Daewoo Solar 130LC-V User manual

Shop Manual
2023-7117E
Serial Number 0001 and Up
Solar 130LC-V

Product Label
Instructions
Trim Out The Label Along
The Lines And Insert Into
Pocket On The Binder Spine
Solar 130LC-V Serial No. 0001 and Up Pub.No. 2023-7117E
Pub. No. 2023-7117E

1TABLE OF CONTENTS
Safety
Track Excavator Safety..........................................................................S0102000
Specifications
Specifications for Solar 130LC-V...........................................................S0206000
General Maintenance
General Maintenance Procedures.........................................................S0302000
Standard Torques..................................................................................S0309000
Upper Structure
Cab ........................................................................................................S0402000
Counterweight........................................................................................S0403000
Fuel Tank...............................................................................................S0405000
Swing Bearing........................................................................................S0407000
Swing Reduction Gearbox .....................................................................S0408020
Lower Structure and Chassis
Track Assembly .....................................................................................S0505050
Engine and Drive Train
Air-Conditioner.......................................................................................S0605010
Hydraulics
Hydraulic System Troubleshooting, Testing and Adjustment ................S0702050
Accumulator...........................................................................................S0703000
Center Joint (Swivel)..............................................................................S0704020
Cylinders................................................................................................S0705000
Swing Motor...........................................................................................S0707220
Travel Motor (With Gearbox) .................................................................S0707340

Main Pump (With Regulator) .................................................................S0708340
Main Control Valve ................................................................................S0709420
Remote Control Valve (Work Lever / Joystick) ......................................S0709450
Travel Control Valve (RCV8C4015A) ....................................................S0709800
Hydraulic Schematic (S130LC-V) ..........................................................S0792040
Electrical System
Electrical System ...................................................................................S0802060
Electrical Schematic (S130LC-V) ..........................................................S0892040
Attachments
Boom and Arm.......................................................................................S0902030
Bucket....................................................................................................S0904000

1SAFETY

S0102000
Page 1
Track Excavator Safety
S0102000
R1
1TRACK EXCAVATOR
SAFETY
TRACK EXCAVATOR SAFETYS0102000
CAUTION!
Follow all safety recommendations and safe shop practices outlined in the front of this manual
or those contained within this section.
Always use tools and equipment that is in good working order.
Use lifting and hoisting equipment capable of safely handling load.
Remember, that ultimately safety is your own personal responsibility.
MODEL SERIAL NUMBER RANGE
Solar 130LC-V 0001 and Up
Solar 220LC-V 0001 and Up
Solar 220N-V 1001 and Up
Solar 290LC-V 0001 and Up
Solar 330LC-V 1001 and Up
Solar 400LC-V 1001 and Up

S0102000
Page 2
Track Excavator Safety
TABLE OF CONTENTS
To the Operator of a Daewoo Excavator ........................................................ 3
General Safety Essentials .............................................................................. 5
Location of Safety Labels ............................................................................... 5
Summary of Safety Precautions for Lifting in Digging Mode .......................... 6
Work-site Precautions .................................................................................... 7
Operation........................................................................................................ 9
Equipment .................................................................................................... 14
Maintenance................................................................................................. 18
Shipping and Transportation ........................................................................ 21
Lifting With Sling........................................................................................... 21

