Daewoo DTQ-25G4FS User manual

Service Guide
Color Television
CHASSIS : CN-207a
Model : DTQ-25G4FS
DTQ-29G4FS
http : //svc.dwe.co.kr Oct. 2000
DAEWOO ELECTRONICS CO., LTD.
S/G No. : TCN207MEF0G1
MODEL
ITEM
TVSTANDARD
POWERINPUT
POWERCONSUMPTION
TUNINGSYSTEM
TUNINGRANGES
SOUNDOUTPUT
SPEAKER
ANTENNAINPUTIMPEDANCE
AUXILIARYINPUTTERMINAL
INTERMEDIATEFREQUENCIES
REMOTECONTROL
SPECIALFUNCTIONS
DTH-25G4FS DTH-29G4FS
NTST-M
120V/220V 50/60HZ
120W 135W
F.S.REMOCON
VHF
UHF
VHF(L):CH2 ~ 6
(H):CH7~13
CH14~ CH69
6.5W+6.5W (R+L)
8 10W+8 10W (R+L)
75ohm
Font:Video,Audio,R/L,1EA
Rear:Video,Audio,R/L,1EA
PIF:45.75MHZ
SIF:41.25MHZ
COLORSUB:3.579545MHZ
R-35H13
1)ICONMENUTYPE
2)3-LanguageOSD
3)WITHCAPTION
4)CHLABEL
5)WITHCAPTION
6)CHLABEL,AUTODEMO
SPECIFICATIONS
CATV CH1~CH125
✔ Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).

DTQ-29G4FS

part_cd part_nm part_desc loc DTQ-
25G4FS DTQ- 29G4FS
CEXF1H228V CELECTRO 50VRSS0.22MF(5X11)TP C306 1 0
CEXF1H478V CELECTRO 50VRSS0.47MF(5X11)TP C306 0 1
CMYH3C822J CMYLAR 1.6KV BUP 8200PF J C404 0 1
CMYH3D752J CMYLAR 2KVBUP7500PFJ C404 1 0
CMYH3C692J CMYLAR 1.6KV BUP 6900PF J C405 1 0
CMYH3C912J CMYLAR 1.6KV BUP 9100PF J C405 0 1
CMXE2J273J CMYLAR 630VPU0.027MFJ(TP) C406 1 0
CMXE2J333J CMYLAR 630VPU0.033MFJ(TP) C406 0 1
CMXE2D683J CMYLAR 200VPU0.068MFJ(TP) C419 0 1
CMYE2D394J CMYLAR 200VPU0.39MFJ C420 1 0
CMYE2D514J CMYLAR 200VPU0.51MFJ C420 0 1
CEXF2C101V CELECTRO 160VRSS100MF(16X25)TP C826 1 0
HCBH224KCA CCHIPCERA 25VX7R0.22MFK2012 CC723 0 1
HCBK223KCA CCHIPCERA 50VX7R0.022MFK2012 CC723 1 0
DRGP15J--- DIODE RGP15J D824 1 0
4856310600 EYELET BSRT0.2(R2.3) E034 0 1
4856310600 EYELET BSRT0.2(R2.3) E035 0 1
85801065GY WIRECOPPER AWG221/0.65TINCOATING J019 1 0
85801065GY WIRECOPPER AWG221/0.65TINCOATING J020 1 0
85801065GY WIRECOPPER AWG221/0.65TINCOATING J200 0 1
85801065GY WIRECOPPER AWG221/0.65TINCOATING J212 0 1
58H0000025 COILH-LINEARITY TRL-330 L401 1 0
58H1600022 COILH-LINEARITY TRL-2093 L401 0 1
58W0000018 COILWIDTH TLN-2092 L402 0 1
4852066501 MASKFRONT HIPSBK M201 0 1
4852073303 MASKFRONT HIPSBK M201 1 0
4856015800 SCREWCRTFIX L=27 M201A 4 0
4856015820 SCREWCRTFIX SWRM+SK5L=35 M201A 0 4
4856215402 WASHERRUBBER CRT2.0 M201B 4 0
4856215404 WASHERRUBBER CRT4.0 M201B 0 4
4852150741 COVERBACK HIPSBK M211 0 1
4852155321 COVERBACK HIPSBK M211 1 0
7172401612 SCREWTAPPTITE TT2TRS4X16MFZNBK M211A 8 0
7172401612 SCREWTAPPTITE TT2TRS4X16MFZNBK M211A 010
4852821201 DOOR ABSBK M281 0 1
4852821900 DOOR ABSBK M281 1 0
4853526600 HOLDERCORD NYLON6(DACB-183) M351 1 0
7172401612 SCREWTAPPTITE TT2TRS4X16MFZNBK M351A 1 0
7178301212 SCREWTAPPTITE TT2WAS3X12MFZNBK M381A 2 0
4854852501 BUTTONPOWER ABSBK M481 0 1
4854856100 BUTTONPOWER ABSBK M481 1 0
4855535401 DECOSENSOR PMMACL M551 0 1
4855540800 DECOSENSOR PMMA M551 1 0
4855616100 MARKBRAND A1050P-H24 M561 1 0
48556174SD MARKBRAND SILVERDIA-CUTTING M561 0 1
4856812400 BAND 18MMX3M M681 1 0
4856812400 BAND 18MMX3M M681 0 1
4857820001 CLOTHBLACK CLOTH320X12X0.5 M781 0 2
4857821103 CLOTHBLACK FELT180X10X1.5 M781 2 0
4858053400 BOXCARTON DW-4ATYPE M801 0 1
4858055500 BOXCARTON DW-2 M801 1 0
4858185900 PAD EPS29G4 M811 0 1
4858192500 PAD EPS25G4 M811 1 0
4858215100 BAGP.E PEFOAMt0.5x1430x1270 M821 1 0
4858215600 BAGP.E PEFOAMt0.5x1600x1270 M821 0 1
RS02Z220JS RM-OXIDEFILM 2W220HMJSMALL R314 1 0
RS02Z620JS RM-OXIDEFILM 2W62OHMJSMALL R314 0 1
RF01Z159J- RFUSIBLE 1W1.5OHMJ(TAPPING) R409 1 0
RF01Z399J- RFUSIBLE 1W3.9OHMJ(TAPPING) R409 0 1
RF01Z518K- RFUSIBLE 1W0.51OHMK(TAPPING) R817 0 1
RF01Z688K- RFUSIBLE 1W0.68OHMK(TAPPING) R817 1 0
RF01Z518K- RFUSIBLE 1W0.51OHMK(TAPPING) R818 0 1
RF01Z688K- RFUSIBLE 1W0.68OHMK(TAPPING) R818 1 0
HRFT512JCA RCHIP 1/105.1KOHMJ2012 RC301 1 0
HRFT682JCA RCHIP 1/106.8KOHMJ2012 RC301 0 1
HRFT104JCA RCHIP 1/10100KOHMJ2012 RC304 1 0
HRFT913JCA RCHIP 1/10 91K OHM J 2012 RC304 0 1
HRFT183JCA RCHIP 1/10 18K OHM J 2012 RC305 1 0
HRFT273JCA RCHIP 1/10 27K OHM J 2012 RC305 0 1
HRFT123JCA RCHIP 1/10 12K OHM J 2012 RC307 0 1
HRFT163JCA RCHIP 1/10 16K OHM J 2012 RC307 1 0
HRFT183JCA RCHIP 1/10 18K OHM J 2012 RC308 0 1
HRFT203JCA RCHIP 1/10 20K OHM J 2012 RC308 1 0
HRFT513JCA RCHIP 1/10 51K OHM J 2012 RC309 1 0
HRFT623JCA RCHIP 1/10 62K OHM J 2012 RC309 0 1
HRFT392JCA RCHIP 1/103.9KOHMJ2012 RC420 1 0
HRFT562JCA RCHIP 1/105.6KOHMJ2012 RC420 0 1
HRFT000-CA RCHIP 1/100OHM2012 RC426 1 0
HRFT479JCA RCHIP 1/104.7OHMJ2012 RC426 0 1
HRFT273JCA RCHIP 1/10 27K OHM J 2012 RC428 1 0
HRFT393JCA RCHIP 1/10 39K OHM J 2012 RC428 0 1
HRFT561JCA RCHIP 1/10560OHMJ2012 RC570 1 0
HRFT911JCA RCHIP 1/10910OHMJ2012 RC570 0 1
HRFT112JCA RCHIP 1/101.1KOHMJ2012 RC571 0 1
HRFT182JCA RCHIP 1/101.8KOHMJ2012 RC571 1 0
HRFT102JCA RCHIP 1/101KOHMJ2012 RC725 0 1
HRFT103JCA RCHIP 1/10 10K OHM J 2012 RC725 1 0
HRFT334JCA RCHIP 1/10330KOHMJ2012 RC820 1 0
HRFT434JCA RCHIP 1/10430KOHMJ2012 RC820 0 1
HRFT184JCA RCHIP 1/10180KOHMJ2012 RC822 1 0
HRFT684JCA RCHIP 1/10680KOHMJ2012 RC822 0 1
HRFT161JCA RCHIP 1/10160OHMJ2012 RC905 1 0
HRFT181JCA RCHIP 1/10180OHMJ2012 RC905 0 1
HRFT181JCA RCHIP 1/10180OHMJ2012 RC911 0 1
HRFT201JCA RCHIP 1/10200OHMJ2012 RC911 1 0
HRFT161JCA RCHIP 1/10160OHMJ2012 RC917 1 0
HRFT181JCA RCHIP 1/10180OHMJ2012 RC917 0 1
7172401412 SCREWTAPPTITE TT2 TRS 4X14 MFZN BK SP01A 0 4
7172401612 SCREWTAPPTITE TT2 TRS 4X16 MFZN BK SP01A 4 0
4859629060 CRT A59KPR84X01(D)P38 V901 1 0
4859629160 CRT A68KTB259X001P38 V901 0 1
48B3235H13 TRANSMITTERREMOCON R-35H13 ZZ100 1 0
48B3235H13 TRANSMITTERREMOCON R-35H13 ZZ100 0 1
PTACPWJ663 ACCESSORYAS DTQ-29G3FS ZZ110 1 0
PTACPWJ663 ACCESSORYAS DTQ-29G3FS ZZ110 0 1
PTBCSHJ752 COVERBACKAS DTQ-29G4FS ZZ120 0 1
PTBCSHJ793 COVERBACKAS DTQ-25G4FS ZZ120 1 0
PTPKCPJ752 PACKINGAS DTQ-29G4FS ZZ130 0 1
