Daewoo DWM-3600 User manual

Service Manual
Washing Machine
Model: DWM-3600 / 3610
DWM-3620(P)
http : //svc.dwe.co.kr Nov. 2000
DAEWOO ELECTRONICS CO., LTD.
S/M No. : WM3600G013

3.5kg PANEL ASSY
NO PART NAME PART CODE Q'TY SPEC REMARKS
1DECORATOR 3611602901 1PET FILIM 0.25T DWM-3610
2KNOB 3613400100 3ABS DWM-3600
3613400500 "DWM-3610,3620"
3KNOB 3613400600 1ABS "DWM-3610,3620"
4CLAMP WIRE 3513006000 2DWAN-2NA DWM-3610
5PANEL 3614200100 1ABS&HIPS DWM-3600
3614202800 DWM-3610
3614205900 DWM-3620
6SCREW TAPPING 7122401211 3T2 TRS 4*14 MFZN
7S/W WATER SELECT AS 450TJ46000 1"SAN,S-K25A" "DWM-3610,3620"
8SCREW TAPPING 7122401211 2T2S TRS 4*14 MFZN DWM-3600
9SPRING PLATE 4509A07050 1SK5 "DWM-3610,3620"
10 LEVER CONTROL 3613700300 1POM "DWM-3610,3620"
11 S/W WATER SELECT AS 3619005500 1VP53A-3H "DWM-3610,3620"
12 FIXTURE MICRO SW 4504A29050 1SK-5 "DWM-3610,3620"
13 SCREW TAPPING 7122401211 1T2S TRS 4*12 MFZN "DWM-3610,3620"
14 TIMER WASH 3619900601 115MIN(S-K36A) 3600(P)-SINGLE VOLT-UL94 HB
3619900611 15MIN(S-K36B) 3600(P)-SINGLE VOLT-UL94V-O
3619906211 15MIN(S-K36C) 3600(P)-DUAL VOLT-UL94 HB
3619900631 15MIN(S-K36D) 3600(P)-DUAL VOLT-UL94V-O
3619903301 15MIN(S-K361B) "3610(P),3620(P),SINGLE"
3619903701 15MIN(S-361P) "3610(P),3620(P),DUAL"
15 SCREW TAPPING 7122401211 2T2S TRS 4*14 MFZN "DWM-3610,DWM-3620"
16 SPRING PLATE 4509A07050 1SK5
17 SWITCH DRAIN 4505D77000 1V15F060A NO/NC "DWM-3610,3620"
18 FIXTURE MICRO SW 4504A29050 1SK-5
19 SCREW TAPPING 7122401211 1T2S TRS 4*12 MFZN
20 LEVER CONTROL 3613700100 1POM DWM-3600
3613700300 "DWM-3610,3620"
21 LINK VALVE 3617802310 1"PP,L=625MM" DWM-3600
3617802010 "PP,L=654MM" "DWM-3610,3620"
22 TIMER SPIN 3619900701 15MIN(S-3600A) "3600,UL94HB"
3619900711 5MIN(S-3600B) 360094V-O
3619900721 5MIN(S-3600C) "3600P,UL94HB"
3619900731 5MIN(S-3600D) 3600PUL94V-O
3619903401 5MIN(S-3600B) "3610,3620,UL94V-O"
3619903901 5MIN(S-3610P) "3610P,3620P,UL94V-O"
23 SCREW TAPPING 7122401211 2T2S TRS 4*14 MFZN
24 SCREW TAPPING 7122401211 1T2S TRS 4*14 MFZN

25 BRACKET SWITCH S/W 4505D37051 1SPG 1.0T
26 COVER SWITCH 4507K44031 115A 220VAC
3619044900 LIP TYPE
27 SCREW TAPPING 7121301611 2T2TRS PAN 3*16
28 CABLETIE 3615406700 1NYLON 66 DA-100
29 TERMINAL 3618700800 1#187-200MM(BK)-12
30 TERMINAL 3618701800 112-1000MM(BK)-12
31 CEC 4509A06072 1PP
32 CEC 450BA06050 1PP
NO PART NAME PART CODE Q'TY SPEC REMARKS