S0102000
Page 3
Track Excavator Safety
TO THE OPERATOR OF A DAEWOO EXCAVATOR
Please respect the importance of taking responsibility for your own s afety, and t hat of other pe ople w ho
may be affected by your actions.
The safety information on the following pages is organized into the following sections:
1. “General Safety Essentials” on page 5
2. “Location of Safety Labels” on page 5
3. “Summary of Safety Precautions for Lifting in Digging Mode” on page 6
4. “Work-site Precautions” on page 7
5. “Operation” on page 9
6. “Equipment” on page 14
7. “Maintenance” on page 18
8. “Shipping and Transportation” on page 21
LEARN THE SIGNAL WORDS USED WITH THE SAFETY ALERT SYMBOL
The words "CAUTION", "WARNING", and "DANGER" used throughout this manual and on decals on the
machine indicate degree of risk of hazards or unsafe practices. All three degrees of risk indicate that safety
is involved. Observe precautions indicated whenever you see the Safety Alert "Triangle," no matter which
signal word appears next to the "Exclamation Point" symbol.
DANGER!
Unsafe use of the excavator could lead to serious injury or death. Operating procedures,
maintenance and equipment practices or traveling or shipping methods that do not follow the
safety guidelines on the following pages could cause serious, potentially fatal injuries or
extensive damage to the machine or nearby property.
SAFETY ALERT SYMBOL
Be Prepared - Get To Know All Operating and Safety Instructions.
This is the Safety Alert Symbol. Wherever it appears in this manual or on safety signs on the
machine you should be alert to the potential for personal injury or accidents. Always observe
safety precautions and follow recommended procedures.
CAUTION!
Indicates potential of a hazardous situation that, if not avoided, could result in minor or
moderate injury. It may also be used to alert against a generally unsafe practice.

S0102000
Page 4
Track Excavator Safety
WARNING!
Indicates potential of a hazardous situation that, if not avoided, could result in serious injury or
death. It may also be used to alert against a highly unsafe practice.
DANGER!
Indicates imminent hazard of a situation that, if not avoided, is very likely to cause death or
extremely serious injury. It may also be used to alert against equipment that may explode or
detonate if handled or treated carelessly.

S0102000
Page 5
Track Excavator Safety
GENERAL SAFETY ESSENTIALS
ACCESSORY APPLICATIONS
The excavator has be en pr imarily designed for m oving ear th wi th a bucket. For us e as a gr apple o r for
other obj ect ha ndling, contact Daew oo f or p roper i nstallation and application. Lifting-work appl ications
(unless restricted or prohi bited by local regul ations) are per mitted in approved lift c onfiguration, t o rated
capacity only, with no side-loading. DO NOT use the machine for activities for which it was not intended.
DO NOT use the bucket for lifting work, unless lift slings are used in the approved configuration.
Use of an ac cessory hydraulic hammer (breaker), work in rough terrain, demolition applications or ot her
hazardous operation may require installation of additional protective structures to safeguard the operator.
LIFTING CAPACITY RATING CONFIGURATION
Lifting capacity ratings that are pr inted at the end of this safety section are based on the m achine bei ng
level, on a firm supporting surface, with hooks and slings attached in approved configuration. Loads must
be balanced and s upported e venly. Us e taglines to k eep t he l oad steady if wi nd c onditions an d l arge
surface area are a problem. Work crew hand s ignals, individual tasks and s afe procedures should all be
universally understood before the lift is made.
LOCATION OF SAFETY LABELS
Location of safety l abels (decals) c an vary f rom uni t to uni t. Ref er t o appropriate O peration a nd
Maintenance Manual, and parts manual for your unit.
Always replace damaged or faded decals.
IMPORTANT
Before using the excavator to make lifts check municipal and regional regulations or statutes
that could apply. Governing ordinances may require that all heavy lifting be done with single
purpose equipment specifically designed for making lifts, or other local restrictions may apply.
Making heavy lifts with a general purpose excavator that can be used for digging, loading,
grading or other work may be expressly forbidden by a regional injunction or other legal
prohibition. Always follow all of the other instructions, guidelines and restrictions for Safe
Lifting in the Operation and Maintenance Manuals.

