Daewoo DWC-UD1222 User manual

Features
DWC-UD1222
Washing Machine Instruction Manual
"Economic wash system
Using artificial intelligence, the washer uses minimum energy
and water by selecting optimal water lever and washing time.
"Low noise system
The washer minimizes the washing and spinning noises by
sensing the amount of laundry.
"Child-Lock
The Child-Lock system has been used to prevent children
from pressing any button to change the program during
operation.
"Nano-silver sterilization washing
By applying very fine silver particles on essential parts inside,
the washer sterilizes up to 99.9% as is done by boiling wash.
"Air bubble washing
This is an advanced technology that generates millions of air
bubbles inside the drum on washing sequence, and the
bubbles dissolve the detergent particles completely and
cleanse all the soil in clothes gently and neatly.
"Waist Care
Designed by the waist, and the most comfortable angle eject
into the laundry is convenient and easy to manipulate.
"The World's First Steam Wash Course
The Steam Wash Course save more 50 percent of Electricity,
Water, Time than previous White
Course.
"The World's First
Shoes Course
Enable to wash shoes.
"Self-Cleaning
Course of Drum.
Enable to Self-Cleaning
of Drum.
"Digital Condensing
Dry System.
Condensing Dry System
with saveing energy.
1
PARTS AND FEATURES.................................................................................................................2
WASHER SAFETY...........................................................................................................................3
INSTALLATION INSTRUCTIONS....................................................................................................4
INLET HOSE CONNECTION...........................................................................................................5
ELECTRICAL REQUIREMENTS .....................................................................................................6
OPERATING YOUR WASHER........................................................................................................7
THE FUNCTIONS OF THE CONTROL PANEL...............................................................................9
WASHING PROGRAM...................................................................................................................10
WASHING PROCEDURE AND SELECTION ................................................................................11
GUIDE FOR OTHER USEFUL PROGRAMS.................................................................................23
MAINTENANCE .............................................................................................................................27
HOW TO CLEAN THE FILTER......................................................................................................28
REMOVING STAINS......................................................................................................................29
TROUBLE SHOOTING ..................................................................................................................30
SPECIFICATION............................................................................................................................31
A NOTE TO YOU
Thank you for buying a DAEWOO appliance.
DAEWOO washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer property and safely.
Please read it carefully.
CONTENTS Page

2
PARTS AND FEATURES
The parts and features of your washer are illustrated on the page.
Become familiar with all parts and features before using your washer.
Accessories
NOTE
The drawings in the book may vary from your washer model.
They are designed to show the different features of all models coverd by this book,
Your model may not include all features.
ADJUSTABLE LEG
CONTROL PANEL
DOOR
PUMP COVER
DETERGENT CASE
INLET HOSE
(HOT, OPTION) INLET HOSE (COLD)
POWER CORD
HOSE DRAIN
Hose drain Inlet hose Spanner Manual Cap holder

3
Save these instructions
Your safety is important to us.
To reduce the risk of fire, electrical shock, or injury when using your washer adhere to the
following basic precautions.
Understanding your responsibilities
• Do not use chlorine bleach and ammonia or acid(such as vinegar or rust remover) in the same
wash. Hazardous fumes can form.
• Unplug power supply cord before attempting to service your washer.
• Do not wash fiberglass material.
Small particles can stick to fabrics washed in following loads and cause skin irritation.
• Do not spray water on the control panel of the washer.
It could cause fire or an electric shock.
• In case of the dual valve model, if you connect only cold water inlet valve, while water
temperature is selected as hot or warm, there can be water leakage from unconnected water
inlet valve.
• This appliance must be grounded.
To avoide electrical shock, use a metal pipe for the ground connection.
• Flammable fluids (dry-cleaning solvents,
kerosene, gasoline, etc.) should not be used
or stored in or near your washer.
Do not add flammable fluids to your wash
water.These substances give off vapors that
can create a fire hazard or explosion.
• After starting a cycle, do not reach into the
washer until all motions stop.
• Do not tamper with the controls.
• The appliance is not intended for use by
young children or infirm persons without
supervision.
• If the supply cord is damaged, it must be
replaced by the manufacturer, or its service
agent or a similarly qualified person in order
to avoid a hazard.
• If the appliance is supplied from a cord
extension set or electrical portable outlet
device it should be positioned so that it is not
subjected to splashing or ingress of
moisture.
Please ...
• Have only a qualified person install, repair,
or replace parts on washer.
• Maintain washer properly.
• Protect washer from the weather and keep
it where the temperature will not fall below
freezing.
• Do not install the washer at a place of
extremely high humidity. It could cause an
electric shock or a short circuit.
• Connect washer to the correct outlet,
electrical supply, water supply, and drain
supply.
WASHER SAFETY
Read all instructions before using your washer

