Service Manual
ColorTelevision
CHASSIS : CP-185M
Model : KR14E5/DTA-14V3VM
KR20E5/DTA-20V3VM
KR21E5/DTA-21V3VM
Feb.2001
DAEWOO ELECTRONICS CO., LTD
http ://svc.dwe.co.kr
Specification
MONO
PAL-SECAM B/G-D/K
75ohm unbalanced
On screen Display
100 programmes
Frequency synthesiser tuning system
8 ohm
Off-air cannels, S-cable channels and hyperband
EURO-SCART:Audio /Video and Out, R/G/B in,
slow and fast wtching, SVHS in.
Audio-Video jack on front of cabinet in common
connection with EURO-SCART.
Headphone jack(3.5mm)on front of cabinet
R-40A10
14": 39W; 20": 42W; 21": 45W
S/M No. :TCP185MEF1
TK
Version
TV Standard
Aerial Input
Power Consumption
Teletext system
Tuning System
Sound Output Power
Speaker
Channel coverage
Channel indication
Remote Control
Program selection
3W
Visual screen size
Auxiliary Output Terminal
14" : 34cm
20" : 48cm
21" : 51cm
14V3/20V3/21V3
Sound system
2.5W(at 60% mod, 10% THD)
NONE

1
TABLE OF CONTENTS
APPENDIX (Appendix is provide only by internet [http://svc.dwe.co.kr])
SAFETY INSTRUCTION......................................................................................................................2
SPECIFICATIONS...............................................................................................................................3
1. 21 Pin EURO-SCART..................................................................................................................................3
2 Channel table...............................................................................................................................................4
CIRCUIT BLOCK DIAGRAM...............................................................................................................6
ALIGNMENT INSTRUCTIONS............................................................................................................7
1. Service mode...............................................................................................................................................7
2. Microcontroller configuration........................................................................................................................7
3. TV SET Alignment........................................................................................................................................7
SCHEMATIC DIAGRAM......................................................................................................................9
EXPLODED VIEW ...............................................................................................................................10
PRINTED CIRCUIT BOARD................................................................................................................13
SERVICE PARTS LIST........................................................................................................................14
1. The different parts list...................................................................................................................................19
FUNCTIONAL DESCRIPTION ............................................................................................................1
IC DESCRIPTION................................................................................................................................16

2
SAFETY INSTRUCTION
WARNING : Only competent service personnel may carry out work involving the testing or repair of this equipment
1. Excessive high voltage can produce potentially hazardous X-RAY RADIATION. To avoid such hazards, the high
voltage must not exceed the specified limit. The nominal value of the high voltage of this receiver is 22-23 kV (14”) or
24-26 kV (20” - 21”) at max beam current. The high voltage must not, under any circumstances, exceed 27.5 kV (14”,
20”), 29KV (21”). Each time a receiver requires servicing, the high voltage should be checked. It is important to use an
accurate and reliable high voltage meter.
2. The only source of X-RAY Radiation in this TV receiver is the picture tube. For continued X-RAY RADIATION
protection, the replacement tube must be exactly the same type tube as specified in the parts list.
X-RAY RADIATION PRECAUTION
1. Potentials of high voltage are present when this receiver is operating. Operation of the receiver outside the cabinet or
with the back cover removed involves a shock hazard from the receiver.
1)Servicing should not be attempted by anyone who is not thoroughly familiar with the precautions necessary when
working on high voltage equipment.
2)Discharge the high potential of the picture tube before handling the tube. The picture tube is highly evacuated and if
broken, glass fragments will be violently expelled.
2. If any Fuse in this TV receiver is blown, replace it with the FUSE specified in the Replacement Parts List.
3. When replacing a high wattage resistor (oxide metal film resistor) in circuit board, keep the resistor body 10 mm away
from the circuit board.
4. Keep wires away from high voltage or high temperature components.
5. This receiver must operate under AC 230 volts, 5O Hz. NEVER connect to a DC supply of any other voltage or
frequency.
SAFETY PRECAUTION
Many electrical and mechanical parts in this equipment have special safety-related characteristics. These characteristics are
often passed unnoticed by a visual inspection and the X-RAY RADIATION protection afforded by them cannot necessarily be
obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which have these spe-
cial safety characteristics are identified in this manual and its supplements, electrical components having such features are
identified by designated symbol on the parts list. Before replacing any of these components, read the parts list in this manual
carefully. The use of substitutes replacement parts which do not have the same safety characteristics as specified in the parts
list may create X-RAY Radiation.
PRODUCT SAFETY NOTICE