S0102000
Page 6
Track Excavator Safety
SUMMARY OF SAFETY PRECAUTIONS FOR LIFTING
IN DIGGING MODE
To lift safely while in Digging Mode, the following items must be evaluated by the operator and the work-site
crew.
• Condition of ground support
• Excavator configuration and attachments
• Weight, lifting height and lifting radius
• Safe rigging of the load
• Proper handling of the suspended load
Taglines on opposite sides of the load can be very helpful in keeping a suspended load secure, if they are
anchored safely to control points on the ground.
Always engage the "Digging Mode" control on the Instrument Panel before using the excavator for lifting
work.
UNAUTHORIZED MODIFICATIONS
Any modification made without authorization or written approval from Daewoo can create a safety hazard,
for which the machine owner must be held responsible.
For safety’s sake, replace all OEM parts with the correct authorized or genuine Daewoo part. For example,
not taking the time to replace fasteners, bolts or n uts with the correct replacement p arts could lead to a
condition in which the safety of critical assemblies is dangerously compromised.
DANGER!
Unsafe use of the excavator while making rated lifts could cause serious, potentially fatal
injuries or extensive damage to the machine or nearby property. Do not let anyone operate the
machine unless they’ve been properly trained and understand the information in the Operation
and Maintenance Manual.
WARNING!
NEVER wrap a tagline around your hands or body.
NEVER rely on taglines or make rated lifts when wind gusts are in excess of 48.3 km/hr (30 mi/h).
Be prepared for any type of wind gust when working with loads that have a large surface area.
WARNING!
If you need more information or have any questions or concerns about safe operating
procedures or working the excavator correctly in a particular application or in the specific
conditions of your individual operating environment, please consult your local Daewoo
representative.

S0102000
Page 7
Track Excavator Safety
WORK-SITE PRECAUTIONS
ATTACHMENT PRECAUTIONS
Options kits a re a vailable through y our deal er. Co ntact Daew oo f or information on av ailable on e-way
(single-acting) and two-way (double-acting) piping/valving/auxiliary control kits. Because Daewoo cannot
anticipate, identify or test all of the attachments that owners may wish to install on their machines, please
contact Daewoo for authorization and approval of attachments, and their compatibility with options kits.
AVOID HIGH-VOLTAGE CABLES
Serious injury or deat h can result from c ontact
or pro ximity to h igh-voltage electric l ines. T he
bucket does not have to make physical contact
with power lines for current to be transmitted.
Use a s potter and hand s ignals t o stay aw ay
from pow er lines no t c learly v isible t o t he
operator.
Use these minimum distances as a guideline only. Depending upon the voltage in the line and atmospheric
conditions, strong current shocks can occur with the boom or bucket as far away as 4 - 6 m (13 - 20 ft) from
the power line. Very high voltage and rainy weather could further decrease that safety margin.
NOTE:
Before s tarting any type of operation near po wer l ines (ei ther abov e ground or buried
cable-type), you should always contact the power utility directly and work out a safety plan
with them.
BEFORE STARTING TO DIG, CONTACT AUTHORITIES
Below ground hazards also include natural gas lines, water mains, tunnels and buried foundations. Know
what’s underneath the work-site before starting to dig.
BE AWARE OF HEIGHT OBSTACLES
Any type of object in the vicinity of the boom could represent a potential hazard, or cause the operator to
react suddenly and cause an accident. Use a spotter or signal person working near bridges, phone lines,
work-site scaffolds, or other obstructions.
USE CARE ON LOOSE SUPPORT
Working heav y loads over l oose, s oft ground or u neven, broken t errain can c ause da ngerous side load
conditions and possible tipover and injury. Travel without a load or balanced load may also be hazardous.
VOLTAGE MINIMUM SAFE
DISTANCE
6.6kV 3.0 m (9' - 10'')
33.0kV 4.0 m (13' - 1'')
66.0kV 5.0 m (16' - 5'')
154.0kV 8.0 m (26' - 3'')
275.0kV 10.0 m (32' - 10'')
HAOA230L
Figure 1

