
(Ton) Standard Dimension (A) Allowable Limit
0.5 28.0 30.8
1.0 34.0 37.4
1.5 32.1 35.3
2.0 33.3 36.6
3.0 40.0 44.0
5.0 48.0 52.8
8.0 67.5 74.2
10.0 67.5 74.2
15.0 93.2 102.5
20.0 95.0 104.5
30.0 112.0 123.2
40.0 140.0 154.0
50.0 138.0 151.8

Black Bear is a registered trademark of Daekyung Co., Ltd.
1521-6 Dadae-dong, Saha-gu, Busan, Korea Tel: [phone] Fax: [phone]
BLACK BEAR HOIST
1) Thank you for purchasing Black Bear hoists/trolleys.
2) All of Black Bear hoists are manufactured under strict quality control and inspection. We assure
quality hoists with reliable customer service.
3) Please contact us or our local distributor immediately if you find problems/defects in our
hoists.
4) Free After-sales service is provided for 1 year after the purchase.
(Even within the warranty period, some services are charged at additional cost.)
※Following After-sales service are charged at additional cost
(even within the free After-sales service period):
- Parts replacements due to wear & tear, and abrasion
-Problems (breaking of the hoist) due to users’ mishap or negligence
- Problems (breaking of the hoist) due to natural disasters
- Problems due to voluntary repair/remodeling of the hoist by the user or anybody else other
than Daekyung Co., Ltd. or service points appointed by Daekyung Co. ltd.
- Problems due to use of the hoist in other special/particular environments or working areas
(Please consult with Daekyung Co., Ltd. first)
8. Warranty
-18 -
ADDRESS : 1521-6 DADAE-DONG, SAHA-GU, BUSAN, KOREA
TEL : [phone] FAX : [phone]
E-MAIL : [email protected]m HTTP : www.dkhoist.com
DAEKYUNG CO., LTD.
