Daewoo DWC-LD141X User manual

INSTRUCTION MANUAL
DWC-LD141X, DWD-LD141X
Washing Machine Instruction Manual
■Economic wash system
Using artificial intelligence, the washer uses minimum energy and water by selecting optimal water level and
washing time.
■Low noise system
The washer minimizes the washing and spinning noises by sensing the amount of laundry.
■Child-Lock
The Child-Lock system has been used to prevent children from pressing any button to change the program
during operation.
■Air bubble washing
This is an advanced technology that generates millions of air bubbles inside the drum on washing sequence,
and the bubbles dissolve the detergent particles completely and cleanse all the soil in clothes gently and neatly.
■Self-Cleaning Course of Drum
Enable to Self-Cleaning of Drum.
■Digital Condensing Dry System.
Condensing Dry System with saveing energy.(for dry model)

E-2
Contents
A NOTE TO YOU
Thank you for buying a DAEWOO appliance.
DAEWOO washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer properly
and safely.
Please read it carefully.
PARTS AND FEATURES ...............................................................................................................3
WASHER SAFETY..........................................................................................................................4
INSTALLATION INSTRUCTIONS ..................................................................................................5
INLET HOSE CONNECTION..........................................................................................................6
ELECTRICAL REQUIREMENTS....................................................................................................7
OPERATING YOUR WASHER.......................................................................................................8
THE FUNCTIONS OF THE CONTROL PANEL...........................................................................10
WASHING PROCEDURE AND PROGRAM SELECTION ..........................................................12
GUIDE FOR OTHER USEFUL PROGRAMS...............................................................................22
MAINTENANCE ............................................................................................................................26
HOW TO CLEAN THE FILTER.....................................................................................................27
REMOVING STAINS .....................................................................................................................28
TROUBLE SHOTING ....................................................................................................................29
SPECIFICATION ...........................................................................................................................30
WIRING DIAGRAM .......................................................................................................................31

E-3
ElParts and features
Accessories
NOTE
The drawings in the book may vary from your washer model.
They are designed to show the different features of all models coverd by this book.
Your model may not include all features.
The parts and features of your washer are illustrated on the page.
Become familiar with all parts and features before using your washer.
INLET HOSE
DETERGENT CASE
DOOR
COVER PUMP
POWER CORD
CONTROL PANEL
HOSE DRAIN
Inlet hose Manual Cap holder
(4EA)
Guide Hose Drain
(Option)
Spanner
(Option)

E-4
Washer safety
Understanding your responsibilities
• Do not use chlorine bleach and ammonia or acid(such as vinegar or rust remover) in the same wash.
Hazardous fumes can form.
• Unplug power supply cord before attempting to service your washer.
• Do not wash fiberglass material.
Small particles can stick to fabrics washed in following loads and cause skin irritation.
• Do not spray water on the control panel of the washer.
It could cause fire or an electric shock.
• In case of the dual valve model, if you connect only one water inlet valve, there can be water leakage from
unconnected water inlet valve.
• This appliance must be grounded.
• To avoid electrical shock, use a metal pipe for the ground connection.
• Turn off the water supply valve whenever the washer is not in use.
Save these instructions
Your safety is important to us.
To reduce the risk of fire, electrical shock, or injury when using your washer adhere to the following basic
precautions.
Read all instructions before using your washer
• Flammable fluids (dry-cleaning solvents,
kerosene, gasoline, etc.) should not be used or
stored in or near your washer. Do
not add flammable fluids to your wash water.
These substances give off vapors that can create
a fire hazard or explosion.
• After starting a cycle, do not reach into the
washer until all motions stop.
• Do not tamper with the controls.
• The appliance is not intended for use by young
children or infirm persons without supervision.
• If the supply cord is damaged, it must be
replaced by the manufacturer, or its service agent
or a similarly qualified person in order to avoid a
hazard.
• If the appliance is supplied from a cord extension
set or electrical portable outlet device it should be
positioned so that it is not subjected to splashing
or ingress of moisture.
Please ...
• Have only a qualified person install, repair, or
replace parts on washer.
• Maintain washer properly.
• Protect washer from the weather and keep it
where the temperature will not fall below freezing.
• Do not install the washer at a place of extremely
high humidity. It could cause an electric shock or
a short circuit.
• Connect washer to the correct outlet, electrical
supply, water supply, and drain supply.
Caution, risk of fire
Oil-affected items can ignite spontaneously, especially when exposed to heat sources such as in a tumble dryer. The items become
warm, causing an oxidation reaction in the oil. Oxidation creates heat. If the heat cannot escape, the items can become hot enough to
catch fire. Piling, stacking or storing oil-affected items can prevent heat from escaping and so create a fire hazard.
If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated by hair care products be placed in a
tumble dryer they should first be washed in hot water with extra detergent - this will reduce, but not eliminate, the hazard.

