Service Manual
COLOR TELEVISION
CHASSIS : CM-907/F
MODEL : DTC-29M5ME/MP/MT/MZ
DTC-29U1ME/MP/MT/MZ
DTC-29U5ME/MP/MT/MZ
KR29M5-ME/MP/MT/MZ
MODEL TEXT PIP
ME O O
MP X O
MT O X
MZ X X
MODEL OPTION LIST
S/M No : TCM907FEF0

-1-
1. SPECIFICATIONS 2
2. SAFETY INSTRUCTION 3
3. CIRCUIT BLOCK DIAGRAM 4
4. ALIGNMENT INSTRUCTIONS 5
5. CM-907 TYPICAL SERVICE DATA 11
6. ELECTRICAL PARTS LIST 12
7. EACH MODEL PARTS LIST 19
8. SCHEMATIC DIAGRAM 20
9. PRINTED CIRCUIT BOARD 21
10. MECHANICAL EXPLODED VIEW AND PARTS LIST 24
11. IC DESCRIPTION 27
12. TROUBLE SHOOTING CHARTS 44
T
TABLE OF CONTENTS ABLE OF CONTENTS
APPENDIX (“Appendix is provided only by internet [http://svc.dwe.co.kr]”)
APPENDIX (“Appendix is provided only by internet [http://svc.dwe.co.kr]”)

-2-
1. SPECIFICATIONS
Items Model DTC-29M5ME/MP/MT/MZ
DTC-29U1ME/MP/MT/MZ
DTC-29U5ME/MP/MT/MZ
KR29M5-ME/MP/MT/MZ
TV Standard Color system PAL/SECAM, NTSC-4.43(AV)
Sound system B/G, D/K, I
Rated Voltage AC 100~250V, 50/60Hz
Power consumption NOMAL : 130W, FLAT : 135W
Sound Output Power 7W+7W
VHF-L : IC1-S6CH (43.25MHz~140.25MHz)
Channel Coverage VHF-H : IC1-S36CH (147.25MHz~423.25MHz)
UHF : S37-C57CH(431.25MHz~863.25MHz)
Tuning System FS Tuning System
Program No. Indication ON-Screen Display
Program Selection 100 Programs
Aux. Terminal AV input 1< RCA : Input, Scart (Option) : Input, Output >
AV Input 2 < SIDE >
DVD1, DVD2
AV OUTPUT < TV Signal >
Remote Control Unit R44C07
Screen size 67.6Cm

BEFORE SERVICING THIS CHASSIS READ THE “X-RAY RADIATION PRECAUTIONS”,
“SAFETY PRECAUTIONS” AND “PRODUCT SAFETY NOTICE” BELOW.
-3-
2. SAFETY INSTRUCTION
NOTE
X-RAY RADIATION PRECAUTIONS
SAFETY PRECAUTIONS
PRODUCT SAFETY
1. Excessive high voltage can produce potentially hazard-
ous X-RAY RADIATION. To avoid such hazards, the
high voltage must not exceed the specified limit. The
nominal value of the high voltage of this receiver is
25kV(21”) at max beam current. The high voltage must
not, under any circumstances, exceed 27kV(21”). Each
time a receiver requires servicing, the high volt-age
should be checked. It is recommended the reading
of the high voltage recorded as a part of the service
recorded as a part of the service records. It is important
to use an accurate and reliable high voltage meter.
2. The only source of X-RAY RADIATION in this TV
receiver is the picture tube. For continuous RADIATION
protection, the replacement tube must be exactly the
same type tube as specified in the “PART LIST”.
1. Potentials of high voltage are present when this receiver
is operating. Operation of the receiver outside the
cabinet or with the back cover removed involves a
shock hazard from the receiver.
1) Servicing should not be attempted by anyone who is not
thoroughly familiar with the precautions necessary
when working on high voltage equipment.
2) Always discharge the picture tube to avoid the shock
harzard before removing the anode cap.
3) Discharge the high potential of the picture tube before
handling the tube. The picture tube is highly evacuated
and if broken, glass fragments will be violently
expelled.
2. If any FUSE in this TV receiver is blown, replace it will
the FUSE specified in the “PART LIST”.
3. When replacing a high wattage resistor (oxide metal
film resistor) in circuit board, keep the resistor 10mm
away from circuit board.
4. Keep wires away from high voltage or high temperature
components.
5. This receiver must operate between AC 100-240
volts,50/60Hz. NEVER connect to DC supply or any
other power or frequency.
Many electrical and mechanical parts in this chassis have
special safety-related characteristics.
These characteristics are often passed unnoticed by a
visual inspection and the X-RAY RADIATION protection
afforded by them cannot necessarily be obtained by using
replacement components rated for higher voltage, wattage,
etc.
Replacement parts which have these special safety char-
acteristics are identified in this manual and its supple-
ments, electrical components having such features are
identified by designated symbol on the “PART LIST”.
Before replacing any of these components, read the
“PARTLIST” in this manual carefully.
The use of substitute replacement part which do not have
the same safety characteristics as specified in the “PART
LIST” may created X-RAY RADIATION.

-4-
3. CIRCUIT BLOCK DIAGRAM

-5-
4. ALIGNMENT INSTRUCTIONS
1. SERVICE REMOCON & EEPROM PRESETTING DATA
1-1. SERVICE REMOCON : R-34SVC (S/N:48B3034SVC)
1-2. EEPROM PRESETTING DATA
KEY Name Details BARE NORMAL FLAT WIDE remark
PAL NTSC NT=PAL+xxx PAL NTSC PAL NTSC
S1 Heat-Run - - -
S2 Screen - - -
S3 Sound Test - - -
S4 Picture Test - - -
S5 BCL BCL THR - 200 180
BCL GAIN 12 12
WHITE PEAK ON ON
S6 Geometry V-CENTER 3930 3952 182 4170 3550 ADJUST DATA
V-SIZE 121 120 -1 147 152 164 169 ADJUST DATA
H-CENTER 82 83 1 86 88 ADJUST DATA
H-SIZE -160 -294 -134 560 410 950 800 ADJUST DATA
PARABOLA -160 -158 2 -92 -140 -71 ADJUST DATA
EW TRAPEZ 36 -3 -39 66 41
CORNER 120 120 0 90 55
H BOW 143 140 -3 -277 -2
H PARALL -2 -2 0 20 10 ADJUST DATA
V LINEAR -3 -5 +2 1 3
S CORRECT -27 -27 0 -22 -32
S7 PIP P H POS 29 33 33
P V POS 9 27 27
P R/G/B Peak 150/150/150 85/85/85 85/85/85
P CONT 04 10 10
P BRIGHT 01 15 15
S8 WHITE R/G/B DRIVE 170/170/170 195/195/195 175/175/175
BALANCE R/G/B BIAS 40/40/40 80/80/80 80/80/80
S9 SUB BRI BRM 140 140 140 For SUB-Bright Adjust Reference
S10 NORMAL BRIGHT 32 32 32
DATA CONTRAST 58 63 63
COLOR 32 32 32
SHARPNESS 48 48 48
S11 OPTION PIP ME/MP:ON, MZ/MT:OFF
DIGIT.EYE ON ON OFF
TEXT SEL.
TELETEXT ME/MT:ON, MZ/MP:OFF
LARGE OFF ON ON
VID FRAME OFF ON ON
HOTEL VOL +00000 +00000 +00000
HOTELMODE OFF OFF OFF
S12 Shipping - - -
SVC Main Menu CONT 32 32 32
IBRM 140 30 30 For Screen Adjust Reference

