Daewoo SDA1685 User manual

1
1.7L 3KW Kettle Kensington Red
Model No. SDA1685
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

2
1.7L 3KW Kettle Kensington Red
Model No. SDA1685
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should always
be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
Read and familiarise yourself with all operating instructions before
using this Kettle.
Before plugging your kettle into the mains, visually check that the kettle
is intact and has not suffered any transit damage.
Check that the voltage indicated on the data plate corresponds with
that of the local network before connecting the appliance to the mains
power supply.
This kettle is only to be used with the stand provided.
Close supervision is required when using this appliance near children.
Never leave this appliance within reach of children.
This appliance can be used by children aged from 8 years and above if
they have been given supervision or instruction concerning use if the
appliance in a safe way and if they understand the hazards involved.
Cleaning and user maintenance shall not be made by children unless
they are older than 8 and supervised. Keep the appliance and its cord
out of reach of children aged less than 8 years. This appliance can be
used by persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not play with the
appliance.
Do not leave the appliance unattended during use.
Do not leave the appliance unattended whilst connected to the mains
supply.

3
1.7L 3KW Kettle Kensington Red
Model No. SDA1685
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Always use this appliance on a solid, level, non-flammable surface.
Do not use this appliance outdoors.
It is imperative to unplug the power cord after the appliance has been
used, before it is cleaned and whilst being repaired.
If the supply cord is damaged, it must be replaced by the manufacturer,
service agent or similarly qualified person in order to avoid hazard.
Repairs to electrical appliances should only be performed by qualified
personnel. Improper repairs may place user at serious risk.
Do not operate this appliance with a damaged plug or cord, after a
malfunction or after being dropped or damaged in any way.
Regular, periodic checks should be carried out on the mains cable to
ensure no damage is evident. Should there be any signs of damage the
appliance should not be used.
Do not allow the mains cable to hang over sharp edges or come in
contact with hot surfaces.
Do not run the mains cable under carpets, rugs, etc.
Allow the unit to cool before storage.
Never place the appliance near to flammable material or high-pressure
containers.
This appliance is intended for household use only and should not be
used for industrial purposes.
Do not use any accessories or attachments with this appliance other
than those supplied or recommended by supplier.
Do not immerse the appliance, base or its cord in water or any other
liquids.
Do not use this appliance for anything other than its intended use.
Do not push objects into any openings as damage to the appliance
and/or electric shock may occur.
Ensure appliance is situated in an open area, do not allow it to come in
contact with cupboards, curtains, wall coverings, clothing or other
flammable materials.
Unplug after each use. Grasp the plug, not the cord.
Do not cover this appliance.
Never place this appliance on an electric, gas, or any other type of hob.
WARNING: Do not open lid whilst the water is boiling.
Never fill the kettle more than its capacity –ensure the water level is
between the min and max marks. If the kettle is overfilled, boiling
water may be ejected.

4
1.7L 3KW Kettle Kensington Red
Model No. SDA1685
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Always close the lid during use and do not open the lid whilst the water
is boiling.
CAUTION: The outside surface of the kettle will get hot during use.
Ensure the kettle has switched off before removing it from the base.
Please note, due to this being a rapid boil kettle it is recommended that
you don’t use this in conjunction with any other appliances on a multi
socket extension lead.
THIS APPLIANCE MUST BE EARTHED

5
1.7L 3KW Kettle Kensington Red
Model No. SDA1685
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste and sent to landfill.
Please ensure it is taken to a suitable facility for disposal. Check
with your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
WARNING!
This designates a hazard with moderate risk, which may result in
severe injury if not adhered to.

6
1.7L 3KW Kettle Kensington Red
Model No. SDA1685
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of parts
Before the first time you use your kettle
Before using the kettle for the first time, fill to the max mark and allow the water
to boil. Pour away the boiled water and then repeat the process. If a slight taste or
odour remains repeat the above process once more.
Using Your Kensington Kettle
1. Spout
2. Filter (Inside)
3. Lid
4. Lid Release Button
5. Handle
6. Water Gauge
7. On Off Switch
8. Base
1
Place the kettle Base (8) on a
flat, level, non-flammable
surface.
Ensure that the kettle is
disconnected from the
mains supply.
2
3
4
8
8
6
5
1
2
7

7
1.7L 3KW Kettle Kensington Red
Model No. SDA1685
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Fill the kettle to the desired level on
the Water Gauge (6) ensuring that it is
above the MIN mark and below the
MAX mark.
WARNING! Do not overfill the
kettle above the MAX mark as this will
risk boil over and may damage the
appliance.