PTPKCPJ793 PACKINGAS DTQ-25G4FS ZZ130 1 0
48519A4010 CRTGROUNDNET 2501H-1015-2P ZZ131 1 0
48519A4210 CRTGROUNDNET 2901H-1015-2P ZZ131 0 1
58G0000148 COILDEGAUSSING DC-25SF ZZ132 1 0
58G0000149 COILDEGAUSSING DC-29SF ZZ132 0 1
PTCACAJ752 CABINETAS DTQ-29G4FS ZZ140 0 1
PTCACAJ793 CABINETAS DTQ-25G4FS ZZ140 1 0
PTFMSJJ752 MASKFRONTAS DTQ-29G4FS ZZ200 0 1
PTFMSJJ793 MASKFRONTAS DTQ-25G4FS ZZ200 1 0
PTMPJ0J752 PCBMAIN(RHU)AS DTQ-29G4FS ZZ200 0 1
PTMPJ0J793 PCBMAIN(RHU)AS DTQ-25G4FS ZZ200 1 0
PTMPJ2J752 PCBCHIPMOUNTBAS DTQ-29G4FS ZZ200 0 1
PTMPJ2J793 PCBCHIPMOUNTBAS DTQ-25G4FS ZZ200 1 0
PTMPJAJ752 PCBMAINAXIAL AS DTQ-29G4FS ZZ200 0 1
PTMPJAJ793 PCBMAINAXIAL AS DTQ-25G4FS ZZ200 1 0
PTMPJBJ752 PCBMAINM-10AS DTQ-29G4FS ZZ200 0 1
PTMPJBJ793 PCBMAINM-10AS DTQ-25G4FS ZZ200 1 0
PTMPJRJ752 PCBMAINRADIALAS DTQ-29G4FS ZZ200 0 1
PTMPJRJ793 PCBMAINRADIALAS DTQ-25G4FS ZZ200 1 0
PTMPMSJ752 PCBMAINMANUALAS DTQ-29G4FS ZZ290 0 1
PTMPMSJ793 PCBMAINMANUALAS DTQ-25G4FS ZZ290 1 0
part_cd part_nm part_desc loc DTQ-
25G4FS DTQ- 29G4FS
The Different Part List
✔ Caution:In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)

LOC PARTCODE PARTNAME PARTDESCRIPTION
ZZ100 48B3235H13 TRANSMITTERREMOCON R-35H13
ZZ110 PTACPWJ663 ACCESSORYAS DTQ-29G3FS
30 4850Q00810 BATTERY R6P/LN
40 4.86E+09 MANUALINSTRUCTION DTQ-29G4FS
M821 4858213800 BAGINSTRUCTION L.D.P.E T0.05X250X400
ZZ120 PTBCSHJ752 COVERBACKAS DTQ-29G4FS
M211 4852150741 COVERBACK HIPSBK
M541 4855415800 SPECPLATE 150ART P/E FILM(C/TV)
M782 4857817630 CLOTHBLACK FELT400X20X0.7
ZZ130 PTPKCPJ752 PACKINGAS DTQ-29G4FS
M641 6520010100 STAPLEPIN 18M/M JD O
M681 4856812400 BAND 18MMX3M
M801 4858053400 BOXCARTON DW-4 A TYPE
M811 4858185900 PAD EPS29G4
M821 4858215600 BAGP.E PE FOAM t0.5x1600x1270
ZZ131 48519A4210 CRTGROUNDNET 2901H-1015-2P
ZZ132 58G0000149 COILDEGAUSSING DC-29SF
ZZ140 PTCACAJ752 CABINETAS DTQ-29G4FS
40 2TF01612CL TAPEFILAMENT 12MMX55ME CLEAR
AD001 4859000240 ADAPTER 2P15A300V(D=4.0)
M201A 4856015820 SCREWCRTFIX SWRM+SK5 L=35
M201B 4856215404 WASHERRUBBER CRT4.0
M211A 7172401612 SCREWTAPPTITE TT2TRS 4X16 MFZNBK
M211B 7172401612 SCREWTAPPTITE TT2TRS 4X16 MFZNBK
M281 4852821201 DOOR ABSBK
M481 4854852501 BUTTONPOWER ABSBK
M481A 4856716000 SPRING SWPAPIE0.5
M491 4854937711 BUTTON ABSBK
M491A 7178301212 SCREWTAPPTITE TT2WAS 3X12 MFZNBK
M501 4855058702 DECOCTRL PVCT0.25
M551 4855535401 DECOSENSOR PMMACL
M551A 7178301212 SCREWTAPPTITE TT2WAS 3X12 MFZNBK
M561 48556174SD MARKBRAND SILVERDIA-CUTTING
M681 4856812001 TIECABLE NYLON66DA100
M685 4856816300 CLAMPWIRE NYLON6 (V0)
M781 4857820001 CLOTHBLACK CLOTH320X12X0.5
M791 4857923300 DOORLOCK LA701(KIFCO)
SP01 48A8304800 SPEAKERSYSTEM SS-78128F0410W 8 OHM
SP01A 7172401412 SCREWTAPPTITE TT2TRS 4X14 MFZNBK
V901 4859629160 CRT A68KTB259X001P38
ZZ200 PTFMSJJ752 MASKFRONTAS DTQ-29G4FS
M201 4852066501 MASKFRONT HIPSBK
ZZ203 PTCTMSJ752 PCBCONTROLMANUAL A DTQ-29G4FS
DF01 DKLR114L-- LED KLR114L
IL01 1TS0P1238W ICPREAMP TS0P1238WI1
JP01 4859102130 JACKEARPHONE YSC-1537
JP02 4859108450 JACKPINBOARD YSC03P-4120-14A
M351 4853530901 HOLDERLED P.P
M381 4853816400 FRAMESUBPCB FR HIPS BK
M683 4856812001 TIECABLE NYLON66DA100
PA907 4850706S01 CONNECTOR YH025-
06+YST025+ULW=200
PA908 4850709S01 CONNECTOR YH025-
09+YST025+ULW=200
SW12 5S50101035 SWTACT KPT-1112 1C-1P
ZZ200 PTCTJRJ752 PCBCONTROLRADIAL A DTQ-29G4FS
C201 CEXF1H229V CELECTRO 50VRSS 2.2MF (5X11)TP
C202 CEXF1H229V CELECTRO 50VRSS 2.2MF (5X11)TP
C203 CEXF1H470V CELECTRO 50VRSS 47MF (6.3X11)TP
C204 CEXF1H470V CELECTRO 50VRSS 47MF (6.3X11)TP
C205 CEXF1C331V CELECTRO 16VRSS 330MF (8X11.5)TP
SW07 5S50101090 SWTACT THVH472GCA
SW08 5S50101090 SWTACT THVH472GCA
SW09 5S50101090 SWTACT THVH472GCA
SW10 5S50101090 SWTACT THVH472GCA
SW11 5S50101090 SWTACT THVH472GCA
ZZ200 PTCTJAJ752 PCBCONTROLAXIAL AS DTQ-29G4FS
10 2TM14006LB TAPEMASKING 3M #232 6.0X2000M
20 2TM10006LB TAPEMASKING 3M #232-MAP-C 6.2X2000M
A001 4859833014 PCBCONTROL 56X246(246X246/1X4)
J298 85801065GY WIRECOPPER AWG221/0.65 TIN COATING
J299 85801065GY WIRECOPPER AWG221/0.65 TIN COATING
R201 RD-4Z300J- RCARBONFILM 1/4 30OHMJ
R202 RD-4Z300J- RCARBONFILM 1/4 30OHMJ
R203 RD-4Z474J- RCARBONFILM 1/4 470KOHMJ
R204 RD-4Z474J- RCARBONFILM 1/4 470KOHMJ
R206 RD-4Z181J- RCARBONFILM 1/4 180OHMJ
R207 RD-2Z221J- RCARBONFILM 1/2 220OHMJ
R208 RD-2Z221J- RCARBONFILM 1/2 220OHMJ
R209 RD-4Z302J- RCARBONFILM 1/4 3KOHMJ
R211 RD-4Z242J- RCARBONFILM 1/4 2.4KOHMJ
R212 RD-4Z152J- RCARBONFILM 1/4 1.5KOHMJ
R213 RD-4Z821J- RCARBONFILM 1/4 820OHMJ
R214 RD-4Z681J- RCARBONFILM 1/4 680OHMJ
R215 RD-4Z681J- RCARBONFILM 1/4 680OHMJ
R216 RD-4Z101J- RCARBONFILM 1/4 100OHMJ
R217 RD-4Z750J- RCARBONFILM 1/4 75OHMJ
ZZ290 PTMPMSJ752 PCBMAINMANUAL AS DTQ-29G4FS
C307 CEYF1V332V CELECTRO 35V RSS3300MF(18X35.5)
C404 CMYH3C822J CMYLAR 1.6KV BUP8200PFJ
C405 CMYH3C912J CMYLAR 1.6KV BUP9100PFJ
C406 CMXE2J333J CMYLAR 630V PU 0.033MFJ(TP)
C420 CMYE2D514J CMYLAR 200V PU 0.51MFJ
C422 CEYD1H689W CELECTRO 50V RHD 6.8MF(16X35.5)
C636 CEYF1V332V CELECTRO 35V RSS3300MF(18X35.5)
C801 CL1JB3104M CLINE ACROSS AC250V0.1MFMECQ-UV
WRL
C802 CEYD2G331D CELECTRO 400V FHS330MF(35X35)
C809 CEYN2D221T CELECTRO 200V FWS220MF(22X30)
C814 CBYB3D152K CCERASEMI 2KV BL(N)1500PFK
C815 CEYF1V222V CELECTRO 35V RSS2200MF(16X31.5)
C825 CH1AFE472M CCERAAC 4KV4700PFM KXDE1610
C827 CH1BFB471K CCERAAC AC400V470PFKSD
C831 CEYF1V332V CELECTRO 35V RSS3300MF(18X35.5)
C832 CCYR3D681K CCERA 2KV R 680PFK125 DE1007
C910 4SG0D00103 SPARKGAP S-23900V-1.5KV
C911 4SG0D00103 SPARKGAP S-23900V-1.5KV
C912 4SG0D00103 SPARKGAP S-23900V-1.5KV
COMB1 5PUGL349KN FILTERCOMB UGL-349KNT
D401 DDG3------ DIODE DG3
D402 DRGP30J--- DIODE RGP30J
D406 DRGP30J--- DIODE RGP30J