-6-
ALIGNMENT INSTRUCTIONS
SVC KEY EXPLAIN
(S5) BCL THD : MAX BEAM CURRENT ADJUST,DIFFERENT DATA FOR INCH.
BCL GAIN : AVERAGE BEAM ADJUST.
(S6) GEOMETRY : PAL (50Hz) adjust.
AV NTSC is auto correction.
(S10) NORMAL : PICTURE NORMAL data setting.
(SLEEP) : TXT CHECK ON LINE
(SIZE) : GAME FUNCTION CHECK ON LINE
(S11) OPTION
- HOTEL VOLUME : HOTEL MODE MAX VOL DATA SETTING
- HOTEL MODE OFF : ON--> VOL MAX SET& INSTALL DONT OPERATING
* Software option for Function Change
PIP (ON) - ON : With PIP Models (xxxxME/MP seiese)
- OFF : Without PIP Models (xxxxMT/MZ seriese)
Digital EYE (ON) - ON : Enable the Digital Sensor (DTC-29M5xx, KR29M5-xx)
- OFF : Disable the Digital Sensor (DTC-29U1xx, DTC-29U5xx)
LARGE (OFF) - ON : For 29 inch Models CM-907/F
- OFF : For 14~21 inch Models CM-907S
LATIN : English,French,Swedish,Czech,German,Spanish,Italian,Estonian
EAST: English,Slovakian,Hungarian,Serbian,Albanian,Polish,Turkian,Rumanian
RUSSIA : English,Russian,Bulgaian,Ukrainian,Serbian,Montenegro
TEXT sel. (OFF) PERSIAN : English,Farsi
ARAB : English,Arabic
OFF : Teletext Language depends on OSD Language selection
Note : If OSD language & text selec. is different then Teletext depends on Text selec.
2.The confirmation of Protection circuit
Protection circuit confirmation is omitted in case of mass production in the factory
2-1. Over Current Protecor (OCP) circuit confirmation
2-1-1. Receive PAL RETMA PATTERN(signal of company:2CH., PAL-B) and adjust
STANDARD MODE in PICTURE.
2-1-2. Connect 1M 1/2W between BASE of Q801 and GND, to confirm operating of
PROTECTOR.
The next place, to confirm normal operation when the resister(1M ) is removed.
2-1-3. After Main Power Switch OFF/ON, to confirm normal operation of picture and sound
when turn the set on by remocon.

-7-
ALIGNMENT INSTRUCTIONS
3.The adjustment of SCREEN
3-1. Confirm the presetting IBRM data of EEPROM according to CRT.
3-2. Press the [S2] KEY of SVC Remocon, horizontal line will be displayed.
3-3. Adjust SCREEN V/R of FBT so that the horizontal line reach the cut-off point.
3-4 To be completed adjustment of screen. Press the [S2] key to escape screen adjustment mode.
4.The adjustment of FOCUS
4-1. Receive PAL RETMA PATTERN(signal of company:2CH., PAL-B).
4-2. Adjust the picture to best distinct picture of 350 Line by revolve Focus Volume.
5.The adjustment of WHITE BALANCE
5-1. NITSUKI Setting : Set Nitsuki to the Auto Mode , Reference to the B, and System to the PAL .
5-2. Setting the Normal Stats
5-2-1. Adjust Picture to Normal mode.
5-2-2. Adjust the Gain of Nitsuki to suitability by manual when condition is Normal.
- Adjust the standard illumination take within limit bright of Nitsuki and luminosity
of SET into acount.
- Exhortative Standard illumination, : High 70Cd/ , LOW BEAM : about 15Cd/
5-2-3. Press the [S8]key of SVC remocon to adjustment of Whit Balance.
X=0.288, Y=0.301
5-2-4. Memorize in Nitsuki after Adjustment of White Balance.
5-3. Adjustment of White Balance
5-3-1.Receive Nitsuki signal.
5-3-2.Adjust Picture to Normal mode.
5-3-3.The Adjustment of High Beam : Adjust R-DRIVE and G-DRIVE to R,G,B BAR come to center.
5-3-4.The Adjustment of Low Beam : Adjust R-BIAS and G-BIAS to R,G,B BAR come to center.
5-3-5.Repeat 5-3-3 and 5-3-4 to R,G,B BAR come to within center 1.
6.The adjustment of GEOMETRY
6-1. Press the [S-6]key on the SVC remocon to call up the Geometry mode.
And then, Geometry OSD will be displayed.
6-1-1. All adjustment is base on PAL(50Hz),
but it can be base on NTSC(60Hz) in case of need.
6-2. The adjustment of VERTICAL CENTER
6-2-1.Receive PAL RETMA pattern(signal of company:PAL-B 2CH).
6-2-2.Press the PR up/down Keys( ) to select V CENTER.
Adjust with Vol Up/Down ( ) keys so that the center mark of the CRT may be located on
the horizontal line in the middle of the pattern. In case of no center mark, adjust with
Vol Up/Down ( ) keys to obtain a vertically symmetrical pattern.

-8-
ALIGNMENT INSTRUCTIONS
6-3. The adjustment of VERTICAL SIZE
6-3-1. Receive PAL RETMA pattern(signal of company:PAL-B 2CH).
6-3-2. Press the PR up/down Keys to select V-SIZE.
Adjust with Vol Up/Down ( /) keys so that the upper and the lower of RETMA
pattern may be located at the boundaries of the screen.
6-4. The adjustment of HORIZONTAL CENTER
6-4-1. Receive PAL RETMA pattern(signal of company:PAL-B 2CH).
6-4-2. Press the PR up/down Keys ( /) to select V-SIZE.
Referring to the both side scales, adjust with Vol Up/Down ( / ) keys
so that RETMA pattern may be symmetrical.
6-5. The adjustment of Vertical Linearity
6-5-1. Receive PAL CROSSHATCH pattern(signal of company:PAL-B 5CH).
6-5-2. Fix adjustment of Vertical Linearity after EEPROM presetting,
but it can be adjusted in case of need.
6-5-3. Press the PR up/down Keys ( /) to select V LINEAR.
Adjust Vertical Linearity with Vol Up/Down ( / ) keys.
6-6. The adjustment of VERTICAL S-Correction
6-6-1. Receive PAL CROSSHATCH pattern(signal of company:PAL-B 5CH).
6-6-2. Fix adjustment of Vertical S-Correction after EEPROM DATA presetting,
but it can be adjusted in case of need.
6-6-3. Press the PR up/down Keys ( /) to select S CORRECT.
Adjust S-Corrction with Vol Up/Down ( / ) keys.