E-5
ElInstallation instructions
Removing transit bolts
Location of washer
• Check location where the washer will be installed. Make sure you have everything necessary for correct
installation.
• Do not place or store your washer below 0°C (32°F) to avoid any damage from freezing.
• Do not place or store laundry products on top of washer at any times
• Install the washer on the horizontal solid floor.
If the washer is installed on an unsuitable floor, it could make
considerable noise, vibrate severely and cause a malfunction. If the
washer is not level, adjust leg up or down for horizontal installation.
• Ventilation openings must not be obstructed by carpeting when the
washer is installed on a carpeted floor.
• Leave some space (right & left : 2cm, rear : 10cm).
• In case of built-in installation, the distance between top of the washer and
bottom of upper plate should be at least 3mm.
1. Before operating the washer, remove the transit
bolts(4ea) along with the rubber.
• If the bolts are not removed, it may cause
heavy vibration, noise and malfunction.
2. Unscrew the 4 bolts with the 10mm hex wrench
or spanner or cross-tip screwdriver. Keep the 4
bolts for a later time.
• When the appliance is transported, transit bolts
will be re-used.
3. Close the holes with the cap holders supplied.
Laundry
Tub
Washer
approx.
2cm
Drain Hose

E-6
Inlet hose connection
The washer should be connected to the water mains using new hose sets and old hose sets should not be
reused.
In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water
inlet valve.
Option : Be careful not to confuse hot water inlet and cold water inlet.
For Ordinary Tap
󱳛Pull down the collar of the inlet
hose to separate it from the
water tap adapter.
󱳝Loosen the four screws properly
in order to fit into water tap.
󱳟 Fit the water tap adapter into
the water tap and tighten the
four screws evenly while
pushing up the adapter so that
the rubber packing can stick to
the water tap tightly.
󱳡Remove the tape, and screw
connector B into connect A
tightly.
󱳣Connect the inlet hose to the
water tap adapter by pulling
down the collar of the hose end.
󱳥Connect the inlet hose adapter
of the hose to the water inlet of
the washer by turning it
clockwise to be fixed tightly.
Raccorclement B
Raccorclement A
Connector
Connector
Rubber
Packing
Hose
Connector
Rubber
Packing
Hose
Connector
inlet
TAPE
Connector
Raccorclement B
Raccorclement A
Connector
Connector
Rubber
Packing
Hose
Connector
Rubber
Packing
Hose
Connector
inlet
TAPE
Connector
Raccorclement B
Raccorclement A
Connector
Connector
Rubber
Packing
Hose
Connector
Rubber
Packing
Hose
Connector
inlet
TAPE
Connector
Raccorclement B
Raccorclement A
Connector
Connector
Rubber
Packing
Hose
Connector
Rubber
Packing
Hose
Connector
inlet
TAPE
Connector
Raccorclement B
Raccorclement A
Connector
Connector
Rubber
Packing
Hose
Connector
Rubber
Packing
Hose
Connector
inlet
TAPE
Connector
Raccorclement B
Raccorclement A
Connector
Connector
Rubber
Packing
Hose
Connector
Rubber
Packing
Hose
Connector
inlet
TAPE
Connector
• Please check the rubber packing
present inside the inlet hose
adapter of the hose.
For Screw-Shaped Tap
󱳛Connect the inlet hose to the
water tap by screwing the
connector tightly.
󱳝Connect the connector- inlet
supplied if necessary.
󱳟Connect the inlet hose adapter
to the water inlet of a washer
and turn it to be fixed.
Raccorclement B
Raccorclement A
Connector
Connector
Rubber
Packing
Hose
Connector
Rubber
Packing
Hose
Connector
inlet
TAPE
Connector
Raccorclement B
Raccorclement A
Connector
Connector
Rubber
Packing
Hose
Connector
Rubber
Packing
Hose
Connector
inlet
TAPE
Connector
Raccorclement B
Raccorclement A
Connector
Connector
Rubber
Packing
Hose
Connector
Rubber
Packing
Hose
Connector
inlet
TAPE
Connector
*Check the packing in the inlet

