Dahua Technology DH-ITSE0804-GN5B-D User manual
DH-ITSE0804-GN5B-D ITC Terminal
Management Device
User's Manual
Version 1.1.1
Dahua Technology CO., LTD
Safeguards and Warnings
Please read the following safeguards and warnings carefully before using the product in order to avoid
damages and losses.
Note:
Do not expose the device to lampblack, steam or dust. Otherwise it may cause fire or electric
shock.
Do not install the device at position exposed to sunlight or in high temperature. Temperature rise in
device may cause fire.
Do not expose the device to humid environment. Otherwise it may cause fire.
The device must be installed on solid and flat surface in order to guarantee safety under load and
earthquake. Otherwise, it may cause device to fall off or turnover.
Do not place the device on carpet or quilt.
Do not block air vent of the device or ventilation around the device. Otherwise, temperature in
device will rise and may cause fire.
Do not place any object on the device.
Do not disassemble the device without professional instruction.
Warning:
Please use battery properly to avoid fire, explosion and other dangers.
Please replace used battery with battery of the same type.
Do not use power line other than the one specified. Please use it properly. Otherwise, it may cause
fire or electric shock.
Special Announcement:
This manual is for reference only.
All the designs and software here are subject to change without prior written notice.
All trademarks and registered trademarks are the properties of their respective owners.
If there is any uncertainty or controversy, please refer to the final explanation of us.
Please visit our website for more information.
About the Manual:
This manual is for reference only. Slight difference may be found in the user interface.
All the designs and software here are subject to change without prior written notice.
All trademarks and registered trademarks mentioned are the properties of their respective owners.
If there is any uncertainty or controversy, please refer to the final explanation of us.
Please visit our website or contact your local retailer for more information
Table of Contents
Safeguards and Warnings ............................................................................................................... ii
1Product Overview .....................................................................................................................1
1.1 Overview ....................................................................................................................1
1.2 Features.....................................................................................................................1
2Product Structure......................................................................................................................3
2.1 Front Panel.................................................................................................................3
2.2 Rear Panel .................................................................................................................3
2.3 HDD Note...................................................................................................................4
3System Networking...................................................................................................................6
4Local Operation ........................................................................................................................7
4.1 View Video .................................................................................................................7
4.2 View Picture ...............................................................................................................8
5WEB Client..............................................................................................................................10
5.1 Intro ..........................................................................................................................10
5.2 System Login............................................................................................................10
5.2.1 Network Connection..........................................................................................10
5.2.2 Login WEB........................................................................................................10
5.3 Preview.....................................................................................................................11
5.3.1 Preview Video and Picture................................................................................11
5.3.2 Preview Video...................................................................................................12
5.3.3 Preview Picture.................................................................................................13
5.4 Search......................................................................................................................14
5.4.1 Search Vehicle Picture .....................................................................................15
5.4.2 Search Video ....................................................................................................16
5.5 Setup........................................................................................................................17
5.5.1 Intelligent Traffic................................................................................................17
5.5.2 Analog Camera.................................................................................................21
5.5.3 Network.............................................................................................................23
5.5.4 Event.................................................................................................................26
5.5.5 Storage..............................................................................................................28
5.5.6 System..............................................................................................................33
5.5.7 System Info.......................................................................................................36
5.6 Alarm........................................................................................................................39
6Quick Configuration Tool........................................................................................................41
6.1 Overview ..................................................................................................................41
6.2 Operation..................................................................................................................41
7FAQ and Maintenance............................................................................................................44
7.1 FAQ..........................................................................................................................44
7.2 Maintenance.............................................................................................................45
1
1 Product Overview
1.1 Overview
This product is a high-performance outdoor intelligent terminal management device, mainly used
to receive transmission of front camera video and pictures, set the video management, data
management, real-time storage, picture display and network switching functions into one.
The products are widely used in various road safety monitoring system and channel monitoring
system to a variety of ways of device storage, storage platforms and PC client storage.
This product can work independently, but also can work with a variety of front-end networking
device, including network cameras, analog cameras, network video servers and etc, with
professional video monitoring software to form an enhanced surveillance network.
1.2 Features
1. Picture Combination
Combine several violation picture into one, the method of combination is flexible which provides
valid proof for violation penalty.
Overlay plate, lane, time and location on picture.
2. User Management
Configure more user groups and users.
Online user search.
3. Log Management
Store up to 1024 records.
4. Storage Function
According to user config and strategy, store corresponding front-end device video and picture to
centralized ITC management device via network.
User can save picture to PC via WEB.
Storage of picture and video on FTP.
5. Search History and Download
Search for picture type, channel plate and other criteria.
Multi-user download search result.
6. Record Function
Record any channel on the device and save the record on PC.
7. Alarm Function
Multi-channel alarm input, output and alarm prompt.
8. Network Management
Via Ethernet manage and control device config
WEB management of device
2
9. COM Interface
RS485 interface, RS232 interface
Dual network multi-address, fault-tolerant, load balance config.