-9-
ALIGNMENT INSTRUCTIONS
7. THE ADJUSTMENT OF SUB-PICTURE (SUB-BRIGHT,SUB-CONTRAST)
7-1. Receive PAL RETMA PATTERN(signal of company:2CH., PAL-B)
7-2. Press the [S9] KEY of SVC Remocon, BRM OSD wil be displayed.
7-3. The adjustment of SUB-BRIGHT
7-3-1. Press the PR up/down Keys ( /) to select SUB-BRIGHT in SUB-PICTURE MENU.
Adjust SUB-BRIGHT with Vol Up/Down ( / ) keys.
7-3-2. Adjust With BRM, When SUB-BRIGHT is lacking in margin of adjustment.
7-3-3. Standard of adjustment : Adjust till instant of 1, 2th cordon disappear in
RETMA CONTRAST CHART(signal of company).
7-3-4. When Sub-Picture mode was exited after SUB s adjustment, Normal vlaue is
brighter(about 18%) than adjustment-point(about 10%) of adjustment-mode because
BRIGHT is set to rise 2~3 step.
8. THE ADJUSTMENT OF PIP
8-1. Receive PAL RETMA pattern(signal of company:PAL-B 2CH) and Color Bar.
8-2. Press the [S7] KEY of SVC Remocon, PIP-Adjustment OSD wil be displayed.
8-3. Fix adjustment of PIP after EEPROM DATA presetting,
but it can be adjusted in case of need.
8-4. Adjust PIP after GEOMETRY, WHITE BALANCE and SUB-BRIGHT are adjusted.
8-5. List of adjustment
PIP H POSITON : Adjustment of H-position Sub-Picture,
(Reference : Presetting Value of EEPROM = 38)
PIP V POSITON : Adjustment of V-position of Sub-Picture,
(Reference : Presetting Value of EEPROM = 27)
PIP R/G/B Peak : Adjustment of Gain of PIP IC R,G,B Output
(Reference : Presetting Value of EEPROM = 85)
P CONTRAST : Adjustment of AC Gain(Contrast) of PIP IC RGB Output
(Reference : Presetting Value of EEPROM = 10)
P BRIGHT : Adjustment of DC Level(SUB BRIGHT) of PIP IC RGB Output
(Reference : Presetting Value of EEPROM = 15)

-10-
ALIGNMENT INSTRUCTIONS
9. REMOCON
9-1. SERVICE REMOCON 9-2. USER REMOCON
9-3. SERVICE REMOCON
1) Enter SERVICE MODE : Press keys of User Remocon, as follows.
Ch91, Sharpness 0, Skip(red), Move(green), Menu.
2) Choice SERVICE MENU : Pr-Up/Down
3) Enter SERVICE SUB MENU : Vol-Up/Down
S1 S2 S3
S4 S5 S6
S7 S8 S9
S11
RECALL
S10 S12
MUTE POWER
TV/CATV
ADD/ERASE
TV/VIDEO
SOUND MODE
SURROUND
NOISECLEAR
CH
VOLVOL
CH
MENU
PIP M/S
CH VOL
V-
POSITION
POSITION
TV/VIDEO PAUSE/
STILL
SIZE SLEEP
1
3
R-34SVC
456
7890
2

-11-
5. CM-907/F TYPICAL SER ICE DATA
NO CH PATTERN BAND V.FREQ. Sound SYSTEM Color SYSTEM ADJUSTMENT
2 PAL H-2CH VL 64.25 BG PAL 7 PAL H-7CH VH 182.25 BG PAL 9 PAL H-9CH VH 196.25 BG PAL
10 PAL H-10CH VH 209.25 BG PAL 28 PAL H-28CH U 527.25 BG PAL 30 PAL-40CH W/B U 623.25 AUTO W/B 31 PAL-2CH RETMA VL 48.25 BG AUTO
FOCUS, V-CENTER, V-SIZE,V-SLOPE H-CENTER,SCREEN
32 PAL-47CH C/HATCH U 679.25 I AUTO “ CONVERGENCE, ADJUSTMENT” 33 PAL-10CH COLOR BAR VH 210.25 BG PAL “ SCREEN, AGC” 34 PAL-4CH DEM VL 62.25 BG PAL “ SOUND, Teletext check” 35 PAL-12CH PHILIPS VH 224.25 BG SECAM SECAM COLOR CHECK 36 PAL-18CH RETMA U 511.25 DK AUTO SOUND
CM-907/F CHASSIS SETTING LIST

-12-
6. ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
ZZ100 48B4844C07 TRANSMITTER REMOCON R-44C07 (AA)
ZZ110 PTACPWD703 ACCESSORY AS DTC-29M5ME
00030 4850Q00810 BATTERY R6P/LN
0200 48586054K1 MANUAL INSTRUCTION DTM-2082CW
M821 4858213801 BAG INSTRUCTION L.D.P.E T0.05X250X400
ZZ120 PTBCSHD703 COVER BACK AS DTC-29M5ME
M211 4852161121 COVER BACK HIPS GY
M781 4857817630 CLOTH BLACK FELT 400X20X0.7
ZZ130 PTPKCPD703 PACKING AS DTC-29M5ME
10 6520010100 STAPLE PIN AUTO W65
M801 4858057600 BOX CARTON DW-3
M811 4858199100 PAD EPS 29M5
M821 4858215601 BAG P.E PE FOAM t0.5x1600x1270
ZZ131 48519A6410 CRT GROUND NET 2902S-1015-1P
ZZ132 58G0000149 COIL DEGAUSSING DC-29SF
ZZ140 PTCACAD703 CABINET AS DTC-29M5ME
M201A 4856015800 SCREW CRT FIX L=27
M201B 4856215402 WASHER RUBBER CR T2.0
M211A 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M211B 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M211C 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M231A 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M541 4855419800 SPEC PLATE ART 150
M682 4856816300 CLAMP WIRE NYLON 6 (V0)
M683 4856812001 TIE CABLE NYLON66 DA100
SP01A 7172401212 SCREW TAPPTITE TT2 TRS 4X12 MFZNBK
SP02A 7172401212 SCREW TAPPTITE TT2 TRS 4X12 MFZNBK
V901 4859626060 CRT A68QBC230X09 P38
ZZ200 PTFMSJD703 MASK FRONT AS DTC-29M5ME
M201 4852079701 MASK FRONT HIPS GY
M231A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M561 48556174SD MARK BRAND SILVER DIA-CUTTING
M781 4857821102 CLOTH BLACK FELT 340X10X1.5
ZZ205 PTPCSWJ912 PANEL CONTROL AS DTQ-29M5
M191 4851945700 BUTTON CTRL 4951401+5545800
M191A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN
M231 4852328201 PANEL DECO ABS GY
M481 4854861401 BUTTON POWER ABS GY
M481A 4856716000 SPRING SWPA PIE0.5
M591 4855933401 DECO EYE ABS BLUE
M591A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN
ZZ210 PTSPPWD703 SPEAKER AS DTC-29M5ME
P601A 4850704S32 CONNECTOR YH025-04+YRT205+ULW900500
SP01 4858311110 SPEAKER 12W 8 OHM SP-58126F
SP02 4858311110 SPEAKER 12W 8 OHM SP-58126F
ZZ290 PTMPMSD703 PCB MAIN MANUAL AS DTC-29M5ME
10 2193102005 SOLDER BAR SN:PB=63:47 S63S-1320
30 2291050616 FLUX SOLDER JS-64T3
40 2291050301 FLUX SOLVENT IM-1000
C306 CEYF1E332V C ELECTRO 25V RSS 3300MF (16X31.5)
C310 CEYD1H689W C ELECTRO 50V RHD 6.8MF (16X35.5)
C405 CMYH3C123J C MYLAR 1.6KV BUP 0.012MF J
C406 CMYH3C722J C MYLAR 1.6KV BUP 7200PF J
C408 CMYE2D624J C MYLAR 200V PU 0.62MF J
C801 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV)+Q/O
C804 CEYN2G221P C ELECTRO 400V LHS 220MF (35X30)
C811 CH1BFE222M C CERA AC U/C/V AC400V 2200PF
C817 CEYF2C221V C ELECTRO 160V RSS 220MF (18X35.5)
D402 DRGP30J—- DIODE RGP30J
D403 DDGP30L—- DIODE DGP30L
D812 DRGP30J—- DIODE RGP30J
D814 DRGP30J—- DIODE RGP30J
DTC-29M5ME LOC PART CODE PART NAME DESCRIPTION REMARK
DC01 DLH2PR5MHS LED HOLDER AS LH-2P-R-5M-H3
F801 5F3GB6322L FUSE GLASS TUBE V/S TL 6.3A 250V MF51
I301 PTF2SW7921 HEAT SINK ASS`Y 1LA7848—- + 7174300811
00001 1LA7848—- IC VERTICAL LA7848
0000A 4857027921 HEAT SINK AL EX BK
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I401 PT82SW6900 HEAT SINK ASS’Y 1K1A7809P1 + 7174300811
00001 1K1A7809P1 IC REGULATOR K1A7809API
0000A 4857026900 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I501 1V3834DW08 IC MICOM MCM VCT3834F-DW08
I601 1TDA7442— IC AUDIO PROCESSOR TDA7442
I602 PTB2SW8228 HEAT SINK ASS`Y 1TDA8946J- + 7174301011
00001 1TDA8946J- IC AUDIO AMP TDA8946J
0000A 4857028228 HEAT SINK AL EX BK
0000B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I701 124LC16B1B IC MEMORY 24LC16B1B
I801 PTE2SW7920 HEAT SINK ASS`Y 1STRF6656- + 7174301211
00001 1STRF6656- IC POWER STR-F6656
0000A 4857027920 HEAT SINK AL EX BK
0000B 7174301211 SCREW TAPPTITE TT2 RND 3X12 MFZN
I802 1LTV817C— IC PHOTO COUPLER LTV-817C
I803 1DP133—— IC ERROR AMP DP133
I804 PTF2SW4902 HEAT SINK ASS`Y 1K78R05—- + 7174301011
00001 1K78R05—- IC REGULATOR KIA78R05PI
0000A 4857024902 HEAT SINK AL EX
0000B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I806 1LP295033- IC REGULATOR LP2950 3.3V
IF01 1KRT30—— IC PREAMP KRT30
JV01 4859111750 JACK PIN BOARD PH-JB-9515
JV02 4859110950 JACK PIN BOARD YS01-0001
L301 58C7070085 COIL CHOKE TLN-3062A
L401 58H0000039 COIL H-LINEARITY TRL-200D
LF801 5PLF3143G- FILTER LINE LF-3143G
M371 4853747800 RETA PCB NYLON 66
P904 4859281320 CONN WAFER TAC-L18X-A3
PW801 4859908110 CORD POWER AS 1-L0+H03VVH2-F+HOU=2200
Q401 PTG2SW7609 HEAT SINK ASS`Y TST2009DH1 + 7174300811
00001 TST2009DH1 TR ST2009DHI
0000A 4857027609 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
Q402 TKTC3229— TR KTC3229
R801 DDC7R0M290 POSISTOR ECPCD7R0M290
R803 RX10T109KS R CEMENT 10W 1 OHM K TRIPOD SMALL
R807 RM02Y158J- R METAL FLAT 2W 0.15 OHM J
SW801 5S40101143 SW POWER PUSH PS3-22SP (P.C.B)
T401 50H0000251 FBT FFA64039L
T402 5TD0000018 TRANS DRIVE THD-120
T801 50M5345C1- TRANS SMPS TSM-5345C1
U101 4859723730 TUNER VARACTOR TMDG1-837
X501 5XE20R250E CRYSTAL QUARTZ HC-49/U 20.2500MHZ 30PPM
ZZ200 PTMPJ0D703 PCB MAIN (RHU) AS DTC-29M5ME
C105 CEXF1C222V C ELECTRO 16V RSS 2200MF (16X31.5) TP
C407 CMXE2G273J C MYLAR 400V PU 0.027MF J (TP)
C419 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)TP
C422 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
C424 CEXF1V471V C ELECTRO 35V RSS 470MF (10X20) TP
C631 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C802 CCXB3A472K C CERA 1KV B 4700PF K (TAPPING)
C803 CCXB3A472K C CERA 1KV B 4700PF K (TAPPING)
C806 CMXH3C152J C MYLAR 1.6KV BUP 1500PF J (TP)
C818 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
C820 CEXF1E222V C ELECTRO 25V RSS 2200MF (16X25) TP