4
Removing transit bolts
1. Before operating the washer, remove the
transit bolts(4ea) along with the rubber.
• If the bolts are not removed, it may cause
heavy vibration, noise and malfunction.
2. Unscrew the 4 bolts with the spanner
supplied. Keep the 4 bolts and spanner for
future use.
• Whenever the appliance is transported, the
transit bolts must be refitted.
3. Close the holes with the cap holders supplied.
Location of washer
• Check location where the washer will be installed. Make sure you have everything necessary for
correct installation.
• Do not place or store your washer below 0°C (32°F) to avoid any damage from freezing.
• Do not place or store laundry products on top of washer at any times.
• Install the washer on the horizontal solid floor.
If the washer is installed on an unsuitable floor, it could make
considerable noise, vibrate severely and cause a malfunction. If the
washer is not level, adjust leg up or down for horizontal installation.
• Ventilation openings must not be obstructed by carpeting when the
washer is installed on a carpeted floor.
• Leave some space (right & left : 2cm, rear : 10cm).
• In case of built-in installation, the distance between top of the washer
and bottom of upper plate should be at least 3mm.
INSTALLATION INSTRUCTIONS
Laundry
Tub
Washer
approx.
2cm
Drain Hose

5
The washer should be connected to the water mains using new hose sets and old hose sets
should not be reused.
In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the
cold water inlet valve.
Option : Be careful not to confuse hot water inlet and cold water inlet.
For Ordinary Tap
For Screw-Shaped Tap
INLET HOSE CONNECTION
1Pull down the collar of the
inlet hose to separate it
from the water tap
adapter.
2Loosen the four screws
properly in order to fit into
water tap.
3Fit the water tap adapter
into the water tap and
tighten the four screws
evenly while pushing up
the adapter so that the
rubber packing can stick
to the water tap tightly.
4Remove the tape, and
screw connector B into
connect A tightly.
5Connect the inlet hose to
the water tap adapter by
pulling down the collar of
the hose end.
6Connect the inlet hose
adapter of the hose to the
water inlet of the washer
by turning it clockwise to
be fixed tightly.
• Please check the rubber
packing present inside the inlet
hose adapter of the hose.
1Connect the inlet hose to
the water tap by screwing
the connector tightly.
2Connect the connector-
inlet supplied if
necessary.
3Connect the inlet hose
adapter to the water inlet
of a washer and turn it to
be fixed.
*Check the packing in the inlet
TAPE
Connector B
Connector A
Connector
Connector
Rubber
Packing
Hose
Connector Rubber
Packing
Hose
Connector
inlet
Connector

6
ELECTRICAL REQUIREMENTS
• Electrical earth is required on this washer
• If it does not fit the outlet, have a proper outlet
installed by a qualified electrician.
• Don’t earth to a gas pipe.
• Don’t change the power supply cord plug.
• Check with a qualified electrician if you are not
sure the washer is properly earthed.
WARNING
Recommended earthing method
Electrical shock hazard : Failure to follow these instructions could result in death or serious injury.
For your personal safety, this washer must be earthed.
This washer is equipped with a power supply cord ‘A’ having a earthing plug ‘B’.
To minimize possible shock hazard, the cord must be plugged into a mating earthing-
type wall receptacle ‘C’. If a mating wall receptacle is not available, it is the personal
responsibility and obligation of the customer to have the proper earthed wall
receptacle installed by a qualified electrician.
C
B
A
Drain system
• Never forget to install drain hose before operating your washer.
• Open the packing box, and there is a drain hose inside the drum.
• Connect the drain hose to the drain outlet at the back side of the washer.
• Proper securing of the drain hose will protect the floor from damage due to water leakage.
• When the drain hose is too long, do not force it back into the washer. This will cause abnormal noise.
• For Pump Model
Top of laundry tub must be at least 60cm high and no higher than 100cm For Pump Model of washer.
When installing the drain hose to tub(sink), secure it tightly with a string.
• For Non-Pump Model
If you need to extend drain hose,
contact the sales agent, or service center.
Level adjustment
1If the washer is installed on an unsuitable floor,
it could make considerable noise, vibrate and
cause a malfunction.
contacting outlet
Connect the - type end
of drain hose to the end
of contacting outlet securely.
less than 1m less than
10cm
Height of Length of
drain hose drain hose
if the height of drain hose less than 10cm less than 1m
is elevated in the middle
If not the height of drain – less than 3m
hose is elevated in the middle
For extending the drain hose, the type of end of drain hose to be used is not "ㄱ" type, but "-" type.