8 100M industrial-level switching network interfaces, integrating switching function.
2 1000M network interfaces, one is 1000M SFP interface which can do photoelectric conversion.
3
2 Product Structure
2.1 Front Panel
Figure 2- 1
Indicator has three statuses, including NO, NC and flashing.
Interface Name
Function
Operation
Indicator NO green, as program is running
normally.
Indicator flash green, as program is upgrading.
HDD
Indicator flash green, as reading HDD.
Alarm
Indicator NO red, as enabling alarm
Indicator flash red, as triggering alarm
Power
Indicator NO red, as power works normally
Indicator flash red, as heating device
,
Up/Down
Move up and down, increase and decrease
,
Left/Right
Move left and right to adjust time
Enter
OK
OK
2.2 Rear Panel
Figure 2- 2
Interface Name
Function
POWER
Power button
Dial switch to turn on/off device
DC 12V
Power interface
Input DC 12V
4
Interface Name
Function
RESET Reset button
Restore default settings.
Note
Under device normal working, power indicator is
green. Hole this button for 10s, system will restore
default settings.
+12V POWER OUT Power output interface
Input GND
A1, B1
A2, B2
A3, B3
A4, B4
RS485 interface Reserved, 4 RS485 interfaces
R1, T1
R2, T2
RS232 serial 2 RS232 interface, R as receiving, T as sending
ALARM
OUT
NO1
～
NO4
4 groups of alarm output interface
（
group 1
：
interface NO1～C1, group 2：interface NO2～
C2, group 3：interface NO3～C3, group 4：
interface NO4～C4），
output alarm signal to
external alarm device, external alarm device
has power supply.
NO：normal open alarm output.
C
：
alarm output public end.
C1～C4
ALARM IN 1～4 Alarm input interface.
AUDIO IN
Audio input
interface
N/A
AUDIOOUT
Audio output
interface
N/A
eSATA eSATA interface
SATA external interface, may connect to SATA
interface device.
USB1,
USB2
USB interface
2 USB interfaces, external connect to USB storage
device, mouse and etc.
OPT -
1 1000M SFP fiber interface, in the same segment
with G1
G1, G2 Dual Ethernet
interface
2 1000M network interfaces, not in the same
segment, one is 1000Mphotoelectric conversion
interface
10/100M
Network
interface
8 RJ45 10M/100M self-adaptive Ethernet interface,
in the same segment with G2
HDMI High-Definition
Multimedia
Interface
HD audio and video signal output interface, transmit
uncompressed high-definition video and multi-
channel audio data to the HDMI interface of display
device
VGA
Video output
interface
Connect to monitor, view video and picture
VIDEO IN
Video input port
4 analog camera interfaces
Input GND
-
2.3 HDD Note
When you use the device for the first time, you shall confirm HDD information.
We recommend you to choose 2T/HDD, and the device support a max of 4*2T capacity.
Total HDD capacity: Formula is total HDD capacity (M)= channel number * required time (hour) *
HDD occupation per hour (M/h), record time formula is:
5
Record time（hour）=
Note:
ITC terminal management device adopts H.264 compression technology, which has big dynamic
range, and HDD capacity calculation is based on stream estimation of file generated by each
channel per hour.
HDD occupation per hour (M/h) *
channel number
Total HDD capacity（M）
6
3 System Networking
In the networking system of the product, central server and monitoring spot (location of front-end
camera) need to be connected to Ethernet at the same time, while there is no need of video line
between center and monitoring spot.
Figure 3- 1
ITC management device is used to store HD encoded video and picture send by HD camera, to
save all passed vehicle data, and upload to central server for management.
Note:
Thie model of device can connect to 4-ch analog camera and store video.
7
4 Local Operation
You can view channel video and picture via monitor locally.
The device supports connection to monitor via VGA port, connection to mouse via USB port,
when successfully connect and boot up the device, the monitor shows local interface, default is
video interface.
Figure 4- 1
Parameter
Note
Open All Click Open All, all channel colors will change from
to ,you can view video of all channels.
Close All Click Close All, all channel colors will change from
to ,you can close video of all channels.
, ,
, ,
From left to right: 1-window, 4-window, 8-window, 9-window,
16-window.
4.1 View Video
If you view a single channel video, you can click one channel, the channel color changes from
to as you can view video.
The following is an example of 4-window. See Figure 4- 2.
9
Figure 4- 3
Click History Picture, you can view picture history. Local display supports up to 1000 pictures and
over 1000 pictures system will auto overwrite old pictures.
10
5 WEB Client
5.1 Intro
The device supports WEB page access and device management on PC client.
WEB client provides preview, search, setup and alarm modules.
5.2 System Login
5.2.1 Network Connection
Step 1. Confirm device is correctly connected into the Internet.
Step 2. Set IP address, subnet mask and gateway of computer and the device.
If there is no router, please allocate IP addresses in the same segment.
If there is router, then set corresponding gateway and subnet mask.