3
SPECIFICATIONS
21Pin EURO-SCART
PIN SIGNAL DESCRIPTION MATCHING VALUE
1Audio Output Right 0.5 Vrms, Impedance < 1kΩ, (RF 54% Mod)
2Audio Input Right 0.5Vrms, Impedance > 10kΩ
3Audio Output Left 0.5 Vrms, Impedance < 1kΩ, (RF 54% Mod)
4Audio Earth
5Blue Earth
6Audio Input Left 0.5Vrms, Impedance > 10kΩ
7Blue Input 0.7Vpp + 0.1V, Inpedance 75Ω
8Slow Switching TV : 0 to 2V, AV : 4.5 to 12V, Impedance > 10kΩ
9Green Earth
10 N.C
11 Green Input 0.7Vpp + 0.1V, Impedance 75Ω
12 N.C
13 Red Earth
14 Blanking Earth
15 Red Input
Chroma Input 0.7Vpp + 0.1V, Impedance 75Ω + 3dB for a luminance signal of 1 Vpp
16 Fast Switching 0 to 0.4V : Logic “0”, 1 to 3V : Logic “1” , Impedance 75Ω
17 Video Out Earth
18 Video In Earth
19 Video Output 1 Vpp + 3dB, Impedance 75Ω
20 Video Input 1 Vpp + 3dB, Impedance 75Ω
21 Common Earth

4
Channel table
FREQUENCY TABLE CP-185M
CH EUROP
E CCIR FRANCE GB(IRE- LAND) EAST OIRT
C01 46.25 -45.75 49.75
C02 48.25 55.75 (L') 53.75 59.25
C03 55.25 60.5 (L') 61.75 77.25
C04 62.25 63.75 (L') 175.25 85.25
C05 175.25 176.00 183.25 93.25
C06 182.25 184.00 191.25 175.25
C07 189.25 192.00 199.25 183.25
C08 196.25 200.00 207.25 191.25
C09 203.25 208.00 215.25 199.25
C10 210.25 216.00 223.25 207.25
C11 217.25 189.25 (LUX) 231.25 215.25
C12 224.25 69.25 (L') 239.25 223.25
C13 53.75 76.25 (L') 247.25 -
C14 -83.25 (L') 49.75 -
C15 82.25 90.25 57.75 -
C16 -97.25 65.75 -
C17 183.75 -77.75 -
C18 192.25 -85.75 -
C19 201.25 ---
C20 ----
C21 471.25 471.25 471.25 471.25
C22 479.25 479.25 479.25 479.25
C23 487.25 487.25 487.25 487.25
C24 495.25 495.25 495.25 495.25
C25 503.25 503.25 503.25 503.25
C26 511.25 511.25 511.25 511.25
C27 519.25 519.25 519.25 519.25
C28 527.25 527.25 527.25 527.25
C29 535.25 535.25 535.25 535.25
C30 543.25 543.25 543.25 543.25
C31 551.25 551.25 551.25 551.25
C32 559.25 559.25 559.25 559.25
C33 567.25 567.25 567.25 567.25
C34 575.25 575.25 575.25 575.25
C35 583.25 583.25 583.25 583.25
C36 591.25 591.25 591.25 591.25
C37 599.25 599.25 599.25 599.25
C38 607.25 607.25 607.25 607.25
C39 615.25 615.25 615.25 615.25
SPECIFICATIONS
CH EUROP
E CCIR FRANCE GB(IRE- LAND) EAST OIRT
C40 623.25 623.25 623.25 623.25
C41 631.25 631.25 631.25 631.25
C42 639.25 639.25 639.25 639.25
C43 647.25 647.25 647.25 647.25
C44 655.25 655.25 655.25 655.25
C45 663.25 663.25 663.25 663.25
C46 671.25 671.25 671.25 671.25
C47 679.25 679.25 679.25 679.25
C48 687.25 687.25 687.25 687.25
C49 695.25 695.25 695.25 695.25
C50 703.25 703.25 703.25 703.25
C51 711.25 711.25 711.25 711.25
C52 719.25 719.25 719.25 719.25
C53 727.25 727.25 727.25 727.25
C54 735.25 735.25 735.25 735.25
C55 743.25 743.25 743.25 743.25
C56 751.25 751.25 751.25 751.25
C57 759.25 759.25 759.25 759.25
C58 767.25 767.25 767.25 767.25
C59 775.25 775.25 775.25 775.25
C60 783.25 783.25 783.25 783.25
C61 791.25 791.25 791.25 791.25
C62 799.25 799.25 799.25 799.25
C63 807.25 807.25 807.25 807.25
C64 815.25 815.25 815.25 815.25
C65 823.25 823.25 823.25 823.25
C66 831.25 831.25 831.25 831.25
C67 839.25 839.25 839.25 839.25
C68 847.25 847.25 847.25 847.25
C69 855.25 855.25 855.25 855.25
C70 863.25 863.25 863.25 863.25
C71 69.25 ---
C72 76.25 ---
C73 83.25 ---
C74 90.25 ---
C75 97.25 ---
C76 59.25 ---
C77 93.25 ---
S01 105.25 104.75 103.25 105.25