3.5kg TUB ASSY
NO PART NAME PART CODE Q'TY SPEC REMARKS
1DOOR WASH 3611400400 1ABS &HIPS DWM-3600
3611703700 ABS&HIPS "DWM-3610,3620"
2SPECIAL SCREW 3616002900 1SUS 304
3PULSATOR AS 4509A32002 1PP(SUS INSERT)
4BASE 3610300400 1PP
5DRAIN STRAINER 4509A05092 1PP
6FILTER OVER FLOW 4509A05071 1PP
7BELLOWS 3616401200 1NBR
8FIXTURE BELLOWS 3612005000 1PP
9COVER SAFETY 4506F61011 1PE-LD
10 RING BASKET 3614602000 1PP
11 SCREW TAPPING 7122401211 1T2 TRS 4*12 MFZN
12 BASKET SPIN 3619102300 1PP
13 PLATE SHAFT AS 3614515400 1AL
14 TUB 3618800500 1PP
15 SHAFT HOUSING AS 4505A17000 1METAL
3611103000 1LUPOL D10*L117
16 GASKET 3612300500 1NBR(K35L)
17 SPECIAL NUT 4505A05050 1ZNDC-1
18 PULLEY PULSATOR 3618405100 1FRPP
19 NUT PULLEY 7392050611 16N-2-6
20 SPECIAL BOLT 3616008300 1SM18C+SILOCK
21 SPRING COVER 450BA01040 1HSW3
22 DOOR SPIN 3611400500 1HABS&HIPS DWM-3600
3611703800 1HABS&HIPS "DWM-3610,3620"
23 LINK BRAKE 3617803010 1PP BAND 444MM "DWM-3600,3610,3620"
24 COVER I 4507K33021 1PP(JI-170)
25 SCREW TAPPING 7122401208 1T2TRS 4*12 SUS
26 SCREW TAPPING 7122401211 1T2TRS 4*13 MFZN
27 PLATE 3614500200 1PP
28 PACKING 4509A05032 1NR DRAIN PUMP
29 CAP VALVE 3610909400 1PP
30 VALVE ROD 3615406700 1PP
31 SPRING VALVE 4505C06022 1SWC WR 1.0D
32 BELLOWS 4509A06042 1NR
33 HOSE DRAIN 4509A06073 1PE
34 SCREW TAPPING 7122401411 1T2S TRS 4*14 MFZN
35 CASE VALVE 3611119300 1PP

