1
Double Stainless Steel Hot Plate
Model Number: SDA1732
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

2
Double Stainless Steel Hot Plate
Model Number: SDA1732
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure
the user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
•Read and familiarise yourself with all operating
instructions before using this Hot Plate.
•Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
•Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
•Close supervision is required when using this appliance
near children.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children unless they are older than 8 and
supervised.

3
Double Stainless Steel Hot Plate
Model Number: SDA1732
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•Keep the appliance and its cord out of reach of children
less than 8 years.
•DO NOT touch hot surfaces. The outer surfaces
are liable to get hot during use. Always use the
handles and knobs.
•DO NOT immerse the appliance or its cord in water or any
other liquids.
•DO NOT leave the appliance unattended during use.
•DO NOT leave the appliance unattended whilst connected
to the mains supply.
•Always use this appliance on a solid, level, non-flammable
surface.
•DO NOT use this appliance outdoors.
•DO NOT use this appliance with a programmer, timer,
separate remote-control system or any other device that
switches the appliance on automatically.
•It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
•Repairs to electrical appliances should only be performed
by a qualified electrician. Improper repairs may place user
at serious risk.
•DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
•Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
•If the power cable is damaged, it should only be replaced
by the manufacturer or a suitable qualified after-sales-
service in order to avoid a hazard
•DO NOT allow the mains cable to hang over sharp edges

4
Double Stainless Steel Hot Plate
Model Number: SDA1732
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
or come in contact with hot surfaces.
•DO NOT run the mains cable under carpets, rugs, etc.
•Allow the unit to cool before storage.
•Before cleaning, disconnect the appliance from the mains
supply and allow to cool.
•This appliance is intended for household use only and
should not be used for industrial purposes.
•DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
•DO NOT use this appliance for anything other than its
intended use.
•DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
•Ensure appliance is situated in an open area, do not allow
it to come in contact with Cupboards, Curtains, wall
coverings, clothing or other flammable materials.
•Unplug after each use. Grasp the plug, not the cord.
During the first few minutes of initial use, you may notice a slight
odour and a little smoke. This is normal and will quickly disappear, it is
the coating applied to the cooking plates to prevent any corrosion
during transit.
THIS APPLIANCE MUST BE EARTHED

5
Double Stainless Steel Hot Plate
Model Number: SDA1732
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and sent to landfill. Please ensure
it is taken to a suitable facility for disposal. Check with your
Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
This symbol provides useful additional information on the use of
this product.
This symbol indicates that the supply uses an alternating
current mains supply.
This symbol indicates that the surface is gets hot and care must
be taken.
Introduction
This is a household Double Hot Plate; it is equipped with two hot plates, the
smaller 1kW Cooking Plate is suitable for saucepans for cooking smaller
portions, sauces and simmering. The larger 1.5kW Cooking Plate is suitable for
larger pans for cooking larger portions, boiling and steaming.
Before the first time you use your Hot Plate
Remove all packing materials and discard responsibly.
Ensure all parts are present (if applicable) see Description of Parts below.

6
Double Stainless Steel Hot Plate
Model Number: SDA1732
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Before using your Hot Plate for the first time, turn the Thermostat Control (4 & 5)
to the highest setting for 3 to 5 minutes to condition the protective coating.
You may notice a slight odour and a little smoke during this initial heating
process. This is normal and will quickly disappear, it is the coating applied to the
heating element to prevent any corrosion during transit.
This should be the only time the Hot Plate is operated without a cooking
utensil on it.
A pan/cooking utensil 15 - 18cm in diameter is recommended for the Large
Cooking Plate (1) and a pan/cooking utensil up to 15cm is recommended for
Small Cooking Plate (2) to achieve best results. Ensure larger pans do not
protrude beyond the edge of the Cooking Plate or the controls.
Operating Instructions
•Place the Hot Plate on a solid, level non-flammable surface.
•Ensure that Thermostat Control (4 & 5) is in the OFF ( ) position.
•Insert the mains plug into the mains socket.
•Rotate the Thermostat Control (4 & 5) clockwise to the desired temperature
setting from 1 (low heat) to 5 (high heat). The Heat Indicators (3 & 6) will
illuminate to show the Hot Plates (1 & 2) are heating up.
•Once the Hot Plates are at the desired temperature and ready to use, the Heat
Indicators (3 & 6) will go out.
The Heat Indicators (3 & 6) will go on and off during use to maintain the
temperature - this is normal.
•Rotate the Thermostat Control (4 & 5) to the OFF ( ) position and remove
the mains plug from the socket after use.
1. Large Hot Plate
2. Small Hot Plate
3. Large Plate Heat Indicator
4. Large Plate Thermostat
5. Small Plate Thermostat
6. Small Plate Heat Indicator
7. Non-Slip Feet (Underneath)
3
1
2
4
5
6
7

7
Double Stainless Steel Hot Plate
Model Number: SDA1732
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Care and Use of your Hot Plate
•Always disconnect the Hot Plate from the mains power supply and allow to cool
before cleaning.
•Clean the outside of the Hot Plate with a soft damp cloth. Never clean the Hot
Plate with harsh or abrasive cleaners.
•Do not submerge any part of the Hot Plate or its cord in water or any other
liquids.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse
cover missing. If in doubt, consult a qualified electrician.
If you need to remove the plug -DISCONNECT FROM THE MAINS- and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Technical Specification
Rated Voltage
220-240V~ 50-60Hz
Rated power
2500W
Protection Class
I (this appliance must be Earthed)
Model Number
SDA1732
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and sent to landfill. Please ensure it is taken to a
suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.

8
Double Stainless Steel Hot Plate
Model Number: SDA1732
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
• The product must becorrectly installed and operated in accordance with the
requirements contained in the instruction manual.
• The product must beused solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The guarantee will berendered invalid if the product is re-sold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