5
CH EUROP
E CCIR FRANCE GB(IRE- LAND) EAST OIRT
S02 112.25 116.75 111.25 112.25
S03 119.25 128.75 119.25 119.25
S04 126.25 140.75 127.25 126.25
S05 133.25 152.75 135.25 133.25
S06 140.25 164.75 143.25 140.25
S07 147.25 176.75 151.25 147.25
S08 154.25 188.75 159.25 154.25
S09 161.25 200.75 167.25 161.25
S10 168.25 212.75 -168.25
S11 231.25 224.75 -231.25
S12 238.25 236.75 -238.25
S13 245.25 248.75 255.25 245.25
S14 252.25 260.75 263.25 252.25
S15 259.25 272.75 271.25 259.25
S16 266.25 284.75 279.25 266.25
S17 273.25 296.75 287.25 273.25
S18 280.25 136.00 295.25 280.25
S19 287.25 160.00 303.25 287.25
S20 294.25 - - 294.25
S21 303.25 303.25 -303.25
SPECIFICATIONS
CH EUROP
E CCIR FRANCE GB(IRE- LAND) EAST OIRT
S22 311.25 311.25 311.25 311.25
S23 319.25 319.25 319.25 319.25
S24 327.25 327.25 327.25 327.25
S25 335.25 335.25 335.25 335.25
S26 343.25 343.25 343.25 343.25
S27 351.25 351.25 351.25 351.25
S28 359.25 359.25 359.25 359.25
S29 367.25 367.25 367.25 367.25
S30 375.25 375.25 375.25 375.25
S31 383.25 383.25 383.25 383.25
S32 391.25 391.25 391.25 391.25
S33 399.25 399.25 399.25 399.25
S34 407.25 407.25 407.25 407.25
S35 415.25 415.25 415.25 415.25
S36 423.25 423.25 423.25 423.25
S37 431.25 431.25 431.25 431.25
S38 439.25 439.25 439.25 439.25
S39 447.25 447.25 447.25 447.25
S40 455.25 455.25 455.25 455.25
S41 463.25 463.25 463.25 463.25

6
CIRCUIT BLOCK DIAGRAM

7
ALIGNMENT INSTRUCTIONS
Microcontroller configuration : Service mode
To switch the TV set into service mode please see instruction below.
1 - Select pr. number 91
2 - Adjust sharpness to minimum and exit all menu.
3 - Quickly press the key sequence : RED - GREEN - menu
To exit SERVICE menu press menu key or Std By key.
In Service Mode press “OK” to stop the microcontroller i.e. the I2C bus is free and the set can be controlled by external equipment.
Press “OK” again to allow the microcontroller to control the set again
Microcontroller configuration :
Tuner Option
System Option
TV set Alignment
1 - G2 alignment
- Set TV in NORMAL I mode
- TV in AV mode without video signal ? Black screen.
- TV preset with WP Red, WP Green and WP Blue equal to 32.
- TV preset with Black R, Black G equal to 8.
-Adjust screen volume( on FBT ) suchthat the highest cathode cut-offvoltage measured onCRT board,is Vcut-off ±5V.
2 - White balance
- Select a dark picture and adjust Black G and Black R to the desired colour temperature.
- Select a bright picture and adjust WP Red, WP Green, WP Blue to the desired colour temperature.
Option Tuner maker
DW DAEWOO / SAMSUNG
PH1 PHILIPS ( Video processor AGC )
PH2 PHILIPS (tuner internal AGC )
Option System
TF PAL -B/G
TK PAL/SECAM - B/G, D/K (set for Russia)
TU PAL - I/I
TA PAL/SECAM - B/G, SECAM -L/L’
Screen size Vcut-off
14”115 V
20”& 21”125 V

8
3 - Focus
- Adjust the Focus volume ( on FBT ) to have the best resolution on screen.
4 - Vertical geometry
- Adjust the Vertical Amplitude, Shift, S-Correction and Slope
to compensate for vertical distortion
5 - Horizontal picture centering
- Adjust H Shift to have the picture in the center of the screen.
7 - AGC
- Adjust the antenna signal level to 68 dB µ V ± 2 for Daewoo tuner (63dB µ V ± 1for Philips tuner).
- Set RF AGC to 0.
- Increase RF AGC level and stop when the level on pin 6 of I501 goes below 2.5 Vdc
ALIGNMENT INSTRUCTIONS