E-7
Electrical requirements
Drain system
• Never forget to install drain hose before operating your washer.
• Open the packing box, and there is a drain hose inside the drum.
• Connect the drain hose to the drain outlet at the back side of the washer.
• Top of laundry tub must be at least 60cm high and no higher than 100cm from bottom of washer.
• When installing the drain hose to tub(sink), secure it tightly with a string.
• Proper securing of the drain hose will protect the floor from damage due to water leakage.
• When the drain hose is too long, do not force it back into the washer. This will cause abnormal noise.
Level adjustment
󱳛If the washer is installed on an unsuitable
floor, it could make considerable noise,
vibrate and cause a malfunction.
Electrical shock hazard
Failure to follow these instructions could result in death or serious injury.
• Electrical earth is required on this washer
• If it does not fit the outlet, have a proper outlet
installed by a qualified electrician.
• Don’t earth to a gas pipe.
• Don’t change the power supply cord plug.
• Check with a qualified electrician if you are not
sure the washer is properly earthed.
WARNING
Recommended earthing method
For your personal safety, this washer must be earthed.
This washer is equipped with a power supply cord ‘A’ having a earthing plug ‘B’.
To minimize possible shock hazard, the cord must be plugged into a mating
earthing-type wall receptacle ‘C’.
If a mating wall receptacle is not available, it is the personal responsibility
and obligation of the customer to have the proper earthed wall receptacle
installed by a qualified electrician.
C
B
A

E-8
Electrical requirements (cont.)
Operating your washer
󱳝Adjust the level of washer using adjustable legs.
• Please check if there is any gap between the
four adjustable legs and the floor.
• Adjust the level of washer by turning adjustable
legs. And make it sure that there
is no swaying of washer.
• After the adjustment is finished, turn the fixing
nuts up tightly so that the
washermaintains the adjustment.
󱳟 Make it sure that the washer does not sway when you press down the four corners of the washer’s top
plate.
To obtain the best washing results, you must operate your washer properly.
This section gives you this important information.
Preparing clothes for washing
• Remove pins, buckles, coins and other hard objects from clothings, pockets, etc before putting the wash into
the washing machine. Failing which can cause malfunction or damages to the drum assembly, pump and
others.
• Close zippers, snaps, and hooks to avoid snagging other items.
Remove pin, buckles, and other hard objects to avoid scratching the washer interior.
• Empty pockets and pull them inside out.
• Turn down cuffs and turn synthetic knits inside out to avoid pilling.
• Tie strings and sashes to avoid tangling.
• Treat spots and stains. (See “Removing stains” on page 28)
Fixing Nut
adjustable leg
NOTE
There should be no swaying of washer and all the adjustable legs
should stick to the floor closely.

