Drum Washing Machine
Model: DWD-L100 Series
Oct. 2009
✔ Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
S/M No. :
DWDLD14003

DRUM WASHING MACHINE
SERVICE MANUAL
1. WHAT IS DRUM WASHING MACHINE?......................................1
2. WASHER SPECIFICATION ..........................................................3
3. PARTS LIST BY ASS'Y.................................................................4
4. CONTROL PART FUNCTION SPECIFICATION ........................34
5. ELECTRONIC FIELD PARTS LIST AND SPECIFICATION .......46
6. WIRING DIAGRAM .....................................................................47

1
Water consumption is reduced by using the power of the laundry falling (free-fall) created when rotating
the drum. With temperature control system, this drum washing machine saves energy and improves
washing performance at the same time.
1. WHAT IS DRUM WASHING MACHINE?
1. Drum Washing Machine
◈Waist Care
Designed by the waist, and the most comfortable
angle eject into the laundry is convenient and easy to
manipulate.
◈Star Drum
Using Star Drum is able to show users higher
Washing Performance and Minimal damage of
laundry, water consumption.
◈LuxuryAudio Dial
Using the advancedAudio Dial is luxury design of
exterior.
◈DD inverter motor
The direct-drive type of which motor is directly
connected to drum without an interim clutch,
significantly reduces noise and vibration.
◈Self-Cleaning Course of Drum.
Enables the machine to do Self-Cleaning of Drum.
◈Digital Condensing Dry System.
Condensing Dry System with saveing energy.
2. Key Features

2
• DD Control: Direct drive type of direct connection between drum and motor
• Rotation by powerful high-performance BLDC motor
3. Power System
Pump Drainage BLDC
LAUNDRY

33
2. WASHER SPECIFICATION
1. Product Specification
■1st Model ■2st Model
MODEL DWC-LU1011/1211 DWD-LU1011/1211 DWC-LD1411/1611 DWD-LD1411/1611
Dimension (mm) 600 X 645 X 850
Maximum mass of textile (kg) 9 Kg
Unit Weight (net/gross) 78/82 71/75 76/80 69/73
Standard Water Consumption 65 ℓ
Spin Speed (RPM) DWC(DWD)-LU10XX : MAX 1000
DWC(DWD)-LU12XX : MAX 1200
DWC(DWD)-LD14XX : MAX 1400
DWC(DWD)-LD16XX : MAX 1600
Operating Water Pressure 0.03MPa ~ 0.8MPa (0.3kgf/cm² ~ 8kgf/cm²)

4
1. PANEL AS
3. PARTS LIST BY ASS'Y
A03
A02
A16
A15
A13
A14
A09-6
A09-5
A09-2
A09-0
A09-7
A11
A10
A01
A04
A05
A06
A07
A08
A09-1
A09-3
A09-4
■ 1st Model

5
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
A01 PANEL *F 36142T2000 ABS 1
A02 DECORATOR WINDOW COURSE 3611696000 ABS 1
A03 WINDOW COURSE 3615509200 C-LU1011 1
A04 DECORATOR WINDOW DISPLAY 3611696100 ABS 1
A05 BUTTON FUNCTION 3616644000 ABS 1
A06 BUTTON PS 3616644100 ABS 1
A07 WINDOW DISPLAY 3615509300 C-LU1011 1
A08 BUTTON LED 3616644200 C-LU1011 1
A09 PCB AS PRPSSWL010 1ST FRONT PCB AS (LD10/LU10) 1 EC
PCB AS PRPSSWL011 1ST FRONT PCB AS (LD12/LU12) 1 EC
PCB AS PRPSSWL012 1ST FRONT PCB AS (LD14) 1 EC
PCB AS PRPSSWL013 1ST FRONT PCB AS (LD16) 1 EC
PCB AS PRPSSWL000 1ST FRONT PCB AS (LD10/LU10) 1 STANDBY 1W
PCB AS PRPSSWL001 1ST FRONT PCB AS (LD12/LU12) 1 STANDBY 1W
PCB AS PRPSSWL002 1ST FRONT PCB AS (LD14) 1 STANDBY 1W
PCB AS PRPSSWL003 1ST FRONT PCB AS (LD16) 1 STANDBY 1W
A09-0 PCB BOARD 3614347000 L SERIES FRONT PCB BOARD 1
A09-1 CUSTOM LED 3613058300 C-LU1011 1
A09-2 LED LAMP DS0302WP-- 9MM FORMING TYPE , D=3MM 36
A09-3 SW TACT 5S50101402 2PIN, 6*6*5 9
A09-4 HOLDER LED OPTION 3613058000 HIPS 1
A09-5 HOLDER LED FUNCTION 3613058100 HIPS 1
A09-6 HOLDER LED COURSE 3613058200 HIPS 1
A09-7 CASE PCB F 36111T1N00 HIPS 1
A10 BUTTON DIAL OUTER 3616643800 ABS 1
A11 BUTTON DIAL INNER 3616643900 ABS 1
A12 CASE DETERGENT AS 36111T1P00 1
A13 CASE DETERGENT 36111T1J00 PP 1
A14 CAP SOFTENER 3610916600 PP 1
A15 CASE HANDLE 3611149200 ABS 1
A16 DECORATOR CASE HANDLE 3611696200 ABS 1