10
EXPLODED VIEW
1. 14V3

11
EXPLODED VIEW
2. 20V3

12
EXPLODED VIEW
3. 21V3

13
PRINTED CIRCUIT BOARD
CIRCUIT DIAGRAM
6. SERVO/SYSCON/CEC CIRCUIT DIAGRAM(T-DECK)

14
ELECTRICAL PARTS LIST
LOC. PART CODE PART NAME PART DESCRIPTION REMARK
ZZ110 PTACPWA652 ACCESSORY AS DTA-14C4TFF
00040 4850A03310 ANT ROD PH-RM-008A
00100 4850Q00910 BATTERY R03/NN
M821 4858213800 BAG INSTRUCTION L.D.P.E T0.05X250X400
ZZ100 48B3740A10 TRANSMITTER REMOCON R-40A10 2
ZZ120 PTBCSHA670 COVER BACK AS DTA-14V3VM
M211 4852152101 COVER BACK HIPS BK
M541 4855415800 SPEC PLATE 150ART P/E FILM (C/TV)
ZZ130 PTPKCPA670 PACKING AS DTA-14V3VM
10 6520010100 STAPLE PIN 18M/M J D O
20 6520010200 STAPLE PIN #3417
M801 4858038700 BOX CARTON SW-2 DTQ-1463FW
M811 4858187500 PAD EPS 14V3
M821 4858210702 BAG P.E L.D.P.E T0.03X1200X1000
ZZ131 48519A4710 CRT GROUND NET 1401S-1015-1P
ZZ132 58G0000084 COIL DEGAUSSING DC-1450 I
ZZ140 PTCACAA670 CABINET AS DTA-14V3VM
M191 4851933402 BUTTON CTRL 4940102+5536600
M201A 4856013301 SCREW CRT FIXING 30X140 YL
M201B 4856215402 WASHER RUBBER CR T2.0
M201C 4856013300 SCREW CRT FIXING 30X80 BK
M211A 7172401412 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M211D 7172401412 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M321 4853214800 BRKT FR HIPS BK
M481 4854940103 BUTTON ABS BK
M561 4855613600 MARK BRAND COPPER T0.4
M681 4856812001 TIE CABLE NYLON66DA100
SP01A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN
V901 PTRTPWA001 CRT AS PAL 14’ ITC CRT AS 2 I
V01 58D1000046 COIL DY ODY-M1401
V02 48A96R004- RUBBER WEDGE HMR 28 SR (|0X54)
V03 4850PM001- MAGNETCP NY-225 (MINI NECK)
V04 2TC26019BE TAPE CLOTH 19X30 BEIGE
V05 2224050026 BOND SILICON RTV 122 CARTRIDGE
V901 48A96414P1 CRT BARE A34JLL90X
ZZ200 PTFMSJA670 MASK FRONT AS DTA-14V3VM
M201 4852068301 MASK FRONT HIPS BK
ZZ210 PTSPPWA652 SPEAKER AS DTA-14C4TFF
P601A 4850703S50 CONNECTOR YH025-03+35098+ULW=200
SP01 4858314010 SPEAKER SP-5070F01 3W 8 OHM 2
ZZ290 PTMPMSA670 PCB MAIN MANUAL AS DTA-14V3VM
C404 CMYH3C822J C MYLAR 1.6KV BUP 8200PF J
C408 CMYE2D334J C MYLAR 200V PU 0.33MF J
C801 CL1JB3474K C LINE ACROSS AC250V 0.47MF U/C/SNDF/SV I
C805 CEYN2W151P C ELECTRO 450V LHS 150MF (25X40) 2
C812 CH1AFE472M C CERA AC 4KV 4700PF M KX DE1610 2 I
D707 DSML1216W- LED SML1216W
D820 DRGP30J--- DIODE RGP30J
F801 5FSCB4022R FUSE CERA SEMKO F4AH 4A 250V MF51 I
G900 4SG0D00103 SPARK GAP S-23 900V-1.5KV
I301 PTA2SW5405 HEAT SINK ASS‘Y1TDA8357J- + 7174301011 2
00001 1TDA8357J- IC VERTICAL TDA8357J 2
0000A 4857025405 HEAT SINK A1050P-H24 T=2
0000B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I501 1DW3813DE1 IC MICOM DW9381/N1/3-DE1 2
I601 1TDA7267A- IC AMP TDA7267A 2
I702 1AT24C08PC IC AT24C08-10PC
I703 1KRT30---- IC PREAMP KRT30
I801 PTA2SW4618 HEAT SINK ASS‘Y1STRF6653- + 7174300811
I801 1STRF6653- IC SMPS STR-F6653 2
I801A 4857024618 HEAT SINK AL EX
I801B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I804 1LTV817C-- IC PHOTO COUPLER LTV-817C 2 I
I806 1SE110N--- IC REGULATOR SE110N 2
I810 TX0202DA-- THYRISTOR X0202DA1BA2
I820 1KA7805--- IC REGULATOR KA7805
I822 1KA7808--- IC REGULATOR KA7808
I823 1LE33CZ--- IC REGULATOR LE33CZ
I901 PTC3SW1100 HEAT SINK ASS‘Y1TDA6107Q- + 7174300811 2
00001 1TDA6107Q- IC VIDEO TDA6107Q 2
0000A 4857031100 HEAT SINK A1050P-H24 T2.0
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
JPA1 4859200401 SOCKETRGB YRS21-R1
JS1 4859109950 JACK PIN BOARD PH-JB-9710A
L401 58H0000016 COIL H-LINEARITY L-102 (102UH)
LF801 5PLF24A1-- FILTER LINE LF-24A1 I
M351 4853533600 HOLDER LED P.P BK
M791 4857913304 RUBBER CUSHION FR RUBBER SPONGE
P401 4850705N16 CONNECTOR BIC-05T-25T+ULW=300
P402 4859240020 CONN WAFER YFW500-05
P501 4850705N16 CONNECTOR BIC-05T-25T+ULW=300
PWC1 4859908110 CORD POWER AS 1-L0+H03VVH2-F+HOU=2200 I
Q401 PTP2SW4510 HEAT SINK ASS‘YTKSC5386-- + 7174300811 2
00001 TKSC5386-- TR KSC5386
0000A 4857024510 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
R801 DEC140M290 POSISTOR ECPCC140M290
R819 RX07B339JP R CEMENT 7W 3.3 OHM J BEN 15MM 4P
LOC. PART CODE PART NAME PART DESCRIPTION REMARK
“ I “ is a safety part, so it must be used the same part.
“ 2 ” is a recommendable part for essential stock.
CAUTION