7
OPERATING YOUR WASHER
2Adjust the level of washer using adjustable legs.
• Please check if there is any gap between the
four adjustable legs and the floor.
• Turning adjustable legs by the enclosed
spanner, adjust the level of washer and make
it sure that there is no swaying of washer.
• After the adjustment is finished, turn the fixing
nuts up tightly so that the washer maintains the adjustment.
3Make it sure that the washer does not sway when you press
down the four corners of the washer's top plate.
adjustable leg
Fixing Nut
NOTE
There should be no swaying of washer and all the
adjustable legs should stick to the floor closely.
To obtain the best washing results, you must operate your washer properly.
This section gives you this important information.
• Close zippers, snaps, and hooks to avoid
snagging other items.
Remove pin, buckles, and other hard
objects to avoid scratching the washer
interior.
• Empty pockets and pull them inside out.
• Turn down cuffs and turn synthetic knits
inside out to avoid pilling.
• Tie strings and sashes to avoid tangling.
• Treat spots and stains.
(See “Removing stains” on page 21)
Preparing clothes for washing

8
• Separate heavily soiled items from lightly soiled ones, even if they would normally be washed
together.
• Separate dark colors from light colors, colorfast items from non-colorfast item.
Soil (Heavy, Normal, Light) Separate clothes according to amount of soil.
Color (White, Lignts, Darks) Separate white clothes from colored clothes.
Lint (Lint producers, Collectors) Wash lint producers and lint collectors separately.
Sorting
• Drop items into washer loosely. Items
should move easily through wash water for
best cleaning and wrinkle-free results.
• Load washer properly and select correct
load size setting.
Overloading and selecting a setting too
small for the wash load can :
- Cause poor cleaning
- Increase wrinkling
- Create excessive lint
- Wear out items faster (because of pilling)
• Mix large and small items in each load.
Load evenly to maintain washer balance.
An unbalanced load can make the washer
vibrate during spin.
• Reduce wash time when using a small load
size setting. Load with only a few small
items needs less wash time.
• Use a large load size setting to reduce
wrinkling with permanent press clothes and
some synthetic knits. These items should
have more room to move in the water than
heavy items. (towels, jeans)
1Detergent case 2Adding fabric softener
• If desired, add measured liquid fabric
softener to the softener inlet.
• Pour liquid fabric softener into the
dispenser using the amount
recommended on the package.
• Do not exceed the maximum fill line.
Overfilling can cause early dispensing of the
fabric softener which could stain clothes.
• Do not open the detergent case when
water is supplied.
• Avoid pouring fabric softener directly on
the clothes.
Loading
Adding detergent
Main wash Pre wash
Fabric softener