3.5kg BASE ASSY
NO PART NAME PART CODE Q'TY SPEC REMARKS
1BELT V 3616500800 1A-36.6 "DWM-3600,3610,3620"
2NUT HEX 7392800011 1M8*P1.25
3WASHER SPRING 7401008011 1SW-8 MFZN
4WASHER PLAN 7400108411 1PW-1-8.4 MFZN
5MOTOR PULLET AS 3618431800 1GA
6SPECIAL BOLT 3616017010 3T2TRS 4*35 MFZN
7MOTOR WASH 3964130200 1"100V, 50/60HZ"
450CD40012 1"110V,60HZ"
450AA40011 1"220V, 50/60HZ"
450AC40021 1"230V-240V, 50HZ"
450CF40002 1"110/220V,50HZ"
450CB40012 1"120/240V,60HZ"
8CUSHION MOTOR 450M712020 3NR
9CUSHION SPOT 450M712010 1PP
10 BOLT HEX(P) 7342602011 26B-6*20 SM20CK
11 NUT HEX 7393600011 26N-3-6MFZN
12 COUPLING DRUM 3619400300 1AL
13 BOLT HEX 7341500811 36B-1-5*10MFZN
14 PLATE BRAKE AS 3614517400 1
15 SPRING BRAKE 3615109000 1"SWC, D1.0"
16 BRAKE WIRE AS 3610029602 1237MM
17 SCREW TAPPTITE 7272400811 1"TT3, TRS 4*8 MFZN"
18 HARNESS 3612701011 1"GN/YW, UL AWG18"
19 SCREW TAPPING 7122401611 3"T2S, TRS 4*16 MFZN"
20 MOTOR SPIN 450CJ181001 1"100V, 50/60HZ"
3964130301 1100V 50/60HZ ONLY JAPAN
450CD81001 1"110V, 60HZ"
450CA81001 1"220V, 50/60HZ"
4505D41022 2"230-240V, 50HZ"
450CF81001 1"110/220V, 50HZ"
450CB40002 1"120/240V, 60HZ"
21 STOPPER 4509A14021 1PP
22 SPRING CUSHION 4509A14031 1"SWC, ZN8C"
23 DAMPER 4509A14012 1SBR
24 STOPPER 3615200200 1PP
25 BACK COVER 3611400700 1PP
26 SCREW TAPPING 7122401211 1T2S TRS 4*12 MFZN
27 SCREW TAPPING 7121401411 2T2S PAN 4*14 MFZN
28 BASE 3610300300 1PP DRAIN PUMP

29 UNIT CAPACITOR 3618943310 18.5/2.6UF "220V,50/60HZ"
3618914510 8.5/4.5UF "230-240V, 50HZ"
3618942710 41.6/20.8UF "110V, 60HZ"
3618942510 45.6/25UF "100V, 50HZ"
30 CAPACITOR WASH 450E411080 20.8*2UF "110/220V, 50HZ"
450E111050 16*2UF "120/240V, 60HZ"
CAPATOR SPIN 4509C11010 20.8UF "110/220V, 50HZ"
450E111060 16UF "120/240V, 60HZ"
HARNESS CONDENSER 3612706710 1"CONA,B(SE,DE,PS,PD)" "CA-WASH,CA-SPIN CON"
31 LEG 3617700200 4PP
32 SCREW TAPPING 7122401211 4T2S TRS 4*12 MFZN
33 DRAIN HOSE AS 3619600500 1820MM
34 CLAMP 4505D56030 1"JSW 2.0D, ZN8-C" DRAIN PUMP
35 HOSE C AS 4505D67002 1DRAIN HOSE DRAIN PUMP
36 HARNESS OUTER 4509D64000 1VSF 50/0.18 GREEN
37 CORD POWER WUK43K763- 1VCTF 3*0.75 CP-2PIN
3611335800 VCTF 3*0.75 3 CORE WIRE
WWK43K763- VCTF 3*0.75 3PIN R TYPE(INDIA)
3611336200 HO5W-F 3*0.75 BK EUROP 3PIN
3611335400 STJ AWG 18/3 GY EP 3PIN
3611336500 VCTF 3*0.75 BS-1363
3611335900 R VCTFK 2*0.75 FLAT 2PIN
3611334900 HO5W-F 3*0.75 BK ITALY 3PIN
WX745N7B2- HO5W-F 3*0.75 BK SOUTH AFRICA 3PIN
38 HOSE PUMP 3613225210 1LD PE
39 SCREW TAPPING 7112403011 1T1 TRS 4*30 MFZN
40 UNIT DRAIN PUMP 3618952620 1W6130TNO13 220V/50HZ
3618952520 W6130CN011 "110V, 60HZ"
3618955740 W6130KN013 "230-240V, 50HZ"
3618952720 30FN013 "110-220V, 50HZ"
3619601801 "120-240V, 60HZ"
41 HARNESS 3612720010 1"CONN A,B(DE, SE)" 9PIN CONNECTOR
3612719910 "CONN A, B(PD,PS)" 9PIN CONNECTOR(PUMP)
NO PART NAME PART CODE Q'TY SPEC REMARKS