15
SCT1 4859303430 SOCKET CRT PCS633A
SF1 5PK2960M-- FILTER SAW K2960M
SW801 5S40101146 SW POWER PUSH SS-160-7-B I
T401 50D10A2--- TRANS DRIVE TD-10A2
T402 50H0000211 FBT 1142.5109
T801 50M3535A1- TRANS SMPS 2074.5046 I
U100 4859719930 TUNER VARACTOR DT5-BF18D
X502 5XE12R000E CRYSTALQUARTZ HC-49/U 12.00000MHZ 30PPM
Z501 5PYXT5R5MB FILTER CERA XT 5.5MB
Z502 5PYXT6R5MB FILTER CERA XT 6.5MB
ZZ200 PTMPJ0A670 PCB MAIN (RHU) AS DTA-14V3VM
C315 CEXF2C470C C ELECTRO 160V RUS 47MF (13X25) TP
C415 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP
C603 CEXF1C471V C ELECTRO 16V RSS 470MF (10X12.5)TP
C810 CCXB3D102K C CERA 2KV B 1000PF K (TAPPING)
C813 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
C814 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
C823 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C832 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C840 CEXF1C222V C ELECTRO 16V RSS 2200MF (13X25) TP
C841 CEXF1C222V C ELECTRO 16V RSS 2200MF (13X25) TP
C861 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C965 CCXB3D102K C CERA 2KV B 1000PF K (TAPPING)
ZZ200 PTMPJBA670 PCB MAIN M-10 AS DTA-14V3VM
N001 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N002 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N003 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N004 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
P601 485923162S CONN WAFER YW025-03 (STICK)
R305 RS02Z331JS R M-OXIDE FILM 2W 330 OHM J SMALL
R402 RF01Z129J- R FUSIBLE 1W 1.2 OHM J (TAPPING)
R415 RS02Z102JS R M-OXIDE FILM 2W 1K OHM J SMALL
R450 RS02Z103JS R M-OXIDE FILM 2W 10K OHM J SMALL
R802 RS02Z753JS R M-OXIDE FILM 2W 75K OHM J SMALL
R803 RS02Z473JS R M-OXIDE FILM 2W 47K OHM J SMALL
R804 RF02Z228K- R FUSIBLE 2W 0.22 OHM K (TAPPING)
R808 RS02Z821JS R M-OXIDE FILM 2W 820 OHM J SMALL
ZZ200 PTMPJRA670 PCB MAIN RADIAL AS DTA-14V3VM
C101 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C102 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C106 CEXF1E221V C ELECTRO 25V RSS 220MF (8X11.5) TP
C120 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C121 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C305 CEXF1E221V C ELECTRO 25V RSS 220MF (8X11.5) TP
C313 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C320 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C390 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
C401 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
LOC. PART CODE PART NAME PART DESCRIPTION REMARK
C412 CEXF2C339V C ELECTRO 160V RSS 3.3MF (8X16) TP
C414 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C417 CMXL2E104K C MYLAR 250V MEU 0.1MF K
C418 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C420 CCXB2H222K C CERA 500V B 2200PF K (TAPPING)
C500 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C501 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C502 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C504 CMXM2A332J C MYLAR 100V 3300PF J (TP)
C509 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C511 CMXM2A224J C MYLAR 100V 0.22MF J
C512 CMXM2A224J C MYLAR 100V 0.22MF J
C513 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C514 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C517 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C519 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C522 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C524 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C525 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C526 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C527 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
C528 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C530 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C532 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C533 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C537 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C555 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C560 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C564 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C565 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C570 CCXB1H472K C CERA 50V B 4700PF K (TAPPING)
C571 CCXB1H821K C CERA 50V B 820PF K (TAPPING)
C580 CEXF1E221V C ELECTRO 25V RSS 220MF (8X11.5) TP
C585 CCXB1H222K C CERA 50V B 2200PF K (TAPPING)
C590 CXCH1H270J C CERA 50V CH 27PF J (TAPPING)
C591 CXCH1H270J C CERA 50V CH 27PF J (TAPPING)
C592 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C593 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C599 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C600 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C601 CEXF1H108V C ELECTRO 50V RSS 0.1MF (5X11) TP
C602 CCXF1H103Z C CERA 50V F 0.01MF Z (TAPPING)
C650 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C770 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C803 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C804 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C806 CEXF1H330V C ELECTRO 50V RSS 33MF (6.3X11) TP
C807 CCXF1H473Z C CERA 50V F 0.047MF Z (TAPPING)
LOC. PART CODE PART NAME PART DESCRIPTION REMARK
ELECTRICAL PARTS LIST