-13-
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
C821 CEXF1C332V C ELECTRO 16V RSS 3300MF (16X25) TP
C837 CEXF1C222V C ELECTRO 16V RSS 2200MF (16X31.5) TP
ZZ200 PTMPJBD703 PCB MAIN M-10 AS DTC-29M5ME
10 2TM18006BE TAPE MASKING 6.2X500
E001 4856310600 EYE LET BSR T0.2 (R2.3)
E002 4856310600 EYE LET BSR T0.2 (R2.3)
E003 4856310600 EYE LET BSR T0.2 (R2.3)
E004 4856310600 EYE LET BSR T0.2 (R2.3)
E005 4856310300 EYE LET BSR T0.2 (R1.6)
E006 4856310300 EYE LET BSR T0.2 (R1.6)
E007 4856310300 EYE LET BSR T0.2 (R1.6)
E008 4856310300 EYE LET BSR T0.2 (R1.6)
E009 4856310300 EYE LET BSR T0.2 (R1.6)
E010 4856310300 EYE LET BSR T0.2 (R1.6)
E011 4856310300 EYE LET BSR T0.2 (R1.6)
E012 4856310600 EYE LET BSR T0.2 (R2.3)
E013 4856310600 EYE LET BSR T0.2 (R2.3)
E014 4856310300 EYE LET BSR T0.2 (R1.6)
E015 4856310300 EYE LET BSR T0.2 (R1.6)
E016 4856310300 EYE LET BSR T0.2 (R1.6)
E017 4856310300 EYE LET BSR T0.2 (R1.6)
E018 4856310300 EYE LET BSR T0.2 (R1.6)
E019 4856310300 EYE LET BSR T0.2 (R1.6)
E020 4856310300 EYE LET BSR T0.2 (R1.6)
E021 4856310600 EYE LET BSR T0.2 (R2.3)
E022 4856310600 EYE LET BSR T0.2 (R2.3)
E023 4856310600 EYE LET BSR T0.2 (R2.3)
E024 4856310600 EYE LET BSR T0.2 (R2.3)
E025 4856310300 EYE LET BSR T0.2 (R1.6)
E026 4856310300 EYE LET BSR T0.2 (R1.6)
E027 4856310300 EYE LET BSR T0.2 (R1.6)
E028 4856310300 EYE LET BSR T0.2 (R1.6)
E029 4856310300 EYE LET BSR T0.2 (R1.6)
E030 4856310300 EYE LET BSR T0.2 (R1.6)
E031 4856310300 EYE LET BSR T0.2 (R1.6)
E032 4856310300 EYE LET BSR T0.2 (R1.6)
E033 4856310300 EYE LET BSR T0.2 (R1.6)
E034 4856310300 EYE LET BSR T0.2 (R1.6)
E035 4856310300 EYE LET BSR T0.2 (R1.6)
E036 4856310600 EYE LET BSR T0.2 (R2.3)
E037 4856310600 EYE LET BSR T0.2 (R2.3)
E038 4856310600 EYE LET BSR T0.2 (R2.3)
E039 4856310600 EYE LET BSR T0.2 (R2.3)
E040 4856310600 EYE LET BSR T0.2 (R2.3)
E041 4856310600 EYE LET BSR T0.2 (R2.3)
E042 4856310600 EYE LET BSR T0.2 (R2.3)
E043 4856310600 EYE LET BSR T0.2 (R2.3)
E049 4856310600 EYE LET BSR T0.2 (R2.3)
E050 4856310600 EYE LET BSR T0.2 (R2.3)
E051 4856310600 EYE LET BSR T0.2 (R2.3)
E054 4856310600 EYE LET BSR T0.2 (R2.3)
E055 4856310600 EYE LET BSR T0.2 (R2.3)
E056 4856310600 EYE LET BSR T0.2 (R2.3)
E057 4856310600 EYE LET BSR T0.2 (R2.3)
E058 4856310600 EYE LET BSR T0.2 (R2.3)
E059 4856310600 EYE LET BSR T0.2 (R2.3)
N001 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N002 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N003 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N004 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N005 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N006 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N007 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
LOC PART CODE PART NAME DESCRIPTION REMARK
N008 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
P501 485923192S CONN WAFER YW025-06 (STICK)
P502 485923172S CONN WAFER YW025-04 (STICK)
P601 485923172S CONN WAFER YW025-04 (STICK)
P602 485923182S CONN WAFER YW025-05 (STICK)
P603 485923202S CONN WAFER YW025-07 (STICK)
P604 485923162S CONN WAFER YW025-03 (STICK)
PD01 485923162S CONN WAFER YW025-03 (STICK)
R105 RS02Z512JS R M-OXIDE FILM 2W 5.1K OHM J SMALL
R317 RS02Z100J- R M-OXIDE FILM 2W 10 OHM J (TAPPING)
R318 RS02Z271JS R M-OXIDE FILM 2W 270 OHM J SMALL
R403 RS01Z472J- R M-OXIDE FILM 1W 4.7K OHM J (TAPPING)
R404 RS01Z101J- R M-OXIDE FILM 1W 100 OHM J (TAPPING)
R406 RS02Z243JS R M-OXIDE FILM 2W 24K OHM J SMALL
R410 RF01Z229J- R FUSIBLE 1W 2.2 OHM J (TAPPING)
R413 RF01Z100J- R FUSIBLE 1W 10 OHM J (TAPPING)
R414 RS02Z472JS R M-OXIDE FILM 2W 4.7K OHM J SMALL
R419 RF01Z229J- R FUSIBLE 1W 2.2 OHM J (TAPPING)
R805 RS02Z683JS R M-OXIDE FILM 2W 68K OHM J SMALL
R813 RF02Z398K- R FUSIBLE 2W 0.39 OHM K (TAPPING)
R829 RF02Z568K- R FUSIBLE 2W 0.56 OHM K (TAPPING)
ZZ200 PTMPJRD703 PCB MAIN RADIAL AS DTC-29M5ME
C104 CEXF1H101V C ELECTRO 50V RSS 100MF (8X11.5) TP
C108 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C301 CMXM2A563J C MYLAR 100V 0.056MF J (TP)
C302 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C303 CXSL2H100D C CERA 500V SL 10PF D (TAPPING)
C304 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C305 CEXD1H109Q C ELECTRO 50V RT 1MF (6.3X11) TP
C307 CEXF1H101V C ELECTRO 50V RSS 100MF (8X11.5) TP
C309 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C311 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C312 CCXB2H561K C CERA 500V B 560PF K (TAPPING)
C313 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C314 CMXM2A332J C MYLAR 100V 3300PF J (TP)
C315 CEXF1H101V C ELECTRO 50V RSS 100MF (8X11.5) TP
C320 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C321 CMXM2A123J C MYLAR 100V 0.012MF J (TP)
C402 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C403 CCXB2H222K C CERA 500V B 2200PF K (TAPPING)
C404 CCXB2H471K C CERA 500V B 470PF K (TAPPING)
C409 CEXF2C339V C ELECTRO 160V RSS 3.3MF (8X16) TP
C410 CCXB2H561K C CERA 500V B 560PF K (TAPPING)
C411 CEXF2E229V C ELECTRO 250V RSS 2.2MF (8X11.5)TP
C413 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C415 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C417 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C421 CMXM2A333J C MYLAR 100V 0.033MF J (TP)
C425 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C502 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
C503 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C505 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C507 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C508 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C509 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C510 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C511 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C512 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C514 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C519 CMXL1J683J C MYLAR 63V MEU 0.068MF J
C522 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C524 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C525 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP

