Daewoo SDA2252 User manual

IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed. These instructions should be saved for future
reference:
• Read and familiarise yourself with all operating instructions before
using this fridge.
• Before plugging your unit into the mains, visually check that the unit is
intact and has not su󰀨ered any transit damage.
• If this appliance is to replace an old refrigerator with a lock, please
remove the lock or door before disposal.
• Your old appliance may contain insulation, gases and refrigerant that
need to be disposed of correctly. Please ensure that the refrigerant
circuit is not damaged before the appliance is disposed of. If in any
doubt contact your local authority for advice.
• This appliance may contain the refrigerant isobutene (R600a). This is
a natural gas with a high level of environmental compatibility, however,
caution is required as isobutene is a ammable gas. It is essential that
refrigerant tubes are not damaged during transit or installation of the
appliance. In the event that the refrigerant circuit is damaged, avoid
naked ames and sources of ignition and ventilate the room in which
the appliance is situated.
• Do not damage the refrigerant circuit
• Following installation ensure the power cable is not trapped beneath
the appliance.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised
• Do not use mechanical devices or other means to accelerate the de-
frosting process, other than those recommended by the manufacturer.
• This appliance is for household use only.
Drinks Chiller
SDA2252
User Manual

• Do not use electrical appliances inside the food
storage compartment of the appliance, unless they are of a type
recommended by the manufacturer.
• Keep all ventilation openings clear of obstruction.
• Do not store explosive substances such as aerosol cans with
ammable propellants in this appliance.
• It is imperative to unplug the power cord after the appliance has been
used, before it is cleaned and whilst being repaired.
• Repairs to electrical appliances should only be performed by a
qualied electrician. Improper repairs may place user at serious risk
• Do not operate this appliance with a damaged plug or cord, after a
malfunction or after being dropped or damaged in any way.
• Regular, periodic checks should be carried out on the mains cable to
ensure no damage is evident. Should there be any signs of damage
the appliance should not be used.
• Do not allow the mains cable to hang over sharp edges or come in
contact with hot surfaces.
• Do not run the mains cable under carpets, rugs, etc.
Drinks Chiller
SDA2252
User Manual

Installation
• IMPORTANT! This appliance must be left to stand in an upright
position for a minimum of 4 hours prior to switching on for the rst
time.
• Please read these operating instructions thoroughly and keep them in
a safe place for future reference.
• Remove all packing materials and discard responsibly.
• Clean the interior of the appliance with lukewarm water containing a
small amount of bicarbonate of soda (5ml to 0.5 l of water)
• Position the appliance out of direct sunshine.
• Do not position next to a cooker or other sources of heat such as a
radiator.
• If positioned next to another fridge or freezer, leave a minimum gap of
2cm between the appliances to avoid condensation.
• A clearance of 50mm should be left above the appliance, if this is
not possible 25mm of clearance should be left on each side of the
appliance.
• Ensure there is a clearance between the condenser and rear wall.
• Do not place heavy items on top of the appliance.
• Position the appliance on a solid at surface.
• This appliance must be level. Adjust the level by screwing the
adjustable feet up or down as required, using your ngers or a
suitable spanner.
• Ensure that the power supply is in accordance with the rating plate
found at the rear of the appliance.
• Do not push objects into any openings as damage to the appliance
and/or electric shock may occur.
• Do not use any accessories or attachments with this appliance other
than those supplied or recommended by supplier.
Operation
You may hear faint gurgling or bubbling sounds as the refrigerant is
pumped around the cooling circuit, this, along with the slight hum of the
compressor is normal and will stop and start as the thermostat operates.
Drinks Chiller
SDA2252
User Manual

Switching on the appliance
Allow the appliance to stand for a minimum of 4 hours after installation.
Plug in the appliance and switch on the mains supply.
Set the thermostat to the required setting (The temperature selector is
situated to the top centre of the icebox, setting 0 = o󰀨, setting 3 or 4 are
most commonly used for normal operation, however this can be changed
to your own preferred temperature, with 7 being the coldest setting).
Leave the appliance for 4 hours to reach temperature before use.
NOTE: During periods of high ambient temperatures (ie hot sunny days)
it may be necessary to set the temperature to a higher setting than is
normally used.
In the event of a power failure
If there is a power failure keep the door closed if possible to maintain the
internal temperature. After power is restored it may take some time to
return to the set temperature level.
Energy saving advice
• Do not install the appliance close to sources of heat such as cookers
or radiators.
• Locate the appliance in a well ventilated area.
• Ensure the door seal is clean and there are no tears or rips.
• Do not overload the fridge.
• Never put hot or warm items into the chiller, allow to cool to room
temperature rst.
• The internal light can be switched o󰀨 manually when required using
the switch on the upper right hand side of the cooler cavity.
Drinks Chiller
SDA2252
User Manual