16
C808 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C820 CCXB3A471K C CERA 1KV B 470PF K (T)
C821 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C824 CCXB3A471K C CERA 1KV B 470PF K (T)
C831 CCXB3A471K C CERA 1KV B 470PF K (T)
C835 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C844 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C863 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C866 CCXB3A471K C CERA 1KV B 470PF K (T)
C888 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C910 CCXB1H561K C CERA 50V B 560PF K (TAPPING)
C968 CMXL2E104K C MYLAR 250V MEU 0.1MF K
CA04 CEXD1H229F C ELECTRO 50V RND 2.2MF (5X11) TP
CA05 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
F801A 4857415001 CLIP FUSE PFC5000-0702
F801B 4857415001 CLIP FUSE PFC5000-0702
L802 58C9430599 COIL CHOKE AZ-9004Y(94MH)
Q101 TKTC3198Y- TR KTC3198Y
Q402 T2SD1207T- TR 2SD1207-T (TAPPING)
Q501 TKTA1266Y- TR KTA1266Y (TP)
Q502 TKTC3198Y- TR KTC3198Y
Q503 TKTC3198Y- TR KTC3198Y
Q510 TKTA1266Y- TR KTA1266Y (TP)
Q511 TKTA1266Y- TR KTA1266Y (TP)
Q520 TKTC3198Y- TR KTC3198Y
Q807 TKTC3198Y- TR KTC3198Y
Q808 TKTC3198Y- TR KTC3198Y
Q809 TKTC3198Y- TR KTC3198Y
Q810 TKTC3198Y- TR KTC3198Y
Q811 TKTC3198Y- TR KTC3198Y
SW700 5S50101090 SW TACT THVH472GCA
SW701 5S50101090 SW TACT THVH472GCA
SW702 5S50101090 SW TACT THVH472GCA
SW703 5S50101090 SW TACT THVH472GCA
SW704 5S50101090 SW TACT THVH472GCA
ZZ200 PTMPJAA670 PCB MAIN AXIAL AS DTA-14V3VM
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M
A001 4859804993 PCB MAIN 246X246
C103 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C104 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C350 CCZF1H473Z C CERA 50V F 0.047MF Z (AXIAL)
C351 CCZF1H473Z C CERA 50V F 0.047MF Z (AXIAL)
C515 CBZR1C222M C CERA 16V Y5R 2200PF M (AXIAL)
C516 CBZR1C472M C CERA 16V Y5R 4700PF M (AXIAL)
C518 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C520 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C521 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
LOC. PART CODE PART NAME PART DESCRIPTION REMARK
C523 CCZF1H103Z C CERA 50V F 0.01MF Z
C529 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C531 CCZF1H473Z C CERA 50V F 0.047MF Z (AXIAL)
C534 CCZF1H223Z C CERA 50V F 0.022MF Z
C535 CCZF1H223Z C CERA 50V F 0.022MF Z
C536 CCZF1H223Z C CERA 50V F 0.022MF Z
C577 CCZB1H561K C CERA 50V B 560PF K
C771 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C809 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C830 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C850 CCZB1H821K C CERA 50V B 820PF K AXIAL
CA01 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA02 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA03 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA10 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
D101 D1N4148--- DIODE 1N4148 (TAPPING)
D313 D1N4937G-- DIODE 1N4937G (TAPPING)
D341 DUZ33B---- DIODEZENER UZ-33B
D350 DUZ12BM--- DIODEZENER UZ-12BM (UNIZON)
D351 DUZ33B---- DIODEZENER UZ-33B
D360 DUZ33B---- DIODEZENER UZ-33B
D361 DUZ33B---- DIODEZENER UZ-33B
D362 DUZ33B---- DIODEZENER UZ-33B
D405 D1N4937G-- DIODE 1N4937G (TAPPING)
D407 D1N4937G-- DIODE 1N4937G (TAPPING)
D408 D1N4937G-- DIODE 1N4937G (TAPPING)
D450 D1N4937G-- DIODE 1N4937G (TAPPING)
D501 D1N4148--- DIODE 1N4148 (TAPPING)
D502 D1N4148--- DIODE 1N4148 (TAPPING)
D503 D1N4148--- DIODE 1N4148 (TAPPING)
D504 D1N4148--- DIODE 1N4148 (TAPPING)
D520 D1N4148--- DIODE 1N4148 (TAPPING)
D521 D1N4148--- DIODE 1N4148 (TAPPING)
D591 DUZ2R4B--- DIODEZENER UZ-2.4B
D710 DMTZJ5R1A- DIODEZENER MTZJ 5.1A
D801 DLT2A05G-- DIODE LT2A05G (TP) I
D802 DLT2A05G-- DIODE LT2A05G (TP) I
D803 DLT2A05G-- DIODE LT2A05G (TP) I
D804 DLT2A05G-- DIODE LT2A05G (TP) I
D805 D1N4937G-- DIODE 1N4937G (TAPPING)
D806 D1N4937G-- DIODE 1N4937G (TAPPING)
D808 D1N4937G-- DIODE 1N4937G (TAPPING)
D809 D1N4937G-- DIODE 1N4937G (TAPPING)
D810 D1N4937G-- DIODE 1N4937G (TAPPING)
D811 DUZ5R6BM-- DIODEZENER UZ-5.6BM
D821 D1N4937G-- DIODE 1N4937G (TAPPING)
D824 D1N4148--- DIODE 1N4148 (TAPPING)
D825 D1N4148--- DIODE 1N4148 (TAPPING)
LOC. PART CODE PART NAME PART DESCRIPTION REMARK
ELECTRICAL PARTS LIST

