Daewoo DWD-FD2442 User manual

A NOTE TO YOU
Thank you for buying a DAEWOO appliance.
DAEWOO washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer properly and safely.
Please read it carefully.
INSTRUCTION MANUAL
DWD-FD2442
Washing Machine Instruction Manual
!Economic wash system
Using artificial intelligence, the washer uses minimum energy and water by
selecting optimal water lever and washing time.
!Low noise system
The washer minimizes the washing and spinning noises by sensing the
amount of laundry.
!Child-Lock
The Child-Lock system has been used to prevent children from pressing any
button to change the program during operation.
!Air bubble washing(Option)
This is an advanced technology that generates millions of air bubbles inside the drum on washing sequence, and
the bubbles dissolve the detergent particles completely and cleanse all the soil in clothes gently and neatly.
CONTENTS Page
PARTS AND FEATURES.................................................................................................................2
WASHER SAFETY...........................................................................................................................3
INSTALLATION INSTRUCTIONS....................................................................................................4
INLET HOSE CONNECTION...........................................................................................................5
ELECTRICAL REQUIREMENTS .....................................................................................................6
OPERATING YOUR WASHER........................................................................................................7
THE FUNCTIONS OF THE CONTROL PANEL...............................................................................9
WASHING PROCEDURE AND PROGRAM SELECTION.............................................................10
MAINTENANCE .............................................................................................................................19
HOW TO CLEAN THE FILTER......................................................................................................20
REMOVING STAINS......................................................................................................................21
TROUBLE SHOOTING ..................................................................................................................22
SPECIFICATION............................................................................................................................23

2
PARTS AND FEATURES
The parts and features of your washer are illustrated on the page.
Become familiar with all parts and features before using your washer.
Accessories
NOTE
The drawings in the book may vary from your washer model.
They are designed to show the different features of all models coverd by this book,
Your model may not include all features.
ADJUSTABLE LEG
CONTROL PANEL
DOOR
DETERGENT CASE
INLET HOSE
LOWER COVER
POWER CORD
HOSE DRAIN
Inlet hose Manual Cap holder(3EA)

3
Save these instructions
Your safety is important to us.
To reduce the risk of fire, electrical shock, or injury when using your washer adhere to the
following basic precautions.
Understanding your responsibilities
• Do not use chlorine bleach and ammonia or acid(such as vinegar or rust remover) in the same
wash. Hazardous fumes can form.
• Unplug power supply cord before attempting to service your washer.
• Do not wash fiberglass material.
Small particles can stick to fabrics washed in following loads and cause skin irritation.
• Do not spray water on the control panel of the washer.
It could cause fire or an electric shock.
• In case of the dual valve model, if you connect only cold water inlet valve, while water
temperature is selected as hot or warm, there can be water leakage from unconnected water
inlet valve.
• This appliance must be grounded.
To avoide electrical shock, use a metal pipe for the ground connection.
• Flammable fluids (dry-cleaning solvents,
kerosene, gasoline, etc.) should not be used
or stored in or near your washer.
Do not add flammable fluids to your wash
water.These substances give off vapors that
can create a fire hazard or explosion.
• After starting a cycle, do not reach into the
washer until all motions stop.
• Do not tamper with the controls.
• The appliance is not intended for use by
young children or infirm persons without
supervision.
• If the supply cord is damaged, it must be
replaced by the manufacturer, or its service
agent or a similarly qualified person in order
to avoid a hazard.
• If the appliance is supplied from a cord
extension set or electrical portable outlet
device it should be positioned so that it is not
subjected to splashing or ingress of
moisture.
Please ...
• Have only a qualified person install, repair,
or replace parts on washer.
• Maintain washer properly.
• Protect washer from the weather and keep
it where the temperature will not fall below
freezing.
• Do not install the washer at a place of
extremely high humidity. It could cause an
electric shock or a short circuit.
• Connect washer to the correct outlet,
electrical supply, water supply, and drain
supply.
WASHER SAFETY
Read all instructions before using your washer