Default G1 IP address of the device is 192.168.1.108, and default G2 IP address is
192.168.0.108.
Step 3. Use ping ***.***.***.*** (device IP address) to check is network is OK.
5.2.2 Login WEB
Step 1. Open Internet Explorer, enter device IP address in address field. Press Enter. You can
see Figure 5- 1.
Figure 5- 1
Step 2. Input username and password. Default username and password are both: admin. Click
Login.
Note:
When you login for the first time, change password box will pop up, please change
your login password for security reason.
Step 3. If WEB control unit “plugin.cab” pops up, click Install.
System will automatically install plug-in, after the installation, you can see WEB preview
page. See Figure 5- 2.
11
Figure 5- 2
Note:
To logout WEB page, click Logout.
5.3 Preview
5.3.1 Preview Video and Picture
Step 1. Click Preview.
Step 2. Click one channel. System shows current channel’s video and snapshot.
Note:
If there is no video or picture in this channel, please confirm front-end camera and the
device’s record and snapshot function are ON.
12
Figure 5- 3
In video window, you can press the following buttons. When button color is ON, it means
corresponding operation is in effect.
Button Icon
Button Name
Button Function
Zoom In
1. Click
，
button color change to
2. Red box select the area to zoom in
3. Click , button color change to ，restore
original size
Local Record
1. Click
，
button color change to
，
system
starts to record
2. Click ，button color change to ，system
stop recording
Records are stored on PC client, please set path in
Ch 5.5.6.2.
Manual
Snapshot
Click
，
system real-time snapshots and displays
Play Audio
N/A
-
Reboot Device
Click reboot device, device will reboot up.
5.3.2 Preview Video
You can preview one or more channels of video, max support 16 channels at the same time.
Step 1. Click Video.
Step 2. Click one channel. System window shoes current channel’s video. See Figure 5- 4.
13
Figure 5- 4
If you want to switch window mode, you can click , as these functions
are: full-screen, 1-window, 4-window, 9-window, 16-window.
Step 3. Click , click Open All to switch to 16-window.
System opens all monitoring channels, you can preview all these channel info. You can click
Close All to close channels.
5.3.3 Preview Picture
You can preview one or more pictures, max supports preview of 12 pictures at the same time.
Analog channel does not support picture preview.
Step 1. Click Picture.
Step 2. Click one channel. System shows picture of current channel. See Figure 5- 5.
14
Figure 5- 5
If you want to switch window mode, you can click , as these functions
are: full-screen, 1-window, 4-window, 9-window, 16-window.
Step 4. Click , click Open All to switch to 16-window.
System opens all monitoring channels, you can preview all these channel info. You can click
Close All to close channels.
5.4 Search
The Search page is shown in Figure 5- 6.
15
Figure 5- 6
5.4.1 Search Vehicle Picture
You can search snapshot vehicle picture via time, picture type, seed and plate no.
Step 1. Click Car.
Step 2. Set search filter according to the following parameters. Click Search
Parameter
Note
Start Time
Select search start time.
End Time
Select search end time.
Channel
Select search channel no. Default it all.
Image Type
Select the image type, including ANPR, run red light, press
the white line, retrograde, less speed, speeding, car lane,
yellow-plate in lane, illegal parking, no travel by lane, illegal
lane change and press the yellow line, the default is all
illegal types
Advanced
Plate
Number
Checked, enter the license plate number, you can input
numbers or characters plus an asterisk were fuzzy query,
such as "* 6 *" You can search all the license plate
numbers of vehicles illustrated belt 6
Speed
Checked, input vehicle speed range
Lane
According to current camera lane, select corresponding
search lane
Combination
Checked, only search combined vehicle picture
Blocklist
Checked, only search picture of vehicle on blocklist.
See Figure 5- 7.
16
Figure 5- 7
Step 3. Select download type, according to system prompt download to local.
By File: in search result, check one or more pictures, click download.
By Time: download all pictures within period from searched start time to end time, click
download.
Step 4. Click Pic Rename, in pop-up box, you can customize picture name. If you need help for
naming, click Help. Click reset to restore default name.
Step 5. In search result, check picture, click Related Video, system plays the related video. If you
want to download the record, click Download.
Step 6. Click Back to go to vehicle search page.
Note:
During record playback, you can use play progress bat to play, pause, stop, slow/fast play the
video. Playback window shows record file’s channel name, time and other information.
5.4.2 Search Video
You can search record on the device via time and channel.
Step 1. Click record.
Step 2. Select search time and channel, click search. See Figure 5- 8.
17
Figure 5- 8
Step 3. Double click search result, system will auto play the record.
You also can click play bar menu to stop, quick play and play record.
Step 4. Check record, select download type, according to system prompt, download record to
local.
By File: in search result, check one or more pictures, click download.
By Time: download all pictures within period from searched start time to end time , click
download.
5.5 Setup
5.5.1 Intelligent Traffic
You can set snapshot combination method and OSD. See Figure 5- 9.
Table of contents