S0102000
Page 8
Track Excavator Safety
If temperatures are changing, be cautious of dark and wet patches when working or traveling over frozen
ground. S tay away f rom ditches, overhangs and al l other weak support surfaces. Halt wor k an d i nstall
support mats or blocking if work is required in an area of poor track support.
USE SOLID SUPPORT BLOCKING
Never rely on lift jacks or other inadequate supports when work is being done. Block tracks fore and aft to
prevent any movement.
OVERHANGS ARE DANGEROUS
Digging the workface under an overhang – the work area beneath a cliff or under the edge of a ditch – is
dangerous. K now t he hei ght and reac h l imits of t he e xcavator and pl an ahead while wor king. A void
creating dangerous situations by moving around the work-site while making excavations. Go on to another
digging area bef ore s teep ov erhangs are formed. W orking arou nd de ep pi ts or a long high walls or
trenching m ay requ ire s upport b locks, especially af ter heavy rai nfalls or during s pring thaws. P ark t he
excavator away from overhangs before work shutdown.
SLOPING TERRAIN REQUIRES CAUTION
Dig evenly aroun d t he wor k-site whenever
possible, t rying t o g radually l evel any e xisting
slope. I f i t’s not possible t o l evel t he area or
avoid working on a slope, reducing the size and
cycling rate of the workload is recommended.
On s loping s urfaces, us e c aution whe n
positioning the excavator prior to starting a work
cycle. Stay alert for instability situations in order
to avoid g etting i nto t hem. F or e xample, y ou
should a lways a void w orking t he buc ket ov er
downhill c rawler t racks when parked
perpendicular t o the s lope. S low al l downhi ll
swing m ovements an d a void f ull e xtensions of
the b ucket in a downhi ll di rection. L ifting t he
bucket too high, too close to the machine, while
the e xcavator is turned u phill can also b e
hazardous.
HAOA210L
Figure 2

S0102000
Page 9
Track Excavator Safety
STAY ALERT FOR PEOPLE MOVING
THROUGH THE WORK AREA
When l oading a truck you should always know
where the driver is.
Avoid loading over the cab of a truck even if the
driver i s i n a s afe s pot. S omeone el se could
have gone i nside, f or any number of reas ons.
Avoid work ing where uns een pa ssersby m ight
be.
Slow down the work cycle and use slower travel
speeds in congested or populated areas. Use a
commonly u nderstood s ignal s o t hat ot her
members of the w ork crew c an w arn t he
operator t o s low or hal t w ork i n an i mpending
hazard situation.
BE AWARE OF AND CONFORM TO LOCAL
REGULATIONS
Minimum levels of insurance coverage, work permits or certification, physical barriers around the work-site
or restricted hours of operation may be mandated by governing authorities. There may also be guidelines,
standards or restrictions on equ ipment t hat m ay be us ed to pe rform certain k inds of wor k. Check a nd
follow all local requirements, which may also be related to below ground hazards and power lines.
OPERATION
OPERATE WHILE SEATED AT THE
OPERATOR’S STATION ONLY
Never reach in t hrough a wi ndow t o w ork a
control. Do not operat e the e xcavator unless
you’re i n t he c ommand pos ition stay al ert and
focused o n your work at all t imes but DO NOT
twist out of the seat if job activity behind you (or
to the side) requires your attention.
Use a s potter or s ignal person if you can’t see
clearly and something is happening behind you.
Replace dam aged s afety l abels an d l ost or
damaged owner’s manuals.
Do not let anyone operat e t he m achine unless
they’ve been f ully and c ompletely t rained, in
safety and in the operation of the machine.
BEFORE STARTING THE ENGINE
Do a "pre-start" safety check:
HAOA170L
Figure 3
HAOA150L
Figure 4