4
Removing transit bolts
1. Before operating the washer, remove the
transit bolts(3ea) along with the rubber.
• If the bolts are not removed, it may cause
heavy vibration, noise and malfunction.
2. Unscrew the 3 bolts with the 10mm hex
wrench or spanner or cross-tip screwdriver.
Keep the 3 bolts for a later time.
• When the appliance is transported, transit
bolts will be re-used.
3. Close the holes with the cap holders supplied.
Location of washer
• Check location where the washer will be installed. Make sure you have everything necessary for
correct installation.
• Do not place or store your washer below 0°C (32°F) to avoid any damage from freezing.
• Do not place or store laundry products on top of washer at any times.
• Install the washer on the horizontal solid floor.
If the washer is installed on an unsuitable floor, it could make
considerable noise, vibrate severely and cause a malfunction. If the
washer is not level, adjust leg up or down for horizontal installation.
• Ventilation openings must not be obstructed by carpeting when the
washer is installed on a carpeted floor.
• Leave some space (right & left : 2cm, rear : 10cm).
• In case of built-in installation, the distance between top of the washer
and bottom of upper plate should be at least 3mm.
INSTALLATION INSTRUCTIONS
Laundry
Tub
Washer
approx.
2cm
Drain Hose

5
The washer should be connected to the water mains using new hose sets and old hose sets
should not be reused.
In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the
cold water inlet valve.
Option : Be careful not to confuse hot water inlet and cold water inlet.
For Ordinary Tap
For Screw-Shaped Tap
INLET HOSE CONNECTION
1Pull down the collar of the
inlet hose to separate it
from the water tap
adapter.
2Loosen the four screws
properly in order to fit into
water tap.
3Fit the water tap adapter
into the water tap and
tighten the four screws
evenly while pushing up
the adapter so that the
rubber packing can stick
to the water tap tightly.
4Remove the tape, and
screw connector B into
connect A tightly.
5Connect the inlet hose to
the water tap adapter by
pulling down the collar of
the hose end.
6Connect the inlet hose
adapter of the hose to the
water inlet of the washer
by turning it clockwise to
be fixed tightly.
• Please check the rubber
packing present inside the inlet
hose adapter of the hose.
1Connect the inlet hose to
the water tap by screwing
the connector tightly.
2Connect the connector-
inlet supplied if
necessary.
3Connect the inlet hose
adapter to the water inlet
of a washer and turn it to
be fixed.
*Check the packing in the inlet
TAPE
Raccorclement B
Raccorclement A
Connector
Connector
Rubber
Packing
Hose
Connector Rubber
Packing
Hose
Connector
inlet
Connector

6
ELECTRICAL REQUIREMENTS
• Electrical earth is required on this washer
• If it does not fit the outlet, have a proper outlet
installed by a qualified electrician.
• Don’t earth to a gas pipe.
• Don’t change the power supply cord plug.
• Check with a qualified electrician if you are not
sure the washer is properly earthed.
WARNING
Recommended earthing method
Electrical shock hazard : Failure to follow these instructions could result in
death or serious injury.
For your personal safety, this washer must be earthed.
This washer is equipped with a power supply cord ‘A’ having a earthing plug ‘B’.
To minimize possible shock hazard, the cord must be plugged into a mating
earthing-type wall receptacle ‘C’. If a mating wall receptacle is not available,
it is the personal responsibility and obligation of the customer to have the
proper earthed wall receptacle installed by a qualified electrician.
C
B
A
Drain system
• Never forget to install drain hose before operating your washer.
• Open the packing box, and there is a drain hose inside the drum.
• Connect the drain hose to the drain outlet at the back side of the washer.
• Top of laundry tub must be at least 60cm high and no higher than 100cm from bottom of washer.
• When installing the drain hose to tub(sink), secure it tightly with a string.
• Proper securing of the drain hose will protect the floor from damage due to water leakage.
• When the drain hose is too long, do not force it back into the washer.
This will cause abnormal noise.
Level adjustment
1If the washer is installed on an
unsuitable floor, it could make
considerable noise, vibrate and
cause a malfunction.

7
OPERATING YOUR WASHER
2Adjust the level of washer using adjustable legs.
• Please check if there is any gap between the
four adjustable legs and the floor.
• Adjust the level of washer by turning
adjustable legs. And make it sure that there is
no swaying of washer.
• After the adjustment is finished, turn the fixing
nuts up tightly so that the washer maintains
the adjustment.
3Make it sure that the washer does not sway when you press
down the four corners of the washer's top plate.
adjustable leg
Fixing Nut
NOTE
There should be no swaying of washer and all the
adjustable legs should stick to the floor closely.
To obtain the best washing results, you must operate your washer properly.
This section gives you this important information.
• Close zippers, snaps, and hooks to avoid
snagging other items.
Remove pin, buckles, and other hard
objects to avoid scratching the washer
interior.
• Empty pockets and pull them inside out.
• Turn down cuffs and turn synthetic knits
inside out to avoid pilling.
• Tie strings and sashes to avoid tangling.
• Treat spots and stains.
(See “Removing stains” on page 21)
Preparing clothes for washing