D801 PTC1SW8902 HEATSINKASS`Y DPBS606GU- + 7174300811
D801 DPBS606GU- DIODEBRIDGE PBS606G
D801A 4857018902 HEATSINK A1050P-H24
D801B 7174300811 SCREWTAPPTITE TT2RND 3X8 MFZN
D804 PTZ2SW5200 HEATSINKASS`Y DFMLG16S-- [phone]
1DFMLG16S-- DIODE FML-G16S
0000A 4857025200 HEATSINK SPCCT1.0 DG
0000B 7174300811 SCREWTAPPTITE TT2RND 3X8 MFZN
D808 DEGP50D--- DIODE EGP50D(TAPPING)
F801 5FKGB6323L FUSEGLASSTUBE KS MF51 6.3A125/250VTL
I301 PTE2SW8200 HEATSINKASS`Y 1LA7845N-- + 7174301011
I301 1LA7845N-- IC LA7845N
I301A 4857028200 HEATSINK ALEX BK
I301B 7174301011 SCREWTAPPTITE TT2RND 3X10 MFZN
I501 1LA76070A- ICVIDEOPROCESSOR LA76070A
I502 1LA7956--- IC LA7956
I503 1LA7956--- IC LA7956
I504 1TC4053BP- IC TC4053BP
I601 1TDA9852-- ICAUDIOPROCESSOR TDA9852
I602 PTA2SW3332 HEATSINKASS`Y 1LA4282--- + 7174301011
11LA4282--- IC LA4282
0000A 4857023332 HEATSINK ALEX
0000B 7174301011 SCREWTAPPTITE TT2RND 3X10 MFZN
I701 1DW8647DM1 ICMICOM DW864732V-DM1(5N74)
I702 1AT24C08PC IC AT24C08-10PC
I801 PTB2SW7900 HEATSINKASS`Y 1STRF6656- + 7174300811
I801 1STRF6656- ICPOWER STR-F6656
I801A 4857027900 HEATSINK ALEX BK
I801B 7174301011 SCREWTAPPTITE TT2RND 3X10 MFZN
I802 1KA78R08-- ICREGULATOR KA78R08
I803 1PQ3RF23-- ICREGULATOR PQ3RF23
I804 TX0202DA-- THYRISTOR X0202DA1BA2
I805 1K1A7806P1 ICREGULATOR KIA7806API
I807 4850M04810 MODULEPOWER DPM011TI
IP01 1M65617SP- ICPIP M65617SP
LOC PARTCODE PARTNAME PARTDESCRIPTION
JP03 4859109250 JACKPINBOARD PH-JB-9614A
JP04 4859109250 JACKPINBOARD PH-JB-9614A
L101 58C5580019 COILCHOKE TRF-9225(0.55UH)
L401 58H1600022 COILH-LINEARITY TRL-2093
L402 58W0000018 COILWIDTH TLN-2092
L403 58C7070085 COILCHOKE TLN-3062A
L502 58N0000037 COILVCO TRF-V004
L503 58S0000045 COILSIF TRF-S001
L801 5PTLF3024- FILTERLINE TLF-3024
L807 58C0000107 COILCHOKE L-680
M682 4856812001 TIECABLE NYLON66DA100
P901 4850703S20 CONNECTOR YH025-
03+YST025+ULW=400
P902 4850705S04 CONNECTOR YH025-
05+YST025+ULW=400
P903 4859238620 CONNWAFER YPW500-02
PWC1 PTWASW0910 CORDPOWERASS`Y 4859901111+ 4857417700
PW000 4859901111 CORDPOWER KKP-419CKLCE-2F (2.1ME)
PW001 4857417700 TERMCLAMP PT-01-T3
Q401 PTK2SW7602 HEATSINKASS`Y T2SD1880-- [phone]
1T2SD1880-- TR 2SD1880
0000A 4857027602 HEATSINK ALEX
0000B 7174300811 SCREWTAPPTITE TT2 RND3X8MFZN
Q406 PTB2SW7602 HEATSINKASS`Y TKTD2058Y- + 7174301011
1TKTD2058Y- TR KTD2058-Y
0000A 4857027602 HEATSINK ALEX
0000B 7174301011 SCREWTAPPTITE TT2 RND3X10MFZN
0000D 4856215200 WASHER SPCC
Q901 TKTC3229-- TR KTC3229
Q903 TKTC3229-- TR KTC3229
Q905 TKTC3229-- TR KTC3229
R400 RX10T402J- RCEMENT 10W4K OHM JTRIPOD
R414 RF01Y478K- RFUSIBLE 1W0.47 OHMK
R802 RX10T109KS RCEMENT 10W1 OHMKTRIPOD
SMALL
R803 RM02Y108K- RMETALFLAT 2W 0.1 OHMK
RP801 DDC7R0M290 POSISTOR ECPCD7R0M290
RS801 DSVC471D14 VARISTOR SVC471D14A
RTH01 DR320K---- THERMISTOR R-320K
SAW1 5PM1859M-- FILTERSAW M1859M
SCT1 4859302830 SOCKETCRT ISH-02S
T401 50H0000189 FBT FFA94048L
T401A 7178301212 SCREWTAPPTITE TT2 WAS3X12MFZNBK
T402 5TD0000018 TRANSDRIVE THD-120
T801 50M5345B4- TRANSSMPS TSM-5345B4
TU01 4859715630 TUNERVARACTOR TELH9-039A
TU03 4850M02910 MODULERF PH-RF-9505B
UT01 4859003750 PLUGPHONEAS PLUG+CABLE
1365AWG26=150B
X502 4850L03110 RESONATORCERA CSB503F44
X601 4850L03810 RESONATORCERA CSB503F58
X701 5XYR03276C CRYSTALQUARTZ C-001R 32.768000KHZ
20PPM
XP01 5XJ14R31DE CRYSTALQUARTZ HC49S 14.318MHZ 30PPM
16P
Y801 5SC0101325 SWRELAY HR-CR7DC12V
Z502 5PYXT4R5MB FILTERCERA XT4.5MB
ZZ200 PTMPJ2J752 PCBCHIPMOUNT B AS DTQ-29G4FS
CC102 HCBK103KCA CCHIPCERA 50V X7R0.01MFK2012
CC103 HCBK103KCA CCHIPCERA 50V X7R0.01MFK2012
CC106 HCBK103KCA CCHIPCERA 50V X7R0.01MFK2012
CC302 HCTBF479MB CCHIPTANTAL 16V 4.7MFM 3528
CC401 HCQK101JCA CCHIPCERA 50V CH100PFJ 2012
CC501 HCBK103KCA CCHIPCERA 50V X7R0.01MFK2012
CC502 HCBK103KCA CCHIPCERA 50V X7R0.01MFK2012
CC504 HCBK103KCA CCHIPCERA 50V X7R0.01MFK2012
CC510 HCBK333KCA CCHIPCERA 50V X7R0.033MFK2012
CC512 HCQK130JCA CCHIPCERA 50V CH13PFJ 2012
CC515 HCBK103KCA CCHIPCERA 50V X7R0.01MFK2012
CC516 HCBK333KCA CCHIPCERA 50V X7R0.033MFK2012
CC517 HCFK104ZCA CCHIPCERA 50V Y5V0.1MFZ 2012
CC518 HCBK103KCA CCHIPCERA 50V X7R0.01MFK2012
CC524 HCBK103KCA CCHIPCERA 50V X7R0.01MFK2012
CC526 HCBK103KCA CCHIPCERA 50V X7R0.01MFK2012
CC529 HCQK101JCA CCHIPCERA 50V CH100PFJ 2012
CC530 HCQK101JCA CCHIPCERA 50V CH100PFJ 2012
LOC PARTCODE PART NAME PART DESCRIPTION
CC535 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CC538 HCQK561JCA CCHIPCERA 50V CH 560PFJ2012
CC548 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CC549 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CC550 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CC553 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CC602 HCTAF229MB CCHIPTANTAL 16V 2.2MF M3216
CC603 HCBK822KCA CCHIPCERA 50V X7R 8200PFK2012
CC604 HCTBF479MB CCHIPTANTAL 16V 4.7MF M3528
CC606 HCTAF229MB CCHIPTANTAL 16V 2.2MF M3216
CC607 HCTBF100MB CCHIPTANTAL 16V 10MF M3528
CC608 HCTBF100MB CCHIPTANTAL 16V 10MF M3528
CC609 HCTAF109MB CCHIPTANTAL 16V 1MF M3216
CC610 HCTAF109MB CCHIPTANTAL 16V 1MF M3216
CC612 HCTBF100MB CCHIPTANTAL 16V 10MF M3528
CC614 HCTBF479MB CCHIPTANTAL 16V 4.7MF M3528
CC617 HCTAF229MB CCHIPTANTAL 16V 2.2MF M3216
CC618 HCBK822KCA CCHIPCERA 50V X7R 8200PFK2012
CC622 HCTAF229MB CCHIPTANTAL 16V 2.2MF M3216
CC623 HCTBF479MB CCHIPTANTAL 16V 4.7MF M3528
CC624 HCTBF479MB CCHIPTANTAL 16V 4.7MF M3528
CC625 HCTBF100MB CCHIPTANTAL 16V 10MF M3528
CC628 HCTBF479MB CCHIPTANTAL 16V 4.7MF M3528
CC632 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CC637 HCFK104ZCA CCHIPCERA 50V Y5V 0.1MFZ2012
CC701 HCQK180JCA CCHIPCERA 50V CH 18PFJ2012
CC702 HCQK180JCA CCHIPCERA 50V CH 18PFJ2012