-14-
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
C530 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C542 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C544 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C545 CEXF1H339V C ELECTRO 50V RSS 3.3MF (5X11) TP
C548 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
C550 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C551 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C562 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C581 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C582 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C583 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C585 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C601 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C606 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C608 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C609 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C610 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C611 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C612 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C615 CCXB1H152K C CERA 50V B 1500PF K (TAPPING)
C617 CCXB1H682K C CERA 50V B 6800PF K (TAPPING)
C618 CCXB1H682K C CERA 50V B 6800PF K (TAPPING)
C619 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C622 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C623 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C624 CMXM2A224J C MYLAR 100V 0.22MF J
C625 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C626 CEXF1H339V C ELECTRO 50V RSS 3.3MF (5X11) TP
C627 CMXM2A224J C MYLAR 100V 0.22MF J
C628 CMXM2A224J C MYLAR 100V 0.22MF J
C629 CMXM2A224J C MYLAR 100V 0.22MF J
C633 CMXM2A682J C MYLAR 100V 6800PF J (TP)
C634 CMXM2A682J C MYLAR 100V 6800PF J (TP)
C805 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C807 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C808 CCXB1H152K C CERA 50V B 1500PF K (TAPPING)
C809 CCXB3A471K C CERA 1KV B 470PF K (T)
C810 CCXB1H152K C CERA 50V B 1500PF K (TAPPING)
C812 CCXB3A471K C CERA 1KV B 470PF K (T)
C813 CCXB3A471K C CERA 1KV B 470PF K (T)
C814 CCXB3A271K C CERA 1KV B 270PF K (TAPPING)
C819 CEXF2A100V C ELECTRO 100V RSS 10MF (6.3X11) TP
C825 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP)
C826 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C827 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C828 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C833 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C836 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
F801A 4857415001 CLIP FUSE PFC5000-0702
F801B 4857415001 CLIP FUSE PFC5000-0702
I702 1K1A7025AP IC RESET KIA7025AP
L601 58CX430599 COIL CHOKE AZ-9004Y 940K TP
L812 58CX430599 COIL CHOKE AZ-9004Y 940K TP
Q101 TKTC3198Y- TR KTC3198Y
Q301 TKTC3198Y- TR KTC3198Y
Q403 TKTC3198Y- TR KTC3198Y
Q502 TKTA1266Y- TR KTA1266Y (TP)
Q503 TKTA1266Y- TR KTA1266Y (TP)
Q504 TKTA1266Y- TR KTA1266Y (TP)
Q505 TKTC3198Y- TR KTC3198Y
Q507 TKTA1266Y- TR KTA1266Y (TP)
Q508 TKTC3198Y- TR KTC3198Y
Q509 TKTC3198Y- TR KTC3198Y
LOC PART CODE PART NAME DESCRIPTION REMARK
Q512 TKSC2330Y- TR KSC2330Y (TP)
Q513 TKSC2330Y- TR KSC2330Y (TP)
Q514 TKTC3198Y- TR KTC3198Y
Q515 TKTC3198Y- TR KTC3198Y
Q581 TKTC3198Y- TR KTC3198Y
Q582 TKTC3198Y- TR KTC3198Y
Q583 TKTC3198Y- TR KTC3198Y
Q601 TKTC3198Y- TR KTC3198Y
Q602 TKTC3198Y- TR KTC3198Y
Q801 TKSA1013Y- TR KSA1013Y (TP)
QF01 TKTC3198Y- TR KTC3198Y
R111 RN02B200JS R METAL FILM 2W 20 OHM J SMALL
R308 RN02B331JS R METAL FILM 2W 330 OHM J SMALL
R309 RN02B121JS R METAL FILM 2W 120 OHM J SMALL
R310 RN02B200JS R METAL FILM 2W 20 OHM J SMALL
R312 RN01B913JS R METAL FILM 1W 91K OHM J SMALL
R314 RN02B103JS R METAL FILM 2W 10K OHM J SMALL
R315 RN01B562JS R METAL FILM 1W 5.6K OHM J SMALL
R407 RN02B102JS R METAL FILM 2W 1K OHM J SMALL
R420 RN02B101JS R METAL FILM 2W 100 OHM J SMALL
R422 RN02B159JS R METAL FILM 2W 1.5 OHM J SMALL
R426 RN02B333JS R METAL FILM 2W 33K OHM J SMALL
R429 RN02B681JS R METAL FILM 2W 680 OHM J SMALL
R824 RN01B102JS R METAL FILM 1W 1K OHM J SMALL
R825 RN02B202JS R METAL FILM 2W 2K OHM J SMALL
R828 RN02B132JS R METAL FILM 2W 1.3K OHM J SMALL
SW701 5S50101090 SW TACT THVH472GCA
SW702 5S50101090 SW TACT THVH472GCA
SW703 5S50101090 SW TACT THVH472GCA
SW704 5S50101090 SW TACT THVH472GCA
SW705 5S50101090 SW TACT THVH472GCA
SW706 5S50101090 SW TACT THVH472GCA
ZZ200 PTMPJAD703 PCB MAIN AXIAL AS DTC-29M5ME
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M
A001 4859806793 PCB MAIN 330X246 D1B
C103 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C308 CZCH1H200J C CERA 50V CH 20PF J (AXIAL)
C501 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C504 CCZF1H473Z C CERA 50V F 0.047MF Z
C506 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C513 CCZF1H103Z C CERA 50V F 0.01MF Z
C515 CCZF1H223Z C CERA 50V F 0.022MF Z
C516 CCZF1H223Z C CERA 50V F 0.022MF Z
C517 CCZF1H223Z C CERA 50V F 0.022MF Z
C520 CCZB1H151K C CERA 50V B 150PF K (AXIAL)
C523 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C526 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C527 CZCH1H309C C CERA 50V CH 3PF C (AXIAL)
C528 CZCH1H309C C CERA 50V CH 3PF C (AXIAL)
C529 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C531 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C532 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C534 CCZF1H103Z C CERA 50V F 0.01MF Z
C538 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C539 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C540 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C543 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C546 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C584 CCZF1H473Z C CERA 50V F 0.047MF Z
C586 CCZF1H473Z C CERA 50V F 0.047MF Z
C602 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C603 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z