8
• Drop items into washer loosely. Items should move
easily through wash water for best cleaning and
wrinkle-free results.
• Load washer properly and select correct load size
setting.
Overloading and selecting a setting too small for
the wash load can :
- Cause poor cleaning
- Increase wrinkling
- Create excessive lint
- Wear out items faster (because of pilling)
• Mix large and small items in each load. Load evenly
to maintain washer balance.
An unbalanced load can make the washer vibrate
during spin.
• Reduce wash time when using a small load size
setting. Load with only a few small items needs
less wash time.
• Use a large load size setting to reduce wrinkling
with permanent press clothes and some synthetic
knits. These items should have more room to move
in the water than heavy items. (towels, jeans)
Loading
1Detergent case 2Adding fabric softener
• If desired, add measured liquid fabric
softener to the softener inlet.
• Pour liquid fabric softener into the
dispenser using the amount
recommended on the package.
• Do not exceed the maximum fill line.
Overfilling can cause early dispensing of the
fabric softener which could stain clothes.
• Do not open the detergent case when
water is supplied.
• Avoid pouring fabric softener directly on
the clothes.
Adding detergent
• Separate heavily soiled items from lightly soiled ones, even if they would normally be washed together.
• Separate dark colors from light colors, colorfast items from non-colorfast item.
Sorting
Soil (Heavy, Normal, Light) Separate clothes according to amount of soil.
Color (White, Lignts, Darks) Separate white clothes from colored clothes.
Lint (Lint producers, Collectors) Wash lint producers and lint collectors separately.
Main wash Pre wash
Fabric softener
• Please use only the powder detergent for the front loader washing machine.
• Please use the proper amount of detergent in conformity with the instruction of the detergent manufacturer.
• A use of a large amount of fetergent more than the recommended amount can cause many soapsuds and
the overload to the motor. In addition to, this will deteriorate the washing and rinse performmance.

9
Press this switch to turn the power on or off.
Operation and temporary stop is repeated as it is pressed.
When you want to change program in operating;
press the “Start/Pause” button "Select the program that you want to change "press the
“Start/Pause” button again.
You can select the course you want, and each lamp is turned on when that course is selected.
For the more detailed information, please refer to the page 11~18.
It can be used to adjust temperature of water according to types of the load to be washed.
As the button is pressed, temperature of water is selected by
Cold "30˚C "40˚C "60˚C "95˚C
By pressing the spin button, the spin speed can be chosen.
Rinse Hold • Is selected by pressing the spin button repeatedly. This function leaves clothes
in the machine; suspended in the water after a rinse without entering into spin.
• To proceed through to a drain or spin, after the Rinse Hold function is
completed, use spin button.
Spin only • If you want only spin, you can operate spin only. (See page 18.)
Crease Care • If you want to prevent crease, select this button with spin speed.
Rinse+ • Is used to add a rinse, which may assist in removing traces of detergent
residue.
• By selecting Rinse+ function, the rinse time and the rinse water are increased.
Pre-Wash • The washer operates one additional wash and spin before the main wash.
• If the laundry is heavily soiled, Pre-Wash course is effective.
• Pre-Wash is available in Cotton and Synthetic programs.
All courses have pre-set washing times, but Time Save decreases it to 10 minutes.
Each time this button is pressed the watch icon is repeated on and off. When it is on, the Time
Save function is set. Time Save is available in Cotton, Eco and Synthetic programs.
It can be used to pre-engage time for wash.
Use this function when you want to protect any accident occurring from handling of washer by a
child.
During an operation of washer, press ‘Time Save’ and ‘Time Delay’ buttons simultaneously.
In Child Lock mode, no button functions except Power button.
In Child Lock mode, press ‘Time Save’ and ‘Time Delay’ buttons simultaneously like setting
Child Lock and Child Lock is cancelled.
To change to the desirde program, while in Child Lock mode;
1. Press both the Time save and Time delay buttons together once again.
2. Press the Start/Pause button.
3. Select the desired program and
press the Start/Pause button again.
* The Child Lock will be cancelled when
power is off.
THE FUNCTIONS OF THE CONTROL PANEL
Change the
desired
program