E-9
Operating your washer (cont.)
Sorting
• Separate heavily soiled items from lightly soiled ones, even if they would normally be washed together.
• Separate dark colors from light colors, colorfast items from non-colorfast item.
Loading
• Drop items into washer loosely. Items should move easily through wash water for best cleaning and wrinkle-
free results.
• Load washer properly and select correct load size setting.
Overloading and selecting a setting too small for the wash load can :
- Cause poor cleaning
- Increase wrinkling
- Create excessive lint
- Wear out items faster (because of pilling)
• Mix large and small items in each load. Load evenly to maintain washer balance.
An unbalanced load can make the washer vibrate during spin.
• Reduce wash time when using a small load size setting. Load with only a few small items needs less
wash time.
• Use a large load size setting to reduce wrinkling with permanent press clothes and some synthetic knits.
These items should have more room to move in the water than heavy items. (towels, jeans)
Adding detergent
Soil (Heavy, Normal, Light) Separate clothes according to amount of soil.
Color (White, Lights, Darks) Separate white clothes from colored clothes.
Lint (Lint producers,Collectors) Wash lint producers and lint collectors separately.
Detergent case Adding fabric softener
• If desired, add measured liquid fabric softener
to the softener inlet.
• Pour liquid fabric softener into the dispenser using
the amount recommended on the package.
• Do not exceed the maximum fill line.
Overfilling can cause early dispensing of the fabric
softener which could stain clothes.
• Do not open the detergent case when water is
supplied.
• Avoid pouring fabric softener directly on the clothes.
• Please use only the powder detergent for the front loader washing machine.
• Please use the proper amount of detergent in conformity with the instruction of the detergent
manufacturer.
• A use of a large amount of detergent more than the recommended amount can cause many soapsuds
and the overload to the motor.
In addition to, this will deteriorate the washing and rinse performance.
Main wash Pre wash
Fabric softener

E-10
The functions of the control panel
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
■ DWC-LD141X
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
Press this switch to turn the power on or off.
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
Operation and temporary stop is repeated as it is pressed.
When you want to change program in operating;
press the “Start/Pause” button →Select the program that you want to change →
press the “Start/Pause” button again.
Steam(option)
Water+(option)
Steam(option)
Water+(option)
Option
Option
LowTemp Iron Cupboard Very Time
You can select the course you want, and each lamp is turned on when that course
is selected.
For the more detailed information, please refer to the page 14~21.
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
It can be used to adjust temperature of water according to types of the load to be
washed.
As the button is pressed, temperature of water is selected by
Cold → 30°C → 40°C → 60°C → 95°C
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
By pressing the spin button, the spin speed can be chosen.
If press "spin button" spin RPM change.
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
You can select the course you want, and each lamp is turned on when that course
is selected.
As the button is pressed, the wash course is selected by
Wash → Soak → Pre-Wash
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
You can select the course you want, and each lamp is turned on when that course
is selected.
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
It can be used to pre-engage time for wash.
Steam(option)
Water +(option)
• Steam - During washing time Steam is sprayed in Drum. Laundry is more clean.
• Water + - If you want to use more water, press this button.
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
Use to memory program you want.
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
• Is used to add a rinse, which may assist in removing traces of detergent residue.
• By selecting Rinse+ function, the rinse time and the rinse water are increased.

E-11
The functions of the control panel (cont.)
* The Child Lock will be cancelled when power is off.
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
■ DWD-LD141X
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
Press this switch to turn the power on or off.
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
Operation and temporary stop is repeated as it is pressed.
When you want to change program in operating;
press the “Start/Pause” button →Select the program that you want to change →
press the “Start/Pause” button again.
Steam(option)
Water+(option)
Steam(option)
Water+(option)
Option
Option
LowTemp Iron Cupboard Very Time
You can select the course you want, and each lamp is turned on when that course
is selected.
For the more detailed information, please refer to the page 14~21.
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
It can be used to adjust temperature of water according to types of the load to be
washed.
As the button is pressed, temperature of water is selected by
Cold → 30°C → 40°C → 60°C → 95°C
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
By pressing the spin button, the spin speed can be chosen.
If press "spin button" spin RPM change.
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
You can select the course you want, and each lamp is turned on when that course
is selected.
As the button is pressed, the wash course is selected by
Wash → Soak → Pre-Wash
Option
You can select the rinse+spin condition yon want and each lamp is turned on when
that course is selected.
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
It can be used to pre-engage time for wash.
Steam(option)
Water +(option)
• Steam - During washing time Steam is sprayed in Drum. Laundry is more clean.
• Water + - If you want to use more water, press this button.
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
Use to memory program you want.
Steam(option)
Water +(option)
Steam(option)
Water +(option)
Option
Option
Low Temp Iron Cupboard Very Time
• Is used to add a rinse, which may assist in removing traces of detergent residue.
• By selecting Rinse+ function, the rinse time and the rinse water are increased.

