Daewoo DWD-FD1211 User manual

Service Manual
Washing Machine
Model: DWD-FD1211
DAEWOO ELECTRONICS CORP.
S/M No. :DWDFD12001
http : //svc.dwe.co.kr 2010.04.02
✔Caution
: In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).

AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER
AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER
AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER
AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER
AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER
AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER
AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER
AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER
AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER
WASHING MACHINE
Contents
1. SPECIFICATIONS....................................................................................................................2
2. INSTALLATION........................................................................................................................3
Transit bolts.....................................................................................................................3
Removing transit bolts...................................................................................................3
Installation place requirement.......................................................................................4
BS Plug Safety Details (For U.K. User).........................................................................4
Connecting inlet hose....................................................................................................5
Installation of drain hose...............................................................................................6
Level adjustment.............................................................................................................7
3. MAINTENANCE.......................................................................................................................8
Cleaning your washer ....................................................................................................8
Cold condition.................................................................................................................8
Cleaning the water inlet filter.........................................................................................9
Cleaning the drain pump filter.......................................................................................9
Cleaning the detergent case........................................................................................10
Cleaning the washing drum.........................................................................................10
4. DIRECTION FOR DISASSEMBLY........................................................................................11
5. EXPLODE VIEW AND PARTS LIST .....................................................................................14
6. FUNCTIONS OF THE CONTROL PANEL............................................................................23
7. FUNCTIONS OF THE CONTROLLER..................................................................................25
8. FUNCTION OF THE CONVENIENT SERVICE.....................................................................27
9. TROUBLESHOOTING GUIDE ..............................................................................................29
10. WIRING DIAGRAM..............................................................................................................33

POWER SOURCE 220-240V, 50/60Hz
DiMENSION (WXDXH) 595mm x 540mm x 850mm
WEIGHT 58 kg
WATER CONSUMPTION 56.1
POWER CONSUMPTION 2200W
MAXIMUM MASS WASH 7 kg
OF TEXTILE SPIN 7 kg
WASHER TYPE DRUM TYPE (FRONT LOADING WASHING MACHINE)
OPERATING WATER PRESSURE 0.3 ~ 8kgf/cm2(29.4 ~ 784kPa)
1. SPECIFICATIONS
2
SPECIFICATIONS
■ Accessories
Hose drain Inlet hose Manual Cap holder(3EA)
MODEL DWD-FD1211
ADJUSTABLE LEG
CONTROL PANEL
DOOR
DETERGENT CASE
INLET HOSE
HOT
(OPTION) COLD
LOWER COVER
POWER CORD
HOSE DRAIN
■ DWD-FD1211 SERIES

2. INSTALLATION
3
INSTALLATION
■ Transit bolts
The appliance is fitted with transit bolts to prevent internal damage during transport.
■ Removing transit bolts
1. To prevent internal damage during transport, the
special 3 bolts are locked. Before operating the
washer, remove the bolts along with the rubber
bungs.
• If they are not removed, it may cause heavy
vibration, noise and malfunction.
2. Unscrew the 3 bolts with the 10mm hex wrench
or spanner or cross-tip screwdriver.
Keep the 3 bolts for a later time.
• When the appliance is transported, transit bolts
will be re-used.
3. Close the holes with the caps supplied.
■ Transit bolts
The appliance is fitted with transit bolts to prevent internal damage during transport.
■ Removing transit bolts

4
INSTALLATION
■ Installation place requirement
■ BS Plug Safety Details (For U.K. User)
Level floor :
Allowable slope under entire washer is 1°.
Power outlet :
Must be with 1.5 meters of entire side of location of
washer. Do not overload the outlet with more than
one appliance.
Additional Clearance :
For wall, door and floor modeling is required.
(10cm : rear / 2cm : right & left side)
Do not place or store laundry products on top of
washer at any times.
They can damage the finish or controls.
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is marked
with the letter E or by the earth symbol or coloured Green or Green and Yellow.
The wire which is coloured Blue must be connected to the terminal which is marked with the letter N or coloured Black.
The wire which is coloured Brown must be connected to the terminal which is marked with the letter L or
coloured Red.
If a 13 amp (BS 1363) plug is used, fit a 13amp BS 1362 fuse.
IMPORTANT
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:
GREEN AND YELLOW : EARTH
BLUE : NEUTRAL
BROWN : LIVE
This appliance must be earthed