10
1. COTTON IS AUTOMATICALLY SELECTED UPON POWER ON
• Press the Power button to start.
• Press the Start/Pause button
• Initial condition
- Program : Cotton
- Wash : main wash
- Rinse : 3 times
- Spin : 800 rpm
- Water temperature : 40˚C
WASHING PROCEDURE AND PROGRAM SELECTION
2. MANUAL SELECTING
• Press the Power button to start
• Select the conditions which you want to use by turning the program dial and pressing each button.
• Press the Start/Pause button.
3. RESERVED WASHING
• Reservation can be made from 2 hours to 12 hours.
example) To make reservation to complete washing in 8 hours.
- Procedure to press the button.
* Each pressing of the button advances time delay by one hour.
• Now the reservation is made.
• If you want to check the selected program, press the “Start/Pause” button again.
• Preparing washing before starting “Time Delay”;
- Turn on the water tap
- Load laundry and close the door
- Place the detergent and fabric softener in the detergent case.
• To cancel the time delay, press the Power button.
ajust to "8"
select the
program
or manual

11
4. FUNCTION
• Recommended programs according to the laundry type
• Pre Wash : If the laundry is heavily soiled, “Pre Wash” program is recommended.
Pre Wash is available in Cotton and Synthetic programs.
• Rinse+ : Used to introduce an additional rinse, which may assist in removing traces of detergent residue.
• Eco : By selecting Eco function, the water temperature is lowered and washing time is increased.
So you can economize your consumption of heating energy.
• Quick : “THE QUICK CYCLE” option has a very short cycle time.
Recommended uses include Small amount of the laundry, a relatively clean laundry, Frequently-
used clothes.
Fabirc
Type
First check if laundry is machine
washable.(white cotton, linen
towel and sheets..)
Colorfast garments
(shirts, night dresses, pajamas..)
and lightly soiled white cottons
(underwear..)
60˚C
(95˚C)
Pre Wash
Rinse+
Crease Care Rating
40°C
(Cold, 30°C,
60°C)
Pre Wash
Rinse+
Crease Care Rating
Laundry type is the same as
Cotton. 60˚CPre Wash
Rinse+
Crease Care Rating
Proper
Temp. Option Maximum Load
Program
Cotton
Eco
Polyamide, Acrylic, Polyester 40°C (Cold, 30°C,
60°C)
Pre Wash
Rinse+
Crease Care
Less than
2.0kg
Synthetic
Delicate laundry easily
damaged
(silk, curtains..)
Cold
(30°C, 40°C) Rinse+ Crease Care Less than 2.0kg
Delicate
Machine washable woolens
with pure new wool only. Cold (30°C, 40°C) Rinse+ Crease Care Less than 2.0kg
Wool
“Hand wash” marked delicate
and wool laundry Cold (30˚C) Rinse+ Crease Care Less than 2.0kg
Hand Wash
Colored laundry which
is lightly soiled fast. 30˚C (Cold, 40˚C) Rinse+ Crease Care Less than 2.0kg
Quick 30

12
* COTTON PROGRAM
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and
press the button you want.
• ‘Cold’, ‘30’°C, ‘40’°C, ‘60’°C and ‘95’˚C washing temperatures are selectable with Cotton program.
• ‘Prewash’, ‘Rinse+’, and ‘Crease Care’ wash options are selectable with Cotton program.
Caution!
• If you select washing temperature ‘95’ ˚C, some cold water is supplied before the drain of main wash. This
is to protect the user from the hazard of burn injury by lowering the temperature of hot wash water instead
of directly draining it. Therefore this is not a malfuction.
(Be careful with the draining water, since it can be still hot although the temperature is lowered.)
Put the laundry in to the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash and prewash compartments in the detergent case.
Softener should be below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with detergent.
1
Press the Power button.
• The LED shows only ‘---’ and all Program Lights turn on.
2
Select the ‘Cotton’ program using program selection dial.
• If you press Start/Pause button after power button without selecting program, the
‘Cotton’ program is selected as default program.
• Washing temperature ‘40’ ˚C, spin ‘800’ rpm and rinse ‘3’ times are selected
automatically.
• If you want to change washing temperature, the spin velocity or add wash options
(Rinse+, Crease Care), press each button.
3
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
4