CC703 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CC705 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CC707 HCTAF109MB CCHIPTANTAL 16V 1MF M3216
CC708 HCBK332KCA CCHIPCERA 50V X7R 3300PFK2012
CC709 HCTAF229MB CCHIPTANTAL 16V 2.2MF M3216
CC710 HCTAF109MB CCHIPTANTAL 16V 1MF M3216
CC711 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CC712 HCQK221JCA CCHIPCERA 50V CH 220PFJ2012
CC723 HCBH224KCA CCHIPCERA 25V X7R 0.22MFK2012
CC816 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CC817 HCFK104ZCA CCHIPCERA 50V Y5V 0.1MFZ2012
CC901 HCQK271JCA CCHIPCERA 50V CH 270PFJ2012
CC902 HCQK271JCA CCHIPCERA 50V CH 270PFJ2012
CC903 HCQK271JCA CCHIPCERA 50V CH 270PFJ2012
CCP01 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CCP02 HCQK120JCA CCHIPCERA 50V CH 12PFJ2012
CCP03 HCQK100DCA CCHIPCERA 50V CH 10PFD2012
CCP04 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CCP06 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CCP08 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CCP13 HCFK104ZCA CCHIPCERA 50V Y5V 0.1MFZ2012
CCP14 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CCP15 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CCP16 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CCP18 HCFK104ZCA CCHIPCERA 50V Y5V 0.1MFZ2012
CCP19 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CCP20 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CCP23 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CCP25 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CCP28 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CCP29 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CCP30 HCFK104ZCA CCHIPCERA 50V Y5V 0.1MFZ2012
CCP32 HCQK510JCA CCHIPCERA 50V CH 51PFJ2012
CCP33 HCQK750JCA CCHIPCERA 50V CH 75PFJ2012
CCP34 HCFK104ZCA CCHIPCERA 50V Y5V 0.1MFZ2012
CCP36 HCBK103KCA CCHIPCERA 50V X7R 0.01MFK2012
CCP38 HCFK104ZCA CCHIPCERA 50V Y5V 0.1MFZ2012
CCP39 HCQK100DCA CCHIPCERA 50V CH 10PFD2012
CCP41 HCQK470JCA CCHIPCERA 50V CH 47PFJ2012
CCV07 HCFK104ZCA CCHIPCERA 50V Y5V 0.1MFZ2012
JC01 HRFT000-CA RCHIP 1/100 OHM2012
JC02 HRFT000-CA RCHIP 1/100 OHM2012
JC03 HRFT000-CA RCHIP 1/100 OHM2012
JC04 HRFT000-CA RCHIP 1/100 OHM2012
JC05 HRFT000-CA RCHIP 1/100 OHM2012
JC06 HRFT000-CA RCHIP 1/100 OHM2012
JC07 HRFT000-CA RCHIP 1/100 OHM2012
JC08 HRFT000-CA RCHIP 1/100 OHM2012
JC09 HRFT000-CA RCHIP 1/100 OHM2012
JC10 HRFT000-CA RCHIP 1/100 OHM2012
JC11 HRFT000-CA RCHIP 1/100 OHM2012
LOC PARTCODE PARTNAME PARTDESCRIPTION
JC12 HRFT000-CA RCHIP 1/100 OHM 2012
JC14 HRFT000-CA RCHIP 1/100 OHM 2012
JC15 HRF8000-EA RCHIP 1/80 OHM 3216
JC16 HRFT000-CA RCHIP 1/100 OHM 2012
JC17 HRFT000-CA RCHIP 1/100 OHM 2012
JC18 HRFT000-CA RCHIP 1/100 OHM 2012
JC19 HRFT000-CA RCHIP 1/100 OHM 2012
JC20 HRFT000-CA RCHIP 1/100 OHM 2012
JC22 HRFT000-CA RCHIP 1/100 OHM 2012
JC23 HRF8000-EA RCHIP 1/80 OHM 3216
JC24 HRFT000-CA RCHIP 1/100 OHM 2012
JC25 HRFT000-CA RCHIP 1/100 OHM 2012
JC26 HRFT000-CA RCHIP 1/100 OHM 2012
JC27 HRFT000-CA RCHIP 1/100 OHM 2012
JC28 HRFT000-CA RCHIP 1/100 OHM 2012
JC29 HRFT000-CA RCHIP 1/100 OHM 2012
JC30 HRFT000-CA RCHIP 1/100 OHM 2012
JC31 HRFT000-CA RCHIP 1/100 OHM 2012
JC32 HRFT000-CA RCHIP 1/100 OHM 2012
JC33 HRFT000-CA RCHIP 1/100 OHM 2012
JC34 HRFT000-CA RCHIP 1/100 OHM 2012
JC35 HRFT000-CA RCHIP 1/100 OHM 2012
JC36 HRFT000-CA RCHIP 1/100 OHM 2012
JC37 HRFT000-CA RCHIP 1/100 OHM 2012
JC39 HRFT000-CA RCHIP 1/100 OHM 2012
JC40 HRFT000-CA RCHIP 1/100 OHM 2012
JC41 HRF8000-EA RCHIP 1/80 OHM 3216
JC42 HRFT000-CA RCHIP 1/100 OHM 2012
JC44 HRFT000-CA RCHIP 1/100 OHM 2012
JC45 HRFT000-CA RCHIP 1/100 OHM 2012
JC46 HRFT000-CA RCHIP 1/100 OHM 2012
JC47 HRFT000-CA RCHIP 1/100 OHM 2012
JC48 HRFT000-CA RCHIP 1/100 OHM 2012
JC49 HRFT000-CA RCHIP 1/100 OHM 2012
JC50 HRFT000-CA RCHIP 1/100 OHM 2012
JC51 HRFT000-CA RCHIP 1/100 OHM 2012
JC52 HRFT000-CA RCHIP 1/100 OHM 2012
JC53 HRFT000-CA RCHIP 1/100 OHM 2012
JC54 HRFT000-CA RCHIP 1/100 OHM 2012
JC55 HRFT000-CA RCHIP 1/100 OHM 2012
JC56 HRF8000-EA RCHIP 1/80 OHM 3216
JC57 HRFT000-CA RCHIP 1/100 OHM 2012
JC58 HRFT000-CA RCHIP 1/100 OHM 2012
JC60 HRFT000-CA RCHIP 1/100 OHM 2012
JC61 HRFT000-CA RCHIP 1/100 OHM 2012
JC62 HRF8000-EA RCHIP 1/80 OHM 3216
JC63 HRFT000-CA RCHIP 1/100 OHM 2012
JC65 HRF8000-EA RCHIP 1/80 OHM 3216
JC66 HRFT000-CA RCHIP 1/100 OHM 2012
JC67 HRF8000-EA RCHIP 1/80 OHM 3216
JC68 HRF8000-EA RCHIP 1/80 OHM 3216
JC70 HRF8000-EA RCHIP 1/80 OHM 3216
JC71 HRFT000-CA RCHIP 1/100 OHM 2012
JC72 HRFT000-CA RCHIP 1/100 OHM 2012
JC73 HRF8000-EA RCHIP 1/80 OHM 3216
JC74 HRFT000-CA RCHIP 1/100 OHM 2012
JC75 HRFT000-CA RCHIP 1/100 OHM 2012
JC76 HRFT000-CA RCHIP 1/100 OHM 2012
JC77 HRFT000-CA RCHIP 1/100 OHM 2012
JC78 HRFT000-CA RCHIP 1/100 OHM 2012
JC79 HRFT000-CA RCHIP 1/100 OHM 2012
JC80 HRFT000-CA RCHIP 1/100 OHM 2012
JC81 HRFT000-CA RCHIP 1/100 OHM 2012
JC83 HRFT000-CA RCHIP 1/100 OHM 2012
JC84 HRFT000-CA RCHIP 1/100 OHM 2012
JC85 HRFT000-CA RCHIP 1/100 OHM 2012
JC86 HRFT000-CA RCHIP 1/100 OHM 2012
JC87 HRFT000-CA RCHIP 1/100 OHM 2012
JC88 HRFT000-CA RCHIP 1/100 OHM 2012
JC89 HRF8000-EA RCHIP 1/80 OHM 3216
JC90 HRF8000-EA RCHIP 1/80 OHM 3216
QC501 T2SA1037KB TRCHIP 2SA1037AKT146-R
QC503 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC504 T2SA1037KB TRCHIP 2SA1037AKT146-R
QC505 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC506 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC507 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC508 T2SC2412KB TRCHIP 2SC2412K-T146-BR
LOC PARTCODE PARTNAME PART DESCRIPTION
QC601 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC602 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC603 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC701 T2SA1037KB TRCHIP 2SA1037AKT146-R