5
INSTALLATION
FOR ORDINARY TAP
6Connect the inlet hose
adapter of the hose to the
water inlet of the washer by
turning it clockwise to be fixed
tightly.
• Please check the rubber pack-
ing present inside the inlet hose
adapter of the hose.
1Pull down the collar
of the inlet hose to
separate it from the
water tap adapter.
2Loosen the four
screws properly in
order to fit into
water tap.
4Remove the tape,
and screw connector
B into connector A
tightly.
5Connect the inlet
hose to the water tap
adapter by pulling
down the collar of the
hose end.
3Fit the water tap adapter into
the water tap and tighten the
four screws evenly while push-
ing up the adapter so that the
rubber packing can stick to the
water tap tightly.
■ Connecting inlet hose
In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water inlet valve.
Option : Be careful not to confuse hot water inlet and cold water inlet.
FOR SCREW-SHAPED TAP
3 Connect the inlet hose adapter
to the water inlet of the washer
and turn it to be fixed.
• Check the packing in the inlet.
1Connect the inlet hose
to the water tap
adapter by pulling
down the collar of the
hose end.
2 Connect the connec-
tor- inlet supplied if
necessary.
Inlet Hose
Connector D Rubber
Packing
Connector C
Connector
Inlet
Rubber
Packing
Connector D
Connector C
Hose
TAPE
Connector B
Connector A

6
INSTALLATION
■ Installation of drain hose
• When installing the drain hose in sink, secure
it tightly with a string.
• Proper securing of the drain hose will protect the
floor from damage due to water leakage.
• The drain hose should not be placed higher than
100cm above the floor.
• Proper securing of the drain hose will protect the
floor from damage due to water leakage.
• When the drain hose is too long, do not force
back in to the washer. This will cause abnor-
mal noise.
■ Installation of drain hose

7
INSTALLATION
■ Level adjustment
1. The level adjustment of the washing machine pre-
vents excessive noise and vibration.
Install the washing machine on a solid and even
floor surface, if possible, in a corner of the room.
Note: The wooden floor may cause excessive
vibration.
2. If the floor is uneven, adjust the adjustable leg as
the following.
(Do not insert pieces of wood etc. under legs.)
• Please check whether there is any gap between
four adjustable legs and the floor.
• Turn adjustable legs by the enclosed spanner in
order to adjust the level of the washing machine.
• Make it sure that there is no swaying of the wash-
ing machine and check that the washing
machine is even completely. (use a spirit level)
• After the level adjustment is finished, turn fixing
nuts up tightly so that the washing machine
maintains the adjustment.
leg
leg
Fixing Nut
❈ Diagonal Check
When pushing down the edges of the washing
machine top plate diagonally, the machine should
not move up and down at all.
(Please, check both of two directions)
If machine rocks when pushing the machine top
plate diagonally, adjust legs again.

3. MAINTENANCE
8
MAINTENANCE
❈Before cleaning the washer interior, unplug the electrical power cord avoid electrical shock hazards.
■ Cleaning your washer
1. Exterior
Proper care of your washer can extend its life.
The outside of the machine can be cleaned with warm water and a neutral non abrasive household detergent.
Immediately wipe off any spills. Wipe with damp cloth.
Try not to hit surface with sharp objects.
• Do not use methylated spirits, diluents or similar products.
2. Interior
Dry around the washer door opening, flexible gasket and door glass.
Run washer through a complete cycle using hot water.
Repeat process if necessary.
• Remove hard water deposits using only cleaners labeled as washer safe.
■ Cold condition
If the washer is stored in an area where freezing may occur or moved in freezing temperature,
follow these instructions to prevent damage to the washer.
1. Turn off water supply tap.
2. Disconnect hoses from water supply and drain water from hoses.
3. Plug electrical cord into a properly grounded electrical outlet.
4. Add 1gallon(3.8L) of nontoxic recreational vehicle(RV) antifreeze into empty wash drum.
Close the door.
5. Set spin cycle and let washer spin for 1minute to drain out all water.
6. Unplug eletrical power cord, dry the drum interior, and close the door.
7. Remove detergent case and dry excessive water from the compartments.
8. Store washer in an upright position.
9. To remove antifreeze from washer after storage, run empty washer through a complete cycle using detergent.
Do not add wash load.