13
* ECO PROGRAM
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and
press the button you want.
• Only ‘60’ ˚C washing temperature is selectable with Eco program.
• Only ‘Rinse+’ and ‘Crease Care’ of all wash options are selectable with Eco program.
Put the laundry in the drum. Put detergent and softener into the detergent case. Then
close the door.
• Put detergent into the main wash and prewash compartments in the detergent
case. Softener should be below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only ‘---’ and all Program Lights turn on.
1
2
Select the ‘Eco’ program using program selection dial.
• Washing temperature ‘60’ ˚C, spin ‘800’ rpm and rinse ‘3’ times are selected
automatically.
• If you want to change the spin velocity or add wash options (Rinse+, Crease Care),
press each button.
3
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
4

14
* SYNTHETIC PROGRAM
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and
press the button you want.
• Only ‘Cold’, ‘30’°C, ‘40’°C and ‘60’ ˚C washing temperatures are selectable with Synthetic program.
• More than 1200rpm of spin velocity is not selectable with Synthetic program in order to protect damage on
laundry.
• ‘Prewash’, ‘Rinse+’, and ‘Crease Care’ wash options are selectable with Synthetic program.
• The appropriate amount of laundry for Synthetic program is below 2.0kg.
Put the laundry in the drum. Put detergent and softener into the detergent case. Then
close the door.
• Put detergent into the main wash and prewash compartments in the detergent
case. Softener should be below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only ‘---’ and all Program Lights turn on.
1
2
Select the ‘Synthetic’ program using program selection dial.
• Washing temperature ‘40’ ˚C, spin ‘800’ rpm and rinse ‘3’ times are selected
automatically.
• If you want to change washing temperature, the spin velocity or add wash options
(Prewash, Rinse+, Crease Care), press each button.
3
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
4

15
* DELICATE PROGRAM
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation
and press the button you want.
• Only ‘Cold’, ‘30’°C and ‘40’°C washing temperature is selectable with Delicate program.
• More than 1000rpm of spin velocity is not selectable with Deliate program.
• Only ‘Rinse+’ and ‘Crease Care’ wash options are selectable with Delicate program.
• The appropriate amount of laundry for Delicate program is below 2.0kg.
Put the laundry in the drum. Put detergent and softener into the detergent case. Then
close the door.
• Put detergent into the main wash compartment in the detergent case. Softener
should be below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only ‘---’ and all Program Lights turn on.
1
2
Select the ‘Delicate’ program using program selection dial.
• Washing temperature ‘Cold’, spin ‘400’ rpm and rinse ‘2’ times are selected
automatically.
• If you want to change the spin velocity or add wash options (Rinse+, Crease Care),
press each button.
3
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
4

16
* WOOL PROGRAM
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and
press the button you want.
• Only ‘Cold’, ‘30’°C and ‘40’°C washing temperature is selectable with Wool program.
• More than 1000rpm of spin velocity is not selectable with Wool program in order to protect damage on
laundry.
• Only ‘Rinse+’ and ‘Crease Care’ wash options are selectable with Wool program.
• The appropriate amount of laundry for Wool program is below 2.0kg.
• Use only special detergent for wool.
(Since special neutral detergent for wool creates a lot of bubbles, use appropriate amount).
Put the laundry in the drum. Put detergent and softener into the detergent case. Then
close the door.
• Put detergent into the main wash compartment in the detergent case. Softener
should be below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only ‘---’ and all Program Lights turn on.
1
2
Select the ‘Wool’ program using program selection dial.
• Washing temperature ‘Cold’, spin ‘400’ rpm and rinse ‘2’ times are selected
automatically.
• If you want to change the spin velocity or add wash options (Rinse+, Crease Care),
press each button.
3
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
4

17
* HAND WASH
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and
press the button you want.
• Only ‘Cold’ and ‘30’ ˚C washing temperatures are selectable with Hand Wash program.
• More than 1000rpm of spin velocity is not selectable with Hand Wash program.
• Only ‘Rinse+’ and ‘Crease Care’ wash options are selectable with Hand Wash program.
• Use Hand Wash program for the laundry that is marked ‘Hand wash’ in the care label.
• The appropriate amount of laundry for Hand Wash Program is below 2.0kg.
Put the laundry in the drum. Put detergent and softener into the detergent case. Then
close the door.
• Put detergent into the main wash compartment in the detergent case. Softener
should be below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only ‘---’ and all Program Lights turn on.
1
2
Select the ‘Hand Wash’ program using program selection dial.
• Washing temperature ‘Cold’, spin ‘400’ rpm and rinse ‘3’ times are selected
automatically.
• If you want to change the washing temperature, spin velocity or add wash options
(Rinse+, Crease Care), press each button.
3
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
4