S0102000
Page 10
Track Excavator Safety
• Walk around your m achine before get ting in the operator’s c ab. Look for evidence of l eaking
fluid, l oose f asteners, m isaligned as semblies or any ot her i ndications of p ossible e quipment
hazard.
• All equipment covers and machinery safety gua rds must be in place, to protect against injury
while the machine is being operated.
• Look around the work-site area for potential hazards, or people or property that could be at risk
while operation is in progress.
• NEVER s tart the engi ne if t here is any i ndication t hat m aintenance or service work i s in
progress, or if a warning tag is attached to controls in the cab.
• A machine that has not been used recently, or is being operated in extremely cold temperatures,
could require a warm-up or maintenance service prior to start-up.
• Check gauges and monitor displays for normal operation prior to starting the engine. Listen for
unusual no ises and rem ain alert for other pot entially h azardous c onditions at t he s tart of t he
work cycle.
NEVER USE ETHER STARTING AIDS
An electric-grid type manifold heater is used for
cold s tarting. T he gl owing heat er el ement c an
cause et her or ot her s tarting f luid t o det onate,
causing injury.
MOUNTING AND DISMOUNTING
NEVER get on or off a moving machine. Do not
jump o n/off. T he entry/egress pat h s hould b e
clear o f mu d, o il a nd s pills a nd mo unting
hardware must be kept tight and secure.
Always use handholds, steps or track shoes and
maintain at l east 3-poi nt c ontact of hand s an d
feet. Never use controls as handholds.
NEVER get up from the operator’s seat or leave
the operator’s station and dismount the machine
if the engine is running.
OBSERVE GENERAL SAFETY RULES
Only trained and authorized personnel, with a good knowledge and awareness of safe procedures, may be
allowed to operate or perform maintenance or service on the excavator.
All personnel at t he w ork-site should be aware of as signed i ndividual r esponsibilities and t asks.
Communication and hand signals used should be understood by everyone.
Figure 5
Figure 6

S0102000
Page 11
Track Excavator Safety
Terrain and s oil conditions at the job site, approaching traffic, weather-related hazards and an y above or
below ground obstacles or hazards should be observed and monitored by all work crew members.
ENGINE VENTILATION
Engine exhaust gases c an c ause f atal
accidents, as well as u nconsciousness, l oss of
alertness, judgement an d m otor control an d
serious injury.
Make s ure of ad equate v entilation bef ore
starting the engine in any enclosed area.
You s hould al so be a ware of open wi ndows,
doors or ductwork into whi ch e xhaust may b e
carried, or blown by the wind, exposing others to
danger.
ASBESTOS DUST HAZARD PREVENTION
Asbestos dust can be HAZARDOUS to your health if it is inhaled.
If you handle materials containing asbestos fibers, follow these guidelines as given below:
• Never use compressed air for cleaning
• Use water for cleaning to keep down the dust.
• Work on the machine or component with the wind at your back whenever possible.
• Use an approved respirator with proper filtration.
TAKE TIME TO PROVIDE GOOD VISIBILITY
Halt work if visibility is poor. Strong rains, snow, fog and extremely dusty conditions can all obscure visibility
so badly that it is best to wait for weather to change or dust to settle before continuing operation.
Night work in areas of limited visibility should be halted if installation of extra work lights on the machine (or
work area) is necessary.
Keep dirt and dust off of windows and off the lens surfaces of work lights. Stop working if lights, windows or
mirrors need cleaning or adjustment.
,,,
,,,






