IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed. These instructions should be saved for future
reference:
• Read and familiarise yourself with all operating instructions before using
this Kettle.
• Before plugging your kettle into the mains, visually check that the kettle is
intact and has not suffered any transit damage.
• Check that the voltage indicated on the data plate corresponds with that of
the local network before connecting the appliance to the mains power
supply.
• This kettle is only to be used with the stand provided.
• Close supervision is required when using this appliance near children.
• Never leave this appliance within reach of children.
• This appliance can be used by children aged from 8 years and above if
they have been given supervision or instruction concerning use if the
appliance in a safe way and if they understand the hazards involved.
Cleaning and user maintenance shall not be made by children unless they
are older than 8 and supervised. Keep the appliance and its cord out of
reach of children aged less than 8 years. This appliance can be used by
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance.
• Do not leave the appliance unattended during use.
• Do not leave the appliance unattended whilst connected to the mains
supply.
• Always use this appliance on a solid, level, non-flammable surface.
• Do not use this appliance outdoors.
• It is imperative to unplug the power cord after the appliance has been
used, before it is cleaned and whilst being repaired.
• If the supply cord is damaged, it must be replaced by the manufacturer,
service agent or similarly qualified person in order to avoid hazard.
• Repairs to electrical appliances should only be performed by qualified
personnel. Improper repairs may place user at serious risk.
• Do not operate this appliance with a damaged plug or cord, after a
malfunction or after being dropped or damaged in any way.
• Regular, periodic checks should be carried out on the mains cable to
ensure no damage is evident. Should there be any signs of damage!the
appliance should not be used.

3
!
• Do not allow the mains cable to hang over sharp edges or come in contact
with hot surfaces.
• Do not run the mains cable under carpets, rugs, etc.
• Allow the unit to cool before storage.
• Never place the appliance near to flammable material or high pressure
containers.
• This appliance is intended for household use only and should not be used
for industrial purposes.
• Do not use any accessories or attachments with this appliance other than
those supplied or recommended by supplier.
• Do not immerse the appliance, base or its cord in water or any other
liquids.
• Do not use this appliance for anything other than its intended use.
• Do not push objects into any openings as damage to the appliance and/or
electric shock may occur.
• Ensure appliance is situated in an open area, do not allow it to come in
contact with cupboards, curtains, wall coverings, clothing or other
flammable materials.
• Unplug after each use. Grasp the plug, not the cord.
• Do not cover this appliance.
• Never place this appliance on an electric, gas, or any other type of hob.
• WARNING: Do not open lid whilst the water is boiling.
• Never fill the kettle more than its capacity – ensure the water level is
between the min and max marks. If the kettle is overfilled, boiling water
may be ejected.
• Always close the lid during use and do not open the lid whilst the water is
boiling.
• CAUTION: The outside surface of the kettle will get hot during
use.
• Ensure the kettle has switched off before removing it from the base.
• Please note, due to this being a rapid boil kettle it is recommended that
you don’t use this in conjunction with any other appliances on a multi
socket extension lead.
THIS APPLIANCE MUST BE EARTHED
! !

4
!
9
1
3
5
7
Description of parts!!
!
!
!
!
!
!
!
!
!
!
Before the first time you use your kettle!
Please read these operating instructions thoroughly and keep them in a
safe place for future reference.
Before using the kettle for the first time fill to the max mark and allow the
water to boil. Pour away the boiled water and then repeat the process. If a
slight taste or odour remains repeat the above process once more.
!
Instructions for use
!
!
!
! !
1. Spout
2. Lid
3. Water Gauge
4.
Lid Open Button
5. Body
6. Handle
7. Base
8. Switch
9. Internal LED’s
2
4
6
8
Place the kettle Base (7) on a
flat, level surface.
!
•Press the Lid Open Button (4) to
open the Lid (2).
1
2

5
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
Boil dry protection
Should you accidentally let the appliance operate without water; the boil-
dry protection will automatically switch off the power. If this occurs, allow
the appliance to cool and reset before use.
Lime scale removal!
• To maintain the performance of your kettle it is recommended you descale
it once every three months to increase the life expectancy and reduce lime
Fill the kettle with water to the
desired level on the Gauge (3)
ensuring that it is above the
MIN mark and below the MAX
mark.
•
3
Push the Lid (2) until it clicks fully
closed and then place the kettle onto
the Base (7).
•
Insert the mains plug (with dry hands) into the
mains socket.
Push the Switch (8) down and the blue internal
LED’s will illuminate and the water will begin to
boil.
At the end of the boiling cycle the Switch (8) will
automatically switch off and the LED’s will go out.
Wait until the water has finished boiling before
removing it from the Base.
•
4
5

6
!
scale build up. In extreme hard water areas we highly recommend using
filtered water in your kettle to increase the life expectancy and help prevent
excessive lime scale build up.
• If the kettle switches off before it boils or has a white deposit building up
inside then it probably needs to be decalcified.
• Do not use vinegar but a commercially available descaling agent; carefully
follow the quantities recommended in the instructions of the agent:
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
Fill your kettle to the ‘MAX’
mark on the body or the water
quantity recommended by the
descaling product.
Add a citric based descaling agent
to the kettle according to the
descaling products instructions.
1
2
Allow the kettle to boil, switch off and
then stand to allow the kettle to soak
for approximately 15 – 20 minutes, (if
necessary adjust the standing time to
the descaling products instructions).
4
Finally, empty the kettle and refill with fresh clean water and allow
to come to the boil and switch off once more, then again pour the
water away. Your Glass Kettle is now descaled and cleaned.
3

7
!
Electrical Connections
This appliance is fitted with a fused three-pin plug to BS 1363. If the plug
has to be removed, it should be cut off and carefully disposed of
immediately. To avoid a possible shock hazard, do not insert the discarded
plug into a mains socket.
!
Fitting a new plug
If for any reason you need to fit a new plug, the flexible mains lead must be
connected as shown below. The wires in the mains lead fitted to this
appliance are coloured in accordance with the following code:
Brown wire = Live (L)
Blue wire = Neutral (N)
Green & Yellow = Earth (E)
!
!
!
!
!
!
!
!
!
If colours of the wires in the mains lead of this appliance do not correspond
with the coloured marking identifying the terminals in your plug, proceed as
follows:
The wire which is coloured Blue must be connected to the terminal which is
marked with the letter N or coloured Black. The wire which is coloured
Brown must be connected to the terminal which is marked with the letter L
or coloured Red. The wire which is coloured Green and Yellow must be
connected to the terminal which is marked with the letter E or coloured
Green.
Before refitting the plug cover check that there are no cut or stray strands
of wire inside the plug. Use a 13 Amp BS 1362 fuse, only BSI or ASTA
Connect
Green &
Yellow to
Earth (E)
Connect
Brown to
Live (L)
Connect
Blue to
Neutral
(N)
Ensure the outer sheath of the
mains lead is securely held by the
cable clamp

8
!
approved fuses should be used. If you are in any way unsure which plug or
fuse to use, always refer to a qualified electrician.
Note: After replacing or changing a fuse on moulded plug which has a fuse
cover, the cover must be refitted to the plug, the appliance must not be
used without a fuse cover.
Technical Data
Voltage : 220-240V ~ 50/60Hz
Rated power : 3000W
Capacity : 1.5L
Protection class : 1 (This appliance must be earthed)
Model : SDA!!!!
!
!
!
!!!!!!!!!!!!!!!!!!Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer for
recycling advice.
!
!
!
!
!