9
MAINTENANCE
■ Cleaning the water inlet filter
• "IE" error message will blink on the control panel when water does not enter the detergent drawer.
• If your water is very hard or contains traces of lime deposit, the water inlet filter may become clogged.
• It is therefore a good idea to clean it from time to time.
■ Cleaning the drain pump filter
• The drain filter collects threads and small objects left in the laundry.
• Check regularly that the filter is clean to ensure smooth running of your machine.
CAUTION Be careful when draining if the water is hot.
1. Turn off the
water tap. 2. Unscrew the water inlet
hose.
3. Clean the filter
using a had
bristle brush.
4. Tighten up the
inlet hose.
1. Open the lower cover(1) by
using a coin. Turn the cap
hose(2) to pull out the hose.
Pull out the hose maximally.
(About 13~14cm.)
2. Unplug the cap hose(2), allowing
the water to flow out. At this time
use a vessel to prevent water
flowing on to the floor. When
water does not flow any more, turn
the pump filter(3) open to the left.
3. Remove any foreign material
from the pump filter(3). After
cleaning, turn the pump filter
clockwise and insert the cap
hose(2) to the original place.
Close the lower cover.
1
100
2
3
about
13~14cm
23
about
13~14cm
■ Cleaning the water inlet filter
• "IE" error message will blink on the control panel when water does not enter the detergent drawer.
• If your water is very hard or contains traces of lime deposit, the water inlet filter may become clogged.
• It is therefore a good idea to clean it from time to time.

10
MAINTENANCE
■ Cleaning the detergent case
❈After a while detergents and fabric softeners leave a deposit in the detergent case.
• It should be cleaned from time to time with a jet of running water.
•If necessary it can be removed completely from the machine by pressing the catch downwards and by pulling it out.
• To facilitate cleanling, the upper part of the fabric softener compartment can be removed.
Inlet box recess
❈Detergent can also accumulate inside the recess which should be cleaned
occasionally with an old toothbrush.
• Once you have finished cleaning, replace the detergent case and run a rinse
cycle without laundry.
MAX
max
MAX
max
■ Cleaning the washing drum
• If you live in a hard water area, limescale may continuously build up in places where it cannot be seen and thus
not easily removed.
• Over time the build up of scale clogs appliances, and if it is not kept in check these may have to be replaced.
• Although the washing drum is made of stainless steel, specks of rust can be caused by small metal articles (paper
clips, safety pins) which have been left in the drum.
• The washing drum should be cleaned from time to time.
• If you use descaling agents, dyes or bleaches, make sure they are suitable for washing machine use.
❈Descaler may contain chemicals that may damage part of your washing machine.
❈Remove any spots with a stainless steel cleaning agent.
❈Never use steel wool.
■ Cleaning the detergent case
❈After a while detergents and fabric softeners leave a deposit in the detergent case.
• It should be cleaned from time to time with a jet of running water.
•If necessary it can be removed completely from the machine by pressing the catch downwards and by pulling it out.
• To facilitate cleanling, the upper part of the fabric softener compartment can be removed.

4. DIRECTION FOR DISASSEMBLY
11
DIRECTION FOR DISASSEMBLY
DOOR LOCK SWITCH
1) Open the door and remove the gasket clamp. 2) Remove the gasket from the front cabinet.
HEATER AND THERMISTOR
1) Remove five screws on the COVER B and separate
the COVER B from washing machine. 2) Remove the connectors of the HEATER.
3) Remove two screws, and remove the door lock
switch.

12
DIRECTION FOR DISASSEMBLY
3) Remove the nut using the 10mm hex wrench and
remove the earth terminal from the HEATER. 4) Loose the nut of the HEATER and pull out the HEATER.
BLDC MOTOR
1) Remove the nut using the 17mm hex wrench. 2) Pull out the ROTOR.
3) Remove six screws using the 10mm hex wrench and
connectors from the STATOR. 4) Separate the STATOR from the TUB.