HAOA070L
Figure 7

S0102000
Page 12
Track Excavator Safety
FUEL, OIL AND HYDRAULIC FLUID FIRE
HAZARDS
Add fuel, oil, antifreeze and hydraulic fluid to the
machine only in a well v entilated are a. The
machine must b e p arked wi th controls, lights
and switches turned off. The engine must be off
and a ny f lames, gl owing em bers, aux iliary
heating un its or s park-causing equipment must
be doused, t urned of f and /or kept wel l c lear of
the machine.
Static electricity can produce dangerous sparks
at t he f uel f illing n ozzle. I n v ery c old, d ry
weather or other conditions t hat could produce
static discharge, keep the tip of the fuel nozzle
in c onstant c ontact wi th t he nec k of t he f uel
filling nozzle, to provide a ground.
Keep f uel and other f luid reservoir c aps t ight
and do not start the engine until caps have been
secured.
BOOST STARTING OR CHARGING ENGINE
BATTERIES
Turn of f all el ectrical equi pment bef ore
connecting l eads t o the bat tery. T his i ncludes
electrical s witches o n t he bat tery c harger or
boost starting equipment.
When boost-starting f rom anot her m achine or
vehicle do not allow the two machines to touch.
Wear s afety gl asses or goggles whi le requi red
parallel bat tery c onnections – p ositive t o
positive and negative to negative – are made.
24 v olt ba ttery uni ts c onsisting of two s eries-
connected twelve volt ba tteries hav e a cable
connecting one pos itive terminal on one of t he
12 volt batteries to a negative terminal on the other battery. Booster or charger cable connections must be
made bet ween the non -series-connected pos itive t erminals and bet ween t he negative t erminal of t he
booster battery and the metal frame of the machine being boosted or charged. Refer to the procedure and
illustration in Operation and Maintenance Manual.
Connect positive cable first when installing cables and disconnect the negative cable first when removing
them. The final cable connection, at the metal frame of the machine being charged or boost-started, should
be as far away from the batteries as possible.
TRAVEL CONTROLS MAY PRODUCE REVERSED OPERATIONS
Before s tarting t he m achine you should al ways c heck t o s ee which e nd of t he t rack frame is und er the
operator’s cab. In the normal travel configuration, track frame travel motors are at the rear of the machine,
under the engine and counterweight. If the operator swings the cab 180°, travel motors will be underneath
the operator’s cab, toward the front of the track frame and operating travel will be reversed.
When traveling the excavator always keep lights on; make sure that you are i n compliance with all state
and local regulations concerning warning flags and signs and keep the operator’s cab positioned over the
HAOA120L
Figure 8
HAOA310L
Figure 9

S0102000
Page 13
Track Excavator Safety
idler end of the track frame. That will keep travel controls in their intended configuration and a t the same
time, maintain the proper orientation of lights on the machine and posted flags and signs.
KEEP "PINCH POINT" AREAS CLEAR - USE
CAUTION IN REVERSE & SWING
Use a signal pers on i n hi gh traffic areas and
whenever the operator’s v iew is not clear, s uch
as when traveling in reverse. Make sure that no
one c omes inside t he s wing r adius of t he
machine.
Anyone standing near t he track f rames, or
working assemblies of the attachment, is at risk
of be ing c aught bet ween m oving pa rts of t he
machine.
Never al low any one t o r ide o n any p art of t he
machine or attachment, including any part of the
turntable or operator’s cab.
TRAVEL PRECAUTIONS
Attachment control levers should not be operated while traveling.
Do not change selected travel mode (FAST/SLOW) while traveling.
Fold in work equipment so that the outer end of the boom is as close to the machine as possible, and is
203 mm – 304 mm (8" – 12") above ground.
Never travel over obstacles or slopes that will cause the machine to tilt severely. Travel around any slope or
obstacle that causes 10 degrees tilt, or more.
OPERATE CAREFULLY ON SNOW AND ICE AND IN VERY COLD TEMPERATURES
In i cy c old w eather av oid s udden t ravel m ovements and s tay a way f rom e ven v ery s light s lopes. T he
machine could skid off to one side very easily.
Snow accumulation could hide or ob scure potential hazards. Use care while operating or whi le using the
machine to clear snow.
Warming up the engine for a short period may be necessary, to avoid operating with sluggish or reduced
working capacity. T he j olting s hocks and i mpact l oads c aused b y bum ping or bot toming t he bo om or
attachment are more likely to cause severe stress in very cold temperatures. Reducing work cycle rate and
work load may be necessary.
PARKING THE MACHINE
Avoid making sudden stops, or parking the machine wherever it happens to be at the end of the work day.
Plan ahead so that the excavator will be on a firm, level surface away from traffic and away from high walls,
cliff e dges and a ny a rea o f p otential w ater a ccumulation o r r unoff. I f p arking o n inclines i s unavoidable,
block the crawler tracks to prevent movement. Lower the bucket or other working attachment completely to
the ground, or to an overnight support saddle. There should be no possibility of unintended or accidental
movement.
HAOA190L
Figure 10