To Fill the Kettle, lift the Lid (3)
by pressing the Lid Release
Catch (4).

Replace the Lid (3) after filling
until it clicks into place.
Insert the mains plug
(with dry hands) into the
mains socket.

3
4
5

8
1.7L 3KW Kettle Kensington Red
Model No. SDA1685
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Boil dry protection
Should you accidentally let the appliance operate without water; the boil-dry
protection will automatically switch off the power. If this occurs, allow the
appliance to cool and reset before use.
Important –Descaling your Kensington Kettle/Reducing Limescale Build up
To prolong the life of your kettle it is imperative that it is descaled regularly.
The frequency of the descaling depends on the hardness of the water in your
area and how often the appliance is used.
In extreme hard water areas, descaling your kettle at least once a month is
highly recommended also the use of filtered water in your kettle will increase
the life expectancy and help prevent excessive lime scale build up.
If the kettle switches off before it boils or has a white deposit building up inside
then it will need to be descaled.
Do not use vinegar but a commercially available descaling agent; carefully
follow the quantities recommended in the instructions of the agent:
Push the On Off Switch (7) down which
will illuminate and the water will begin
to boil.
At the end of the boiling cycle the On Off
Switch (7) will automatically switch off
(pop up).
Wait until the water has finished boiling
before removing the kettle from the
Base (8).
Fill your kettle to the ‘MAX’ mark on the
body or the water quantity
recommended by the descaling product.
Add a descaling agent to the kettle
according to the descaling products
instructions.
6
1
2

9
1.7L 3KW Kettle Kensington Red
Model No. SDA1685
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Replacing the Filter (2)
Care and Use of Your Kettle
Ensure the mains plug is removed from the socket outlet before cleaning.
Do not immerse the kettle or the base in water or any other liquids.
Wipe the kettle clean with a clean damp cloth.
Do not use harsh or abrasive scouring pads, powders or cleaners.
Do not clean any part of the kettle in a dishwasher.
Allow the kettle to boil, switch off and then stand to allow the kettle
to soak for approximately 15 –20 minutes, (if necessary, adjust the
standing time to the descaling products instructions).
Finally, empty the kettle and refill with fresh clean water and allow
to come to the boil and switch off once more, then again pour the
water away. Your kettle is now descaled and cleaned.
The Filter (2) is located inside the kettle
behind the Spout (1) and is accessible
from inside the kettle when the Lid (3)
is raised.
Lift the Lid (3) using the Lid Release
Catch (4). Pull out the Filter (2)
upwards as shown left.
Replace the Filter (2) by pushing it back
inside the kettle behind the Spout (1)
and then replace the Lid (3).
Filter
3
4

10
1.7L 3KW Kettle Kensington Red
Model No. SDA1685
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Troubleshooting Guide
Problem
Possible Cause
Possible Fix
Kettle not boiling
On Off Switch is not
pressed down.
Press the On Off Switch (7) down.
Plug not inserted into the
mains socket and/or not
switched on.
Ensure the mains plug is plugged
into the mains socket and the socket
is switched on.
Kettle not seated on the
base correctly.
Ensure the Kettle is seated correctly
on the base (8).
Fuse blown in plug.
Check fuse by substitution.
Kettle switches off
before boiling.
Not enough water in the
Kettle.
Ensure the Kettle is filled with
sufficient water and the water level
is above the ‘MIN’ mark on the
Water Gauge (6).
Kettle requires descaling.
Follow ‘Descaling your Kensington
Kettle’ above.
Kettle boils over.
Kettle is overfilled.
Ensure that the Kettle is not filled
above the ‘MAX’ mark on the Water
Gauge (6).
Non-Wireable Mains Plug
If your appliance is supplied with a non-wireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). If in doubt, consult a qualified
electrician who will be pleased to do this for you. If you need to remove the plug
–DISCONNECT FROM THE MAINS –and then cut it off the mains lead and
immediately dispose of it safely. Never attempt to reuse the plug or insert it into
a socket outlet as there is a danger of electric shock.
Technical Data
Model Number
SDA1685
Rated Voltage
220-240V AC ~ 50/60Hz
Rated Power
3000W
Protection Class
I (This appliance must be Earthed)
Capacity
1.7 Litre

11
1.7L 3KW Kettle Kensington Red
Model No. SDA1685
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
• The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
• Theproduct must be used solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
ESG Ltd. Manchester M3 1JS
EU Rep: Euromagpie Ireland Ltd. DO5 X006
www.esgltd.com