6
2. PANEL F AS
A01
A02
A03
A04
A05-3
A05-4
A06
A07
A08
A05-1
A05-0
A09
A13 A12 A11 A10
A05-2
A05
■ 2nd Model

7
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
A01 PANEL FRONT 36142T2100 ABS 2 4x16 SUS 430
A02 BUTTON FUNCTION 3616644400 ABS 1
A03 BUTTON OPTION 3616644700 ABS 1
A04 HOLDER LED FUNCTION 3613058500 HIPS 1
A05 PCB AS PRPSSWL060 2nd FRONT PCB AS (LD10/LU10) 1 EC
PCB AS PRPSSWL061 2nd FRONT PCB AS (LD12/LU12) 1 EC
PCB AS PRPSSWL062 2nd FRONT PCB AS (LD14) 1 EC
PCB AS PRPSSWL063 2nd FRONT PCB AS (LD16) 1 EC
PCB AS PRPSSWL050 2nd FRONT PCB AS (LD10/LU10) 1 STANDBY1W
PCB AS PRPSSWL051 2nd FRONT PCB AS (LD12/LU12) 1 STANDBY1W
PCB AS PRPSSWL052 2nd FRONT PCB AS (LD14) 1 STANDBY1W
PCB AS PRPSSWL053 2nd FRONT PCB AS (LD16) 1 STANDBY1W
A05-0 HOLDER LED DISPLAY 3613058600 ABS 1
A05-1 CASE PCB F 36111T1R00 HIPS 1
A05-2 SCREW TAPPING 7122401611 T2S TRS 1 4x16 MFZN
A05-3 PCB BOARD F 3614348500 FR-1 1
A05-4 HOLDER LED COURSE 3613058400 HIPS 1
A06 BUTTON DIAL 3616644300 ABS 1
A07 DECORATOR BUTTON DIAL 3611696400 ABS 1 CHROMIUM CILDING
A08 BUTTON START 3616644600 ABS 1
A09 BUTTON POWER 3616644500 ABS 1
A10 DECORATOR FILM 3611696500 P.C FILM 1
A11 WINDOW COURSE 3615509400 TR-ABS 1
A12 SCREW TAPPING 7122401608 T2S TRS 1
A13 CASE DETERGENT AS 36111T1P10 PP 1

8
B01
B02
B03
B05
B04
B08
B07
B06
B10
B09
B11
B12
B13
B14
3. INLET BOX AS

9
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
B01 NOZZLE *T 3618111100 PP 1
B02 NOZZLE *U 3618111000 PP 1
B03 BOX INLET 3610526500 PP 1
B04 HOSE INLET 3613274600 EPDM 1
B05 CLAMP AS 3611203200 ID=60, WIRE+GUIDE+BOLT+NUT 1
B06 VALVE INLET 36154L3A00 220-240V.VDE.BITRON.4WAY V1:DRY V2:STEAM 1
VALVE INLET 36154L3B00 220-240V.VDE.BITRON.3WAY V2:STEAM 1
VALVE INLET 36154L3D10 120V.BITRON.4WAY V1:DRY V2:STEAM 1
VALVE INLET 3615414900 220-240V 2-WAY PP/BRACKET 1
VALVE INLET 3615415050 220~240V,3WAY,RINSE GUIDE,PP/BRACKET 1
VALVE INLET 3615415070 100~130V,3WAY,RINSE GUIDE,PP/BRACKET 1
VALVE INLET 3615416820 220-240V.VDE.BITRON.2WAY 1
VALVE INLET 3615416821 220-240V.VDE.BITRON.2WAY + DR TECH INSPECTION COST 1
VALVE INLET 3615416720 220-240V60HZ.VDE.BITRON.1WAY 1
VALVE INLET 3615416970 UL 220~240V,BITRON 3WAY V1,V3 WITH CONTROL PC 1
B07 HOSE WATER SUPPLY 3613270900 EPDM ID9.5 OD14.5, WASHING 1
B08 HOSE WATER SUPPLY 3613270900 EPDM ID9.5 OD14.5, PRE.WASH 2
B09 CLAMP HOSE 3611205800 100H, ID=13.8 W=10.0 0.9T 10
B10 VALVE INLET 3615414800 220-240V 1-WAY HOT PP-BRACKET 1
VALVE INLET 3615414820 220-240V 1-WAY HOT PP-BRACKET 180 1
VALVE INLET 3615415700 100-130 1-WAY HOT PP-BRACKET 1
B11 HOSE WATER SUPPLY 3613270900 EPDM ID9.5 OD14.5, HOT 1
B12 HOSE WATER SUPPLY 3613270900 EPDM ID9.5 OD14.5, STEAM 1
B13 PIPE JOINT I 3614426000 PP 1
PIPE JOINT(HOSE INLET) 3614413300 PP , T-type 1
B14 Unit Steam AS 36189M2U00 L-SERIES STEAM UNIT 900W 1option