9
Press this switch to turn the power 'ON' or 'OFF'.
Operation and temporary stop is repeated as it is pressed. When you want to change program
in operating; Press the 'Start/Pause' button →Select the program that you want to change →
Press the 'Start/Pause' button again.
You can select the course you want and each lamp is turned on when that course is selected.
You can select the wash course you want and each lamp is turned on when that course is
selected.As this button is pressed, the wash course is selected by Soak →Prewash →Main
Wash.
You can select the rinse time(s) you want and each lamp is turned on when that course is
selected.As this button is pressed, the rinse time(s) is selected by '1' →'Add water' →'2' →
'Add water' →... ...→'5' →'Add water' →'1'.
You can select the spin speed you want and each lamp is turned on when that course is
selected.
It can be used to pre-engage time for wash from 1 hr to 12 hrs.
It can be used to adjust water temperature according to types of the load to be washed.As this
button is pressed, water temperature is selected by Cold →30°C →40°C →60°C →95°C.
You can select the dry condition you want and each lamp is turned on when that course is
selected.
‘Use this function when you want to protect any accident occurring from handling of washer by
a child.During an operation of washer, press 'SPIN' and 'DRY' buttons simultaneously during 3
second.If this mode will be set successfully, CHL and remain time will be showen on PCB
board alternately.In Child Lock mode, no button functions except Power button.If you want to
set this mode, press 'SPIN' and 'DRY' buttons simultaneously during 3 second.And if you want
to release this mode, press 'SPIN' and 'DRY' buttons simultaneously again during 3 second.
If you want to change to the desire program, while this mode is working;
1. Press 'SPIN' and 'DRY' buttons simultaneously again during 3 second.
2. Press the 'Start/Pause' button.
3. Select the desired program and
press the 'Start/Pause' buttom
again.
* The Child Lock will be cancelled when power is off.
If you want to open Door intensionally during operation, press the 'Start/Pause' button and
press again 'Door unlock' button.
In this case, signal will be appeared on PCB board, then you can open Door after cooling
insideTub temperature and draining water, also no button functions except Power button.
THE FUNCTION OF CONTROL PANEL
Change
the desired
program

Colorfast garments (shirts, night
dresses, pajamas,..) and lightly
soiled white cottons(underwares,..)
First check whether laundry is
machine washable.
(white cotton, linen, towel and
sheets..)
Heavy soiled clothes
(blue-jean,climbing clothes, ruck
sack, sports wear,...)
Delicated laundry easily damaged.
(silk, curtains,..)
Blanket, curtains,..
Lightly soiled clothes and frequently
washing clothes and small amount
of clothes.
Use to memory program you want.
Use to clean
the Tub and Drum.
enable to white(white cotton, linen,
towel, shees..)
Only sports shoes
Baby Clothes
disinfect or deodorize
10
WASHING PROGRAM
Program Fabric type Proper Temp. Default data Maximum Load
Normal
Whites
Heavy Stain
Delicate
Blanket
Quick 30
Memory
Tub
Clean
Steam
Wash
Sports
Shoes
Baby Care
Air Wash
40°C
(cold,30°C, 60°C)
95°C
(fixed)
40°C
(cold, 30°C, 60°C)
Cold
(fixed, in order to
prevent textile damage)
Cold
(fixed, in order to
prevent textile damage)
Cold
(fixed)
Cold
40°
40°
40°
Cold
Wash: main wash
Rinse: 2
Spin : Medium
Temp.: 40°C
Wash: main wash
Rinse: 3
Spin : Medium
Temp.: 95°C
Wash: pre wash
Rinse: 3
Spin : Medium
Temp.: 40°C
Wash: main wash
Rinse: 2
Spin: low
Temp.: cold
Wash: main wash
Rinse: 3
Spin : Medium
Temp.: cold
Wash: main wash
Rinse: 1
Spin : Medium
Temp.: cold
Wash: soak
Rinse: 2
Spin: low
Temp.: cold
Dry : Low Temp
Wash :main wash
Rinse : 2
Spin : Medium
Temp. : 40°C
Steam: Strong
Wash :main wash
Rinse : 2
Spin : low
Temp. : 40°C
Dry : Low Temp
Wash :main wash
Rinse : 4
Spin : Medium
Temp. : 40°C
Steam : Strong
Dry
Maximum Load
Maximum Load
Maximum Load
Maximum Load
Maximum Load
Less than 3 kg
without load.
Maximum Load
Maximum Load
Maximum Load
Below 4 kg