QC702 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC703 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC704 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC705 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC805 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC809 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC901 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC902 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC904 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC906 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QC907 T2SA1037KB TRCHIP 2SA1037AKT146-R
QCP01 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QCP02 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QCP03 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QCP04 T2SC2412KB TRCHIP 2SC2412K-T146-BR
QCV01 T2SC2412KB TRCHIP 2SC2412K-T146-BR
RC102 HRFT102JCA RCHIP 1/101K OHMJ2012
RC103 HRFT102JCA RCHIP 1/101K OHMJ2012
RC104 HRFT102JCA RCHIP 1/101K OHMJ2012
RC301 HRFT682JCA RCHIP 1/106.8K OHMJ2012
RC303 HRFT153JCA RCHIP 1/1015K OHMJ2012
RC304 HRFT913JCA RCHIP 1/1091K OHMJ2012
RC305 HRFT273JCA RCHIP 1/1027K OHMJ2012
RC307 HRFT123JCA RCHIP 1/1012K OHMJ2012
RC308 HRFT183JCA RCHIP 1/1018K OHMJ2012
RC309 HRFT623JCA RCHIP 1/1062K OHMJ2012
RC404 HRFT331JCA RCHIP 1/10330 OHMJ2012
RC405 HRFT511JCA RCHIP 1/10510 OHMJ2012
RC412 HRFT363JCA RCHIP 1/1036K OHMJ2012
RC413 HRFT223JCA RCHIP 1/1022K OHMJ2012
RC415 HRFT222JCA RCHIP 1/102.2K OHMJ2012
RC416 HRFT203JCA RCHIP 1/1020K OHMJ2012
RC417 HRFT822JCA RCHIP 1/108.2K OHMJ2012
RC420 HRFT562JCA RCHIP 1/105.6K OHMJ2012
RC422 HRFT103JCA RCHIP 1/1010K OHMJ2012
RC423 HRFT244JCA RCHIP 1/10240K OHMJ2012
RC424 HRFT823JCA RCHIP 1/1082K OHMJ2012
RC425 HRFT752JCA RCHIP 1/107.5K OHMJ2012
RC426 HRFT479JCA RCHIP 1/104.7 OHMJ2012
RC428 HRFT393JCA RCHIP 1/1039K OHMJ2012
RC429 HRFT102JCA RCHIP 1/101K OHMJ2012
RC432 HRFT362JCA RCHIP 1/103.6K OHMJ2012
RC433 HRFT332JCA RCHIP 1/103.3K OHMJ2012
RC434 HRFT472JCA RCHIP 1/104.7K OHMJ2012
RC502 HRFT303JCA RCHIP 1/1030K OHMJ2012
RC503 HRFT124JCA RCHIP 1/10120K OHMJ2012
RC504 HRFT393JCA RCHIP 1/1039K OHMJ2012
RC505 HRFT823JCA RCHIP 1/1082K OHMJ2012
RC506 HRFT622JCA RCHIP 1/106.2K OHMJ2012
RC507 HRFT272JCA RCHIP 1/102.7K OHMJ2012
RC508 HRFT824JCA RCHIP 1/10820K OHMJ2012
RC510 HRFT182JCA RCHIP 1/101.8K OHMJ2012
RC512 HRFT222JCA RCHIP 1/102.2K OHMJ2012
RC513 HRFT750JCA RCHIP 1/1075 OHM J2012
RC514 HRFT183JCA RCHIP 1/1018K OHMJ2012
RC515 HRFT333JCA RCHIP 1/1033K OHMJ2012
RC516 HRFT363JCA RCHIP 1/1036K OHMJ2012
RC517 HRFT122JCA RCHIP 1/101.2K OHMJ2012
RC519 HRFT151JCA RCHIP 1/10150 OHMJ2012
RC520 HRFT681JCA RCHIP 1/10680 OHMJ2012
RC521 HRFT331JCA RCHIP 1/10330 OHMJ2012
RC522 HRFT102JCA RCHIP 1/101K OHMJ2012
RC523 HRFT102JCA RCHIP 1/101K OHMJ2012
RC524 HRFT102JCA RCHIP 1/101K OHMJ2012
RC525 HRFT102JCA RCHIP 1/101K OHMJ2012
RC526 HRFT102JCA RCHIP 1/101K OHMJ2012
RC528 HRFT102JCA RCHIP 1/101K OHMJ2012
RC529 HRFT684JCA RCHIP 1/10680K OHMJ2012
RC530 HRFT394JCA RCHIP 1/10390K OHMJ2012
RC532 HRFT561JCA RCHIP 1/10560 OHMJ2012
RC533 HRFT564JCA RCHIP 1/10560K OHMJ2012
RC535 HRFT304JCA RCHIP 1/10300K OHMJ2012
RC537 HRFT000-CA RCHIP 1/100 OHM2012
RC538 HRFT331JCA RCHIP 1/10330 OHMJ2012
LOC PARTCODE PART NAME PART DESCRIPTION
Electrical Parts List

RC539 HRFT331JCA RCHIP 1/10330 OHMJ2012
RC540 HRFT331JCA RCHIP 1/10330 OHMJ2012
RC543 HRFT824JCA RCHIP 1/10820K OHM J2012
RC546 HRFT824JCA RCHIP 1/10820K OHM J2012
RC547 HRFT131JCA RCHIP 1/10130 OHMJ2012
RC548 HRFT102JCA RCHIP 1/101K OHMJ2012
RC549 HRFT102JCA RCHIP 1/101K OHMJ2012
RC553 HRFT561JCA RCHIP 1/10560 OHMJ2012
RC554 HRFT102JCA RCHIP 1/101K OHMJ2012
RC555 HRFT102JCA RCHIP 1/101K OHMJ2012
RC556 HRFT102JCA RCHIP 1/101K OHMJ2012
RC557 HRFT472JCA RCHIP 1/104.7K OHMJ2012
RC558 HRFT102JCA RCHIP 1/101K OHMJ2012
RC559 HRFT472JCA RCHIP 1/104.7K OHMJ2012
RC560 HRFT472JCA RCHIP 1/104.7K OHMJ2012
RC561 HRFT472JCA RCHIP 1/104.7K OHMJ2012
RC562 HRFT472JCA RCHIP 1/104.7K OHMJ2012
RC563 HRFT102JCA RCHIP 1/101K OHMJ2012
RC564 HRFT472JCA RCHIP 1/104.7K OHMJ2012
RC565 HRFT103JCA RCHIP 1/1010K OHM J2012
RC566 HRFT103JCA RCHIP 1/1010K OHM J2012
RC567 HRFT103JCA RCHIP 1/1010K OHM J2012
RC570 HRFT911JCA RCHIP 1/10910 OHMJ2012
RC571 HRFT112JCA RCHIP 1/101.1K OHMJ2012
RC601 HRFT203JCA RCHIP 1/1020K OHM J2012
RC602 HRFT222JCA RCHIP 1/102.2K OHMJ2012
RC603 HRFT822FCA RCHIP 1/108.2K OHMF2012
RC604 HRFT161FCA RCHIP 1/10160 OHMF2012
RC605 HRFT102JCA RCHIP 1/101K OHMJ2012
RC606 HRFT102JCA RCHIP 1/101K OHMJ2012
RC607 HRFT102JCA RCHIP 1/101K OHMJ2012
RC608 HRFT102JCA RCHIP 1/101K OHMJ2012
RC610 HRFT222JCA RCHIP 1/102.2K OHMJ2012
RC612 HRFT203JCA RCHIP 1/1020K OHM J2012
RC613 HRFT222JCA RCHIP 1/102.2K OHMJ2012
RC614 HRFT752JCA RCHIP 1/107.5K OHMJ2012
RC620 HRFT102JCA RCHIP 1/101K OHMJ2012
RC621 HRFT102JCA RCHIP 1/101K OHMJ2012
RC622 HRFT102JCA RCHIP 1/101K OHMJ2012
RC623 HRFT102JCA RCHIP 1/101K OHMJ2012
RC624 HRFT473JCA RCHIP 1/1047K OHM J2012
RC626 HRFT162JCA RCHIP 1/101.6K OHMJ2012
RC627 HRFT162JCA RCHIP 1/101.6K OHMJ2012
RC701 HRFT101JCA RCHIP 1/10100 OHMJ2012
RC702 HRFT150JCA RCHIP 1/1015 OHMJ2012
RC703 HRFT101JCA RCHIP 1/10100 OHMJ2012
RC704 HRFT101JCA RCHIP 1/10100 OHMJ2012
RC705 HRFT102JCA RCHIP 1/101K OHMJ2012
RC706 HRFT102JCA RCHIP 1/101K OHMJ2012
RC707 HRFT102JCA RCHIP 1/101K OHMJ2012
RC709 HRFT472JCA RCHIP 1/104.7K OHMJ2012
RC710 HRFT472JCA RCHIP 1/104.7K OHMJ2012
RC711 HRFT472JCA RCHIP 1/104.7K OHMJ2012
RC712 HRFT821JCA RCHIP 1/10820 OHMJ2012
RC713 HRFT101JCA RCHIP 1/10100 OHMJ2012
RC714 HRFT101JCA RCHIP 1/10100 OHMJ2012
RC715 HRFT514JCA RCHIP 1/10510K OHM J2012
RC716 HRFT471JCA RCHIP 1/10470 OHMJ2012
RC717 HRFT103JCA RCHIP 1/1010K OHM J2012
RC718 HRFT103JCA RCHIP 1/1010K OHM J2012