17
D830 D1N4937G-- DIODE 1N4937G (TAPPING)
D831 D1N4937G-- DIODE 1N4937G (TAPPING)
D840 D1N4148--- DIODE 1N4148 (TAPPING)
D841 D1N4148--- DIODE 1N4148 (TAPPING)
D860 D1N4937G-- DIODE 1N4937G (TAPPING)
DA02 DUZ12BM--- DIODE ZENER UZ-12BM (UNIZON)
DA03 DMTZJ5R1A- DIODE ZENER MTZJ 5.1A
DA05 DUZ5R6BM-- DIODE ZENER UZ-5.6BM
DA06 DUZ5R6BM-- DIODE ZENER UZ-5.6BM
DA08 DUZ5R6BM-- DIODE ZENER UZ-5.6BM
DA09 DUZ5R6BM-- DIODE ZENER UZ-5.6BM
DA10 DUZ5R6BM-- DIODE ZENER UZ-5.6BM
DA11 DUZ5R6BM-- DIODE ZENER UZ-5.6BM
DA27 DUZ5R6BM-- DIODE ZENER UZ-5.6BM
J035 RD-4Z390J- R CARBON FILM 1/4 39 OHM J
L101 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L301 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
L350 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
L351 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
L500 5CPZ120K02 COIL PEAKING 12UH K (AXIAL 3.5MM)
L501 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L502 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L510 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L511 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L512 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L600 5MC0000100 COIL BEAD HC-3550
L801 5MC0000100 COIL BEAD HC-3550
L803 5MC0000100 COIL BEAD HC-3550
R101 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R102 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R103 RD-AZ123J- R CARBON FILM 1/6 12K OHM J
R104 RD-AZ104J- R CARBON FILM 1/6 100K OHM J
R105 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
R106 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R107 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R120 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R170 RD-AZ133J- R CARBON FILM 1/6 13K OHM J
R302 RD-2Z159J- R CARBON FILM 1/2 1.5 OHM J
R310 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R311 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R340 RD-4Z473J- R CARBON FILM 1/4 47K OHM J
R341 RD-4Z242J- R CARBON FILM 1/4 2.4K OHM J
R350 RN-4Z1501F R METAL FILM 1/4 1.50K OHM F
R351 RN-4Z1501F R METAL FILM 1/4 1.50K OHM F
R355 RD-AZ272J- R CARBON FILM 1/6 2.7K OHM J
R356 RD-4Z562J- R CARBON FILM 1/4 5.6K OHM J
R360 RD-4Z564J- R CARBON FILM 1/4 560K OHM J
R390 RD-4Z159J- R CARBON FILM 1/4 1.5 OHM J
LOC. PART CODE PART NAME PART DESCRIPTION REMARK
R401 RD-4Z272J- R CARBON FILM 1/4 2.7K OHM J
R404 RD-4Z399J- R CARBON FILM 1/4 3.9 OHM J
R420 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
R501 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R502 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R505 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R506 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R507 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R508 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R509 RD-AZ681J- R CARBON FILM 1/6 680 OHM J
R511 RD-AZ333J- R CARBON FILM 1/6 33K OHM J
R512 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R513 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R514 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R515 RD-AZ153J- R CARBON FILM 1/6 15K OHM J
R516 RD-AZ393J- R CARBON FILM 1/6 39K OHM J
R517 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R518 RD-AZ273J- R CARBON FILM 1/6 27K OHM J
R520 RD-AZ183J- R CARBON FILM 1/6 18K OHM J
R521 RD-AZ391J- R CARBON FILM 1/6 390 OHM J
R522 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R523 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R524 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R525 RD-AZ104J- R CARBON FILM 1/6 100K OHM J
R526 RD-4Z479J- R CARBON FILM 1/4 4.7 OHM J
R527 RD-AZ431J- R CARBON FILM 1/6 430 OHM J
R528 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R530 RD-AZ470J- R CARBON FILM 1/6 47 OHM J
R531 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R533 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R534 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R535 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R537 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R538 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R539 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R555 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R556 RD-AZ822J- R CARBON FILM 1/6 8.2K OHM J
R567 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R571 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
R572 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R573 RD-AZ272J- R CARBON FILM 1/6 2.7K OHM J
R575 RD-AZ123J- R CARBON FILM 1/6 12K OHM J
R580 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R585 RD-AZ224J- R CARBON FILM 1/6 220K OHM J
R586 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R587 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R588 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R589 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
LOC. PART CODE PART NAME PART DESCRIPTION REMARK
ELECTRICAL PARTS LIST