11
1. NORMAL PROGRAM
Note
• If you want to change the setting program during operation, press the 'Start/Pause' button to hold the
operation and change the program you want to change by pressing each corresponding button.
• Water temperature '95°C' is not selected in order to prevent clothes from damaging.
• If you want to add the clothes during operation, press 'Start/Pause' button and 'Door unlock' button, then
open the Door and put the clothes into the Drum and then close Door and press 'Start/Pause' button again.
Put the laundry into the Drum and put the detergent and softerner into the detergent
case.
Then close the Door.
• Put the detergent into the main wash room(I I marking).
• Softener should be below 'MAX' level.
• Put the detergent into the pre wash room(I marking) only if you want to add prewash.
• When you want to use bleach, put it into the main wash room (I I marking) with
detergent.
Press the Power button.
• The LED shows only '- --' signal.
Select the 'NORMAL' program using the program selection dial.
• If you press 'Start/Pause' button aftrer pressing Power button without selecting
program, the 'NORMAL' program is selected as default program.
• Main wash' and '2' times rinse and 'Medium' spin speed and '40°C' water temperature
are selected automatically.
• If you want to change the 'Washing course' and 'Rinse time(s)' and 'Spin speed' and
'water temperature', select program what you want to change by pressing each
button.
Press the 'Start/Pause' button.
• The washer will be operated with locking Door and supplying water after sensing the
amount of laundry automatically.
1
2
3
4
WASHING PROCEDURE AND SELECTION

12
2. WHITES PROGRAM
Note
• If you want to change the setting program during operation, press the 'Start/Pause' button to hold the
operation and change the program you want to change by pressing each corresponding button.
• Water temperature is set only to '95°C'.
• If you want to add the clothes during operation, press 'Start/Pause' button and 'Door unlock' button, then
open the Door and put the clothes into the Drum and then close Door and press 'Start/Pause' button again.
• If much SUDS is happened during operation, the washer will clean SUDS automatically.
Put the laundry into the Drum and put the detergent and softerner into the detergent
case
Then close the Door
• Put the detergent into the main wash room(I I marking .
• Softener should be below 'MAX' level.
• Put the detergent into the pre wash room(I marking) only if you want to add prewash.
• When you want to use bleach, put it into the main wash room (I I marking) with
detergent
Press the Power button
• The LED shows only '- --' signal
Select the 'WHITE' program using the program selection dial.
• If you press 'Start/Pause' button aftrer pressing Power button without selecting
program, the 'NORMAL' program is selected as default program.
• 'Main wash' and '3' times rinse and 'Medium' spin speed and '95°C' water
temperature are selected automatically.
• If you want to change the 'Washing course' and 'Rinse time(s)' and 'Spin speed' ,
select program what you want to change by pressing each button.
Press the 'Start/Pause' button.
• The washer will be operated with locking Door and supplying water after sensing the
amount of laundry automatically.
1
2
3
4

13
3. HEAVY STAIN PROGRAM
Note
• If you want to change the setting program during operation, press the 'Start/Pause' button to hold the
operation and change the program you want to change by pressing each corresponding button.
• Water temperature '95°C' is not selected in order to prevent clothes from damaging.
• If you want to add the clothes during operation, press 'Start/Pause' button and 'Door unlock' button, then
open the Door and put the clothes into the Drum and then close Door and press 'Start/Pause' button again.
Put the laundry into the Drum and put the detergent and softerner into the detergent
case.
Then close the Door.
• Put the detergent into the main wash room(I I marking) and prewash room(I marking)
in the detergent case.
• Softener should be below 'MAX' level.
• When you want to use bleach, put it into the main wash room (I I marking) with
detergent.
Press the Power button.
• The LED shows only '- --' signal.
Select the 'HEAVY STRAIN' program using the program selection dial.
• If you press 'Start/Pause' button aftrer pressing Power button without selecting
program, the 'NORMAL' program is selected as default program.
• 'Pre wash' and '3' times rinse and 'Medium' spin speed and '40°C' water temperature
are selected automatically.
• If you want to change the 'Washing course' and 'Rinse time(s)' and 'Spin speed' and
'water temperature', select program what you want to change by pressing each
button.
Press the 'Start/Pause' button.
• The washer will be operated with locking Door and supplying water.
1
2
3
4