E-12
Washing procedure and program selection
1. Cotton is automatically selected upon power on
• Press the Power button to start.
• Press the Start/Hold button
• Initial condition
- Program : Cotton
- Wash : main wash
- Rinse : 3 times
- Spin : 800
- Water temperature : 40°C
2. MANUAL SELECTING
• Press the Power button to start
• Select the conditions which you want to use by turning the program dial and pressing each button.
• Press the Start/Pause button.
3. Reserved washing
• Reservation can be made from 1 hour to 12 hours.
example) To make reservation to complete washing in 8 hours.
- Procedure to press the button.
* Each pressing of the button advances time delay by one hour.
• Now the reservation is made.
• If you want to check the selected program, press the “Start/Pause” button again.
• Preparing washing before starting “Time Delay”;
- Turn on the water tap
- Load laundry and close the door
- Place the detergent and fabric softener in the detergent case.
• To cancel the time delay, press the Power button.
select the
program
or manual
select the
program
or manual

E-13
Washing procedure and program selection (cont.)
Program Fabric
Type
Proper
Temp. Option Maximum Load
Cotton/Normal
First check if laundry is machine
washable.(white cotton, linen
towel and sheets..)
60°C
(Cold, 30°C,
40°C, 95°C)
Pre Wash
Rinse+ Rating
Colorfast garments
(shirts, night dresses, pajamas..)
and lightly soiled white cottons
(underwear..)
40°C
(Cold, 30°C,
60°C)
Pre Wash
Rinse+ Rating
Synthetic Polyamide, Acrylic, Polyester 30°C
(Cold, 40°C)
Pre Wash
Rinse+
Less than
3kg
Delicate/
Handwash
Delicate laundry easily
damaged
(silk, curtains..)
Cold Less than
3kg
Intensive
Heavy soiled clothes
(blue-jean, climbing clothes,
ruck sack, sports wear,..)
60°C
(Cold, 30°C,
40°C, 95°C)
Pre Wash
Rinse+
Refer to
rating label
Quick 20 Colored laundry which
is lightly soiled fast. Cold Less than 3kg
Sports Wear lightly soiled fast
and thin laundry
Cold
(Cold, 30°C,
40°C)
Pre Wash
Rinse+
Tub Clean Use to clean
(and dry for dry model) Cold dry for only Dry model without load.
Drain Drain water in drum to outside
• Pre Wash : If the laundry is heavily soiled, “Pre Wash” program is recommended.
Pre Wash is available in Cotton and Synthetic programs.
• Rinse+ : Used to introduce an additional rinse, which may assist in removing traces of detergent residue.
4. FUNCTION
• Recommended programs according to the laundry type

E-14
Washing procedure and program selection (cont.)
NOTE
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and press
the button you want.
• ‘Cold’, ‘30’ °C, ‘40’ °C, ‘60’ °C and ‘95’ °C washing temperatures are selectable with Cotton/normal program.
• ‘Prewash’, ‘Rinse+’ wash options are selectable with Cotton/normal program.
CAUTION
• If you select washing temperature ‘95’ °C, some cold water is supplied before the drain of main wash.
This is to protect the user from the hazard of burn injury by lowering the temperature of hot wash water instead
of directly draining it. Therefore this is not a malfuction.
(Be careful with the draining water, since it can be still hot although the temperature is lowered.)
1
Put the laundry in to the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash and prewash compartments in the detergent case.
Softener should be below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
2
Press the Power button.
• The LED shows only ‘---’ and all Program Lights turn on.
3
Select the ‘Cotton/normal’ program using program selection dial.
• If you press Start/Hold button after power button without selecting program, the
‘Cotton/normal’ program is selected as default program.
• Washing temperature ‘40’ °C, spin ‘800’ rpm are selected automatically.
• If you want to change washing temperature, the spin velocity or add wash options
(Rinse+, Pre-Wash), press each button.
4
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
* COTTON/NORMAL PROGRAM