Door Reversal Instructions
Your refrigerator is built with a reversible door. You have the choice of ei-
ther opening it from the left or the right side. In order to reverse the open-
ing direction of your door, please follow these instructions.
1. Glass door 8. Self-tapping screw
2. Adjustable feet 9. Fixed feet
3. Lower hinge 10.Bolt
4. Lower hinge shaft pin 11.Upper hinge
5. Spacer 12.Upper hinge cover
6. Nut 13. Screw hole
7. Door mat
• Remove the hinge cover and unscrew upper hinge screw. Remove
upper hinge.
• Lie the unit down on the oor for support.
• Remove the door leg and unscrew screws. Remove lower hinge.
• Change the position of lower hinge to the opposite side of the ap-
pliances, locate and support the door onto the lower hinge, replace
screws and adjustable foot, align door and replace the upper hinge
and replace screws.
• Rotate the door 180°to the left.
• Fit the hinge cover.
Drinks Chiller
SDA2252
User Manual

Cleaning and maintenance
WARNING: Before any maintenance or cleaning is carried out
disconnect the appliance from the mains supply.
Internal cleaning
Clean the interior and accessories with warm water and bicarbonate of
soda (5ml to 0.5l of water). Rinse and dry thoroughly. Do not use
detergents, abrasives, highly perfumed cleaning products, wax polishes
or cleaning products containing bleach or alcohol.
External cleaning
Wash the outer cabinet with warm soapy water. Do NOT use abrasive
cleaners. There may be some sharp edges on the underside of the
appliance so care should be taken when cleaning. Once or twice a year
clean the rear of the appliance and the compressor using a soft brush or
vacuum cleaner as an accumulation of dust will a󰀨ect the performance of
the appliance and cause increased energy consumption.
If the appliance is not in use for some time, disconnect from the mains
supply and leave the door slightly ajar until next use.
Drinks Chiller
SDA2252
User Manual

• The Blue wire must be connected to the terminal marked N or
coloured Black.
• The Brown wire must be connected to the terminal marked L or
coloured Red.
• The Green & Yellow wire must be connected to the terminal marked E
or coloured Green.
• Check that there are no cut or stray strands of wire inside the plug.
• Use a 3 Amp BS 1362 fuse, only use BSI or ASTA approved fuses.
• If you are in any way unsure which plug or fuse to use, always refer to
a qualied electrician.
• After replacing or changing a fuse on a moulded plug, the cover must
be retted to the plug; the appliance must not be used without a fuse
cover.
Connect Blue
to Neutral (N)
Connect Green &
Yellow to Earth (E) Connect Brown
to Live (L)
Electrical Connections
This appliance is tted with a fused three-pin plug to BS 1363. If the plug
has to be removed, it should be cut o󰀨 and carefully disposed of
immediately. To avoid a possible shock hazard, do not insert the
discarded plug into a mains socket.
Fitting a new plug
The mains lead must be connected as shown below. The wires are
coloured with the following code - Brown wire = Live (L), Blue wire =
Neutral (N), Green & Yellow = Earth (E).
Ensure the outer sheath of the mains lead
is securely held by the cable clamp
Drinks Chiller
SDA2252
User Manual

Technical Data
Model SDA2252
Rated voltage 220-240V AC
Rated frequency 50Hz
Rated cooling current 0.7A
Lamp power 1W
Input power 60W
Refrigerant R600a (24grams)
Protection class Class I
Climate type N,ST
Blowing gas C5H10
Net weight 19kg (approx)
Customer Support
Should you require any product information,
replacement parts or accessories, please contact our
customer care team at [email protected] or
call 0161 831 7879.
• Replacement parts and accessories are guaranteed
for 1 year from the date of purchase.
• It is important to note that your warranty becomes
invalid should non Daewoo parts or accessories be used
with this appliance
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check with
your Local Authority or retailer for recycling advice.
Drinks Chiller
SDA2252
User Manual

Thank you for purchasing your Daewoo product.
As part of our commitment to quality we are offering you an extra 2 years warranty in addition to your
1 year guarantee.
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof of purchase or
receipt. If any defects should arise due to faulty workmanship or material, your faulty product should be returned
to the place of purchase, replacement or refund is at the discretion of the retailer.
The guarantee is subject to the following provisions:
• The product must be correctly installed and operated in accordance with the requirements contained
in the instruction manual.
• The product must be used solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The Guarantee is rendered invalid if the product has been resold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your individual product upon
registration. (Note: products must be registered individually and covers the main body and housing) If you do not
register your product within 28 days of the original purchase date, your product will only be guaranteed for 1
year.
To validate your extended 2 year warranty* please register your purchase online within 28 days of the original
purchase date by registering at
www.daewoowarrantyregistration.com/warranty-registration
*Your extended warranty is only valid with proof of purchase receipt and
subject to the conditions outlined above.
Daewoo® is a registered trademark.
Produced and imported under licence by ESG Ltd
ESG Ltd
Manchester M3 1JS
www.esgltd.com
WARRANTY