RC719 HRFT102JCA RCHIP 1/101K OHMJ2012
RC720 HRFT101JCA RCHIP 1/10100 OHMJ2012
RC721 HRFT103JCA RCHIP 1/1010K OHM J2012
RC722 HRFT105JCA RCHIP 1/101M OHM J2012
RC723 HRFT102JCA RCHIP 1/101K OHMJ2012
RC725 HRFT102JCA RCHIP 1/101K OHMJ2012
RC726 HRFT103JCA RCHIP 1/1010K OHM J2012
RC727 HRFT473JCA RCHIP 1/1047K OHM J2012
RC728 HRFT103JCA RCHIP 1/1010K OHM J2012
RC729 HRFT623JCA RCHIP 1/1062K OHM J2012
RC730 HRFT163JCA RCHIP 1/1016K OHM J2012
RC731 HRFT472JCA RCHIP 1/104.7K OHMJ2012
RC732 HRFT102JCA RCHIP 1/101K OHMJ2012
RC733 HRFT131JCA RCHIP 1/10130 OHMJ2012
RC734 HRFT102JCA RCHIP 1/101K OHMJ2012
RC735 HRFT102JCA RCHIP 1/101K OHMJ2012
RC736 HRFT131JCA RCHIP 1/10130 OHMJ2012
RC737 HRFT102JCA RCHIP 1/101K OHMJ2012
LOC PARTCODE PARTNAME PART DESCRIPTION
RC738 HRFT131JCA RCHIP 1/10 130 OHMJ2012
RC745 HRFT102JCA RCHIP 1/10 1K OHMJ2012
RC746 HRFT102JCA RCHIP 1/10 1K OHMJ2012
RC747 HRFT103JCA RCHIP 1/10 10K OHMJ2012
RC819 HRFT102JCA RCHIP 1/10 1K OHMJ2012
RC820 HRFT434JCA RCHIP 1/10 430K OHMJ2012
RC822 HRFT684JCA RCHIP 1/10 680K OHMJ2012
RC830 HRFT303JCA RCHIP 1/10 30K OHMJ2012
RC832 HRFT101JCA RCHIP 1/10 100 OHMJ2012
RC833 HRFT431JCA RCHIP 1/10 430 OHMJ2012
RC834 HRFT103JCA RCHIP 1/10 10K OHMJ2012
RC842 HRFT102JCA RCHIP 1/10 1K OHMJ2012
RC901 HRFT103JCA RCHIP 1/10 10K OHMJ2012
RC903 HRFT471JCA RCHIP 1/10 470 OHMJ2012
RC904 HRFT471JCA RCHIP 1/10 470 OHMJ2012
RC905 HRFT181JCA RCHIP 1/10 180 OHMJ2012
RC906 HRFT121JCA RCHIP 1/10 120 OHMJ2012
RC909 HRFT471JCA RCHIP 1/10 470 OHMJ2012
RC910 HRFT471JCA RCHIP 1/10 470 OHMJ2012
RC911 HRFT181JCA RCHIP 1/10 180 OHMJ2012
RC912 HRFT121JCA RCHIP 1/10 120 OHMJ2012
RC915 HRFT471JCA RCHIP 1/10 470 OHMJ2012
RC916 HRFT471JCA RCHIP 1/10 470 OHMJ2012
RC917 HRFT181JCA RCHIP 1/10 180 OHMJ2012
RC918 HRFT121JCA RCHIP 1/10 120 OHMJ2012
RC919 HRFT561JCA RCHIP 1/10 560 OHMJ2012
RC920 HRFT122JCA RCHIP 1/10 1.2K OHMJ2012
RC921 HRFT221JCA RCHIP 1/10 220 OHMJ2012
RCA01 HRFT474JCA RCHIP 1/10 470K OHMJ2012
RCA02 HRFT474JCA RCHIP 1/10 470K OHMJ2012
RCA03 HRFT300JCA RCHIP 1/10 30 OHMJ2012
RCA04 HRFT300JCA RCHIP 1/10 30 OHMJ2012
RCA05 HRFT224JCA RCHIP 1/10 220K OHMJ2012
RCA06 HRFT331JCA RCHIP 1/10 330 OHMJ2012
RCA07 HRFT331JCA RCHIP 1/10 330 OHMJ2012
RCA08 HRFT224JCA RCHIP 1/10 220K OHMJ2012
RCP01 HRFT301JCA RCHIP 1/10 300 OHMJ2012
RCP02 HRFT104JCA RCHIP 1/10 100K OHMJ2012
RCP03 HRFT202JCA RCHIP 1/10 2K OHMJ2012
RCP04 HRFT824JCA RCHIP 1/10 820K OHMJ2012
RCP05 HRFT222JCA RCHIP 1/10 2.2K OHMJ2012
RCP06 HRFT153JCA RCHIP 1/10 15K OHMJ2012
RCP07 HRFT153JCA RCHIP 1/10 15K OHMJ2012
RCP08 HRFT101JCA RCHIP 1/10 100 OHMJ2012
RCP09 HRFT101JCA RCHIP 1/10 100 OHMJ2012
RCP10 HRFT101JCA RCHIP 1/10 100 OHMJ2012
RCP12 HRFT123JCA RCHIP 1/10 12K OHMJ2012
RCP13 HRFT104JCA RCHIP 1/10 100K OHMJ2012
RCP14 HRFT103JCA RCHIP 1/10 10K OHMJ2012
RCP15 HRFT202JCA RCHIP 1/10 2K OHMJ2012
RCP16 HRFT102JCA RCHIP 1/10 1K OHMJ2012
RCP17 HRFT153JCA RCHIP 1/10 15K OHMJ2012
RCP18 HRFT202JCA RCHIP 1/10 2K OHMJ2012
RCP19 HRFT202JCA RCHIP 1/10 2K OHMJ2012
RCP20 HRFT153JCA RCHIP 1/10 15K OHMJ2012
RCP21 HRFT153JCA RCHIP 1/10 15K OHMJ2012
RCP22 HRFT102JCA RCHIP 1/10 1K OHMJ2012
RCP23 HRFT511JCA RCHIP 1/10 510 OHMJ2012
RCP24 HRFT304JCA RCHIP 1/10 300K OHMJ2012
RCP25 HRFT304JCA RCHIP 1/10 300K OHMJ2012
RCP26 HRFT103JCA RCHIP 1/10 10K OHMJ2012
RCP40 HRFT102JCA RCHIP 1/10 1K OHMJ2012
RCP41 HRFT681JCA RCHIP 1/10 680 OHMJ2012
RCV01 HRFT750JCA RCHIP 1/10 75 OHMJ2012
RCV02 HRFT101JCA RCHIP 1/10 100 OHMJ2012
RCV03 HRFT680JCA RCHIP 1/10 68 OHMJ2012
RCV05 HRFT512JCA RCHIP 1/10 5.1K OHMJ2012
RCV06 HRFT302JCA RCHIP 1/10 3K OHMJ2012
RCV07 HRFT100JCA RCHIP 1/10 10 OHMJ2012
ZZ200 PTMPJ0J752 PCBMAIN(RHU) AS DTQ-29G4FS
C104 CEXF1C102V CELECTRO 16V RSS1000MF(10X20)TP
C311 CEXF1V471V CELECTRO 35V RSS470MF(10X20)TP
C409 CEXF2E479V CELECTRO 250V RSS 4.7MF(10X16)TP
C413 CEXF1C102V CELECTRO 16V RSS1000MF(10X20)TP
C415 CEXF1C102V CELECTRO 16V RSS1000MF(10X20)TP
C419 CMXE2D683J CMYLAR 200V PU 0.068MFJ(TP)
C503 CEXF1C102V CELECTRO 16V RSS1000MF(10X20)TP
C525 CEXF1C102V CELECTRO 16V RSS1000MF(10X20)TP
LOC PARTCODE PARTNAME PARTDESCRIPTION
C614 CEXF1V102V CELECTRO 35VRSS 1000MF(13X25)TP
C615 CEXF1V102V CELECTRO 35VRSS 1000MF(13X25)TP
C803 CH1BEE472M CCERAAC U/C/V 2.5KV4700PFTP
C804 CH1BEE472M CCERAAC U/C/V 2.5KV4700PFTP
C811 CBXB3D471K CCERASEMI 2KV BL(N)470PFK (T)
C823 CEXF1C102V CELECTRO 16VRSS 1000MF(10X20)TP
C828 CEXF2C101C CELECTRO 160VRUS 100MF(16X25)TP
C908 CCXB3D102K CCERA 2KVB 1000PFK(TAPPING)
ZZ200 PTMPJBJ752 PCBMAINM-10 AS DTQ-29G4FS
10 2TM18006BE TAPEMASKING 6.2X500
E001 4856310600 EYELET BSRT0.2 (R2.3)
E002 4856310300 EYELET BSRT0.2 (R1.6)
E003 4856310600 EYELET BSRT0.2 (R2.3)
E004 4856310600 EYELET BSRT0.2 (R2.3)
E005 4856310600 EYELET BSRT0.2 (R2.3)
E006 4856310600 EYELET BSRT0.2 (R2.3)
E007 4856310600 EYELET BSRT0.2 (R2.3)
E008 4856310600 EYELET BSRT0.2 (R2.3)
E009 4856310600 EYELET BSRT0.2 (R2.3)
E010 4856310600 EYELET BSRT0.2 (R2.3)
E011 4856310300 EYELET BSRT0.2 (R1.6)
E012 4856310600 EYELET BSRT0.2 (R2.3)
E013 4856310600 EYELET BSRT0.2 (R2.3)
E014 4856310600 EYELET BSRT0.2 (R2.3)
E015 4856310600 EYELET BSRT0.2 (R2.3)
E016 4856310600 EYELET BSRT0.2 (R2.3)
E017 4856310600 EYELET BSRT0.2 (R2.3)
E018 4856310600 EYELET BSRT0.2 (R2.3)
E019 4856310600 EYELET BSRT0.2 (R2.3)
E020 4856310600 EYELET BSRT0.2 (R2.3)
E021 4856310600 EYELET BSRT0.2 (R2.3)
E022 4856310300 EYELET BSRT0.2 (R1.6)
E023 4856310300 EYELET BSRT0.2 (R1.6)
E024 4856310300 EYELET BSRT0.2 (R1.6)
E025 4856310600 EYELET BSRT0.2 (R2.3)
E026 4856310300 EYELET BSRT0.2 (R1.6)
E027 4856310300 EYELET BSRT0.2 (R1.6)
E028 4856310300 EYELET BSRT0.2 (R1.6)
E029 4856310300 EYELET BSRT0.2 (R1.6)
E030 4856310600 EYELET BSRT0.2 (R2.3)