E-15
Washing procedure and program selection (cont.)
NOTE
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and press
the button you want.
• Only ‘Cold’, ‘30’ °C, ‘40’ °C washing temperatures are selectable with Synthetic program.
• ‘Prewash’, ‘Rinse+’ wash options are selectable with Synthetic program.
• The appropriate amount of laundry for Synthetic program is below 3kg.
1
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash and prewash compartments in the detergent case.
Softener should be below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
2
Press the Power button.
• The LED shows only ‘---’ and all Program Lights turn on.
3
Select the ‘Synthetic’ program using program selection dial.
• Washing temperature ‘30’ °C, spin ‘800’ rpm are selected automatically.
• If you want to change washing temperature, the spin velocity or add wash options
(Prewash, Rinse+), press each button.
4
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
* SYNTHETIC PROGRAM

E-16
Washing procedure and program selection (cont.)
NOTE
• All programs are not selectable.
• The appropriate amount of laundry for Delicate program is below 3kg.
1
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash compartments in the detergent case.
Softener should be below the ‘MAX’ level.
• When you want to use bleach, put it into the main wash compartment with
detergent.
2
Press the Power button.
• The LED shows only ‘---’ and all Program Lights turn on.
3
Select the ‘Delicate / Handwash’ program using program selection dial.
• Washing temperature ‘Cold’, spin ‘400’ rpm are selected automatically.
4
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
* DELICATE / HANDWASH PROGRAM

E-17
Washing procedure and program selection (cont.)
NOTE
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and press
the button you want.
• All washing temperatures are selectable with Intensive program.
• ‘Prewash’, ‘Rinse+’ wash options are selectable with Intensive program.
1
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash and prewash compartments in the detergent case.
Softener should be below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
2
Press the Power button.
• The LED shows only ‘---’ and all Program Lights turn on.
3
Select the ‘Intensive’ program using program selection dial.
• Washing temperature ‘60’ °C, spin ‘1000’ rpm are selected automatically.
• If you want to change washing temperature, the spin velocity or add wash options
(Prewash, Rinse+), press each button.
4
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
* INTENSIVE PROGRAM

E-18
Washing procedure and program selection (cont.)
NOTE
• All programs are not selectable with Quick 20 program.
• The appropriate amount of laundry for Quick 20 program is below 3kg.
1
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash compartments in the detergent case. Softener
should be below the ‘MAX’ level.
• When you want to use bleach, put it into the main wash compartment with
detergent.
2
Press the Power button.
• The LED shows only ‘---’ and all Program Lights turn on.
3
Select the ‘Quick’ program using program selection dial.
• Washing temperature ‘Cold’, spin ‘800’ rpm are selected automatically.
4
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
* QUICK 20

E-19
Washing procedure and program selection (cont.)
NOTE
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and press
the button you want.
• Only 'Cold', '30'°C and '40'°C washing temperatures are selectable with Sports Wear program.
1
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash and prewash compartments in the detergent case.
Softener should be below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
2
Press the Power button.
• The LED shows only ‘---’ and all Program Lights turn on.
3
Select ‘Sports Wear’ program using program selection dial.
• Washing temperature ‘Cold’, spin ‘800’ rpm are selected automatically.
4
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
* SPORTS WEAR PROGRAM

E-20
Washing procedure and program selection (cont.)
NOTE
• All programs are not selectable.
• Use this program WITHOUT load.
• The appropriate cleaning time is one time per a month.
1
Press the Power button.
• The LED shows only ‘---’ signal.
2
Select the ‘Tub Clean’ program using program selection dial.
• ‘Soak’ and spin ‘400’ rpm and ‘Cold’ water temperature.
3
Press Start/Pause button.
• The washer will be operated with locking Door and supplying water.
* TUB CLEAN PROGRAM