13
DIRECTION FOR DISASSEMBLY
DRAIN PUMP
1) Lay the right side of the washer on the floor, and
remove the lower panel by pressing six sanp fits. 2) Remove connectors.
3) Remove the screw, and remove the drain pump from
the lower frame. 4) Remove the drain hose.
5) Remove the inner drain hose, and remove the drain
pump.

5. EXPLODE VIEW AND PARTS LIST
14
EXPLODE VIEW AND PARTS LIST
A01 HANDLE CASE (CASE HANDLE) 3612608702 HIPS 1
A02 CASE DETERGENT 3611140300 PP 1
A03 CAP SOFTENER 3610916600 PP 1
A04 BOX INLET 3610526500 PP 1
A05 NOZZLE AS 3618103510 NOZZLE TOP + NOZZLE UNDER 1 COLD
A06 SCREW TAPPING 7122402011 T2S TRS 4x20 MFZN 1
A07 CLAMP AS 3611203200 ID=60,WIRE+GUIDE+BOLT+NUT 1
A08 HOSE INLET 3613267200 EPDM U-TRAP 1
A09 CLAMP HOSE I 3611201400 HSW3, D2.6, MFZN, ID=38 1
A10 HOSE WATER SUPPLY 3613270900 EPDM,ID=9.5,OD=14.5,L=225 2(3) COLD(HOT)
A11 CLAMP HOSE 3611205800 ID=13.8, W=10.0, T=0.9 4(6) COLD(HOT)
A12 VALVE INLET 3615416821 220-240V.VDE.BITRON.2WAY + DR TECH 1COLD(230/50,EU)
A13 VALVE INLET 3615416820 220-240 50/60-1WAY,HOT,BITRON,VDE 1 HOT(230/50,(EU)
A14 SCREW TAPTITE 7272400811 TT3 TRS 4x8 MFZN 2(4) COLD(HOT)
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
■ BOX INLET AS

15
EXPLODE VIEW AND PARTS LIST
■ PANEL FRONT AS
B01 PANEL *F 3814282702 HIPS 1
3814282710 SILVER SPRAY
B02 BUTTON POWER 3616603600 ABS 1
3616603620 ABS + AL COATING
B03 WINDOW DIAL 3615503100 ABS-TR 1
B04 BUTTON SELECT 3616603500 ABS 1
3616603520 ABS + AL COATING
B05 WINDOW DISPLAY AS 3615503020 ABS-TR + STICKER 1
B06 PCB AS PRPSSWFE3G DWD-FD14'S, DONGSUH MOTOR 1
B07 HOLDER LED 3613049600 ABS 1
B08 CASE PCB 3611143100 HIPS 1
B09 HOLDER DIAL 3613049700 ABS 1
B10 SCREW TAPPING 7122401611 T2S TRS 4x16 MFZN 4
B11 KNOB DIAL AS 3613405000 ABS 1
3613405010 SPRAY
B12 SCREW TAPPING 7122401608 T2S TRS 4x16 SUS 2
B13 SCREW TAPPING 7122401211 T2S TRS 4x12 MFZN 2
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK

16
EXPLODE VIEW AND PARTS LIST
■ CABINET FRONT AS

17
EXPLODE VIEW AND PARTS LIST
C01 CABINET *F 3610811220 SECD 0.7T 1
3610811210 PCM, SGCC 0.8T, SILVER
C02 SWITCH DOOR LOCK 3619047100 DL-LC BITRON_3P 250V 16A BI-METAL 1
C03 SCREW TAPPING T2S TRS 4X12 SUS 2
C04 PLATE HINGE SUPPORT 3614531900 SGCC T1.6 0 No use
C05 HINGE DOOR 3612902800 ALDC 1
C06 CAP HINGE DOOR 3610916500 POM 2
C07 SCREW TAPPING F/L BOLT(SE) 5*12 SUS 2
C08 SCREW TAPPING 3616029950 TTS"S" HEX F/L 4*8 6
C09 CLAMP DOOR AS 3611204810 HSW3, D=1.4 GS 1
C10 FRAME DOOR I 3612205200 PP 1
C11 HANDLE DOOR 3612608600 ABS 1
C12 PIN HANDLE 3618200200 SUS304, D3, L48 1
C13 SPRING HOOK 3615114600 SUS D1.4 1
C14 HOOK DOOR 3613100700 ZNDC 1
C15 DOOR GLASS 361A110700 GLASS PI300 1
C16 FRAME DOOR O 3612205102 HIPS D-F'S 1
C17 SCREW TAPPING T1S FLT 4*20 SUS 6
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK

18
EXPLODE VIEW AND PARTS LIST
■ TUB ASS’Y

19
EXPLODE VIEW AND PARTS LIST
D01 BALANCER WEIGHT F L/R 3616106320 FRONT, 5.5kg 2
D02 SPECIAL SCREW(BALANCER)
3616029400 SWCH 8.5X30 8
D03 GASKET 3612321400 EPDM 1
D04 CLAMP GASKET AS 3611204520 HSW3,GS 1
D05 TUB *F 3618821010 FRPP FH7304GM 1
D06 SPECIAL SCREW(TUB) 3616029800 SWCH 6.5X30 14
D07 FIXTURE HEATER 3612007300 SUS 0.7T 440°ø45 1
D08 DRUM SUB AS 3617004002 SUS 0.5T 1
D09 LIFTER WASH 361A400400 PP 3
361A400410 NANO OPTION
D10 SPIDER AS 361A300510 ALDC+SM45C 1
D11 SPECIAL SCREW(SPIDER) 3616029500 SUS430 8x25 3
D12 HOSE DRAIN 3613267300 EPDM 1
D13 CLAMP AS 3611203210 ID=60,WIRE+GUIDE+BOLT+NUT 1
D14 CLAMP HOSE I 3611201401 HSW3, D2.6, MFZN, D=38 1
D15 AIR TRAP 361A500101 PP 1
D16 CLAMP HOSE 3611204700 D27 1
D17 HOSE AIR 3613268600 ID=4, OD=8, L=700 1
D18 TUB REAR AS 36100E2U10 D-FD14 1
D18-1 TUB REAR 3618821110 FRPP FH7304GM 1 1
D18-2 BEARING HOUSING 3616303321 ALDC M8 TAP D-FD'S DOMESTIC 1
D19 BEARING OUTER 3616303200 6205Z FAG 1
D20 BEARING HOUSING 3616303321 ALDC M8 TAP D-FD'S DOMESTIC 1
D21 BEARING INNER 3616303100 6206Z FAG 1
D22 WATER SEAL 361A600100 NBR 1
D23 GASKET TUB (SEALING TUB) 3612321601 EPDM L=1600(-0,+10) 1
D24 DAMPER FRICTION 361A700120 120N, AKS, ST=170-160, DL=197.5 2
D25 DAMPER PIN 361A700200 AKS, D=14.5 2
D26 HOSE VENT 3613267100 EPDM 1
D27 CLAMP HOSE 3611204700 D26, wire-type 1
D28 UNIT STATOR BLDC 36189L4820 AL-16T 36SLOT 2SNESOR 1 DONGSU
36189L621A AL,DON1000W 18T 36POLE,NMT,PBT 1 NEWMOTECH
36189L621E AL,DON1000W 18T 36POLE,ENTEK,NMT,PBT 1NEWMOTECH
D29 SPECIAL BOLT AS 3616029920 SWCH M8+SILOCK, 35MM 6 DONGSU
3616029910 SWCH M8+SILOCK,49MM 6 NEWMOTECH
D30 UNIT ROTOR BLDC 36189L4910 MAGENT24 SERRATION 1 DONGSU
36189l6310 DON1000W SR-FERRITE12, 18T, NMT 1 NEWMOTECH
D32 HEATER WASH 3612803700 230V 2000W.1R5A721002.IRCA FUSE 2EA 1
D33 UNIT BUBBLE PUMP 36189L4120 220-240V DBK-240DB RP CHSHION 1 OPTION(220-240)
D34 SPRING SUSPENSION 3615115310 D3.2, L164 2
D35 THERMISTOR WASH 361AAAAB10 R25=1.704kΩR80=11.981kΩ1
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