E031 4856310300 EYELET BSRT0.2 (R1.6)
E032 4856310300 EYELET BSRT0.2 (R1.6)
E033 4856310600 EYELET BSRT0.2 (R2.3)
E034 4856310600 EYELET BSRT0.2 (R2.3)
E035 4856310600 EYELET BSRT0.2 (R2.3)
E036 4856310300 EYELET BSRT0.2 (R1.6)
E037 4856310300 EYELET BSRT0.2 (R1.6)
E038 4856310300 EYELET BSRT0.2 (R1.6)
E039 4856310300 EYELET BSRT0.2 (R1.6)
E040 4856310300 EYELET BSRT0.2 (R1.6)
E041 4856310300 EYELET BSRT0.2 (R1.6)
E042 4856310300 EYELET BSRT0.2 (R1.6)
E043 4856310300 EYELET BSRT0.2 (R1.6)
E044 4856310300 EYELET BSRT0.2 (R1.6)
E045 4856310300 EYELET BSRT0.2 (R1.6)
E046 4856310300 EYELET BSRT0.2 (R1.6)
E047 4856310300 EYELET BSRT0.2 (R1.6)
E049 4856310300 EYELET BSRT0.2 (R1.6)
E050 4856310600 EYELET BSRT0.2 (R2.3)
E051 4856310300 EYELET BSRT0.2 (R1.6)
E052 4856310600 EYELET BSRT0.2 (R2.3)
E053 4856310300 EYELET BSRT0.2 (R1.6)
E054 4856310600 EYELET BSRT0.2 (R2.3)
E055 4856310600 EYELET BSRT0.2 (R2.3)
E056 4856310300 EYELET BSRT0.2 (R1.6)
E057 4856310600 EYELET BSRT0.2 (R2.3)
E058 4856310600 EYELET BSRT0.2 (R2.3)
E059 4856310600 EYELET BSRT0.2 (R2.3)
E060 4856310600 EYELET BSRT0.2 (R2.3)
N001 4857417500 TERMPIN DA-IB0214(D2.3/DYPIN)
N002 4857417500 TERMPIN DA-IB0214(D2.3/DYPIN)
N003 4857417500 TERMPIN DA-IB0214(D2.3/DYPIN)
N004 4857417500 TERMPIN DA-IB0214(D2.3/DYPIN)
N006 4857417500 TERMPIN DA-IB0214(D2.3/DYPIN)
N007 4857417500 TERMPIN DA-IB0214(D2.3/DYPIN)
P101 485923522S CONNWAFER YW025-09(STICK)
P102 485923162S CONNWAFER YW025-03(STICK)
P601 485923172S CONNWAFER YW025-04(STICK)
LOC PARTCODE PART NAME PART DESCRIPTION
P907 485923192S CONNWAFER YW025-06 (STICK)
P908 485923522S CONNWAFER YW025-09 (STICK)
PA901 485923162S CONNWAFER YW025-03 (STICK)
PA902 485923182S CONNWAFER YW025-05 (STICK)
R302 RS02Z109JS RM-OXIDEFILM 2W 1 OHMJSMALL
R306 RS02Z109JS RM-OXIDEFILM 2W 1 OHMJSMALL
R314 RS02Z620JS RM-OXIDEFILM 2W 62 OHMJSMALL
R315 RS02Z561JS RM-OXIDEFILM 2W 560 OHMJSMALL
R316 RF01Z229J- RFUSIBLE 1W2.2 OHMJ(TAPPING)
R407 RF01Z100J- RFUSIBLE 1W10 OHM J(TAPPING)
R408 RF01Z241J- RFUSIBLE 1W240 OHM J(TAPPING)
R409 RF01Z399J- RFUSIBLE 1W3.9 OHMJ(TAPPING)
R415 RS02Z103JS RM-OXIDEFILM 2W 10K OHMJSMALL
R430 RS02Z102JS RM-OXIDEFILM 2W 1K OHMJSMALL
R435 RS02Z100JS RM-OXIDEFILM 2W 10 OHMJSMALL
R601 RS02Z209JS RM-OXIDEFILM 2W 2 OHMJSMALL
R602 RS02Z209JS RM-OXIDEFILM 2W 2 OHMJSMALL
R810 RF01Z228K- RFUSIBLE 1W0.22 OHM K(TAPPING)
R817 RF01Z518K- RFUSIBLE 1W0.51 OHM K(TAPPING)
R818 RF01Z518K- RFUSIBLE 1W0.51 OHM K(TAPPING)
R836 RS02Z279JS RM-OXIDEFILM 2W 2.7OHMJSMALL
R902 RS02Z123JS RM-OXIDEFILM 2W 12K 0HMJSMALL
R908 RS02Z123JS RM-OXIDEFILM 2W 12K 0HMJSMALL
R914 RS02Z123JS RM-OXIDEFILM 2W 12K 0HMJSMALL
ZZ200 PTMPJRJ752 PCBMAINRADIAL AS DTQ-29G4FS
C101 CEXF1H109V CELECTRO 50VRSS 1MF (5X11)TP
C105 CEXF1E101V CELECTRO 25VRSS 100MF (6.3X11)TP
C107 CEXF1H229V CELECTRO 50VRSS 2.2MF (5X11)TP
C301 CMXB1H103J CMYLAR 50VEU 0.01MF J(TP)
C303 CEXF1H101V CELECTRO 50VRSS 100MF (8X11.5)TP
C304 CMXL1J224J CMYLAR 63VMEU 0.22MF J(TP)
C305 CEXF1H100V CELECTRO 50VRSS 10MF (5X11)TP
C306 CEXF1H478V CELECTRO 50VRSS 0.47MF (5X11)TP
C308 CMXB1H473J CMYLAR 50V0.047MF J(TP)
C309 CXSL2H100D CCERA 500VSL 10PF D(TAPPING)
C310 CCXB2H102K CCERA 500VB 1000PF K(TAPPING)
C312 CEXD1H109Q CELECTRO 50VRT 1MF(6.3X11)TP
C402 CEXF2C109V CELECTRO 160VRSS 1MF (6.3X11)TP
C403 CCXB2H102K CCERA 500VB 1000PF K(TAPPING)
C408 CCXB2H102K CCERA 500VB 1000PF K(TAPPING)
C410 CEXF1H479V CELECTRO 50VRSS 4.7MF (5X11)TP
C411 CEXF2C109V CELECTRO 160VRSS 1MF (6.3X11)TP
C412 CCXB2H102K CCERA 500VB 1000PF K(TAPPING)
C414 CEXF1H470V CELECTRO 50VRSS 47MF (6.3X11)TP
C417 CMXB1H104J CMYLAR 50VEU 0.1MFJ(TP)
C418 CMXB1H104J CMYLAR 50VEU 0.1MFJ(TP)
C421 CMXM2A104J CMYLAR 100V0.1MF J(TP)
C506 CEXF1H100V CELECTRO 50VRSS 10MF (5X11)TP
C507 CMXB1H473J CMYLAR 50V0.047MF J(TP)
C509 CEXF1H109V CELECTRO 50VRSS 1MF (5X11)TP
C513 CEXF1H228V CELECTRO 50VRSS 0.22MF (5X11)TP
C514 CEXF1H228V CELECTRO 50VRSS 0.22MF (5X11)TP
C515 CEXF1H108V CELECTRO 50VRSS 0.1MF (5X11)TP
C517 CEXF1H109V CELECTRO 50VRSS 1MF (5X11)TP
C519 CEXF1E101V CELECTRO 25VRSS 100MF (6.3X11)TP
C523 CEXF1H339V CELECTRO 50VRSS 3.3MF (5X11)TP
C527 CEXF1H109V CELECTRO 50VRSS 1MF (5X11)TP
C528 CEXF1H478V CELECTRO 50VRSS 0.47MF (5X11)TP
C534 CEXF1H100V CELECTRO 50VRSS 10MF (5X11)TP
C536 CEXF1H100V CELECTRO 50VRSS 10MF (5X11)TP
C537 CEXF1H109V CELECTRO 50VRSS 1MF (5X11)TP
C541 CEXF1H109V CELECTRO 50VRSS 1MF (5X11)TP
C542 CEXF1C331V CELECTRO 16VRSS 330MF (8X11.5)TP
C544 CEXF1H100V CELECTRO 50VRSS 10MF (5X11)TP
C545 CEXF1H478V CELECTRO 50VRSS 0.47MF (5X11)TP
C547 CEXF1C331V CELECTRO 16VRSS 330MF (8X11.5)TP
C549 CEXF1H100V CELECTRO 50VRSS 10MF (5X11)TP
C550 CEXF1H100V CELECTRO 50VRSS 10MF (5X11)TP
C552 CEXF1H220V CELECTRO 50VRSS 22MF (5X11)TP
C601 CMXL1J154J CMYLAR 63VMEU 0.15MF J
C605 CEXF1E101V CELECTRO 25VRSS 100MF (6.3X11)TP
C610 CEXF1E101V CELECTRO 25VRSS 100MF (6.3X11)TP
C611 CMXB1H473J CMYLAR 50V0.047MF J(TP)
C613 CMXB1H104J CMYLAR 50VEU 0.1MFJ(TP)
C616 CMXL1J154J CMYLAR 63VMEU 0.15MF J
C617 CMXB1H104J CMYLAR 50VEU 0.1MFJ(TP)
C618 CMXB1H104J CMYLAR 50VEU 0.1MFJ(TP)
C619 CMXB1H153J CMYLAR 50VEU 0.015MF J(TP)
LOC PARTCODE PARTNAME PART DESCRIPTION
C620 CMXB1H153J CMYLAR 50V EU 0.015MFJ(TP)
C621 CMXB1H103J CMYLAR 50V EU 0.01MFJ(TP)
C622 CEXF1H470V CELECTRO 50V RSS 47MF(6.3X11)TP
C623 CEXF1E101V CELECTRO 25V RSS 100MF(6.3X11)TP
C624 CEXF1H479V CELECTRO 50V RSS 4.7MF(5X11)TP
C625 CMXB1H103J CMYLAR 50V EU 0.01MFJ(TP)
C626 CMXL1J474J CMYLAR 63V MEU 0.47MFJ
C627 CMXL1J224J CMYLAR 63V MEU 0.22MFJ(TP)
C628 CEXF1H479V CELECTRO 50V RSS 4.7MF(5X11)TP
C629 CEXF1E101V CELECTRO 25V RSS 100MF(6.3X11)TP
C630 CEXF1H100V CELECTRO 50V RSS 10MF(5X11)TP
C633 CEXF1E101V CELECTRO 25V RSS 100MF(6.3X11)TP