14
4. DELICATE PROGRAM
Note
• If you want to change the setting program during operation, press the 'Start/Pause' button to hold the
operation and change the program you want to change by pressing each corresponding button.
• Water temperature 'Cold' is only selected in order to prevent delicate clothes from damaging.
• Spin speed 'low' and 'Rinse Hold' are only selectable.
• DRY function is not selected(option function).
• DELAY START is not selected.
• SOAK and Pre Wash in wash program are not selected.
• If you want to add the clothes during operation, press 'Start/Pause' button and 'Door unlock' button, then
open the Door and put the clothes into the Drum and then close Door and press 'Start/Pause' button again.
Put the laundry into the Drum and put the detergent and softerner into the detergent
case.
Then close the Door.
• Put the detergent into the main wash room(I I marking) in the detergent case.
• Softener should be below 'MAX' level.
• When you want to use bleach, put it into the main wash room (I I marking) with
detergent.
Press the Power button.
• The LED shows only '- --' signal.
Select the 'DELICATE' program using the program selection dial.
• If you press 'Start/Pause' button aftrer pressing Power button without selecting
program, the 'NORMAL' program is selected as default program.
•'Main wash' and '2' times rinse and 'low' spin speed and 'Cold' water temperature are
selected automatically.
• If you want to change the 'Washing course' and 'Rinse time(s)' and 'Spin speed',
select program what you want to change by pressing each button.
Press the 'Start/Pause' button.
• The washer will be operated with locking Door and supplying water.
1
2
3
4

15
5. BLANKET PROGRAM
Note
• If you want to change the setting program during operation, press the 'Start/Pause' button to hold the
operation and change the program you want to change by pressing each corresponding button.
• Water temperature 'Cold' is only selected in order to prevent delicate clothes from damaging.
• Spin speed 'low' and 'medium' and 'Rinse Hold' are only selectable.
• DRY function is not selected(option function).
• DELAY START is not selected.
• SOAK and Pre Wash in wash program are not selected.
• If you want to add the clothes during operation, press 'Start/Pause' button and 'Door unlock' button, then
open the Door and put the clothes into the Drum and then close Door and press 'Start/Pause' button again.
Put the laundry into the Drum and put the detergent and softerner into the detergent
case.
Then close the Door.
• Put the detergent into the main wash room(I I marking) in the detergent case.
• Softener should be below 'MAX' level.
• When you want to use bleach, put it into the main wash room (I I marking) with
detergent.
Press the Power button.
• The LED shows only '- --' signal.
Select the 'BLANKET' program using the program selection dial.
• If you press 'Start/Pause' button aftrer pressing Power button without selecting
program, the 'NORMAL' program is selected as default program.
• 'Main wash' and '3' times rinse and 'Medium' spin speed and 'Cold' water temperature
are selected automatically.
• If you want to change the 'Washing course' and 'Rinse time(s)' and 'Spin speed',
select program what you want to change by pressing each button.
Press the 'Start/Pause' button.
• The washer will be operated with locking Door and supplying water.
1
2
3
4

16
6. QUICK 30 PROGRAM
Note
• The appropriate amount of laundry is below 3 kg.
• If you want to change the setting program during operation, press the 'Start/Pause' button to hold the
operation and change the program you want to change by pressing each corresponding button.
• Water temperature only Cold.
• Spin speed 'extra/high' is not selected.
• All wash program are not selected except main wash..
• If you want to add the clothes during operation, press 'Start/Pause' button and 'Door unlock' button, then
open the Door and put the clothes into the Drum and then close Door and press 'Start/Pause' button again.
Put the laundry into the Drum and put the detergent and softerner into the detergent
case.
Then close the Door.
• Put the detergent into the main wash room(I I marking) in the detergent case.
• Softener should be below 'MAX' level.
• When you want to use bleach, put it into the main wash room (I I marking) with
detergent.
Press the Power button.
• The LED shows only '- --' signal.
Select the 'QUICK 30' program using the program selection dial.
• If you press 'Start/Pause' button aftrer pressing Power button without selecting
program, the 'NORMAL' program is selected as default program.
• 'Main wash' and '1' times rinse + add water and 'Medium' spin speed and 'Cold'
water temperature (and 'Cupboard' dry condition) are selected automatically.
• If you want to change the 'Washing course' and 'Rinse time(s)' and 'Spin speed' and
'water temperature', select program what you want to change by pressing each
button.
Press the 'Start/Pause' button.
• The washer will be operated with locking Door and supplying water.
1
2
3
4