10
4. CABINET F ASSY
C12
C01
C02
C03
C14
C15
C06
C07
C04
C05
C11
C08
C09
C10
C13
■ 1st Model

11
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
C01 CABINET *F 3610814000 SECD 0.8T 1
C02 SWITCH DOOR LOCK 3619047230 DL-S2, 250V16A, BITRON, VE-TYPE 1
SWITCH DOOR LOCK 3619047210 DL-S1, 125V16A, BITRON 1
C03 PLATE HINGE SUPPORT 3614539800 SPG 0.8T, DWD-T110R 1
C04 FRAME DOOR *O 36122UD800 ABS 1
C05 PROTECTOR GLASS 3618345500 ABS 1
C06 DECORATOR DOOR *O 3611695900 ABS 1
C07 HOOK DOOR 3613101700 ALDC 1
C08 SPRING HOOK 3615115400 SUS304, 1
C09 HOOK SHAFT 3613101000 SUS, D=3.0 1
C10 FRAME DOOR *I 36122UD600 PP 1
C11 HINGE DOOR 3612903800 AL, DWD-T110R 1
C12 CAP HINGE DOOR 3610916500 POM 4
C13 DOOR GLASS 361A113300 GLASS 1
C14 CASE PUMP AS 36111T1K10 CASE PUMP(PP)+PAD 1
C15 COVER PUMP 3611431500 ABS 1

12
5. DOOR AS
C11
C01
C02
C03
C12
C10
C09
C04
C07
C05
C06
C08
■ 2nd Model

13
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
C01 FRAME DOOR 0 36122UDC00 ABS 1
C02 PROTECTOR GLASS 3618345600 TR-ABS 1
C03 DOOR GLASS 361A113300 GLASS 1
C04 FRAME DOOR 1 36122UDD00 PP 1
C05 HINGE DOOR 3612903800 ALDC 1
C06 CAP HINGE DOOR 3610916500 POM 4
C07 SCREW TAPPING 7115402029 T1S FLT 14 4*20 STS430 NATURE
C08 HOOK DOOR 3613101700 ALDC 1
C09 SPRING HOOK 3615115400 SUS 1
C10 HOOK SHAFT 36131010001` SUS 1
C11 CASE SPRING DOOR 3611149300 ABS 1
C12 SCREW TAPPING 7122401611 T2STRS 2 4*6 MFZN

14
DOOR AS
C01
C04
C05
C03
C06
C07
C09
C02
C08
■ 3rd Model (Wash Only)

15
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
C01 FRAME DOOR I 36122UDD00 PP 1
C02 FRAME DOOR O 36122UDW00 ABS 1
C03 DOOR GLASS 361A113300 GLASS 1
C04 HINGE DOOR 3612903800 ALDC 1
C05 CAP HINGE DOOR 3610916500 POM 4
C06 HOOK DOOR 3613101700 ALDC 1
C07 HOOK SHAFT 3613101000 SUS 1
C08 SPRING HOOK 3615115400 SUS 1
C09 CASE SPRING DOOR 3611149300 ABS 1
-SCREW TAPPING 7115402029 T1S FLT 13 4*20 STS430 NATYRE
-SCREW TAPPING 7122401611 T2STRS 2 4*6 MFZN
-DOOR AS 36117ADM00 D-LU10,WASHER ONLY 1 C1+~+C9+SCREW TAPPING

16
6. TUB ASSY(UNIVERSAL)
D26
D23
D22
D25
D24
D20
D18
D17
D19
D16
D15
D10
D21
D11
D04
D07
D05
D06
D08
D03
D01
D02 D43
D32
D46
D38
D45
D50
D47
D48
D49
D36
D35
D37
D40
D28
D30
D27
D29 D31
D34
D09
D13
D14
D12
D44
D42
D41
D33
D39