-15-
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
C604 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C605 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C607 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C613 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C614 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C616 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C630 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C642 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C643 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C823 CCZF1H103Z C CERA 50V F 0.01MF Z
C830 CCZF1H103Z C CERA 50V F 0.01MF Z
C832 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C834 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
D101 DUZ33B—— DIODE ZENER UZ-33B
D102 DUZ5R6BM— DIODE ZENER UZ-5.6BM
D301 D1N4004S— DIODE 1N4004S
D304 DUZ33B—— DIODE ZENER UZ-33B
D306 D1N4004S— DIODE 1N4004S
D307 D1N4004S— DIODE 1N4004S
D401 D1N4937G— DIODE 1N4937G (TAPPING)
D405 DUZ9R1BM— DIODE ZENER UZ-9.1BM
D406 D1N4937G— DIODE 1N4937G (TAPPING)
D407 D1N4937G— DIODE 1N4937G (TAPPING)
D410 D1N4937G— DIODE 1N4937G (TAPPING)
D411 DUZ12BM—- DIODE ZENER UZ-12BM (UNIZON)
D412 D1N4148—- DIODE 1N4148 (TAPPING)
D501 D1N4148—- DIODE 1N4148 (TAPPING)
D502 D1N4148—- DIODE 1N4148 (TAPPING)
D503 DUZ5R1B—- DIODE ZENER UZ-5.1B
D504 DUZ5R1B—- DIODE ZENER UZ-5.1B
D505 DUZ5R1B—- DIODE ZENER UZ-5.1B
D506 D1N4148—- DIODE 1N4148 (TAPPING)
D507 D1N4148—- DIODE 1N4148 (TAPPING)
D508 D1N4148—- DIODE 1N4148 (TAPPING)
D509 DUZ2R7B—- DIODE ZENER UZ-2.7B
D511 DUZ7R5BM— DIODE ZENER UZ-7.5BM
D512 DUZ7R5BM— DIODE ZENER UZ-7.5BM
D513 DUZ7R5BM— DIODE ZENER UZ-7.5BM
D581 DUZ5R6BM— DIODE ZENER UZ-5.6BM
D601 D1N4148—- DIODE 1N4148 (TAPPING)
D602 D1N4148—- DIODE 1N4148 (TAPPING)
D802 DLT2A05G— DIODE LT2A05G (TP)
D803 DLT2A05G— DIODE LT2A05G (TP)
D804 DLT2A05G— DIODE LT2A05G (TP)
D805 DLT2A05G— DIODE LT2A05G (TP)
D806 D1N4937G— DIODE 1N4937G (TAPPING)
D807 D1N4937G— DIODE 1N4937G (TAPPING)
D808 D1N4937G— DIODE 1N4937G (TAPPING)
D809 D1N4937G— DIODE 1N4937G (TAPPING)
D810 D1N4004S— DIODE 1N4004S
D811 DUZ3R3B—- DIODE ZENER UZ-3.3B
D813 D1N4937G— DIODE 1N4937G (TAPPING)
D816 DRGP15J—- DIODE RGP15J
DF01 DUZ5R1B—- DIODE ZENER UZ-5.1B
DF02 DUZ5R1B—- DIODE ZENER UZ-5.1B
J001 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J002 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J003 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J004 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J005 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J006 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J007 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J008 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
LOC PART CODE PART NAME DESCRIPTION REMARK
J009 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J010 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J011 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J012 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J013 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J014 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J015 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J016 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J017 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J018 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J019 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J020 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J021 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J022 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J023 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J024 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J025 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J026 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J027 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J028 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J029 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J031 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J032 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J033 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J034 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J035 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J036 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J037 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J038 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J039 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J040 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J041 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J042 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J043 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J044 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J045 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J046 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J047 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J048 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J049 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J050 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J051 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J052 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J053 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J054 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J055 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J056 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J058 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J059 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J060 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J061 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J062 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J063 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J064 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J065 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J067 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J068 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J069 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J070 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J071 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J072 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J073 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J074 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING

-16-
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
J075 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J076 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J077 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J078 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J079 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J080 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J081 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J082 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J083 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J084 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J085 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J086 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J087 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J088 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J089 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J090 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J091 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J092 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J093 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J094 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J095 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J096 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J097 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J098 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J099 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J100 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J101 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J102 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J103 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J104 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J105 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J106 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J107 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J108 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J109 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J110 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J111 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J112 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J113 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J114 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J115 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J116 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J117 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J118 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J119 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J120 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J121 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J122 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J123 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J124 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J125 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J126 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J127 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J128 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J129 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J130 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J131 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J132 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J133 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J134 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J135 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
L101 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
L404 58C0000026 COIL BEAD HC-4035
LOC PART CODE PART NAME DESCRIPTION REMARK
L405 5CPZ109M02 COIL PEAKING 1UH M (AXIAL 3.5MM)
L501 5CPZ101K02 COIL PEAKING 100UH K (AXIAL 3.5MM)
L502 5CPZ220K02 COIL PEAKING 22UH K (AXIAL 3.5MM)
L503 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L504 5CPZ101K02 COIL PEAKING 100UH K (AXIAL 3.5MM)
L505 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L566 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L577 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L581 5CPZ470K02 COIL PEAKING 47UH K (AXIAL 3.5MM)
L582 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L599 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM)
L602 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
L801 5MC0000100 COIL BEAD HC-3550
LD01 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
R103 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R107 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R108 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R109 RD-AZ272J- R CARBON FILM 1/6 2.7K OHM J
R110 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R301 RN-AZ3601F R METAL FILM 1/6 3.60K OHM F
R302 RN-4Z2002F R METAL FILM 1/4 20.0K OHM F
R303 RN-4Z1003F R METAL FILM 1/4 100K OHM F
R304 RN-4Z1102F R METAL FILM 1/4 11K OHM F
R305 RD-AZ562J- R CARBON FILM 1/6 5.6K OHM J
R306 RD-AZ563J- R CARBON FILM 1/6 56K OHM J
R307 RD-AZ113J- R CARBON FILM 1/6 11K OHM J
R311 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R313 RD-4Z103J- R CARBON FILM 1/4 10K OHM J
R316 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R319 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R320 RD-AZ479J- R CARBON FILM 1/6 4.7 OHM J
R321 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R322 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R323 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R324 RD-2Z109J- R CARBON FILM 1/2 1 OHM J
R326 RD-AZ391J- R CARBON FILM 1/6 390 OHM J
R327 RN-4Z2701F R METAL FILM 1/4 2.70K OHM F
R328 RN-AZ3301F R METAL FILM 1/6 3.3K OHM F
R401 RD-4Z121J- R CARBON FILM 1/4 120 OHM J
R402 RD-4Z122J- R CARBON FILM 1/4 1.2K OHM J
R405 RD-4Z330J- R CARBON FILM 1/4 33 OHM J
R408 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R409 RD-4Z103J- R CARBON FILM 1/4 10K OHM J
R411 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R412 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R418 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
R421 RD-4Z914J- R CARBON FILM 1/4 910K OHM J
R424 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R501 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R502 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R503 RD-AZ203J- R CARBON FILM 1/6 20K OHM J
R504 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R505 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R506 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
R507 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R510 RD-AZ912J- R CARBON FILM 1/6 9.1K OHM J
R511 RD-AZ511J- R CARBON FILM 1/6 510 OHM J
R512 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R513 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
R514 RD-AZ271J- R CARBON FILM 1/6 270 OHM J
R515 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R516 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R517 RD-AZ181J- R CARBON FILM 1/6 180 OHM J

-17-
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
R518 RD-AZ181J- R CARBON FILM 1/6 180 OHM J
R519 RD-AZ181J- R CARBON FILM 1/6 180 OHM J
R520 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R521 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R522 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R523 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R524 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R525 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R526 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R527 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R528 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R529 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R532 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
R533 RD-AZ271J- R CARBON FILM 1/6 270 OHM J
R534 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R535 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
R536 RD-AZ271J- R CARBON FILM 1/6 270 OHM J
R537 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R538 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
R539 RD-AZ271J- R CARBON FILM 1/6 270 OHM J
R540 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R541 RD-AZ330J- R CARBON FILM 1/6 33 OHM J
R542 RD-AZ330J- R CARBON FILM 1/6 33 OHM J
R543 RD-AZ330J- R CARBON FILM 1/6 33 OHM J
R544 RD-AZ220J- R CARBON FILM 1/6 22 OHM J
R545 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R546 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R547 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R548 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
R549 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R550 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R551 RD-AZ201J- R CARBON FILM 1/6 200 OHM J
R552 RD-2Z100J- R CARBON FILM 1/2 10 OHM J
R556 RD-AZ513J- R CARBON FILM 1/6 51K OHM J
R559 RD-AZ243J- R CARBON FILM 1/6 24K OHM J
R560 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R561 RD-4Z103J- R CARBON FILM 1/4 10K OHM J
R564 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
R566 RD-AZ361J- R CARBON FILM 1/6 360 OHM J
R570 RD-2Z101J- R CARBON FILM 1/2 100 OHM J
R573 RD-AZ560J- R CARBON FILM 1/6 56 OHM J
R574 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R577 RD-AZ361J- R CARBON FILM 1/6 360 OHM J
R580 RD-4Z331J- R CARBON FILM 1/4 330 OHM J
R581 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
R582 RD-AZ683J- R CARBON FILM 1/6 68K OHM J
R583 RD-AZ683J- R CARBON FILM 1/6 68K OHM J
R584 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R585 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R586 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
R587 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R588 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R589 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R590 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R591 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
R592 RD-AZ829J- R CARBON FILM 1/6 8.2 OHM J
R593 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R594 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R595 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R596 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
R597 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
R598 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R599 RD-AZ361J- R CARBON FILM 1/6 360 OHM J
LOC PART CODE PART NAME DESCRIPTION REMARK
R603 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R604 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R605 RD-AZ153J- R CARBON FILM 1/6 15K OHM J
R606 RD-AZ562J- R CARBON FILM 1/6 5.6K OHM J
R607 RD-AZ562J- R CARBON FILM 1/6 5.6K OHM J
R608 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R609 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R610 RD-AZ752J- R CARBON FILM 1/6 7.5K OHM J
R611 RD-AZ752J- R CARBON FILM 1/6 7.5K OHM J
R612 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
R613 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
R614 RD-AZ513J- R CARBON FILM 1/6 51K OHM J
R615 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R616 RD-AZ181J- R CARBON FILM 1/6 180 OHM J
R617 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R642 RD-AZ829J- R CARBON FILM 1/6 8.2 OHM J
R643 RD-AZ829J- R CARBON FILM 1/6 8.2 OHM J
R701 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R702 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R802 RC-2Z824KP R CARBON COMP 1/2 820K OHM K
R806 RD-4Z821J- R CARBON FILM 1/4 820 OHM J
R809 RD-2Z332J- R CARBON FILM 1/2 3.3K OHM J
R810 RD-2Z100J- R CARBON FILM 1/2 10 OHM J
R811 RD-4Z123J- R CARBON FILM 1/4 12K OHM J
R812 RC-2Z825KP R CARBON COMP 1/2 8.2M OHM K
R814 RD-4Z473J- R CARBON FILM 1/4 47K OHM J
R815 RD-4Z163J- R CARBON FILM 1/4 16K OHM J
R816 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R817 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R826 RD-4Z122J- R CARBON FILM 1/4 1.2K OHM J
RF01 RD-AZ241J- R CARBON FILM 1/6 240 OHM J
RF02 RD-AZ391J- R CARBON FILM 1/6 390 OHM J
RF03 RD-AZ681J- R CARBON FILM 1/6 680 OHM J
RF04 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
RF05 RD-AZ112J- R CARBON FILM 1/6 1.1K OHM J
RF06 RD-AZ822J- R CARBON FILM 1/6 8.2K OHM J
RF08 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
RF09 RD-AZ131J- R CARBON FILM 1/6 130 OHM J
RF10 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
ZZ400 PTPMMSD703 PCB PIP MANUAL AS DTC-29M5ME
IP02 1K78R33—- IC REGULATOR KIA78R33API
PP01 4859279820 CONN WAFER TAC-L18P-A3 (ANGLE)
XP01 5XE20R250E CRYSTAL QUARTZ HC-49/U 20.2500MHZ 30PPM
ZZ200 PTPMJ2D703 PCB PIP CHIP B AS DTC-29M5ME
IP01 1SDA9488XE IC CHIP PIP SDA9488X
ZZ200 PTPMJRD703 PCB PIP RADIAL AS DTC-29M5ME
CP01 CXCH1H240J C CERA 50V CH 24PF J (TAPPING)
CP02 CXCH1H240J C CERA 50V CH 24PF J (TAPPING)
CP03 CCXB1H222K C CERA 50V B 2200PF K (TAPPING)
CP04 CCXB1H222K C CERA 50V B 2200PF K (TAPPING)
CP05 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CP08 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
CP10 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
CP11 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
CP12 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CP14 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
CP16 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CP18 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CP20 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CP21 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
CP22 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
CP23 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
QP01 TKTC3198Y- TR KTC3198Y