17
7. MEMORY PROGRAM
Note
• If you start memorized program, this data will be saved automatically.
• If you want to change the setting program during operation, press the 'Start/Pause' button to hold the
operation and change the program you want to change by pressing each corresponding button.
• If you want to add the clothes during operation, press 'Start/Pause' button and 'Door unlock' button, then
open the Door and put the clothes into the Drum and then close Door and press 'Start/Pause' button again.
Put the laundry into the Drum and put the detergent and softerner into the detergent
case.
Then close the Door.
• Put the detergent into the main wash room(I I marking) .
• Softener should be below 'MAX' level.
• Put the detergent into the pre wash room(I marking) only if you want to add prewash.
• When you want to use bleach, put it into the main wash room (I I marking) with
detergent.
Press the Power button.
• The LED shows only '- --' signal.
Select the 'MEMORY' program using the program selection dial.
• If you press 'Start/Pause' button aftrer pressing Power button without selecting
program, the 'NORMAL' program is selected as default program.
• If you want to memorize the 'Washing program' and 'Washing course' and 'Rinse
time(s)' and 'Spin speed' and 'water temperature' (and 'Dry condition'), select
somethings what you want to change by pressing each button and using the program
selection dial.
Press the 'Start/Pause' button.
• The washer will be operated with locking Door and supplying water.
1
2
3
4

18
8. TUB CLEAN PROGRAM
Note
• All programs are not selectable except rinse time(s).
• DELAY START is not selected.
• Use this program WITHOUT load.
• The appropriate cleaning time is one time per a month.
Press the Power button.
• The LED shows only '- --' signal.
Select the 'TUB CLEAN' program using the program selection dial.
• If you press 'Start/Pause' button aftrer pressing Power button without selecting
program, the 'NORMAL' program is selected as default program.
• 'Soak' and '2' times rinse and 'low' spin speed and 'Cold' water temperature (and 'Low
Temp' dry condition) are selected automatically.
Press the 'Start/Pause' button.
• The washer will be operated with locking Door and supplying water.
1
2
3

19
9. STEAM WASH
Note
• If you want to change the setting program during operation, press the 'Start/Pause' button to hold the
operation and change the program you want to change by pressing each correspinding button.
• If you want to add the clothes during operation, press 'Start/Pause' button and 'Door unlock' button, then
open the door and put the clothes into the drum and then close door and press 'Start/Pause' button again.
Put the laundry into the Drum and put the detergent and softerner into the detergent
case.
Then close the door.
• Put the detergent into the main wash room(II marking).
• Softener should be below 'MAX' level.
• Put the detergent into the prewash room only if you want to add prewash.
• When you want to use bleach put it into the main wash room with detergent
Press the Power button
• The LED shows only '- --' signal.
Select the 'Steam Wash' program using the program selection dial
• Main wash and 2 times rinse and 'Medium' spin speed and 40°C water temperature
"Steam : Strong" are selected automatically.
• If you want to change the 'Washing course' and 'Rinse time' and Spin speed' and
'water temperature',select program what you want to change by pressing each
button.
Press the 'Start/Pause' button
• The washer will be operated with locking door and supplying water after sensing the
amount of laundry automatically.
1
2
3
4

20
10. SPORTS SHOES
Note
• Please wash only sports shoes.
• If you wash boots or shoes, clothes are damaged.
Put the laundry into the Drum and put the detergent and softerner into the detergent
case.
Then close the door.
• Put the detergent into the main wash room and prewash room in the detergent case.
• When you want to use bleach put it into the main wash room with detergent
Press the Power button
• The LED shows only '- --' signal.
Select the 'Sports shoes' program using the program selection dial
• Main wash and 2 times rinse and low spin speed and 40°C water temperature (Dry :
Low Temp) are selected automatically.
• If you want to change the 'Washing course' and 'Rinse time' and Spin speed' and
'water temperature',select program what you want to change by pressing each
button.
Press the 'Start/Pause' button
• The washer will be operated with locking door and supplying water after sensing the
amount of laundry automatically.
1
2
3
4