17
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
D01 BALANCER WEIGHT L 3616110600 PP, D-LU1011, 6.6KG 1
D02 SPECIAL SCREW 3616029400 SWCH 8.5X30 8
D03 BALANCER WEIGHT R 3616110500 PP, D-LU1011, 6.6KG 1
D04 CLAMP GASKET AS 3611207000 C-LU1011 1
D05 GASKET 3612325300 EPDM , WASH , D-LU1011 1 FOR WASH
D06 GASKET 3612325400 EPDM , DRY , C-LU1011 1 FOR DRY
D07 NOZZLE SHOWER 3618111200 PP 1
D08 CLAMP GASKET BUSHING 3611206800 GI 1.2T 1 FOR DRY
D09 SPECIAL SCREW 3616029810 SWCH 6.5X45 4
D10 DUCT B AS 3610DUTL00 C-L E 1 FOR DRY
D11 HOSE DRAIN *I 3613275200 EPDM D-LU1011 1
D12 CLAMP AS 3611203210 ID=61, WIRE+GUIDE+BOLT, GS 1
D13 CLAMP HOSE 3611204700 D26 1
D14 CLAMP HOSE 3611201401 HSW3,YW,D2.6,ID36,W44.5 1
D15 AIR TRAP 361A500101 PP 1
D16 HOSE AIR(PRESSURE) 3613266930 ID=4,OD=8, L=680MM(L-SERIES) 1
D17 DAMPER FRICTION 361A700110 70N AKS ST=170-260 DL=197.5 LOW NOISE 2
D18 DAMPER PIN 361A700200 AKS D=14.5 2
D19 TUB *F (FRONT) 3618830000 FRPP, C-LU1011 1
D20 SPRING SUSPENSION 3615116800 KGF 2
D21 SPECIAL SCREW 3616029800 SWCH 6.5X30 14
D22 SPECIAL SCREW 3616029500 SUS430 8*25 3
D23 LIFTER WASH 361A401300 PP,1PIECE,TWIST 3
D24 SCREW TAPPING 7122401408 T2S TRS 4X14 SUS,STS 3
D25 DRUM SUB AS 3617012600 D-LU1011 1
D26 SPIDER AS 361A301200 D-LU1011 1
D27 WATER SEAL 361A600100 NBR 1
D28 SEALING TUB 3612321601 EPDM L1600(-0~ +10) 1
D29 FIXTURE HEATER 3612006700 SUS 1
D30 BEARING INNER 3616303100 6206Z 1
D31 UNIT MOTOR UNIVERSAL 36189L4H10 DC220/50 G&J 2P PI340 45T(CCA) 1
D32 BALANCER WEIGHT LOWER 3616110300 PP, D-LU1011, 3.5KG 1
D33 SPECIAL SCREW 3616029400 SWCH 8.5X30 2
D34 SPECIAL SCREW 3616062800 SWRCH18A 7.4*25.5 2
D35 DAMPER FRICTION 361A700130 60N AKS ST=170-260 DL=197.5 LOW NOISE 2
D36 DAMPER PIN 361A700200 AKS D=14.5 2
D37 TUB REAR AS 36100T1400 D-LU1011 1
D38 BALANCER WEIGHT T 3616110400 PP, C-LU1011, 2.48KG 1 FOR DRY
D39 BALANCER WEIGHT T(WASH) 3616110700 PP, D-LU1011, 2.48KG 1 FOR WASH
D40 SPECIAL SCREW 3616029400 SWCH 8.5X30 2
D41 CLAMP HOSE 3611204700 D26 1
D42 SPECIAL SCREW 3616007400 T2S TRS 4X10+24 2 OPTION
D43 UNIT BUBBLE PUMP AS 36189L4120 220-240V DBK-240DB RP CHSHION 1 OPTION
D44 HOSE VENT 3613267100 EPDM 1
D45 BEARING OUTER 3616303200 6205Z 1
D46 HEATER WASH 3612803700 230V 2000W.1R5A721002.IRCA FUSE 2EA 1
D47 PIPE DUCT AS 3614414001 C-L PIPE DUCT+HOSE+CLAMP 1 FOR DRY
D48 PULLEY 3618434100 ALDC 1
D49 SPECIAL BOLT AS 3616029600 SWCH 10*30,F/L BOLT S.P/W SEAL LOCK 1
D50 BELT V 3616591120 GATES 4PJ1175 BUTADIENE RUBBER 1

18
7. TUB ASSY(DD MOTOR)
D26
D23
D22
D25
D24
D20
D18
D17
D19
D16
D15
D10
D21
D11
D04
D07
D05
D06
D08
D03
D01
D02 D39
D42
D34
D41
D43
D32
D31
D33
D36
D28
D30
D27
D29
D09
D13
D14
D12
D40
D38
D37
D35
D44
D45
D46
D47
D44-1