C637 CEXF1H100V CELECTRO 50V RSS 10MF(5X11)TP
C706 CEXF1C331V CELECTRO 16V RSS 330MF(8X11.5)TP
C805 CEXF2A479V CELECTRO 100V RSS 4.7MF(5X11)TP
C806 CEXF1H470C CELECTRO 50V RUS 47MF(6.3X11)TP
C810 CEXF1E101V CELECTRO 25V RSS 100MF(6.3X11)TP
C817 CEXF1E101V CELECTRO 25V RSS 100MF(6.3X11)TP
C818 CEXF1H109V CELECTRO 50V RSS 1MF(5X11)TP
C820 CEXF1E101V CELECTRO 25V RSS 100MF(6.3X11)TP
C824 CEXF1E101V CELECTRO 25V RSS 100MF(6.3X11)TP
C833 CEXF1E101V CELECTRO 25V RSS 100MF(6.3X11)TP
C834 CEXF1E470V CELECTRO 25V RSS 47MF(5X11)TP
C835 CEXF1E470V CELECTRO 25V RSS 47MF(5X11)TP
CA01 CEXF1H229V CELECTRO 50V RSS 2.2MF(5X11)TP
CA02 CEXF1H229V CELECTRO 50V RSS 2.2MF(5X11)TP
CA03 CEXF1H100V CELECTRO 50V RSS 10MF(5X11)TP
CA04 CEXF1H100V CELECTRO 50V RSS 10MF(5X11)TP
CP04 CMXL1J154J CMYLAR 63V MEU 0.15MFJ
CP05 CMXL1J224J CMYLAR 63V MEU 0.22MFJ(TP)
CP22 CEXF1H100V CELECTRO 50V RSS 10MF(5X11)TP
CP37 CEXF1H108V CELECTRO 50V RSS 0.1MF(5X11)TP
CP38 CEXF1H100V CELECTRO 50V RSS 10MF(5X11)TP
CP39 CEXF1H100V CELECTRO 50V RSS 10MF(5X11)TP
CP40 CEXF1H100V CELECTRO 50V RSS 10MF(5X11)TP
CP42 CEXF1H100V CELECTRO 50V RSS 10MF(5X11)TP
CV01 CEXF1H100V CELECTRO 50V RSS 10MF(5X11)TP
CV02 CEXF1E470V CELECTRO 25V RSS 47MF(5X11)TP
CV03 CEXF1E101V CELECTRO 25V RSS 100MF(6.3X11)TP
CV04 CEXF1C331V CELECTRO 16V RSS 330MF(8X11.5)TP
CV06 CEXF1H100V CELECTRO 50V RSS 10MF(5X11)TP
F801A 4857415001 CLIPFUSE PFC5000-0702
F801B 4857415001 CLIPFUSE PFC5000-0702
ID01 1UPC574J-- IC UPC574J
L602 58C0000116 COILBEAD HC-3550R
L603 58C0000116 COILBEAD HC-3550R
L604 58C0000096 COILCHOKE 610G0233(470K)
L803 58C0000116 COILBEAD HC-3550R
L806 58C0000116 COILBEAD HC-3550R
L808 58C0000116 COILBEAD HC-3550R
Q403 TKTC3207-- TR KTC3207(TP)
Q404 TKTC3198Y- TR KTC3198Y
Q405 TKTA1266Y- TR KTA1266Y(TP)
Q601 TKTC3198Y- TR KTC3198Y
Q801 TKSA1013Y- TR KSA1013Y(TP)
Q806 TKTC3205Y- TR KTC3205Y(TP)
R106 RN02B473JS RMETALFILM 2W 47KOHMJ SMALL
R108 RN02B360JS RMETALFILM 2W 36OHMJ SMALL
R109 RN02B360JS RMETALFILM 2W 36OHMJ SMALL
R110 RN02B391JS RMETALFILM 2W 390OHMJ SMALL
R312 RN02B221JS RMETALFILM 2W 220OHMJ SMALL
R805 RN02B473JS RMETALFILM 2W 47KOHMJ SMALL
R807 RN02B752JS RMETALFILM 2W 7.5KOHMJ SMALL
R808 RN02B222JS RMETALFILM 2W 2.2KOHMJ SMALL
R830 RN01B301JS RMETALFILM 1W 300OHMJ SMALL
R834 RN02B200JS RMETALFILM 2W 20OHMJ SMALL
R835 RN02B200JS RMETALFILM 2W 20OHMJ SMALL
R838 RN02B100JS RMETALFILM 2W 10OHMJ SMALL
R839 RN02B470JS RMETALFILM 2W 47OHMJ SMALL
RV401 RV5426203P RSEMI FIXED EVN-DJAA0320K OHM B
RV402 RV5426203P RSEMI FIXED EVN-DJAA0320K OHM B
X501 5XEX3R579C CRYSTALQUARTZ HC-49U3.579545M (TP)
Z501 5PXLT4R5MH FILTERCERA LT 4.5MH
ZZ200 PTMPJAJ752 PCBMAINAXIAL AS DTQ-29G4FS
10 2TM14006LB TAPEMASKING 3M#232 6.0X2000M
20 2TM10006LB TAPEMASKING 3M#232-MAP-C 6.2X2000M
A001 4859814292 PCBMAIN 330X246
C555 CCZF1H103Z CCERA 50V F 0.01MFZ
LOC PARTCODE PARTNAME PART DESCRIPTION
C556 CCZF1H103Z CCERA 50VF 0.01MF Z
D101 DUZ9R1BM-- DIODEZENER UZ-9.1BM
D102 DUZ5R6BM-- DIODEZENER UZ-5.6BM
D301 D1N4004S-- DIODE 1N4004S
D302 D1N4937G-- DIODE 1N4937G(TAPPING)
D403 D1N4148--- DIODE 1N4148(TAPPING)
D404 D1N4937G-- DIODE 1N4937G(TAPPING)
D405 D1N4937G-- DIODE 1N4937G(TAPPING)
D407 DRGP15J--- DIODE RGP15J
D501 DUZ9R1BM-- DIODEZENER UZ-9.1BM
D504 D1N4148--- DIODE 1N4148(TAPPING)
D505 D1N4148--- DIODE 1N4148(TAPPING)
D602 D1N4148--- DIODE 1N4148(TAPPING)
D605 D1N4148--- DIODE 1N4148(TAPPING)
D701 DUZ3R9B--- DIODEZENER UZ-3.9B
D702 D1N4148--- DIODE 1N4148(TAPPING)
D802 85801065GY WIRECOPPER AWG221/0.65 TINCOATING
D803 DRGP15J--- DIODE RGP15J
D805 DRGP15J--- DIODE RGP15J
D809 DRGP15J--- DIODE RGP15J
D810 D1N4148--- DIODE 1N4148(TAPPING)
D812 D1N4148--- DIODE 1N4148(TAPPING)
D813 DUZ9R1BM-- DIODEZENER UZ-9.1BM
D814 D1N4148--- DIODE 1N4148(TAPPING)
D815 DUZ7R5BM-- DIODEZENER UZ-7.5BM
D816 DRGP15J--- DIODE RGP15J
D818 D1N4148--- DIODE 1N4148(TAPPING)
D819 D1N4148--- DIODE 1N4148(TAPPING)
J001~017 85801065GY WIRECOPPER AWG221/0.65 TINCOATING
J018 RD-4Z473J- RCARBONFILM 1/4 47KOHMJ
J021~227 85801065GY WIRECOPPER AWG221/0.65 TINCOATING
L405 5MC0000100 COILBEAD HC-3550
L501 5CPZ560K02 COILPEAKING 56UHK (AXIAL3.5MM)
L505 5CPZ560K03 COILPEAKING 56UHK (AXIAL7MM)
L506 5CPZ560K03 COILPEAKING 56UHK (AXIAL7MM)
L508 5CPZ180K02 COILPEAKING 18UHK (AXIAL3.5MM)
L601 5CPZ560K02 COILPEAKING 56UHK (AXIAL3.5MM)
L701 5CPZ560K03 COILPEAKING 56UHK (AXIAL7MM)
L802 5MC0000100 COILBEAD HC-3550
L804 85801065GY WIRECOPPER AWG221/0.65 TINCOATING
L901 5CPZ101K04 COILPEAKING 100UHK (AXIAL10.5MM)
LP01 5CPZ229M02 COILPEAKING 2.2UHM (AXIAL 3.5MM)
LP02 5CPZ159M02 COILPEAKING 1.5UH3.5MM M(LAL02TB)
LP03 5CPZ150K02 COILPEAKING 15UHK (AXIAL3.5MM)
LP04 5CPZ560K03 COILPEAKING 56UHK (AXIAL7MM)
LP05 5CPZ560K03 COILPEAKING 56UHK (AXIAL7MM)
R406 RD-2Z472J- RCARBONFILM 1/2 4.7K OHMJ
R410 RD-4Z100J- RCARBONFILM 1/4 10 OHMJ
R411 RD-4Z684J- RCARBONFILM 1/4 680KOHMJ
R437 RD-4Z330J- RCARBONFILM 1/4 33 OHMJ
R501 RD-AZ103J- RCARBONFILM 1/6 10KOHMJ
R537 RD-AZ303J- RCARBONFILM 1/6 30KOHMJ
R617 RD-AZ752J- RCARBONFILM 1/6 7.5K OHMJ
R629 RD-4Z471J- RCARBONFILM 1/4 470 OHMJ
R630 RD-4Z229J- RCARBONFILM 1/4 2.2 OHMJ
R640 RD-4Z229J- RCARBONFILM 1/4 2.2 OHMJ
R724 RD-AZ102J- RCARBONFILM 1/6 1KOHMJ
R742 RD-4Z102J- RCARBONFILM 1/4 1KOHMJ
R801 85801065GY WIRECOPPER AWG221/0.65 TINCOATING
R814 RD-4Z241J- RCARBONFILM 1/4 240 OHMJ
R820 RD-AZ681J- RCARBONFILM 1/6 680 OHMJ
R831 RD-4Z271J- RCARBONFILM 1/4 270 OHMJ
R843 RD-AZ102J- RCARBONFILM 1/6 1KOHMJ
R844 RC-2Z565KP RCARBONCOMP 1/2 5.6M OHMK
R901 RD-2Z202J- RCARBONFILM 1/2 2KOHMJ
R907 RD-2Z202J- RCARBONFILM 1/2 2KOHMJ
R913 RD-2Z202J- RCARBONFILM 1/2 2KOHMJ
RV04 RD-4Z201J- RCARBONFILM 1/4 200 OHMJ
LOC PARTCODE PARTNAME PART DESCRIPTION

CN207a.sch-1 - Fri Oct 20 09:14:42 2000