18
R590 RD-4Z103J- R CARBON FILM 1/4 10K OHM J
R591 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R592 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R593 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R594 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R595 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R596 RD-AZ302J- R CARBON FILM 1/6 3K OHM J
R597 RD-AZ153J- R CARBON FILM 1/6 15K OHM J
R598 RD-AZ153J- R CARBON FILM 1/6 15K OHM J
R599 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R601 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
R602 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R610 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R710 RD-AZ431J- R CARBON FILM 1/6 430 OHM J
R711 RD-AZ431J- R CARBON FILM 1/6 430 OHM J
R713 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R720 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R721 RD-AZ181J- R CARBON FILM 1/6 180 OHM J
R722 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R723 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R724 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R805 RD-2Z100J- R CARBON FILM 1/2 10 OHM J
R806 RD-4Z472J- R CARBON FILM 1/4 4.7K OHM J
R807 RD-2Z272J- R CARBON FILM 1/2 2.7K OHM J
R810 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R811 RC-2Z565KP R CARBON COMP 1/2 5.6M OHM K I
R817 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R820 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R821 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R823 RD-4Z432J- R CARBON FILM 1/4 4.3K OHM J
R829 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
LOC. PART CODE PART NAME PART DESCRIPTION REMARK
R830 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R840 RD-4Z220J- R CARBON FILM 1/4 22 OHM J
R841 RD-2Z249J- R CARBON FILM 1/2 2.4 OHM J
R850 RD-2Z479J- R CARBON FILM 1/2 4.7 OHM J
R855 RD-4Z185J- R CARBON FILM 1/4 1.8M OHM J
R870 RD-4Z222J- R CARBON FILM 1/4 2.2K OHM J
R888 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R910 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R911 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R912 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R913 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
R914 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
R915 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
R921 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R922 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R923 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RA01 RD-AZ680J- R CARBON FILM 1/6 68 OHM J
RA02 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RA03 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RA04 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RA05 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RA06 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA08 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA09 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA10 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RA11 RD-AZ183J- R CARBON FILM 1/6 18K OHM J
RA12 RD-AZ183J- R CARBON FILM 1/6 18K OHM J
RA16 RD-AZ680J- R CARBON FILM 1/6 68 OHM J
RA19 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA30 RD-AZ183J- R CARBON FILM 1/6 18K OHM J
RA44 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
LOC. PART CODE PART NAME PART DESCRIPTION REMARK
ELECTRICAL PARTS LIST

19
ELECTRICAL PARTS LIST
DIFFERENT PART LIST
LOC PART NAME 14 INCH 20 INCH 21 INCH
C404 C MYLAR 1.6KV BUP 8200PF J 1.6KV BUP 8200PF J 1.6KV BUP 7500PF J
C408 C MYLAR 200V PU 0.33MF J 200V PU 0.27MF J 200V PU 0.27MF J
C417 C MYLAR 250V MEU 0.1MF K 100V 0.22MF J 250V MEU 0.1MF K
L401 COIL H-LINEARITY L-102 (102UH) L-76(76.5UH) L-102 (102UH)
P401 CONNECTOR BIC-05T-25T+ULW=300 BIC-05T-25T+ULW=400 BIC-05T-25T+ULW=400
P402 CONN WAFER YFW500-05 YFW500-05 YFW500-06
P501 CONNECTOR BIC-05T-25T+ULW=300 BIC-05T-25T+ULW=400 BIC-05T-25T+ULW=400
R350 R METAL FILM 1/4 1.50K OHM F 1/4 1.80K OHM F 1/4 2.0K OHM F
R351 R METAL FILM 1/4 1.50K OHM F 1/4 1.80K OHM F 1/4 2.0K OHM F
R402 R FUSIBLE 1W 1.2 OHM J (TAPPING) 1W 0.68 OHM K (TAPPING) 1W 1.2 OHM J (TAPPING)
R556 R CARBON FILM 1/6 8.2K OHM J 1/6 7.5K OHM J 1/6 6.8K OHM J
R575 R CARBON FILM 1/6 12K OHM J 1/6 10K OHM J 1/6 12K OHM J
R801 POSISTOR ECPCC140M290 ECPCD7R0M290 ECPCD7R0M290
R823 R CARBON FILM 1/4 4.3K OHM J 1/4 3K OHM J 1/4 3K OHM J
SCT1 SOCKET CRT PCS633A PCS629-03C PCS629-03C
M191 BUTTON CTRL 4940102+5536600 4940002+5536900
M201 MASK FRONT HIPS BK HIPS BK
M201A SCREW CRT FIXING 30X140 YL 30X80 BK
M201B WASHER RUBBER CR T2.0 CR T2.0
M201C SCREW CRT FIXING 30X80 BK 30X190 BK
M211 COVER BACK HIPS BK HIPS BK
M321 BRKT FR HIPS BK FR HIPS BK
M351 HOLDER CORD FR HIPS BK
M481 BUTTON ABS BK ABS BK ABS
M561 MARK BRAND COPPER T0.4 A1050P-H24 T0.4
M781 CLOTH BLACK FELT 250X20X0.7 FELT 250X20X0.7
M801 BOX CARTON SW-2 DTQ-1463FW "DW-3 2058,2051" DW-2
M811 PAD EPS 14V3 EPS 20V3 EPS 21V3
M821 BAG P.E L.D.P.E T0.03X1200X1000 L.D.P.E T0.03X1200X1000 L.D.P.E T0.03X1300X1000
V01 COIL DY ODY-M1401 ODY-M2002
V901 CRT BARE A34JLL90X A48JLL90X (P)
V901 CRT(with DY COIL) A51EFK155X01
ZZ290 PCB MAIN MANUAL AS DTA-14V3VM DTA-20V3VM DTA-21V3VM