S0102000
Page 14
Track Excavator Safety
SHUTDOWN CONTROL FUNCTIONS
After t he m achine has bee n l owered t o t he ov ernight s torage pos ition and al l s witches and operat ing
controls are in the OFF position, the control stand lock lever must be engaged. Release the left console to
disable all pilot circuit control functions.
Insert the swing l ock pin and eng age al l brakes and l ock-down s ecurity eq uipment that may have be en
installed on the machine.
EQUIPMENT
ROUGH OPERATION MAY REQUIRE USE OF
CERTIFIED SAFETY EQUIPMENT
Working in mines, tunnels, deep pits or on loose
or wet surfaces could produce danger o f falling
rock or haz ardous f lying objects. A dditional
protection f or t he operator’s cab c ould b e
required i n t he form of a F OG / Falling O bject
Guard or windows guards.
Any r einforcement s ystem t hat is i nstalled on
the m achine m ust pass safety an d certification
standards and c arry appropr iate l abeling an d
rating information. For example, the most often
added type of reinforcement system, FOG, must
meet or e xceed I nternational S tandard
ISO10262, Laborat ory Tests an d P erformance
Requirements Earth-Moving Machinery.
Never attempt t o alter or m odify any t ype of
protective structure re inforcement syst em, by
drilling holes, w elding, r emounting or relocating
fasteners. Any serious impact or damage to the
system requi res a c omplete i ntegrity
reevaluation. Rei nstallation, rec ertification and/
or repl acement of t he s ystem m ay b e
necessary.
IMPORTANT
When hydraulic system maintenance or service work must be performed, you should be aware
that an accumulator in the system stores fluid under pressure after system lock down, even after
the control stand is raised. Release this energy by working controls with the engine off, until
pressure in the pilot circuit has been completely bled away.
HAOA110L
Figure 11
HAOA100L
Figure 12

S0102000
Page 15
Track Excavator Safety
INSTALL ADDITIONAL SAFETY EQUIPMENT IF CONDITIONS REQUIRE
When working with a breaker or in some shear work applications, a front guard over the windshield may be
required. The windshield guard may or may not be OPS/certified, depending upon the specific application
and working situation.
Laminate glass protection for the front, side or rear windows may also be recommended depending upon
particular site conditions.
Contact your Daewoo distributor for available safety guards and/or recommendations if there is any danger
of getting hi t b y o bjects that c ould s trike the operator’s c ab. M ake s ure t hat al l other w ork-site c rew
members are kept well away from the excavator and safe from potential hazards.
MOVEMENT ALARMS
If t he e xcavator i s equi pped wi th an audi ble t ravel m ovement al arm or v isible s wing m ovement al arm
(strobe light), test the alarm on a daily basis. The audible alarm should sound as soon as the travel system
is engaged. The strobe light should begin to flash as soon as the swing system is engaged.
SEAT BELTS SHOULD BE USED AT ALL
TIMES
Whenever t he e ngine is run ning, t he ope rator
should be seated at the control station with the
seat belt properly engaged.
WINDOW GLASS BREAKING TOOL
This excavator is equipped with a glass breaking
tool. It is located behind the operator seat in the
upper ri ght c orner of t he cab. T his tool c an be
used i n c ase of an em ergency s ituation wh ich
requires t he b reaking o f gl ass t o exit f rom t he
operator’s cabin. Grip the handle firmly and use
the sharp point to break the glass.
Figure 13
Figure 14