18
* QUICK 30
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and
press the button you want.
• Only ‘Cold’, ‘30’ ˚C and ‘40’ ˚C washing temperatures are selectable with Quick 30 program.
• Only ‘Rinse+’ and ‘Crease Care’ wash options are selectable with Quick 30 program.
• The appropriate amount of laundry for Quick 30 Program is below 2.0kg.
Put the laundry in the drum. Put detergent and softener into the detergent case. Then
close the door.
• Put detergent into the main wash compartment in the detergent case. Softener
should be below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only ‘---’ and all Program Lights turn on.
1
2
Select the ‘Quick’ program using program selection dial.
• Washing temperature ‘30’ ˚C, spin ‘800’ rpm and rinse ‘2’ times are selected
automatically.
• If you want to change the washing temperature, spin velocity or add wash options
(Rinse+, Crease Care), press each button.
3
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
4
* SPIN ONLY
Put the laundry in the drum. Then close the door.
Press the Power button.
• The LED shows only “--” and all Program Lights turn on.
Select the spin speed by pressing Spin button.
Press the Start/Pause button.
• The washing machine will start operating by locking the door.
1
2
3
4

19
MAINTENANCE
Proper care of your washer can extend its life. This section explains how to care for your washer
properly and safely.
Cleaning your washer
Winter storage or moving care
Install and store your washer where it will not freeze. Because some water may stay in the
hoses, freezing can damage your washer.
If you store or move your washer during freezing weather, winterize it.
Non-use or vacation care
Operate your washer only when you are at home.
If you are on vacation or don’t use your washer for an extended period of time, you should:
• Unplug the power supply cord or turn off eletrical power to the washer.
• Turn off the water supplier to the washer.
This helps avoid accidental flooding (due to a water pressure surge) while you are away.
Wipe up detergent, bleach, and other spills with
a soft, damp cloth or sponge as they occur.
Occasionally wipe the outside of the washer to
keep its looking like new one.
Clean interior with 250ml of chlorine bleach
mixed with 500ml of detergent.
Run washer through a complete cycle.
Repeat this process if necessary.
Exterior Interior
• Turn off water faucet.
• Disconnect and drain water inlet hoses.
• Run washer on a drain and spin setting (see
page 10) for 1 minute.
• Unplug the power supply cord.
• Flush water pipes and hoses.
• Reconnect water inlet hoses.
• Turn on water faucet.
• Reconnect power supply cord.
To winterize washer To use washer again
Do not put sharp or metal object in your washer, or they
can damage the finish. Check all pockets for pins, clips,
money, bolts, nuts, etc.
Do not lay these objects in your washer after emptying
pockets.

20
HOW TO CLEAN THE FILTER
Cleaning the water inlet filter
• Clean the filter when water leaks from the water inlet.
Cleaning the drain filter
• This drain filter is used to screen the foreign stuffs such as threads, coins, pins, buttons etc..
• If the drain filter is not cleaned at proper time(every 10 times of use), drain problem could be
caused.
CAUTION : Be careful when draining if the water is hot.
Cleaning the detergent case
*After a while detergent and fabric softeners leave a deposit in the case;
- It should be cleaned from time to time with a jet of running water.
- If necessary it can be removed completely from the machine by pressing the catch downwards
and by pulling it out.
- To facilitate cleaning, the upper part of the fabric softener compartment can be removed.
*Detergent can also accumulate inside the recess which should be
cleaned occasionally with a brush.
*Once you have finished cleaning, replace the case and run a rinse
cycle without laundry.
1Pull the power
plug out before
cleaning it.
2Turn off the water
supply to the
washer and
separate the inlet
hose.
3Pull the inlet filter
out. 4Remove the dirt from the inlet filter
with a brush.
1. Open the lower cover(1) by
using a coin. Turn the cap
hose(2) to pull out the hose.
Pull out the hose maximally.
(About 13~14cm.)
2. Unplug the cap hose(2), allowing
the water to flow out. At this time
use a vessel to prevent water
flowing on to the floor. When water
does not flow any more, turn the
pump filter(3) open to the left.
3. Remove any foreign material
from the pump filter(3). After
cleaning, turn the pump filter
clockwise and insert the cap
hose(2) to the original place.
Close the lower cover.
1
100
23
about
13~14cm
2
3
about
13~14cm