-18-
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
QP02 TKSA1013Y- TR KSA1013Y (TP)
QP03 TKSA1013Y- TR KSA1013Y (TP)
QP04 TKSA1013Y- TR KSA1013Y (TP)
ZZ200 PTPMJAD703 PCB PIP AXIAL AS DTC-29M5ME
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M
A001 4859812524 PCB PIP 88X54.5(197X246/8) C1B
CP06 CBZP1C103M C CERA SEMI 16V Y5S 0.01MF M (AXIAL)
CP09 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
CP13 CCZF1H103Z C CERA 50V F 0.01MF Z
CP15 CCZF1H103Z C CERA 50V F 0.01MF Z
CP17 CCZF1H103Z C CERA 50V F 0.01MF Z
CP19 CCZF1H103Z C CERA 50V F 0.01MF Z
CP24 CCZB1H820K C CERA 50V B 82PF K (AXIAL)
DP02 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
DP03 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
DP04 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP01 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP02 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP03 RD-4Z569J- R CARBON FILM 1/4 5.6 OHM J
JP04 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP05 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP06 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP07 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
LP02 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
LP03 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
LP04 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
LP05 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
RP01 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
RP02 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
RP03 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
RP04 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
RP05 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
RP06 RD-AZ273J- R CARBON FILM 1/6 27K OHM J
RP07 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RP08 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RP09 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RP10 RD-AZ151J- R CARBON FILM 1/6 150 OHM J
RP11 RD-AZ151J- R CARBON FILM 1/6 150 OHM J
RP12 RD-AZ151J- R CARBON FILM 1/6 150 OHM J
RP13 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RP14 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RP15 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
ZZ600 PTUNSWD703 PCB UNION AS DTC-29M5ME
C908 CCYB3D472K C CERA 2KV B 4700PF K
HP01 4859105240 JACK PHONE LGT1516-0100
I901 PTB2SW5403 HEAT SINK ASS`Y 1TEA5101B- + 7174300811
I901 1TEA5101B- IC VIDEO AMP TEA5101B
I901A 4857025403 HEAT SINK AL050P-H24 T=2
I901B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
ID01 1PNA4603H- IC PHOTO SENSOR PNA4603H
JV03 4859105450 JACK PIN BOARD YSC03P-4120-9S
M231 4851114004 PANEL AV ASSY 2326802+5934302
M231A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN
M681 4856812001 TIE CABLE NYLON66 DA100
M781 4857821300 CLOTH BLACK CLOTH
P501A 4850706S18 CONNECTOR YH025-06+YST025+ULW=500
P502A 4850704S04 CONNECTOR YH025-04+YST025+ULW=400
P602A 4850705S12 CONNECTOR YH025-05+YST025+ULW=500
P603A 4850707S09 CONNECTOR YH025-07+YST025+ULW=500
LOC PART CODE PART NAME DESCRIPTION REMARK
P604A 4850703S45 CONNECTOR YH025-03+YST025+USW=400
PDA1 4850703S18 CONNECTOR YH025-03+YBNH250+ULW=200
SCT1 4859303530 SOCKET CRT PCS629-03C
ZZ200 PTUNJ0D703 PCB UNION RHU AS DTC-29M5ME
C904 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP
C909 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP
C910 CEXF1E331V C ELECTRO 25V RSS 330MF (10X12.5)TP
ZZ200 PTUNJBD703 PCB UNION M-10 AS DTC-29M5ME
R907 RS01Z683J- R M-OXIDE FILM 1W 68K OHM J (TAPPING)
R908 RS01Z683J- R M-OXIDE FILM 1W 68K OHM J (TAPPING)
R909 RS01Z683J- R M-OXIDE FILM 1W 68K OHM J (TAPPING)
R919 RS02Z399JS R M-OXIDE FILM 2W 3.9 OHM J SMALL
R922 RS02Z100JS R M-OXIDE FILM 2W 10 OHM J SMALL
ZZ200 PTUNJRD703 PCB UNION RADIAL AS DTC-29M5ME
C905 CMXL2E104K C MYLAR 250V MEU 0.1MF K
C906 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C911 4SG0DX0001 SPARK GAP SSG-102-A1(1.0KV) TAP
CS01 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CS02 CEXF1H100A C ELECTRO 50V RSM 10MF (5X7) TP
Q901 TKTA1266Y- TR KTA1266Y (TP)
RS01 RN01B151JS R METAL FILM 1W 150 OHM J SMALL
RS02 RN01B151JS R METAL FILM 1W 150 OHM J SMALL
ZZ200 PTUNJAD703 PCB UNION AXIAL AS DTC-29M5ME
A001 4859809460 PCB UNION 246X246 D1B
C901 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
C902 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
C903 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CD01 CCZB1H561K C CERA 50V B 560PF K
D901 DLT2A05G— DIODE LT2A05G (TP)
D902 D1N4937G— DIODE 1N4937G (TAPPING)
D903 D1N4148—- DIODE 1N4148 (TAPPING)
D904 D1N4148—- DIODE 1N4148 (TAPPING)
D905 D1N4148—- DIODE 1N4148 (TAPPING)
D906 D1N4148—- DIODE 1N4148 (TAPPING)
DD01 DUZ7R5BM— DIODE ZENER UZ-7.5BM
J901 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J902 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J903 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J904 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JS01 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
R901 RD-2Z102J- R CARBON FILM 1/2 1K OHM J
R902 RD-2Z102J- R CARBON FILM 1/2 1K OHM J
R903 RD-2Z102J- R CARBON FILM 1/2 1K OHM J
R904 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R905 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R906 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R910 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R911 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R912 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R913 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R914 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R915 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R916 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
R917 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
R918 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
R920 RD-2Z102J- R CARBON FILM 1/2 1K OHM J
R921 RD-2Z105J- R CARBON FILM 1/2 1M OHM J
R923 RD-4Z471J- R CARBON FILM 1/4 470 OHM J
RD01 RD-AZ511J- R CARBON FILM 1/6 510 OHM J

-19-
7. EACH MODEL PARTS LIST
LOC PART NAME NORMAL FLAT
L401 COIL H-LINEARITY TRL-200D TRL-350B
T401 FBT FFA64039L BSC29-0197
C408 C MYLAR 200V 0.62 MF 200V 0.39MF
C405 C MYLAR 1.6KV 0.01MF 1.6KV 6900PF
C406 C MYLAR 1.6KV 91200PF 1.6KV 8200PF
R919 R M-OXIDE FILM 2W 3.9 OHM 2W 3.6 OHM
R429 R METAL FILM 2W 680 OHM J SMALL N.C
D515 DIODE ZENER N.C UZ-5.6BM
A001 PCB MAIN 4859806793 4859807493
DIGITAL EYE MODULE O X
